Engine Controls - Specifications - 5.0L: Other Ford Mustang IV

Specifications 1 illustration ~217 words

ENGINE COMPRESSION

Warm engine to normal operating temperature. Check compression at cranking speed with throttle wide open and all spark plugs removed. Ensure crankcase is at correct level and oil is of correct viscosity. With compression gauge installed, use remote starter to crank engine.

Crank engine 5 revolutions (minimum) and record highest reading. Repeat procedure for all cylinders using approximately same number of revolutions. Lowest compression reading should not be less than 75 percent of highest compression reading. Cylinder compression readings should not be less than 100 psi (7 kg/cm 2 ).

ApplicationCompression Ratio
5.0L9.0:1

COMPRESSION RATIO SPECIFICATIONS

VALVE CLEARANCE

Note. Hydraulic valve lifters are used and valve adjustment is not required. If incorrect valve clearance is suspected, lifter must be collapsed before clearance can be checked.

ApplicationIn. (mm)
Allowable.098-.198 (2.49-5.03)
Preferred.123-.146 (3.12-3.71)

COLLAPSED VALVE LIFTER CLEARANCE

IGNITION COIL

ApplicationPrimary (Ohms)Secondary (Ohms)
Distributorless Systems(1)(1) *
Distributor Systems0.8-1.68000-11,500
(1) Resistance value is not available. For testing, see IGNITION SYSTEMS in SYSTEM/COMPONENT TESTS - EEC-IV (5.0L) article in the ENGINE PERFORMANCE section.
(1)Resistance value is not available. For testing, see IGNITION SYSTEMS in SYSTEM/COMPONENT TESTS - EEC-IV (5.0L) article in the ENGINE PERFORMANCE section.

IGNITION COIL RESISTANCE

HIGH TENSION WIRE RESISTANCE

Application (1)Ohms
5.0L7000 Per Foot
(1) On distributorless systems, high tension wire resistance is 30,000 ohms max. entire wire.
(1)On distributorless systems, high tension wire resistance is 30,000 ohms max. entire wire.

HIGH TENSION WIRE RESISTANCE

SPARK PLUGS

ApplicationMotorcraft No.
5.0L(1) ASF-42C
(1) For Cobra models, use AWSF-32C.
(1)For Cobra models, use AWSF-32C.

SPARK PLUG TYPE

ApplicationGap: In. (mm)Torque: Ft. Lbs. (N.m)
5.0L.054 (1.37)15 (20)

SPARK PLUG SPECIFICATIONS

Firing Order & Timing Marks. Scheme 7

Scheme 7: Firing Order & Timing Marks

IGNITION TIMING

ApplicationDegrees BTDC @ Idle
5.0L(1) 10
(1) Disconnect single in-line SPOUT connector, or remove shorting bar from double-wire SPOUT connector.
(1)Disconnect single in-line SPOUT connector, or remove shorting bar from double-wire SPOUT connector.

BASE IGNITION TIMING

FUEL PUMP

Note. For fuel pressure specifications, see FUEL PRESSURE SPECIFICATIONS article.

IDLE SPEED & MIXTURE

Note. Idle mixture is not adjustable. If idle mixture is incorrect, see TESTS W/CODES - EEC-IV (5.0L) article in the ENGINE PERFORMANCE section.

ModelRPM
A/T625
M/T675

IDLE SPEED SPECIFICATIONS

THROTTLE POSITION (TP) SENSOR

Throttle Angle(1) Volts
.50
10°.97
20°1.44
30°1.90
40°2.37
50°2.84
60°3.31
70°3.78
80°4.24
(1) Values may vary by 15 percent.
(1)Values may vary by 15 percent.

TP SENSOR SPECIFICATIONS
