INTERIOR FUSE PANEL IDENTIFICATION

Fuse panel is located in instrument panel, just to the left of steering column.

Scheme 1

Scheme 1: INTERIOR FUSE PANEL IDENTIFICATION

Fuse & Circuit Breaker Identification

  1. 1 - 15 Amp - Turn Signal/Backup Lights, Air Bag Diagnostic Monitor, DRL Module, IGN Power, Illuminated Entry, Heated Rear Window, Convertible Top, Transmission Control Switch, Brakeshift Interlock
  2. 2 - 30 Amp - Windshield Wiper/Washer Systems
  3. 3 - Not Used
  4. 4 - 10 Amp - Air Bag Diagnostic Monitor (Alt Power)
  5. 5 - 15 Amp - Headlights On Warning Chime, Clock, Front Park/Tail/Rear Side Marker & License Plate Lights, Fuse 13
  6. 6 - 15 Amp - Clock Display, Speed Control Amplifier, Warning Chime Module, A/C Clutch Coil, Door Lock Control Processor, Anti-Theft Alarm Control
  7. 7 - 10 Amp - Anti-Lock Brake Control Module, Low Oil Relay
  8. 8 - 10 Amp - Courtesy/Glove Box/Dome/Map/Visor Vanity/Luggage Compartment/ Underhood Lights, Key Warning Chime, Radio Memory, Power Mirror, Clock Operation, Door Lock Control Processor Battery Save/Power
  9. 9 - 15 Amp - Hazard/Stoplights, High Mounted Rear Light, Brakeshift Interlock Solenoid
  10. 10 - 20 Amp - HO2S Sensors (5.0L)
  11. 11 - 15 Amp - Radio
  12. 12 - 20 Amp (Circuit Breaker) - Deck Lid Release, Door Lock Control Processor, Power Door Locks
  13. 13 - 10 Amp - Illumination Of: Clock, Radio, Heated Rear Window Switch, Instrument Cluster, A/C Heater Control, Transmission Range Indicator, Ashtray, Foglight Switch
  14. 14 - 20 Amp (Circuit Breaker) - Power Windows
  15. 15 - 15 Amp - Gauges & Indicator Lights, Speedometer, Seat Belt Warning Chime, Air Bag Diagnostic Monitor
  16. 16 - 20 Amp - Headlight Flash-To-Pass, Anti-Theft Alarm Control Module
  17. 17 - 30 Amp - A/C-Heater Blower Motor
  18. 18 - 20 Amp - CCRM Power, Ignition Coil, Charging System Warning Light Regulator Signal, Transmission Control Switch Module (5.0L), Ignition Control Module (5.0L)

UNDERHOOD FUSE PANEL IDENTIFICATION

The "high-current" fuse panel is located in the engine compartment on the L/H fender apron.

Scheme 2

Scheme 2: UNDERHOOD FUSE PANEL IDENTIFICATION
WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.

Fuse & Relay Identification

  1. A - 40 Amp - Ignition Switch
  2. B - 40 Amp - Ignition Switch
  3. C - 40 Amp - Ignition Switch
  4. D - 50 Amp - Headlight Switch, Instrument Panel Fuses 4, 8 & 16, Instrument Panel Circuit Breaker 12
  5. E - 20 Amp - PCM, Fuel Pump, HO2S (3.8L), Canister Purge Solenoid, EVR Solenoid, IAC Solenoid, Ignition Control Module (3.8L) Fuel Injector, Automatic Transmission, Camshaft Position Sensor (3.8L), MAF Sensor
  6. F - 40 Amp - Heated Rear Window
  7. G - 20 Amp - Fuel Pump
  8. H - 60 Amp - Fan Control
  9. J - Not Used
  10. K - 10 Amp - Anti-Lock Brake Control Module
  11. L - 20 Amp - Fan Control Monitor (PCM)
  12. M - 25 Amp - Horn, Foglights, Daytime Running Lights Module
  13. N - 25 Amp - Fuses 5 & 9
  14. P - 20 Amp - Radio Amplifier
  15. Q - 20 Amp - Generator
  16. S - 30 Amp - Convertible Top Motor
  17. T - 60 Amp - Anti-Lock Brake System
  18. RA - Relay - Spare (Open)
  19. RB - Relay - Horn
  20. RC - Relay - Starter
  21. RD - Relay - Foglights
