GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Azimuth system check object position 1 (P1) and position 5 (P5), distance from sensor | 30 cm (12 in) rear |
| Azimuth system check object position 2 (P2) and position 4 (P4), distance from sensor | 91 cm (36 in) rear |
| Azimuth system check object position 3 (P3), distance from sensor | 152 cm (60 in) rear |
GENERAL SPECIFICATIONS
Note. The smart junction box (SJB) is also known as the generic electronic module (GEM).
The parking aid system calculates the distance to an object around the rear of the vehicle by the use of 4 ultrasonic sensors. The parking aid system detects objects behind the vehicle when the REVERSE (R) gear is selected.
The parking aid system consists of
- Parking aid sensors (located in the rear bumper cover)
- Parking aid module (PAM) (located behind the LH rear seat trim panel)
- Parking aid speaker (located under the left side of the parcel shelf)
- Parking aid disable feature (integral to the instrument cluster message center)
Special Tools Illustration Tool Name Tool Number 73III Automotive Meter 105-R0057 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool Flex Probe Kit 105-R025C or equivalent
Scheme 1
Scheme 2
