Multifunction Electronic Modules: Removal & Installation Ford Kuga II

Cruise Control Systems 2 illustrations ~812 words

Removal

Note. If installing a new BCM , verify at least 2 of the vehicle keys are available prior to carrying out this procedure.

Pinpoint Test B

B1 BCM
  1. NOTE: If installing a new module, it is necessary to upload the module configuration information to the scan tool prior to removing the module. This information must be downloaded into the new module after installation.
  2. Upload the module configuration information from the BCM into the scan tool by following the scan tool on-screen instructions.
  3. Refer to: «MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION»(ref-658827-S36740861182014092900000) .

Installation

Note. The BCM still communicates with the scan tool with the ignition off. Use the previous scan tool session or start a scan tool session using the part number or tear tag number on the PCM . The tear tag number can be found by double-clicking the VIN in the top left corner of PTS after OASIS has been run for the VIN.

Note. Low vehicle battery state-of-charge can affect proper module programming. Battery state-of-charge can be monitored on the scan tool. A red battery icon indicates low vehicle battery state-of-charge. Over-voltage may also affect module programming.

Note. Make sure the battery is fully charged before starting the installation procedure. Do not have a battery charger connected to the vehicle charging system during the installation procedure.

Note. Carry out Steps 2-15 only if installing a new BCM .

Pinpoint Test B

B2 PMI
B5 OASIS
  1. NOTE: If a diagnostic scan tool is connected to the Internet, it will automatically obtain As-Built data. If a diagnostic scan tool is not connected to the Internet, obtain the As-Built data from PTS OASIS . Download the As-Built data to the scan tool or other storage device, such as a flash drive, following the on-screen instructions.
  2. From the Car Configuration screen select "Retrieve PTS derived ASBUILT data". Follow the on-screen instructions to install the as-built data into the BCM .
  3. click to open the image
B10 PCM
  1. NOTE: If a PCM tear tag or part number was used to establish the scan tool session, it may be necessary to establish a new session using the normal process.
  2. Using a scan tool, enter the PATS functions and follow the on-screen instructions to enter PATS security access.
B11 BCM
  1. NOTE: This step is only required if equipped with push button start.
  2. Select parameter reset BCM and RFA module. Follow the on-screen instructions.
B12 PATS
  1. NOTE: PATS security access may need to be granted again.
  2. Select parameter reset BCM and PCM . Follow the on-screen instructions.
B16 BCM

Note. If installing a new RFA module, verify at least 2 of the vehicle keys are available prior to carrying out this procedure.

All vehicles

Pinpoint Test B

B1 Sony® sound
  1. Refer to: «LOADSPACE TRIM PANEL»(ref-658897-S16386144412014092900000) .
  2. Sony® sound
B2 All vehicles
  1. Refer to: «SUBWOOFER SPEAKER»(ref-658929-S15936290362014092900000) .
  2. All vehicles

Note. If installing a new RFA module, the ignition cannot be turned ON until a parameter reset is performed and 2 keys are programmed to the vehicle. The RFA module still communicates with the scan tool with the ignition OFF. Use the previous scan tool session or start a scan tool session using the PCM part number or tear tag.

Pinpoint Test B

B2 RFA
  1. Vehicles With: Keyless Entry and Push Button Start, Refer to: «PASSIVE ANTI-THEFT SYSTEM (PATS) PARAMETER RESET»(ref-658895-S01596358592014092900000) .
  2. Vehicles Without: Keyless Entry and Push Button Start, Refer to: «PASSIVE ANTI-THEFT SYSTEM (PATS) PARAMETER RESET»(ref-658898-S38310045002014092900000) .
B3 RFA
  1. Vehicles Without: Keyless Entry and Push Button Start, Refer to: «KEY PROGRAMMING USING DIAGNOSTIC EQUIPMENT»(ref-658898-S25393509062014092900000) .
  2. Vehicles With: Keyless Entry and Push Button Start, Refer to: «KEY PROGRAMMING USING DIAGNOSTIC EQUIPMENT»(ref-658895-S06943647832014092900000) .
B4 RFA

Scheme 2

Scheme 2: Removal
Scheme 2: Removal
  1. Remove the front door trim panel. Refer to: «FRONT DOOR TRIM PANEL»(ref-658897-S15640252982014092900000) .
  1. To install, reverse the removal procedure.
  1. Remove the front door trim panel. Refer to: «FRONT DOOR TRIM PANEL»(ref-658897-S15640252982014092900000) .
  1. To install, reverse the removal procedure.

Scheme 3

Scheme 3: Removal
Scheme 3: Removal
  1. Remove the rear door trim panel. Refer to: «REAR DOOR TRIM PANEL»(ref-658897-S35480198642014092900000) .
  1. To install, reverse the removal procedure.

More articles — Multifunction Electronic Modules
