Steering Column: Removal & Installation Ford Grand C-MAX II

Installation

1. To install, reverse the removal procedure.

Scheme 1

Scheme 2

Scheme 3

1. WARNING: Before beginning any service procedure in this information, refer to «HEALTH AND SAFETY PRECAUTIONS»(ref-539149-S05516616262013040100000) Safety Warnings in information 100-00 General Information. Failure to follow this instruction may result in serious personal injury. NOTE: To prevent damage to the clockspring, make sure the front wheels are in the straight-ahead position. NOTE: Removal steps in this procedure may contain installation details. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-539149-S05516616262013040100000) (100-00 General Information, Description and Operation).
2. Refer to: «STEERING WHEEL»(ref-539197-S28674360392013040100000) (211-04 Steering Column, Removal and Installation).
3. Refer to: «DRIVER LOWER AIRBAG»(ref-539162-S26563158282013040100000) (501-20B Supplemental Restraint System, Removal and Installation).
4. Vehicles with IA (Intelligent Access).
5. Vehicles without IA (Intelligent Access).
6. Discard the specified component. Follow local disposal regulations. Torque : 28 Nm
7. Discard the specified component. Follow local disposal regulations. Torque : 28 Nm

1. NOTE: Transfer parts as needed. To install, reverse the removal procedure.
