Engine: Overhaul Ford Freestyle I

Disassembly

Scheme 205

1. Remove the hydraulic lash adjusters.
2. Using the special tools, remove the keys, retainer and spring.
3. Remove the valve from the cylinder head.
4. Remove the valve stem seal.

Scheme 206

1. Using the special tool, install the valve stem seal.
2. Install the valve.
3. Using the special tools, install the valve spring, retainer and key.
4. Install the hydraulic lash adjusters.

1. Remove the piston rings from the piston. Discard the piston rings.
2. Remove the 2 piston pin retainers and the piston pin.
3. Separate the piston from the connecting rod.
4. Clean and inspect the piston and connecting rod. For additional information, refer to «SPECIFICATIONS»(ref-255260-S17134136022007053000000) .

Assembly

1. Align the piston-to-connecting rod orientation marks and position the connecting rod in the piston.
2. Lubricate the piston pin and pin bore with clean engine oil.
3. Install the piston pin in the piston and connecting rod assembly.
4. Install the piston pin retaining clips in the piston.
5. Lubricate the piston and the new piston rings with clean engine oil.
6. Install the piston rings onto the piston as shown in the figure below. Center line of the piston parallel to the wrist pin bore Upper compression ring gap location Upper oil control segment ring gap location Lower oil control segment ring gap location Expander ring and lower compression ring gap location

Scheme 207

SPECIAL TOOL TABLE Installer, Crankshaft Vibration Damper 303-102 (T74P-6316-B) Installer, Front Cover Oil Seal 303-335 (T88T-6701-A) Strap Wrench 303-D055 (D85L-6000-A) Installer, Power Steering Pump Pulley 211-185 (T91P-3A733-A) Protector, Camshaft Oil Seal 303-463 (T94P-6256-AH) Installer, Camshaft Pulley 303-458 (T94P-6312-AH3) Installer, Camshaft Oil Seal 303-1139 Installer, Crankshaft Rear Main Oil Seal 303-178 (T82L-6701-A) Installer Bolts, Crankshaft Rear Main Oil Seal 303-384 (T91P-6701-A) Lifting Brackets, Engine 134-00243 or equivalent Spreader Bar 303-D089 (D93P-6001-A3) or equivalent

Scheme 208

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

Scheme 214

MATERIAL TABLE

Scheme 215

Scheme 216

Scheme 217

All vehicles

Note. Assembly of the engine requires various inspections/measurements of the engine components (engine block, crankshaft, connecting rods, pistons and piston rings). These inspections/measurements will aid in determining if the engine components will require replacement. For additional information, refer to ENGINE SYSTEM - GENERAL INFORMATION .

Scheme 218

Scheme 219

Scheme 220

Scheme 221

Scheme 222

Scheme 223

Scheme 224

Scheme 225

Scheme 226

Scheme 227

Scheme 228

Scheme 229

Scheme 230

Scheme 231

Scheme 232

Scheme 233

Scheme 234

Scheme 235

Scheme 236

Scheme 237

Scheme 238

Scheme 239

Scheme 240

Scheme 241

Scheme 242

Scheme 243

Scheme 244

Scheme 245

Scheme 246

Scheme 247

Scheme 248

Scheme 249

Scheme 250

Scheme 251

Scheme 252

Scheme 253

Scheme 254

Scheme 255

Scheme 256

Scheme 257

Scheme 258

Scheme 259

Scheme 260

Scheme 261

Scheme 262

Scheme 263

Scheme 264

Scheme 265

Scheme 266

Scheme 267

Scheme 268

Scheme 269

Scheme 270

Scheme 271

Scheme 272

Scheme 273

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

Scheme 279

Scheme 280

Scheme 281

Scheme 282

Scheme 283

Scheme 284

Scheme 285

1. Select the crankshaft main bearings for each crankshaft journal. Read the code on the crankshaft flange. Read the code on the cylinder block rear face. The first two numbers after the asterisk make up the code for main No. 1 and the next two numbers for main No. 2. The first two numbers after the second asterisk make up the code for main No. 3 and the last two numbers for main No. 4.
2. Using the chart (Scheme 221), choose a bearing for each main. Match the block and crankshaft code with its corresponding column or row, by reading across the "crankshaft" row and down the "block" column. For example: If the block code is * 0609 * 0711 * and the crankshaft code is * 8580 * 8082 *, main No. 1 should use grade 1 bearings, as determined by the intersection of the 06 block column and the 85 crankshaft row. Mains 2, 3 and 4 should all be grade 2.
3. Lubricate the upper crankshaft main bearings with clean engine oil and install the 4 crankshaft main bearings in the cylinder block.
4. Lubricate the lower crankshaft main bearings with clean engine oil and install the 4 crankshaft main bearings in the lower cylinder block.
5. Lubricate the crankshaft thrust bearing with clean engine oil and install in the cylinder block.
6. If removed, install the crankshaft key into the keyway on the crankshaft.
7. Apply clean engine oil to the crankshaft main and rod bearing journals.
8. Position the crankshaft in the cylinder block.
9. Apply gasket and sealant to the cylinder block as shown.
10. Position the lower cylinder block and install the bolts and studs. Tighten the bolts and studs in the sequence shown in four stages. Stage 1: Tighten fasteners 1--8 to 25 Nm (18 lb-ft). Stage 2: Tighten fasteners 9--16 to 40 Nm (30 lb-ft). Stage 3: Tighten fasteners 1--16 90 degrees. Stage 4: Tighten fasteners 17-22 to 25 Nm (18 lb-ft).
11. Using the Dial Indicator Gauge with Holding Fixture, measure crankshaft end play. Position the crankshaft to the rear of the cylinder block. Zero the Dial Indicator Gauge with Holding Fixture. Move the crankshaft to the front of the cylinder block. Note and record the crankshaft end play. Acceptable crankshaft end play is 0.100-0.255 mm (0.003-0.010 in). If the crankshaft end play exceeds the specified range, install new parts as necessary.
12. Using the Crankshaft Rear Main Oil Seal Installer and the Crankshaft Rear Main Oil Seal Installer Bolts, install the crankshaft rear oil seal.
13. Install the engine-to-transaxle separator plate.
14. Position the flexplate and install the bolts. Tighten to 80 N.m (59 lb-ft).
15. Mount the engine on an engine stand.
16. Using the chart (Scheme 232), select the correct piston grade size for the cylinder bores. Measure the cylinder block bore diameter. Mark the outside of the block with the appropriate number(s) to identify bore grade size. Choose the correct piston grade size for the cylinder bore.
17. Using the special tools, install the piston and connecting rod assemblies.
18. Install the connecting rod caps and the new bolts. Tighten the bolts in two stages. Stage 1: Tighten to 23 Nm (17 lb-ft). Stage 2: Tighten to 43 Nm (32 lb-ft).
19. Install the oil separator cover, a new gasket and the 2 bolts. Tighten to 10 N.m (89 lb-in).
20. Install the power steering pump bracket and the 3 bolts. Tighten to 25 N.m (18 lb-ft).
21. NOTE: RH shown, LH similar. NOTE: Position the new gaskets and the LH and RH cylinder heads. Install new bolts and tighten in the sequence shown in 6 stages: Stage 1: Tighten to 40 N.m (30 lb-ft). Stage 2: Tighten to 90 N.m (66 lb-ft). Stage 3: Loosen 1 full turn. Stage 4: Tighten to 40 N.m (30 lb-ft). Stage 5: Tighten 90 degrees. Stage 6: Tighten 90 degrees.
22. Install the crankshaft damper bolt and rotate the crankshaft key way to the 11 o'clock position to locate top dead center (TDC).
23. Apply clean engine oil to the LH and RH camshaft roller followers.
24. Install the LH and RH camshaft roller followers.
25. Apply clean engine oil to the LH and RH camshafts.
26. Install the LH and RH camshafts. Locate the camshafts as shown in illustration.
27. Lubricate the camshaft journal caps with clean engine oil. Position the LH camshaft caps and install the bolts. Tighten in the sequence shown to 10 N.m (89 lb-in).
28. Position the RH camshaft caps and install the bolts. Tighten in the sequence shown to 10 N.m (89 lb-in).
29. Install the camshaft oil seal retainer and the 3 bolts. Tighten to 10 N.m (89 lb-in).
30. Position the new camshaft oil seal on the special tool.
31. Position the special tool and the camshaft oil seal on the camshaft.
32. Using the special tools, install the camshaft oil seal.
33. Remove the crankshaft damper bolt.
34. Install the crankshaft sprocket with the timing mark facing out. The timing mark on the LH and RH timing chains will be aligned to this mark during assembly.
35. Position the chain tensioner in a soft-jawed vise.
36. Hold the chain tensioner ratchet lock mechanism away from the ratchet stem with a small pick.
37. Slowly compress the timing chain tensioner.
38. Retain the tensioner piston with a 1.5 mm (0.06 in) wire or paper clip.
39. If timing marks in the timing chains are not evident, use a permanent-type marker to mark the crankshaft and camshaft timing marks on the LH and RH timing chains. Mark any link to use as the crankshaft timing mark. Starting with the crankshaft timing mark, count 29 links and mark the link. Continue counting to link 42 and mark the link.
40. Verify that the LH camshafts are correctly positioned.
41. Position the LH timing chain and guide and install the 2 bolts. Tighten to 25 N.m (18 lb-ft). Align the marks on the timing chain with the marks on the camshaft and crankshaft sprockets.
42. Install the LH timing chain tensioner arm and the LH timing chain tensioner. Install the tensioner arm. Position the tensioner. Install the 2 bolts. Tighten to 25 N.m (18 lb-ft).
43. Install the crankshaft damper bolt and rotate the crankshaft clockwise 120 degrees until the crankshaft keyway is in the 3 o'clock position.
44. Verify that the RH camshafts are correctly positioned.
45. Install the RH timing chain and chain guide and install the 2 bolts. Tighten to 25 N.m (18 lb-ft). Align the marks on the timing chain with the marks on the camshaft and crankshaft sprockets.
46. Install the RH timing chain tensioner and tensioner arm. Install the tensioner arm. Position the tensioner. Install the 2 bolts. Tighten to 25 N.m (18 lb-ft).
47. Remove the LH and RH timing chain tensioner piston retaining wires.
48. Rotate the crankshaft counterclockwise 120 degrees to top dead center (TDC).
49. Verify the timing with the following steps. There should be 12 chain links between the camshaft timing marks. There should be 27 chain links between the camshaft and the crankshaft timing marks. There should be 30 chain links between the camshaft and the crankshaft timing marks.
50. Remove the crankshaft damper bolt.
51. Install the ignition pulse wheel.
52. Install the LH and RH spark plugs. Tighten to 15 N.m (11 lb-ft).
53. Install 3 new gaskets in the engine front cover.
54. Apply a 6 mm (0.24 in) dot of silicone gasket and sealant to the cylinder block-to-lower cylinder block and cylinder head mating surfaces.
55. Position the engine front cover. Install the 14 bolts and the stud bolt. Tighten in the sequence shown to 25 N.m (18 lb-ft).
56. Install the belt tensioner and the bolt. Tighten to 45 N.m (33 lb-ft).
57. Using the special tool, install a new crankshaft front seal.
58. Apply silicone gasket and sealant to the end of the crankshaft damper keyway slot.
59. Using the special tools, install the crankshaft pulley.
60. Using the special tool to hold the crankshaft pulley, install the bolt and washer and tighten in 4 stages. Stage 1: Tighten to 120 N.m (89 lb-ft). Stage 2: Loosen 1 full turn (360 degrees). Stage 3: Tighten to 50 N.m (37 lb-ft). Stage 4: Tighten to 90 N.m (66 lb-ft).
61. If equipped, install the block heater. Tighten to 14 N.m (10 lb-ft).
62. Install the oil pressure sender. Tighten to 14 N.m (10 lb-ft).
63. Install the oil pan baffle and the 8 nuts. Tighten the M8 nuts to 15 N.m (11 lb-ft) and then rotate 45 degrees. Tighten the M6 nuts to 5 N.m (44 lb-in) and then rotate 45 degrees.
64. Position the oil pump screen and pickup tube and install the 2 bolts. Tighten to 10 N.m (89 lb-in).
65. Install the radio interference capacitor and the bolt. Tighten to 8 N.m (71 lb-in).
66. Install the coolant bypass tube and the 2 bolts. Tighten to 10 N.m (89 lb-in).
67. Remove the center coolant pump bolt from the coolant pump and discard the sealing washer. Install a new sealing washer on the center coolant pump bolt, then install the center coolant pump bolt in the coolant pump.
68. Install the coolant pump and the 4 bolts. Tighten in 4 stages: Stage 1: Tighten the coolant pump center bolt to 4 N.m (35 lb-in). Stage 2: Loosely install the 3 coolant pump outer bolts. Stage 3: Tighten the coolant pump center bolt to 25 N.m (18 lb-ft). Stage 4: Tighten the 3 coolant pump outer bolts to 10 N.m (89 lb-in).
69. Install the thermostat housing and the 2 bolts. Tighten to 10 N.m (89 lb-in).
70. Clean the LH and RH valve cover sealing surfaces.
71. Apply a 5 mm (0.19 in) dot of silicone gasket sealant to the front cover-to-RH cylinder head joints.
72. Position the RH valve cover. Install the 9 bolts and 5 stud bolts. Tighten in the sequence shown to 10 N.m (89 lb-in).
73. Apply a 5 mm (0.19 in) dot of silicone gasket sealant to the front cover-to-LH cylinder head joints.
74. Position the LH valve cover. Install the 6 bolts and 8 stud bolts. Tighten in the sequence shown to 10 N.m (89 lb-in).
75. Install the RH and LH ignition coils and the 6 bolts. Tighten to 6 N.m (53 lb-in).
76. Install 6 new LH exhaust manifold studs. Tighten to 12 N.m (9 lb-ft).
77. Position a new gasket and the LH exhaust manifold and converter. Install the 6 new nuts. Tighten to 20 N.m (15 lb-ft).
78. Install 6 new RH exhaust manifold studs. Tighten to 12 N.m (9 lb-ft).
79. Position a new gasket and the RH exhaust manifold and converter. Install the 6 new nuts. Tighten to 20 N.m (15 lb-ft).
80. Install the RH engine insulator bracket and the 4 bolts. Tighten to 55 N.m (41 lb-ft).
81. Install the generator, nuts and the bolt. Tighten to 48 N.m (35 lb-ft).
82. Position the oil filter adapter and loosely install the bolts. Tighten in 3 stages: Stage 1: Tighten the M22 bolt to 25 N.m (18 lb-ft). Stage 2: Tighten the M8 bolt to 25 N.m (18 lb-ft). Stage 3: Tighten the M22 bolt to 155 N.m (114 lb-ft).
83. Install a new oil filter. Tighten to 16 N.m (12 lb-ft).
84. Install the oil level indicator tube and the stud bolt. Tighten to 9 N.m (80 lb-in).
85. Position the engine wiring harness.
86. Connect the bypass and the coolant pump hoses.
87. Connect the engine coolant temperature (ECT) sensor and the radio interference capacitor electrical connectors.
88. Connect the LH ignition coil electrical connectors and attach the wiring retainers.
89. Connect the crankshaft position sensor (CKP) electrical connector and attach the wiring retainer.
90. Attach the ground wire and install the nut. Tighten to 20 N.m (15 lb-ft).
91. Connect the generator wiring and install the nut. Attach the wiring retainer. Tighten to 8 N.m (71 lb-in).
92. Connect the RH ignition coil electrical connectors and attach the wiring retainers.
93. Position the wiring conduit on the valve cover studs and install the nut. Tighten to 6 N.m (53 lb-in).
94. Position the new gaskets and the upper and lower intake manifold. Install the bolts. Tighten in the sequence shown to 10 N.m (89 lb-in).
95. Position the power steering pump, reservoir bracket and tubes. Install the 3 nuts. Tighten to 25 N.m (18 lb-ft).
96. Install the power steering fluid reservoir bracket nut. Tighten to 9 N.m (80 lb-in).
97. Position the power steering fluid reservoir and install the 2 nuts. Tighten to 9 N.m (80 lb-in).
98. Position the power steering tube bracket and install the bolt. Tighten to 7 N.m (62 lb-in).
99. Position the power steering tube bracket and install the bolt. Tighten to 7 N.m (62 lb-in).
100. Connect the RH HO2S and attach the retainer.
101. Connect the fuel charging wiring harness electrical connector.
102. Connect the fuel rail pressure and temperature sensor vacuum tube and electrical connector.
103. Install and connect the positive crankcase ventilation (PCV) tube.
104. Connect the throttle body electrical connector.
105. Connect the exhaust gas recirculation (EGR) system module electrical connector.
106. Position the EGR system module tube. Tighten to 40 N.m (30 lb-ft).
107. Connect the camshaft position sensor (CMP) electrical connector, attach the wiring retainers and install the 2 wiring conduit nuts. Tighten to 6 N.m (53 lb-in).
108. Connect the oil pressure sensor electrical connector.
109. Connect the LH heated oxygen sensor (HO2S) electrical connector and attach the wiring retainer.
110. Install the A/C compressor bracket and the 5 bolts. Tighten to 25 N.m (18 lb-ft).
111. Install the A/C compressor, 2 nuts and 2 bolts. Tighten to 25 N.m (18 lb-ft).
112. Install the A/C compressor and the bolt. Tighten to 25 N.m (18 lb-ft).
113. Install the A/C compressor shield, 2 nuts and the bolt. Tighten to 25 N.m (18 lb-ft).
114. Connect the LH catalyst monitor sensor electrical connector and attach the wiring retainer.
115. Connect the A/C compressor electrical connector.
116. Rotate the tensioner counterclockwise and install the accessory drive belt.
117. Install the A/C compressor pulley shield and the 3 retainers.
118. Install the special tool to the RH cylinder head.
119. Install the special tool to the LH cylinder head.
120. Install the lower half of the special tool.
121. Install the upper half of the special tool.
122. Using the special tools and a suitable engine crane, remove the engine from the engine stand.

SPECIAL TOOL TABLE Lifting Brackets, Engine 134-00243 or equivalent Powertrain Lift with Tilting Plate 014-00765 Spreader Bar 303-D089 (D93P-6001-A3) or equivalent Engine Lifting Bracket Set 303-1140

Scheme 286

MATERIAL TABLE

Scheme 287

Scheme 288

Scheme 289

Scheme 290

Scheme 291

Scheme 292

Scheme 293

Scheme 294

Scheme 295

Scheme 296

Scheme 297

Scheme 298

Scheme 299

Scheme 300

Scheme 301

Scheme 302

Scheme 303

Scheme 304

Scheme 305

Scheme 306

Scheme 307

Scheme 308

Scheme 309

Scheme 310

Scheme 311

Scheme 312

Scheme 313

Scheme 314

Scheme 315

Scheme 316

Scheme 317

Scheme 318

Scheme 319

Scheme 320

Scheme 321

Scheme 322

Scheme 323

Scheme 324

Scheme 325

Scheme 326

Scheme 327

Scheme 328

Scheme 329

Scheme 330

Scheme 331

Scheme 332

Scheme 333

Scheme 334

Scheme 335

Scheme 336

1. Using the special tools and a suitable engine crane, align the engine with the transaxle.
2. Install the 4 transaxle-to-engine bolts. Tighten to 40 N.m (30 lb-ft).
3. Install the 3 transaxle-to-engine bolts. Tighten to 40 N.m (30 lb-ft).
4. Install the engine-to-transaxle bolt. Tighten to 40 N.m (30 lb-ft).
5. Position the knock sensor (KS), install the bolt and connect the electrical connector. Tighten to 20 N.m (15 lb-ft).
6. Attach the heat shield to the KS.
7. Using the special tools and a suitable engine crane, position the powertrain on the subframe.
8. Install the LH engine insulator upper nut. Tighten to 70 N.m (52 lb-ft).
9. Install the RH engine insulator upper nut. Tighten to 70 N.m (52 lb-ft).
10. Position the RH exhaust manifold heat shield and install the 3 bolts. Tighten to 11 N.m (8 lb-ft).
11. Install the front transaxle stabilizer bolt. Tighten to 40 N.m (30 lb-ft).
12. If equipped, install the upper power transfer unit (PTU) bracket and the bolts. Tighten to 55 N.m (41 lb-ft).
13. Clean the 3 rear transaxle insulator bracket bolts using a wire brush and apply new threadlock to the threads.
14. Install the 3 rear transaxle insulator bracket bolts. Tighten to 55 N.m (41 lb-ft).
15. Position the ground cable and install the bolt. Tighten to 12 N.m (9 lb-ft).
16. Position the starter motor and install the 2 bolts. Tighten to 25 N.m (18 lb-ft).
17. Position the starter motor wiring and install the nuts. Tighten the larger nut to 12 N.m (9 lb-ft). Tighten the smaller nut to 9 N.m (80 lb-in).
18. Install the starter motor terminal cover.
19. Clean the 2 roll restrictor bolts using a wire brush and apply new threadlock to the threads.
20. Position the roll restrictor and install the 2 bolts. Tighten to 55 N.m (41 lb-ft).
21. Clean the 4 roll restrictor bracket bolts using a wire brush and apply new threadlock to the threads.
22. Position the roll restrictor bracket and install the 4 bolts. Tighten to 55 N.m (41 lb-ft).
23. Connect the transmission control unit (TCU) wire harness.
24. Clean the 4 rear transaxle insulator bolts using a wire brush and apply new threadlock to the threads.
25. Install the 4 rear transaxle insulator bracket bolts. Tighten to 55 N.m (41 lb-ft).
26. Position the ground cable and install the bolt. Tighten to 12 Nm (9 lb-ft).
27. Position the starter motor and install the 2 bolts. Tighten to 25 N.m (18 lb-ft).
28. Position the starter motor wiring and install the nuts. Tighten the larger nut to 12 N.m (9 lb-ft). Tighten the smaller nut to 9 N.m (80 lb-in).
29. Install the starter motor terminal cover.
30. Clean the 2 roll restrictor bolts using a wire brush and apply new threadlock to the threads.
31. Position the roll restrictor and install the 2 bolts. Tighten to 55 N.m (41 lb-ft).
32. Attach the wiring harness to the roll restrictor.
33. Clean the 4 roll restrictor bracket bolts using a wire brush and apply new threadlock to the threads.
34. Position the roll restrictor bracket and install the 4 bolts. Tighten to 55 N.m (41 lb-ft).
35. Attach the lower wiring harness retainers to the transaxle.
36. Attach the wiring harness retainers to the transaxle.
37. Attach the wiring harness retainer to the transaxle.
38. Connect the transaxle bulkhead electrical connector. All vehicles
39. Attach the pin-type retainers to the subframe and connect the RH catalyst monitor sensor electrical connector.
40. Connect the power steering fluid tubes and install the bolt. Tighten to 25 Nm (18 lb-ft).
41. Install the power steering pressure (PSP) tube bracket bolt and connect the PSP switch electrical connector. Tighten to 25 N.m (18 lb-ft).
42. Using the special tool, position the powertrain and subframe in the vehicle.
43. Install the 2 forward subframe bolts and washers. Tighten to 200 Nm (148 lb-ft).
44. Position the rear subframe brackets and install the 6 bolts. Tighten the 2 larger bolts to 150 N.m (111 lb-ft). Tighten the 4 smaller bolts to 55 N.m (41 lb-ft).
45. Attach the steering column intermediate shaft and install a new bolt. Tighten to 23 N.m (17 lb-ft).
46. Attach the outer tie rods to the wheel knuckles and install new nuts. Tighten to 115 N.m (85 lb-ft).
47. Attach the stabilizer bar links to the struts and install new nuts. Tighten to 55 N.m (41 lb-ft).
48. If equipped, connect the driveshaft and install the bolts. Tighten to 25 N.m (18 lb-ft).
49. If equipped, position the driveshaft support bracket and install the 2 bolts. Tighten to 25 N.m (18 lb-ft).
50. Apply a 10 mm (0.39 in) diameter dot of silicone sealant to the areas indicated.
51. Position the oil pan and a new gasket. Loosely install the 15 bolts.
52. Position the LH catalytic converter bracket and install the 3 engine-to-transaxle bolts. Tighten to 40 N.m (30 lb-ft).
53. Tighten the 15 oil pan bolts in the sequence shown to 25 N.m (18 lb-ft).
54. Install the oil pan-to-oil filter adapter bolt. Tighten to 25 N.m (18 lb-ft).
55. Install the 4 new torque converter nuts. Tighten to 36 N.m (27 lb-ft).
56. Position the lower torque converter access plug and install the pin-type retainers.
57. If equipped, connect the block heater electrical connector and attach the wiring retainers.
58. Connect the power steering cooler hose.
59. Connect the transmission cooler hoses.
60. Position the A/C tube and install the nut. Tighten to 8 N.m (71 lb-in).
61. Position the A/C manifold assembly tubes and install the bolt. Tighten to 20 N.m (15 lb-ft).
62. Connect the A/C high-pressure switch electrical connector.
63. Connect the 10-pin electrical connector and attach the wiring retainers.
64. Position the coolant tube and secure the tube in the clips.
65. Connect the coolant hoses to the thermostat housing.
66. Connect the brake booster vacuum hose to the upper intake manifold.
67. Connect the heater hose and the positive crankcase ventilation (PCV) coolant hose.
68. Position the shift cable bracket and install the 3 bolts. Tighten to 25 N.m (18 lb-ft).
69. Connect the 16-pin electrical connector and attach the wiring retainer. Connect the electrical connector to the shift cable bracket.
70. Connect the shift cable.
71. Position the shift cable bracket and install the 2 bolts. Tighten to 25 N.m (18 lb-ft).
72. Connect the 16-pin electrical connector and attach the wiring retainers. Attach the electrical connector to the shift cable bracket.
73. Connect the shift cable.
74. Attach the B+ terminal to the battery cable and install the nut. Tighten to 5 N.m (44 lb-in).
75. Position the ground wire on the LH fender and install the bolt. Tighten to 10 N.m (89 lb-in).
76. Connect the power steering reservoir hose and attach the retainer.
77. Connect the 2 powertrain control module (PCM) electrical connectors and attach the wiring conduit.
78. Connect the vapor tube to the purge valve.
79. Connect the fuel tube to the fuel rail. Connect the fuel tube redundant clip.
80. Attach the fuel tube retainer to the upper intake manifold.
81. Position the ground strap on the RH fender and install the bolt. Tighten to 10 N.m (89 lb-in).
82. Clean the 4 roll restrictor cross brace bolts using a wire brush and apply new threadlock to the threads.
83. Position the roll restrictor cross brace and install the 4 new bolts. Tighten to 55 N.m (41 lb-ft).
84. Clean the roll restrictor cross brace-to-roll restrictor bolt using a wire brush and apply new threadlock to the threads.
85. Install a new roll restrictor cross brace-to-roll restrictor bolt. Tighten to 48 N.m (35 lb-ft).
86. Install the LH and RH half shafts. For additional information, refer to «INSTALLATION»(ref-255248-S40942864902007053000000) and «INSTALLATION»(ref-255248-S18281948382007053000000) .
87. Install the exhaust flex pipe and the LH catalytic converter. For additional information, refer to «REMOVAL AND INSTALLATION»(ref-255257-S13433610652007053000000) .
88. Install the cowl vent panel. For additional information, refer to «REMOVAL AND INSTALLATION»(ref-255297-S21419825242007053000000) .
89. Install the air cleaner outlet pipe and air cleaner. For additional information, refer to «REMOVAL AND INSTALLATION»(ref-255254-S23832507712007053000000) .
90. Fill the engine with clean engine oil.
91. Connect the negative and positive battery cables. For additional information, refer to «REMOVAL AND INSTALLATION»(ref-255287-S23279756482007053000000) .
92. Evacuate and recharge the A/C system. For additional information, refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-255298-S14835036442007053000000) .
93. Fill the power steering system. For additional information, refer to «POWER STEERING SYSTEM FILLING»(ref-255265-S15564975222007053000000) .
94. Fill and bleed the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-255255-S00333417942007053000000) .
