Multifunction Electronic Modules: Removal & Installation Ford Fusion I facelift

Communication Devices 1 illustration ~471 words

REMOVAL AND INSTALLATION

Note. Electronic modules are sensitive to static electrical charges. If exposed to these charges, damage may result.

Note. Prior to the removal of the module, it is necessary to upload the module configuration information to the appropriate scan tool. This information needs to be downloaded into the new module once installed. For additional information, refer to MODULE CONFIGURATION article.

  1. Upload the module configuration information from the driver door module (DDM) into the scan tool. For additional information, refer to «MODULE CONFIGURATION»(ref-291882) article.
  2. Remove the driver door trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-291874) article.
  3. Remove the 2 nuts. To install, tighten to 3 Nm (27 lb-in).
  4. Disconnect the 2 electrical connectors and remove the DDM.
  5. To install, reverse the removal procedure. Download the DDM configuration from the scan tool into the new DDM. For additional information, refer to «MODULE CONFIGURATION»(ref-291882) article.

Scheme 2

Scheme 2: Driver Seat Module (DSM)
Scheme 2: Driver Seat Module (DSM)
ItemPart NumberDescription
1Driver seat module (DSM) rivets (2 required)
2DSM electrical connectors (part of 14A699)
313C789DSM

Note. Electronic modules are sensitive to static electrical charges. If exposed to these charges, damage may result.

Note. Prior to the removal of the module, it is necessary to upload the module configuration information to the appropriate scan tool. This information needs to be downloaded into the new module once installed. For additional information, refer to MODULE CONFIGURATION article.

  1. Upload the module configuration information from the driver seat module (DSM) into the scan tool. For additional information, refer to «MODULE CONFIGURATION»(ref-291882) article.
  2. Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-291883) article.
  3. Remove the driver seat. For additional information, refer to «SEATING»(ref-291875) article.
  4. Drill out the 2 rivets.
  5. Disconnect the 4 electrical connectors and remove the DSM.
  6. To install, reverse the removal procedure. Download the DSM configuration from the scan tool into the new DSM. For additional information, refer to «MODULE CONFIGURATION»(ref-291882) article.

REMOVAL

Note. Electronic modules are sensitive to static electrical charges. If exposed to these charges, damage to the module may result.

Note. Prior to the removal of the module, it is necessary to upload the module configuration information to a scan tool. This information must be downloaded into the new SJB after installation. For additional information, refer to MODULE CONFIGURATION article.

  1. Upload the module configuration information from the SJB into the scan tool. For additional information, refer to «MODULE CONFIGURATION»(ref-291882) article.
  2. Disconnect the 6 electrical connectors.
  3. Remove the 2 nuts and the SJB.

INSTALLATION

  1. Position the SJB and install the 2 nuts. Tighten to 5 Nm (44 lb-in).
  2. Connect the 6 electrical connectors.
  3. Download the SJB configuration information from the scan tool to the SJB. For additional information, refer to «MODULE CONFIGURATION»(ref-291882) article.
  4. Train the tire pressure sensors. For additional information, refer to «WHEELS AND TIRES»(ref-291853) article.
  5. Carry out the SJB on-demand self-test by clearing the DTCs and then retrieving the DTCs to confirm all DTCs have been cleared.
