Contents Wiring diagrams Section: Suspension Front All sections

Front Suspension: Other Ford Kuga II

Suspension Front 10 illustrations ~366 words

Front Stabilizer Bar

SPECIAL TOOL DESCRIPTION 502-002 (T94P-2100-AH) Alignment Pins, Subframe TKIT-1994-FH/FMH/FLMH TKIT-1994-LMH/MH2 Tie Rod End Remover Transmission Jack

Scheme 17

Scheme 17: Front Stabilizer Bar

Front Stabilizer Bar Bushing

Special Tool(s)/General Equipment

Vise

Front Wheel Bearing and Wheel Hub

SPECIAL TOOL DESCRIPTION 204-023 (T73T-1217-A) Installer, Wheel Hub Bearing Cup 204-180 (T93P-5493-A) Remover/Installer, Bushing TKIT-1993-FM TKIT-1993-FLM TKIT-1993-LM 205-138 (T80T-4000-D) Installer, Drive Pinion Bearing Cup 205-140 (T80T-4000-F) Installer, Drive Pinion Bearing Cup 205-153 (T80T-4000-W) Handle 205-480 Installer, Drive Pinion Inner Bearing Cup TKIT-2002-F/FM TKIT-2000AP-FLM/LM 205-538 Remover, Axle Bushing TKIT-2003D-TBIRD TKIT-2003A-FLM 205-D064 (D84L-1123-A) Puller, Bearing Hydraulic Press

Scheme 18

Scheme 18: Front Wheel Bearing and Wheel Hub

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 21

Scheme 21

Scheme 22

Scheme 22

Scheme 23

Scheme 23

Scheme 24

Scheme 24

Lower Arm

Special Tool(s)/General Equipment

Vehicle/Axle Stands

Wheel Knuckle

SPECIAL TOOL DESCRIPTION 204-161 (T97P-1175-A) Installer, Halfshaft TKIT-1997-F/FM2 TKIT-1997-FLM2 TKIT-1997-LM2 205-D070 (D93P-1175-B) Remover, Front Wheel Hub Tie Rod End Remover

Scheme 25

Scheme 25: Wheel Knuckle

Scheme 26

Scheme 26: Removal
  1. NOTE: Disconnect the battery ground cable or damage to the steering gear internal power relay may occur resulting in steering gear replacement. Refer to: «BATTERY DISCONNECT AND CONNECT»(ref-658873-S03187421432014092900000) .
  2. Refer to: «WHEEL AND TIRE»(ref-658846-S39478507132014092900000) .
  3. NOTE: Do not bend the inner joint more than 18 degrees and the outer joint more than 45 degrees. Damage to the halfshaft will occur. Use Special Service Tool: 205-D070 (D93P-1175-B) Remover, Front Wheel Hub .
  4. NOTE: Do not use a hammer to separate the outer tie-rod end from the wheel knuckle or damage to the wheel knuckle may result. NOTE: Use care when installing the tie rod separator or damage to the outer tie-rod end boot may occur. Use the General Equipment: Tie Rod End Remover
  5. NOTE: Do not use a prying device to open the slot in the knuckle to separate the lower ball joint from the knuckle assembly. Damage to the knuckle assembly may occur. NOTE: Do not use a prying device or separator fork between the ball joint and the wheel knuckle. Damage to the ball joint or ball joint seal may result. Only use the pry bar by inserting it into the lower arm body opening. NOTE: Use care when releasing the lower arm and wheel knuckle into the resting position or damage to the ball joint seal may occur.
  6. Refer to: «BRAKE DISC SHIELD»(ref-658874-S13614776952014092900000) .
