Material
| Item | Specification | Fill Capacity |
|---|
| Premium Quality Windshield Washer Fluid (Canada) CXC-37-(A, B, C, D, E, F, G, H) (Canada) | | |
| Premium Windshield Washer Concentrate (US) ZC-32-A or B (US) | WSB-M8B16-A2 | |
Windshield Washer System
The washer pump relay is hard-wired to the SJB. The washer switch portion of the multi-function switch will ground circuit CRW07 (GY/BN) which will signal the SJB to energize the washer pump relay (integral to the SJB). The relay will then provide voltage to the windshield washer pump through circuit CRW14 (BU/WH). The windshield washer pump is grounded through circuit GD123 (BK/GY).
Washer Hose Repair
- Locate and verify the leaking washer hose.
- Cut the hose cleanly and remove the damaged portion of the washer hose.
- Install a windshield washer hose adapter between the cut ends of the hose.
- Install a segment of 6.4 mm (0.25 in) inside diameter black rubber hose over the ends of the washer hose, and clamp both ends of the rubber hose using spring clamps.
Scheme 28
Scheme 28: Wiper and Washer System - Exploded View
| Item | Part Number | Description |
|---|
| 1 | 17C526 | Wiper pivot arm caps (2 required) |
| 2 | 17D592 | Wiper pivot arm nuts (2 required) |
| 3 | 17C495 LH/ 17B589 RH | Wiper pivot arm assembly |
| 4 | W701121 | Windshield wiper mounting arm and pivot shaft assembly bolts (2 required) |
| 5 | | Windshield wiper mounting arm and pivot shaft assembly |
| 6 | | Wiper motor-to-wiper mounting arm bolts (2 required) |
| 7 | | Wiper motor assembly |
Scheme 29
| Item | Part Number | Description |
|---|
| 1 | W505252 | Windshield washer reservoir bolts (2 required) |
| 2 | W702751 | Windshield washer reservoir nut |
| 3 | 17A605 | Windshield washer reservoir hose |
| 4 | | Windshield washer pump |
| 5 | 17618 | Windshield washer reservoir |
| 6 | W500214 | Windshield washer reservoir filler neck retaining bolt |
| 7 | N623332 | Windshield washer reservoir filler neck |
- For additional information, refer to the procedures.
Washer Pump
| Item | Specification |
|---|
| Premium Quality Windshield Washer Fluid (Canada) CXC-37-(A, B, C, D, E, F, G, H) (Canada) | |
| Premium Windshield Washer Concentrate (US) ZC-32-A or B (US) | WSB-M8B16-A2 |
Washer Reservoir
| Item | Specification |
|---|
| Premium Quality Windshield Washer Fluid (Canada) CXC-37-(A, B, C, D, E, F, G, H) (Canada) | |
| Premium Windshield Washer Concentrate (US) ZC-32-A or B (US) | WSB-M816-A2 |
