REMOVAL AND INSTALLATION
- Remove the LH side C-pillar trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-291874) article.
- Remove the LH rear seat bolster. For additional information, refer to «SEATING»(ref-291875) article.
- Remove the 2 screws and the parking aid module (PAM). Disconnect the PAM electrical connectors.
- To install, reverse the removal procedure.
Scheme 10
| Item | Part Number | Description |
|---|---|---|
| 1 | W713167 | Parking aid speaker push pins (2 required) |
| 2 | 15K864 | Parking aid speaker |
| 3 | Parking aid speaker electrical connector (part of 14A005) |
- Remove the parcel shelf. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-291874) article.
- Remove the 2 push pins and the parking aid speaker. Disconnect the parking aid speaker electrical connector.
- To install, reverse the removal procedure.
Scheme 11
| Item | Part Number | Description |
|---|---|---|
| 1 | 14489 | Parking aid sensor(s) |
| 2 | Parking aid sensor electrical connectors (part of 14N139) |
- Remove the rear bumper cover. For additional information, refer to «BUMPERS»(ref-291877) article.
- Disconnect the parking aid sensor(s) electrical connector(s).
- Press the retaining tabs and remove the parking aid sensor(s).
- To install, reverse the removal procedure.
