Multifunction Electronic Modules System: Diagnosis

Diagnostic Trouble Code Chart

DTC	Description	Source	Action
B1003	Mode Doors Circuit Failure	Electronic Automatic Temperature Control (EATC) Module	REFER to PINPOINT TEST E: INCORRECT/ERRATIC DIRECTION OF AIRFLOW FROM OUTLET(S) .
B1010	Parking Aid Module Switch Not Connected	Parking Aid Module	REFER to PINPOINT TEST I: DTC B1010 PARKING AID SWITCH NOT CONNECTED .
B1200	Climate Control Push Button Circuit Failure	EATC Module	REFER to EATC MODULE .
B1202	Fuel Sender Circuit Open	Instrument Cluster	REFER to PINPOINT TEST B: INCORRECT FUEL GAUGE INDICATION .
B1204	Fuel sender Circuit Short to Ground	Instrument Cluster	REFER to PINPOINT TEST B: INCORRECT FUEL GAUGE INDICATION .
B1205	EIC Switch-1 Assembly Circuit Failure	Instrument Cluster	REFER to PINPOINT TEST D: THE MESSAGE CENTER SWITCH DOES NOT OPERATE CORRECTLY .
B1213	Anti-Theft Number of Programmed Keys is Below Minimum	Powertrain Control Module (PCM)	REFER to PINPOINT TEST F: DTC B1213-ANTI-THEFT NUMBER OF PROGRAMMED KEYS IS BELOW MINIMUM .
B1231	Event Threshold Exceeded	Restraint Control Module (RCM)	REFER to INSPECTION AND REPAIR AFTER A SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPLOYMENT .
B1234	Mirror Switch Invalid Code	Driver Seat Module (DSM)	REFER to PINPOINT TEST D: THE MEMORY MIRROR IS INOPERATIVE .
B1242	Air Flow Recirculation Door Driver Circuit Failure	EATC Module	REFER to PINPOINT TEST D: DTC B1242 AIR INLET DOOR SHORT/FAILURE .
B1247	Panel Dim Switch Circuit Open	Smart Junction Box (SJB)	REFER to PINPOINT TEST F: THE CONTROL ILLUMINATION DOES NOT DIM .
B1251	Air Temperature Internal Sensor Circuit Open	EATC Module	REFER to PINPOINT TEST A: DTC B1251 OR DTC B1253 -- A/C IN-VEHICLE TEMPERATURE SENSOR OPEN CIRCUIT OR SHORT TO GROUND .
B1253	Air Temperature Internal Sensor Short to Ground	EATC Module	REFER to PINPOINT TEST A: DTC B1251 OR DTC B1253 -- A/C IN-VEHICLE TEMPERATURE SENSOR OPEN CIRCUIT OR SHORT TO GROUND .
B1255	Air Temperature External Sensor Circuit Open	EATC Module	REFER to PINPOINT TEST B: DTC B1255 OR DTC B1257 -- A/C AMBIENT TEMPERATURE SENSOR OPEN CIRCUIT OR SHORT TO GROUND .
B1257	Air Temperature External Sensor Short to Ground	EATC Module	REFER to PINPOINT TEST B: DTC B1255 OR DTC B1257 -- A/C AMBIENT TEMPERATURE SENSOR OPEN CIRCUIT OR SHORT TO GROUND .
B1299	Power Supply Sensor Circuit Short to Ground	Parking Aid Module	REFER to PINPOINT TEST C: DTCS C1700, C1703, C1706, C1709 PARKING AID SENSOR CIRCUIT FAILURE AND B1299 POWER SUPPLY SENSOR CIRCUIT SHORT TO GROUND .
B1309	Power Door Lock Circuit Short to Ground	SJB	REFER to PINPOINT TEST A: ALL DOOR LOCKS ARE INOPERATIVE FROM ONE SWITCH .
B1317	Battery Voltage High	Audio Control Module	REFER to PINPOINT TEST A: THE BATTERY IS DISCHARGED OR BATTERY VOLTAGE IS LOW .
B1317	Battery Voltage High	DSM	REFER to PINPOINT TEST A: THE BATTERY IS DISCHARGED OR BATTERY VOLTAGE IS LOW .
B1317	Battery Voltage High	RCM	REFER to PINPOINT TEST A: THE BATTERY IS DISCHARGED OR BATTERY VOLTAGE IS LOW .
B1317	Battery Voltage High	SJB	REFER to PINPOINT TEST A: THE BATTERY IS DISCHARGED OR BATTERY VOLTAGE IS LOW .
B1317	Battery Voltage High	Instrument Cluster	REFER to PINPOINT TEST A: THE BATTERY IS DISCHARGED OR BATTERY VOLTAGE IS LOW .
B1318	Battery Voltage Low	Audio Control Module	REFER to PINPOINT TEST A: THE BATTERY IS DISCHARGED OR BATTERY VOLTAGE IS LOW .
B1318	Battery Voltage Low	DSM	REFER to PINPOINT TEST A: THE BATTERY IS DISCHARGED OR BATTERY VOLTAGE IS LOW .
B1318	Battery Voltage Low	RCM	REFER to PINPOINT TEST A: THE BATTERY IS DISCHARGED OR BATTERY VOLTAGE IS LOW .
B1318	Battery Voltage Low	SJB	REFER to PINPOINT TEST A: THE BATTERY IS DISCHARGED OR BATTERY VOLTAGE IS LOW .
B1318	Battery Voltage Low	Instrument Cluster	REFER to PINPOINT TEST A: THE BATTERY IS DISCHARGED OR BATTERY VOLTAGE IS LOW .
B1320	Driver Door Ajar Circuit Open	SJB	REFER to PINPOINT TEST E: THE INTERIOR LAMPS STAY ON CONTINUOUSLY .
B1328	Passenger Door Ajar Circuit Open	SJB	REFER to PINPOINT TEST E: THE INTERIOR LAMPS STAY ON CONTINUOUSLY .
B1334	Decklid Ajar Rear Door Circuit Shorted to Ground	SJB	REFER to PINPOINT TEST E: THE INTERIOR LAMPS STAY ON CONTINUOUSLY .
B1336	Door Ajar RR Circuit Open	SJB	REFER to PINPOINT TEST E: THE INTERIOR LAMPS STAY ON CONTINUOUSLY .
B1341	Power Door Unlock Circuit Short to Ground	SJB	REFER to PINPOINT TEST A: ALL DOOR LOCKS ARE INOPERATIVE FROM ONE SWITCH .
B1342	ECU Defective (EEPROM in PCM not working)	PCM	INSTALL a new PCM. REFER to INSTALLATION .
B1342	ECU is Faulted	Anti-Lock Brake System (ABS) Module	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new ABS module. REFER to REMOVAL AND INSTALLATION . TEST the system for normal operation.
B1342	ECU is Faulted	Audio Control Module	REFER to SYMPTOM TABLE - AUDIO SYSTEM . TEST the system for normal operation.
B1342	ECU is Faulted	DSM	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new DSM. refer to DRIVER SEAT MODULE (DSM) . TEST the system for normal operation.
B1342	ECU is Faulted	EATC Module	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new EATC module. REFER to EATC MODULE . TEST the system for normal operation.
B1342	ECU is Faulted	Parking Aid Module	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new parking aid module. REFER to REMOVAL AND INSTALLATION . TEST the system for normal operation.
B1342	ECU is Faulted	RCM	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new RCM. REFER to INSTALLATION . TEST the system for normal operation.
B1342	ECU is Faulted	SJB	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new SJB. refer to SMART JUNCTION BOX (SJB) . TEST the system for normal operation.
B1342	ECU is Faulted	Instrument Cluster	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new instrument cluster. REFER to REMOVAL AND INSTALLATION . TEST the system for normal operation.
B1345	Heated Backlite Input Circuit Short to Ground	SJB	REFER to PINPOINT TEST F: THE DEFROST SYSTEM IS INOPERATIVE .
B1352	Ignition Key-In Circuit Failure	Instrument Cluster	REFER to PINPOINT TEST A: THE KEY-IN-IGNITION WARNING CHIME IS INOPERATIVE .
B1472	Lamp Headlamp Input Circuit Short to Ground	SJB	REFER to PINPOINT TEST E: THE HEADLAMPS ARE ON CONTINUOUSLY .
B1482	Wiper Washer Fluid Level Sensor Circuit Short to Ground	SJB	REFER to PINPOINT TEST U: THE LOW WASHER FLUID INDICATOR IS NEVER/ALWAYS ON .
B1484	Brake Pedal Input Open Circuit	ABS Module	REFER to PINPOINT TEST I: THE STOPLAMPS ARE INOPERATIVE .
B1486	Brake Pedal Input Circuit Ground Short	SJB	REFER to PINPOINT TEST I: THE STOPLAMPS ARE INOPERATIVE .
B1510	Flash to Pass Switch Circuit Short to Ground	SJB	REFER to PINPOINT TEST E: THE HEADLAMPS ARE ON CONTINUOUSLY .
B1520	Hood Switch Circuit Open	SJB	REFER to PINPOINT TEST C: THE ALARM SYSTEM DOES NOT OPERATE CORRECTLY .
B1530	Memory Set Switch Circuit Short to Ground	DSM	REFER to PINPOINT TEST L: THE MEMORY SEAT DOES NOT OPERATE CORRECTLY - DOES NOT OPERATE USING THE MEMORY SET SWITCH .
B1534	Memory 1 Switch Circuit Short to Ground	DSM	REFER to PINPOINT TEST L: THE MEMORY SEAT DOES NOT OPERATE CORRECTLY - DOES NOT OPERATE USING THE MEMORY SET SWITCH .
B1538	Memory 2 Switch Circuit Short to Ground	DSM	REFER to PINPOINT TEST L: THE MEMORY SEAT DOES NOT OPERATE CORRECTLY - DOES NOT OPERATE USING THE MEMORY SET SWITCH .
B1554	Liftgate Release Circuit Short to Ground	SJB	REFER to PINPOINT TEST B: THE LUGGAGE COMPARTMENT LID IS INOPERATIVE -- FROM THE LUGGAGE COMPARTMENT LID RELEASE SWITCH .
B1570	Lamp Headlamp High-Beam Circuit Short to Ground	SJB	REFER to PINPOINT TEST E: THE HEADLAMPS ARE ON CONTINUOUSLY .
B1572	Door Ajar LR Circuit Open	SJB	REFER to PINPOINT TEST E: THE INTERIOR LAMPS STAY ON CONTINUOUSLY .
B1578	Lamp Park Input Circuit Short to Ground	SJB	REFER to PINPOINT TEST R: ONE OR MORE PARKING, REAR, OR LICENSE PLATE LAMP IS INOPERATIVE .
B1596	Service Continuous Codes	ABS	REFER to ANTI-LOCK BRAKE SYSTEM (ABS) MODULE .
B1600	PATS Ignition Key Transponder Signal is Not Received	PCM	REFER to PINPOINT TEST B: DTC B1600-PATS IGNITION KEY TRANSPONDER SIGNAL IS NOT RECEIVED .
B1601	PATS Received Incorrect Code From Ignition Key Transponder	PCM	REFER to PINPOINT TEST C: DTC B1601-PATS RECEIVED INCORRECT KEY-CODE FROM IGNITION KEY TRANSPONDER .
B1602	PATS Ignition Invalid Format of Key-Code From Ignition Key Transponder	PCM	REFER to PINPOINT TEST D: DTC B1602-PATS RECEIVED INVALID FORMAT OF KEY-CODE FROM IGNITION KEY TRANSPONDER .
B1626	Lamp Keypad Output Circuit Failure	SJB	REFER to PINPOINT TEST L: THE REMOTE KEYLESS ENTRY (RKE) KEYPAD ILLUMINATION IS INOPERATIVE .
B1663	Seat Driver Front Up/Down Motor Stalled	DSM	REFER to PINPOINT TEST K: THE MEMORY SEAT IS INOPERATIVE .
B1664	Seat Driver Rear Up/Down Motor Stalled	DSM	REFER to PINPOINT TEST K: THE MEMORY SEAT IS INOPERATIVE .
B1665	Seat Driver Forward/Backward Motor Stalled	DSM	REFER to PINPOINT TEST K: THE MEMORY SEAT IS INOPERATIVE .
B1666	Seat Driver Recline Motor Stalled	DSM	REFER to PINPOINT TEST K: THE MEMORY SEAT IS INOPERATIVE .
B1667	Mirror Driver Up/Down Motor Stalled	DSM	REFER to PINPOINT TEST E: THE MEMORY MIRROR IS INOPERATIVE - DOES NOT OPERATE FROM THE MEMORY SET SWITCH .
B1668	Mirror Driver Right/Left Motor Stalled	DSM	REFER to PINPOINT TEST D: THE MEMORY MIRROR IS INOPERATIVE .
B1669	Mirror Passenger Up/Down Motor Stalled	DSM	REFER to PINPOINT TEST D: THE MEMORY MIRROR IS INOPERATIVE .
B1670	Mirror Passenger Right/Left Motor Stalled	DSM	REFER to PINPOINT TEST D: THE MEMORY MIRROR IS INOPERATIVE .
B1676	Battery Pack Voltage Out of Range	ABS Module	REFER to PINPOINT TEST C: DTC B1676, BATTERY PACK VOLTAGE OUT OF RANGE .
B1676	Battery Voltage Out of Range	EATC Module	REFER to ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) MODULE DIAGNOSTIC TROUBLE CODE (DTC) INDEX .
B1681	PATS Ignition Module Signal is not Received	PCM	REFER to PINPOINT TEST E: DTC B1681-PATS TRANSCEIVER MODULE SIGNAL IS NOT RECEIVED .
B1688	Lamp Dome Input Circuit Short to Ground	SJB	REFER to PINPOINT TEST E: THE INTERIOR LAMPS STAY ON CONTINUOUSLY .
B1692	Autolamp Delay Circuit Short to Ground	SJB	REFER to PINPOINT TEST H: THE AUTOLAMPS ARE ON CONTINUOUSLY .
B1703	Seat Driver Recline Forward Switch Circuit Short To Battery	DSM	REFER to PINPOINT TEST K: THE MEMORY SEAT IS INOPERATIVE .
B1707	Seat Driver Recline Rearward Switch Circuit Short To Battery	DSM	REFER to PINPOINT TEST K: THE MEMORY SEAT IS INOPERATIVE .
B1711	Seat Driver Front Up Switch Circuit Short to Battery	DSM	REFER to PINPOINT TEST K: THE MEMORY SEAT IS INOPERATIVE .
B1715	Seat Driver Front Down Switch Circuit Short to Battery	DSM	REFER to PINPOINT TEST K: THE MEMORY SEAT IS INOPERATIVE .
B1719	Seat Driver Forward Switch Circuit Short to Battery	DSM	REFER to PINPOINT TEST K: THE MEMORY SEAT IS INOPERATIVE .
B1723	Seat Driver Rearward Switch Circuit Short to Battery	DSM	REFER to PINPOINT TEST K: THE MEMORY SEAT IS INOPERATIVE .
B1727	Seat Driver Rear Up Switch Circuit Short to Battery	DSM	REFER to PINPOINT TEST K: THE MEMORY SEAT IS INOPERATIVE .
B1731	Seat Driver Rear Down Switch Circuit Short to Battery	DSM	REFER to PINPOINT TEST K: THE MEMORY SEAT IS INOPERATIVE .
B1792	Autolamp Sensor Input Short to Battery	SJB	REFER to PINPOINT TEST H: THE AUTOLAMPS ARE ON CONTINUOUSLY .
B1793	Autolamp Sensor Input Circuit Short to Ground	SJB	REFER to PINPOINT TEST G: THE AUTOLAMPS ARE INOPERATIVE .
B1795	Lamp Headlamp Low-Beam Circuit Open	SJB	REFER to PINPOINT TEST A: THE LOW BEAMS ARE INOPERATIVE .
B1797	Lamp Headlamp Low-Beam Circuit Short to Ground	SJB	REFER to PINPOINT TEST A: THE LOW BEAMS ARE INOPERATIVE .
B1799	Lamp Turn Signal Front Output Circuit Open	SJB	REFER to PINPOINT TEST L: THE TURN SIGNAL LAMPS ARE INOPERATIVE .
B1801	Lamp Turn Signal Front Output Circuit Short to Ground	SJB	REFER to PINPOINT TEST L: THE TURN SIGNAL LAMPS ARE INOPERATIVE .
B1868	Lamp Airbag Warning Indicator Circuit Failure	Instrument Cluster	REFER to INSTRUMENT CLUSTER .
B1870	Lamp Airbag Warning Indicator Circuit Short to Battery	Instrument Cluster	REFER to INSTRUMENT CLUSTER .
B1875	Turn Signal/Hazard Switch Signal Circuit Failure	SJB	REFER to PINPOINT TEST P: THE HAZARD LAMPS ARE INOPERATIVE .
B1884	PAD Warning Lamp Circuit Failure	RCM	REFER to PINPOINT TEST O: LFC 18/DTC B1884 - PAD WARNING LAMP CIRCUIT FAILURE .
B1890	PAD Warning Lamp Circuit Short to Battery	RCM	REFER to PINPOINT TEST P: LFC 18/DTC B1890 - PAD WARNING LAMP CIRCUIT SHORT TO BATTERY .
B1952	Seat Rear Up/Down Position Feedback Circuit Short to Battery	DSM	REFER to PINPOINT TEST L: THE MEMORY SEAT DOES NOT OPERATE CORRECTLY - DOES NOT OPERATE USING THE MEMORY SET SWITCH .
B1953	Seat Rear Up/Down Position Feedback Circuit Short to Ground	DSM	REFER to PINPOINT TEST L: THE MEMORY SEAT DOES NOT OPERATE CORRECTLY - DOES NOT OPERATE USING THE MEMORY SET SWITCH .
B1956	Seat Front Up/Down Position Feedback Circuit Short to Battery	DSM	REFER to PINPOINT TEST L: THE MEMORY SEAT DOES NOT OPERATE CORRECTLY - DOES NOT OPERATE USING THE MEMORY SET SWITCH .
B1957	Seat Front Up/Down Position Feedback Circuit Short to Ground	DSM	REFER to PINPOINT TEST L: THE MEMORY SEAT DOES NOT OPERATE CORRECTLY - DOES NOT OPERATE USING THE MEMORY SET SWITCH .
B1960	Seat Recline Forward/Backward Feedback Circuit Short to Battery	DSM	REFER to PINPOINT TEST L: THE MEMORY SEAT DOES NOT OPERATE CORRECTLY - DOES NOT OPERATE USING THE MEMORY SET SWITCH .
B1961	Seat Recline Forward/Backward Position Feedback Circuit Short to Ground	DSM	REFER to PINPOINT TEST L: THE MEMORY SEAT DOES NOT OPERATE CORRECTLY - DOES NOT OPERATE USING THE MEMORY SET SWITCH .
B1964	Seat Horizontal Forward/Rearward Position Feedback Circuit Short to Battery	DSM	REFER to PINPOINT TEST L: THE MEMORY SEAT DOES NOT OPERATE CORRECTLY - DOES NOT OPERATE USING THE MEMORY SET SWITCH .
B1965	Seat Horizontal Forward/Rearward Position Feedback Circuit Short to Ground	DSM	REFER to PINPOINT TEST L: THE MEMORY SEAT DOES NOT OPERATE CORRECTLY - DOES NOT OPERATE USING THE MEMORY SET SWITCH .
B1987	Pedal Forward/Rearward Motor Stalled	DSM	REFER to PINPOINT TEST C: ADJUSTABLE BRAKE PEDAL IS INOPERATIVE/DOES NOT OPERATE CORRECTLY - MEMORY .
B1988	Pedal Position Forward Switch Circuit Short to Battery	DSM	REFER to PINPOINT TEST C: ADJUSTABLE BRAKE PEDAL IS INOPERATIVE/DOES NOT OPERATE CORRECTLY - MEMORY .
B1989	Pedal Position Rearward Switch Circuit Short to Battery	DSM	REFER to PINPOINT TEST C: ADJUSTABLE BRAKE PEDAL IS INOPERATIVE/DOES NOT OPERATE CORRECTLY - MEMORY .
B2026	Incandescent Backlighting Output Circuit Failure	SJB	REFER to PINPOINT TEST D: ONE OR MORE MODULE-CONTROLLED ILLUMINATION SOURCE(S) IS INOPERATIVE .
B2027	LED Backlighting Output Circuit Failure	SJB	REFER to PINPOINT TEST D: ONE OR MORE MODULE-CONTROLLED ILLUMINATION SOURCE(S) IS INOPERATIVE .
B2030	Front Fog Lamp Relay Circuit Failure	SJB	REFER to PINPOINT TEST T: THE FOG LAMPS ARE INOPERATIVE .
B2044	Left Rear Stop Lamp Circuit Short to Ground	SJB	REFER to PINPOINT TEST J: ONE OR MORE STOPLAMPS ARE INOPERATIVE .
B2045	Left Rear Stop Lamp Circuit Open	SJB	REFER to PINPOINT TEST J: ONE OR MORE STOPLAMPS ARE INOPERATIVE .
B2046	Right Rear Stop Lamp Circuit Short to Ground	SJB	REFER to PINPOINT TEST J: ONE OR MORE STOPLAMPS ARE INOPERATIVE .
B2047	Right Rear Stop Lamp Circuit Open	SJB	REFER to PINPOINT TEST J: ONE OR MORE STOPLAMPS ARE INOPERATIVE .
B2077	Liftgate Ajar Switch Circuit Failure	SJB	REFER to INTERIOR LIGHTING .
B2084	Memory SET Indicator Short to Ground	DSM	REFER to SWITCH - MEMORY SET .
B2097	Compass Module Failure	Instrument Cluster	REFER to PINPOINT TEST B: THE COMPASS IS INOPERATIVE .
B2103	Antenna Not Connected	PCM	REFER to PINPOINT TEST A: DTC 2103 - ANTENNA NOT CONNECTED .
B2116	Door Driver Reset Switch Stuck Failure	SJB	REFER to PINPOINT TEST C: THE ALARM SYSTEM DOES NOT OPERATE CORRECTLY .
B2143	Non Volatile Memory Failure	DSM	REFER to DRIVER SEAT MODULE (DSM) DIAGNOSTIC TROUBLE CODE (DTC) INDEX .
B2143	NVM Memory Failure	Instrument Cluster	REFER to INSTRUMENT CLUSTER .
B2223	Mirror Driver Drive Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B2224	Mirror Passenger Drive Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B2266	Left Side Blend Door Circuit Failure	EATC Module	REFER to ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) MODULE DIAGNOSTIC TROUBLE CODE (DTC) INDEX .
B2267	Right Side Blend Door Circuit Failure	EATC Module	REFER to ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) MODULE DIAGNOSTIC TROUBLE CODE (DTC) INDEX .
B2276	Less Than 2 Transmitters Programmed	SJB	REFER to PINPOINT TEST F: THE DOORS DO NOT LOCK/UNLOCK USING THE REMOTE KEYLESS ENTRY (RKE) TRANSMITTER .
B2281	Right Turn Switch Short to Ground	SJB	REFER to PINPOINT TEST M: THE TURN SIGNAL LAMPS ARE ALWAYS ON .
B2282	Left Turn Switch Short to Ground	SJB	REFER to PINPOINT TEST M: THE TURN SIGNAL LAMPS ARE ALWAYS ON .
B2290	Occupant Classification System Fault	RCM	REFER to PINPOINT TEST Q: LFC 16/DTC B2290 - OCCUPANT CLASSIFICATION SYSTEM (OCS) FAULT .
B2292	Restraint System - Seatbelt Pretensioner Fault	RCM	REFER to PINPOINT TEST R: LFC 33 AND 34/DTC B2292 - RESTRAINT SYSTEM - SEAT BELT PRETENSIONER FAULT .
B2293	Restraint System - Airbag Fault	RCM	REFER to PINPOINT TEST S: LFC 19 AND 21/DTC B2293 - RESTRAINT SYSTEM - AIR BAG FAULT .
B2294	Restraint System - Curtain Fault	RCM	REFER to PINPOINT TEST T: LFC 24, 25, 31 OR 32 DTC B2294 - RESTRAINT SYSTEM - CURTAIN FAULT .
B2295	Restraint System - Side Airbag Fault	RCM	REFER to PINPOINT TEST U: LFC 22 OR 23 DTC B2295 - RESTRAINT SYSTEM - SIDE AIR BAG FAULT .
B2296	Restraint System - Impact Sensor Fault	RCM	REFER to PINPOINT TEST V: LFC 42, 43, 44, 45, 46 AND 47/DTC B2296 - RESTRAINT SYSTEM - IMPACT SENSOR FAULT .
B2312	Mirror Passenger Horiz. Feedback Pot. Ckt. Failure	DSM	REFER to PINPOINT TEST E: THE MEMORY MIRROR IS INOPERATIVE - DOES NOT OPERATE FROM THE MEMORY SET SWITCH .
B2314	Mirror Passenger Horiz. Feedback Pot. Ckt. Short to Battery	DSM	REFER to PINPOINT TEST E: THE MEMORY MIRROR IS INOPERATIVE - DOES NOT OPERATE FROM THE MEMORY SET SWITCH .
B2316	Mirror Passenger Vert. Feedback Pot. Ckt. Failure	DSM	REFER to PINPOINT TEST E: THE MEMORY MIRROR IS INOPERATIVE - DOES NOT OPERATE FROM THE MEMORY SET SWITCH .
B2318	Mirror Passenger Vert. Feedback Pot. Ckt. Short to Battery	DSM	REFER to PINPOINT TEST E: THE MEMORY MIRROR IS INOPERATIVE - DOES NOT OPERATE FROM THE MEMORY SET SWITCH .
B2320	Mirror Driver Horiz. Feedback Pot. Ckt Failure	DSM	REFER to PINPOINT TEST E: THE MEMORY MIRROR IS INOPERATIVE - DOES NOT OPERATE FROM THE MEMORY SET SWITCH .
B2322	Mirror Driver Horiz. Feedback Pot. Ckt Short to Battery	DSM	REFER to PINPOINT TEST E: THE MEMORY MIRROR IS INOPERATIVE - DOES NOT OPERATE FROM THE MEMORY SET SWITCH .
B2324	Mirror Driver Vert. Feedback Pot. Ckt. Failure	DSM	REFER to PINPOINT TEST E: THE MEMORY MIRROR IS INOPERATIVE - DOES NOT OPERATE FROM THE MEMORY SET SWITCH .
B2326	Mirror Driver Vert. Feedback Pot. Ckt. Short to Battery	DSM	REFER to PINPOINT TEST E: THE MEMORY MIRROR IS INOPERATIVE - DOES NOT OPERATE FROM THE MEMORY SET SWITCH .
B2373	LED 1 Circuit Short to Battery	Parking Aid Module	REFER to PINPOINT TEST H: DTC C1920 AND B2373 LED NO. 1 CIRCUIT FAILURE .
B2406	Audio Disc CD Player Internal Fault	Audio Control Module	REFER to INFORMATION AND ENTERTAINMENT SYSTEM .
B2425	Remote Keyless Entry Out of Synchronization	SJB	REFER to PINPOINT TEST J: THE REMOTE KEYLESS ENTRY (RKE) TRANSMITTER IS OUT OF SYNCHRONIZATION .
B2426	Passenger Solar Radiation Sensor Circuit Open	EATC Module	REFER to ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) MODULE DIAGNOSTIC TROUBLE CODE (DTC) INDEX .
B2427	Passenger Solar Radiation Sensor Circuit Short to Ground	EATC Module	REFER to ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) MODULE DIAGNOSTIC TROUBLE CODE (DTC) INDEX .
B2431	Key Program Failure	PCM	VERIFY if the correct Pats Key is being used. If the PATS key is defective, use a new key for programming.
B2434	Drivers Seatbelt Buckle Switch Circuit Short to Ground	RCM	REFER to PINPOINT TEST W: LFC 53/DTC B2434 - DRIVERS SEAT BELT BUCKLE SWITCH CIRCUIT SHORT TO GROUND .
B2435	Drivers Seatbelt Buckle Switch Resistance Out of Range	RCM	REFER to PINPOINT TEST X: LFC 53/DTC B2435 - DRIVERS SEAT BELT BUCKLE SWITCH RESISTANCE OUT OF RANGE .
B2438	Passenger Seatbelt Buckle Switch Circuit Short to Ground	RCM	REFER to PINPOINT TEST Y: LFC 54/DTC B2438 - PASSENGERS SEAT BELT BUCKLE SWITCH CIRCUIT SHORT TO GROUND .
B2439	Passenger Seatbelt Buckle Switch Resistance Out of Range	RCM	REFER to PINPOINT TEST Z: LFC 54/DTC B2439 - PASSENGERS SEAT BELT BUCKLE SWITCH RESISTANCE OUT OF RANGE .
B2477	ECU Configuration Failure	ABS Module	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	Audio Control Module	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	DSM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	SJB	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	Instrument Cluster	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	Parking Aid Module	REFER to PARKING AID .
B2479	Brake Park Switch Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B2498	Headlamp Switch OFF Position OPEN	SJB	REFER to PINPOINT TEST E: THE HEADLAMPS ARE ON CONTINUOUSLY .
B2627	Fuel Sender Circuit Open #2	Instrument Cluster	REFER to PINPOINT TEST B: INCORRECT FUEL GAUGE INDICATION .
B2628	Fuel Sender Circuit Short to Ground #2	Instrument Cluster	REFER to PINPOINT TEST B: INCORRECT FUEL GAUGE INDICATION .
B2675	Trip Reset Button Stuck	Instrument Cluster	REFER to INSTRUMENT CLUSTER .
B2678	Low Coolant Sender Failure	SJB	REFER to INSTRUMENT CLUSTER .
B2691	Front Passengers Seatbelt Buckle Switch Circuit Fault	RCM	REFER to PINPOINT TEST AA: LFC 53/DTC B2691 - SEAT BELT BUCKLE SWITCH CIRCUIT FAULT - FRONT DRIVER SIDE .
B2692	Front Passenger Seatbelt Buckle Switch Circuit Fault, Front Driver's Side	RCM	REFER to PINPOINT TEST R: LFC 33 AND 34/DTC B2292 - RESTRAINT SYSTEM - SEAT BELT PRETENSIONER FAULT .
B2695	Keypad A Switch Circuit Failure	SJB	REFER to PINPOINT TEST E: THE DOORS DO NOT LOCK/UNLOCK USING THE REMOTE KEYLESS ENTRY (RKE) KEYPAD .
B2696	Keypad B Switch Circuit Failure	SJB	REFER to PINPOINT TEST E: THE DOORS DO NOT LOCK/UNLOCK USING THE REMOTE KEYLESS ENTRY (RKE) KEYPAD .
B2697	Keypad C Switch Circuit Failure	SJB	REFER to PINPOINT TEST E: THE DOORS DO NOT LOCK/UNLOCK USING THE REMOTE KEYLESS ENTRY (RKE) KEYPAD .
B2795	Driver Solar Radiation Sensor Circuit Short to Ground	EATC Module	REFER to PINPOINT TEST C: DTC B2796 OR DTC B2795 -- SOLAR RADIATION SENSOR OPEN CIRCUIT OR SHORT TO GROUND .
B2796	Driver Solar Radiation Sensor Circuit Open	EATC Module	REFER to PINPOINT TEST C: DTC B2796 OR DTC B2795 -- SOLAR RADIATION SENSOR OPEN CIRCUIT OR SHORT TO GROUND .
B2879	Fuel Tank Jetpump Fault	Instrument Cluster	REFER to PINPOINT TEST B: INCORRECT FUEL GAUGE INDICATION .
B2900	VIN Mismatch	ABS Module	REFER to MODULE CONFIGURATION .
B2909	Belt Tension Sensor Fault	RCM	REFER to PINPOINT TEST AC: LFC 16/DTC B2909 - BELT TENSION SENSOR FAULT .
B2916	Rear Blend Door Circuit Failure	EATC Module	REFER to PINPOINT TEST R: THE TEMPERATURE CONTROL IS INOPERATIVE/DOES NOT OPERATE CORRECTLY USING THE FRONT/REAR AUXILIARY CLIMATE CONTROLS .
B2917	Rear Mode Door Circuit Failure	EATC Module	REFER to PINPOINT TEST S: THE PANEL/FLOOR CONTROL IS INOPERATIVE/DOES NOT OPERATE CORRECTLY USING THE FRONT/REAR AUXILIARY CLIMATE CONTROLS .
B2918	Aux. Temp. Blend Input Circuit Failure	EATC Module	REFER to PINPOINT TEST R: THE TEMPERATURE CONTROL IS INOPERATIVE/DOES NOT OPERATE CORRECTLY USING THE FRONT/REAR AUXILIARY CLIMATE CONTROLS .
B2919	Aux. Blower Motor Speed Input Circuit Failure	EATC Module	REFER to PINPOINT TEST Q: THE AUXILIARY BLOWER MOTOR DOES NOT OPERATE CORRECTLY .
B2924	Audio Button Stuck	Audio Control Module	REFER to PINPOINT TEST M: DTC B2924 - AUDIO BUTTON STUCK .
B2965	Audio System Speaker Circuit Fault	Audio Control Module	REFER to PINPOINT TEST E: POOR QUALITY/DISTORTED/NO SOUND FROM ONE OR MORE SPEAKERS (NOT ALL SPEAKERS) .
B2971	Pedal Position Input Short to Ground	DSM	REFER to PINPOINT TEST C: ADJUSTABLE BRAKE PEDAL IS INOPERATIVE/DOES NOT OPERATE CORRECTLY - MEMORY .
B2972	Pedal Position Input Short to Battery	DSM	REFER to PINPOINT TEST C: ADJUSTABLE BRAKE PEDAL IS INOPERATIVE/DOES NOT OPERATE CORRECTLY - MEMORY .
B2984	Deployable Steering Column Circuit Open	RCM	REFER to PINPOINT TEST AD: LFC 57/DTC B2984 - DEPLOYABLE STEERING COLUMN CIRCUIT OPEN .
B2985	Deployable Steering Column Circuit Short to Battery	RCM	REFER to PINPOINT TEST AE: LFC 57/DTC B2985 - DEPLOYABLE STEERING COLUMN CIRCUIT SHORT TO BATTERY .
B2986	Deployable Steering Column Circuit Short to Ground	RCM	REFER to PINPOINT TEST AF: LFC 57/DTC B2986 - DEPLOYABLE STEERING COLUMN CIRCUIT SHORT TO GROUND .
B2987	Deployable Steering Column Circuit Resistance Low on Squib	RCM	REFER to PINPOINT TEST AG: LFC 57/DTC B2987 - DEPLOYABLE STEERING COLUMN CIRCUIT RESISTANCE LOW ON SQUIB .
B2999	Restraint Event Notification Signal Fault	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
C1093	Traction Control Disable Switch Circuit Failure	Instrument Cluster	REFER to PINPOINT TEST K: THE TRACTION CONTROL SYSTEM CANNOT BE DISABLED .
C1125	Brake Fluid Level Sensor Input Circuit Failure	SJB	REFER to VEHICLE DYNAMIC SYSTEMS .
C1145	Speed Wheel Sensor RF Input Circuit Failure	ABS Module	REFER to PINPOINT TEST D: DTCS C1145, C1155, C1165 AND C1175 - WHEEL SPEED SENSOR INPUT CIRCUIT FAILURE .
C1155	Speed Wheel Sensor LF Input Circuit Failure	ABS Module	REFER to PINPOINT TEST D: DTCS C1145, C1155, C1165 AND C1175 - WHEEL SPEED SENSOR INPUT CIRCUIT FAILURE .
C1165	Speed Wheel Sensor RR Input Circuit Failure	ABS Module	REFER to PINPOINT TEST D: DTCS C1145, C1155, C1165 AND C1175 - WHEEL SPEED SENSOR INPUT CIRCUIT FAILURE .
C1175	Speed Wheel Sensor LR Input Circuit Failure	ABS Module	REFER to PINPOINT TEST D: DTCS C1145, C1155, C1165 AND C1175 - WHEEL SPEED SENSOR INPUT CIRCUIT FAILURE .
C1222	Speed Wheel Mismatch	ABS Module	REFER to PINPOINT TEST F: DTCS C1222, C1296 (LF), C1297 (RF), C1298 (LR) AND C1299 (RR) -- WHEEL SPEED SENSOR FAULT .
C1222	Speed Wheel Mismatch	Transmission Control Module (TCM) - Continuously Variable Transaxle (CVT)	REFER to DIAGNOSTIC TROUBLE CODE (DTC) TABLES .
C1266	ABS Valve Power Relay Circuit Failure	ABS Module	REFER to PINPOINT TEST E: DTC C1266 ANTI-LOCK BRAKE SYSTEM (ABS) POWER VALVE RELAY CIRCUIT FAILURE .
C1284	Oil Pressure Switch Failure	SJB	REFER to PINPOINT TEST D: THE LOW OIL PRESSURE WARNING INDICATOR IS NEVER/ALWAYS ON .
C1296	Wheel Speed LF Signal Fault	ABS Module	REFER to PINPOINT TEST F: DTCS C1222, C1296 (LF), C1297 (RF), C1298 (LR) AND C1299 (RR) -- WHEEL SPEED SENSOR FAULT .
C1297	Wheel Speed RF Signal Fault	ABS Module	REFER to PINPOINT TEST F: DTCS C1222, C1296 (LF), C1297 (RF), C1298 (LR) AND C1299 (RR) -- WHEEL SPEED SENSOR FAULT .
C1298	Wheel Speed RR Signal Fault	ABS Module	REFER to PINPOINT TEST F: DTCS C1222, C1296 (LF), C1297 (RF), C1298 (LR) AND C1299 (RR) -- WHEEL SPEED SENSOR FAULT .
C1299	Wheel Speed LR Signal Fault	ABS Module	REFER to PINPOINT TEST F: DTCS C1222, C1296 (LF), C1297 (RF), C1298 (LR) AND C1299 (RR) -- WHEEL SPEED SENSOR FAULT .
C1300	ABS Pump Motor Circuit Failure	ABS Module	REFER to PINPOINT TEST G: DTC C1300 -- ABS HYDRAULIC PUMP MOTOR CIRCUIT FAILURE .
C1414	Incorrect Module Design Level	RCM	REFER to PINPOINT TEST AH: LFC 15/DTC C1414 - INCORRECT MODULE DESIGN LEVEL .
C1699	Left Rear Sensor Circuit Short to Vbat	Parking Aid Module	REFER to PINPOINT TEST D: DTCS C1699, C1702, C1705 AND C1708 PARKING AID SENSOR CIRCUIT SHORT TO BATTERY .
C1700	Left Rear Sensor Circuit Failure or Blockage	Parking Aid Module	REFER to PINPOINT TEST C: DTCS C1700, C1703, C1706, C1709 PARKING AID SENSOR CIRCUIT FAILURE AND B1299 POWER SUPPLY SENSOR CIRCUIT SHORT TO GROUND .
C1701	Left Rear Sensor Circuit Fault	Parking Aid Module	REFER to PINPOINT TEST E: DTCS C1701, C1704, C1707 AND C1710 PARKING AID SENSOR FAULT .
C1702	Right Rear Sensor Circuit Short to Vbat	Parking Aid Module	REFER to PINPOINT TEST D: DTCS C1699, C1702, C1705 AND C1708 PARKING AID SENSOR CIRCUIT SHORT TO BATTERY .
C1703	Right Rear Sensor Circuit Failure or Blockage	Parking Aid Module	REFER to PINPOINT TEST C: DTCS C1700, C1703, C1706, C1709 PARKING AID SENSOR CIRCUIT FAILURE AND B1299 POWER SUPPLY SENSOR CIRCUIT SHORT TO GROUND .
C1704	Right Rear Sensor Circuit Fault	Parking Aid Module	REFER to PINPOINT TEST E: DTCS C1701, C1704, C1707 AND C1710 PARKING AID SENSOR FAULT .
C1705	Left Rear Center Sensor Circuit Short to Battery	Parking Aid Module	REFER to PINPOINT TEST D: DTCS C1699, C1702, C1705 AND C1708 PARKING AID SENSOR CIRCUIT SHORT TO BATTERY .
C1706	Left Rear Center Sensor Circuit Failure	Parking Aid Module	REFER to PINPOINT TEST C: DTCS C1700, C1703, C1706, C1709 PARKING AID SENSOR CIRCUIT FAILURE AND B1299 POWER SUPPLY SENSOR CIRCUIT SHORT TO GROUND .
C1707	Left Rear Center Sensor Circuit Fault	Parking Aid Module	REFER to PINPOINT TEST E: DTCS C1701, C1704, C1707 AND C1710 PARKING AID SENSOR FAULT .
C1708	Right Rear Center Sensor Circuit Short to Vbat	Parking Aid Module	REFER to PINPOINT TEST D: DTCS C1699, C1702, C1705 AND C1708 PARKING AID SENSOR CIRCUIT SHORT TO BATTERY .
C1709	Right Rear Center Sensor Circuit Failure	Parking Aid Module	REFER to PINPOINT TEST C: DTCS C1700, C1703, C1706, C1709 PARKING AID SENSOR CIRCUIT FAILURE AND B1299 POWER SUPPLY SENSOR CIRCUIT SHORT TO GROUND .
C1710	Right Rear Center Sensor Circuit Fault	Parking Aid Module	REFER to PINPOINT TEST E: DTCS C1701, C1704, C1707 AND C1710 PARKING AID SENSOR FAULT .
C1742	Rear Sounder Circuit Failure	Parking Aid Module	REFER to PINPOINT TEST F: DTC C1742 AND C1743 REAR SOUNDER CIRCUIT FAILURE/SHORT TO BATTERY .
C1743	Rear Sounder Circuit Short to Vbat	Parking Aid Module	REFER to PINPOINT TEST F: DTC C1742 AND C1743 REAR SOUNDER CIRCUIT FAILURE/SHORT TO BATTERY .
C1748	Switch Input Circuit Short to Ground	Parking Aid Module	REFER to PINPOINT TEST G: DTC C1748 SWITCH INPUT CIRCUIT SHORT TO GROUND .
C1805	Mismatched PCM and/or ABS/TC Module	ABS Module	REFER to PINPOINT TEST A: NO COMMUNICATION WITH THE ANTI-LOCK BRAKE SYSTEM (ABS) MODULE .
C1920	LED #1 Circuit Failure	Parking Aid Module	REFER to PINPOINT TEST H: DTC C1920 AND B2373 LED NO. 1 CIRCUIT FAILURE .
C1947	Front Driver's Seat Track Position Switch Circuit Short to Ground	RCM	REFER to PINPOINT TEST AL: LFC 51 /DTC C1947 - FRONT DRIVERS SEAT TRACK POSITION SENSOR CIRCUIT SHORT TO GROUND .
C1948	Front Driver's Seat Track Position Switch Circuit Resistance Out of Range	RCM	REFER to PINPOINT TEST AJ: LFC 51/DTC C1948 - FRONT DRIVERS SEAT TRACK POSITION SENSOR CIRCUIT RESISTANCE OUT OF RANGE .
C1981	Front Driver's Seat Track Position Switch Circuit Fault	RCM	REFER to PINPOINT TEST AK: LFC 51/DTC C1981 - FRONT DRIVERS SEAT TRACK POSITION SENSOR CIRCUIT FAULT .
P0218	Transmission Fluid Overtemperature Condition	TCM - CVT Transmission	REFER to DIAGNOSIS BY SYMPTOM .
P0562	System Voltage Low	Differential Electronic Module (DEM)	REFER to PINPOINT TEST A: THE BATTERY IS DISCHARGED OR BATTERY VOLTAGE IS LOW .
P0562	System Voltage Low	TCM - AISIN Transmission	REFER to PINPOINT TEST A: THE BATTERY IS DISCHARGED OR BATTERY VOLTAGE IS LOW .
P0563	System Voltage High	DEM	REFER to PINPOINT TEST A: THE BATTERY IS DISCHARGED OR BATTERY VOLTAGE IS LOW .
P0563	System Voltage High	TCM - AISIN Transmission	REFER to PINPOINT TEST A: THE BATTERY IS DISCHARGED OR BATTERY VOLTAGE IS LOW .
P0579	Cruise Control Multifunction Input A Circuit Range/Performance	Powertrain Control Module (PCM)	REFER to PINPOINT TEST C: DTC P0579 OR DTC P0581 - SPEED CONTROL SWITCH CIRCUIT FAILURE .
P0581	Cruise Control Multifunction Circuit High	PCM	REFER to PINPOINT TEST C: DTC P0579 OR DTC P0581 - SPEED CONTROL SWITCH CIRCUIT FAILURE .
P0601	Powertrain Control Module Read Only Memory (ROM) Error	TCM - AISIN Transmission	REFER to INTRODUCTION - GASOLINE article .
P0603	Powertrain Control Module Keep Alive Memory (KAM) Error	TCM - AISIN Transmission	REFER to INTRODUCTION - GASOLINE article .
P0604	Powertrain Control Module Random Access Memory (RAM) Error	TCM - AISIN Transmission	REFER to INTRODUCTION - GASOLINE article .
P0604	Powertrain Control Module Random Access Memory (RAM) Error	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0605	Powertrain Control Module Read Only Memory (ROM) Error	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0610	Control Module Vehicle Options Error	DEM	REFER to MODULE CONFIGURATION .
P0613	TCM Processor	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0615	Starter Relay Circuit	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0657	Actuator Supply Voltage A Circuit/Open	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0658	Actuator Supply Voltage A Circuit Low	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0659	Actuator Supply Voltage A Circuit High	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0701	Transmission Control System Range/Performance	TCM - CVT Transmission	REFER to ON-BOARD DIAGNOSTIC (OBD) WITH DIAGNOSTIC TOOL .
P0702	Transmission Control System Electrical	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0706	Transmission Range Sensor A Circuit Range/Performance	TCM - CVT Transmission	REFER to PINPOINT TEST C: TRANSMISSION RANGE (TR) SENSOR .
P0706	Transmission Range Sensor A Circuit Range/Performance	TCM - AISIN Transmission	REFER to TRANSMISSION CONTROL MODULE (TCM) .
P0707	Transmission Range Sensor A Circuit Low Input	TCM - AISIN Transmission	REFER to TRANSMISSION CONTROL MODULE (TCM) .
P0708	Transmission Range Sensor A Circuit High Input	TCM - AISIN Transmission	REFER to TRANSMISSION CONTROL MODULE (TCM) .
P0710	Transmission Fluid Temperature Sensor A Circuit	TCM - CVT Transmission	REFER to PINPOINT TEST B: TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR .
P0711	Transmission Fluid Temperature Sensor A Circuit Range/Performance	TCM - CVT Transmission	REFER to PINPOINT TEST B: TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR .
P0711	Transmission Fluid Temperature Sensor A Circuit Range/Performance	TCM - AISIN Transmission	REFER to PINPOINT TEST B: TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR .
P0712	Transmission Fluid Temperature Sensor A Circuit Low Input	TCM - AISIN Transmission	REFER to PINPOINT TEST B: TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR .
P0713	Transmission Fluid Temperature Sensor A Circuit High Input	TCM - AISIN Transmission	REFER to PINPOINT TEST B: TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR .
P0714	Transmission Fluid Temperature Sensor A Circuit Intermittent	TCM - CVT Transmission	REFER to PINPOINT TEST B: TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR .
P0715	Turbine/Input Shaft Speed Sensor A Circuit	TCM - CVT Transmission	REFER to PINPOINT TEST G: TURBINE SHAFT SPEED (TSS) SENSOR .
P0716	Turbine/Input Shaft Speed Sensor A Circuit Range/Performance	TCM - CVT Transmission	REFER to PINPOINT TEST G: TURBINE SHAFT SPEED (TSS) SENSOR .
P0716	Turbine/Input Shaft Speed Sensor A Circuit Range/Performance	TCM - AISIN Transmission	REFER to PINPOINT TEST D: TURBINE SHAFT SPEED SENSOR .
P0717	Turbine/Input Shaft Speed Sensor A Circuit No Signal	TCM - AISIN Transmission	REFER to PINPOINT TEST D: TURBINE SHAFT SPEED SENSOR .
P0720	Output Shaft Speed Sensor Circuit	TCM - CVT Transmission	REFER to PINPOINT TEST F: OUTPUT SHAFT SPEED (OSS) SENSORS .
P0720	Output Shaft Speed Circuit Fault	PCM	REFER to INTRODUCTION - GASOLINE article .
P0721	Output Shaft Speed Circuit Fault	PCM	REFER to INTRODUCTION - GASOLINE article .
P0721	Output Shaft Speed Sensor Circuit Range/Performance	TCM - CVT Transmission	REFER to PINPOINT TEST F: OUTPUT SHAFT SPEED (OSS) SENSORS .
P0721	Output Shaft Speed Sensor A Circuit Range/Performance	TCM - AISIN Transmission	REFER to PINPOINT TEST C: OUTPUT SHAFT SPEED (OSS) SENSORS .
P0722	Output Shaft Speed Sensor A Circuit No Signal	TCM - AISIN Transmission	REFER to PINPOINT TEST C: OUTPUT SHAFT SPEED (OSS) SENSORS .
P0729	Gear 6 Incorrect Ratio	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0730	Incorrect Gear Ratio	TCM - CVT Transmission	REFER to PINPOINT TEST A: TRANSMISSION FLUID PRESSURE SENSORS .
P0730	Incorrect Gear Ratio	TCM - AISIN Transmission	REFER to PINPOINT TEST A: TRANSMISSION FLUID PRESSURE SENSORS
P0731	Gear 1 Incorrect Ratio	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0732	Gear 2 Incorrect Ratio	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0733	Gear 3 Incorrect Ratio	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0734	Gear 4 Incorrect Ratio	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0735	Gear 5 Incorrect Ratio	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0736	Reverse Incorrect Ratio	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0740	Torque Converter Clutch Solenoid Circuit/Open	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0741	Torque Converter Clutch Solenoid Circuit Performance or Stuck Off	TCM - CVT Transmission	REFER to PINPOINT TEST D: TORQUE CONVERTER CLUTCH .
P0742	Torque Converter Clutch Solenoid Circuit Stuck On	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0743	Torque Converter Clutch Solenoid Circuit Electrical	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0780	Shift Malfunction	TCM - AISIN Transmission	REFER to MAIN CONTROL VALVE BODY .
P0790	Normal/Performance Switch Circuit	TCM - CVT Transmission	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - CVT .
P0810	Clutch Position Control Error	TCM - CVT Transmission	REFER to PINPOINT TEST E: EXCESSIVE CLUTCH SLIPPAGE .
P0811	Excessive Clutch Slippage	TCM - CVT Transmission	REFER to PINPOINT TEST E: EXCESSIVE CLUTCH SLIPPAGE .
P0817	Starter Disable Circuit	TCM - AISIN Transmission	REFER to PINPOINT TEST E: PARK NEUTRAL SIGNAL .
P0840	Transmission Fluid Pressure Sensor/Switch A Circuit	TCM - CVT Transmission	REFER to PINPOINT TEST A: TRANSMISSION FLUID PRESSURE SENSORS .
P0845	Transmission Fluid Pressure Sensor/Switch B Circuit	TCM - CVT Transmission	REFER to PINPOINT TEST A: TRANSMISSION FLUID PRESSURE SENSORS .
P0868	Transmission Fluid Pressure Low	TCM - CVT Transmission	REFER to PINPOINT TEST A: TRANSMISSION FLUID PRESSURE SENSORS .
P0871	Transmission Fluid Pressure Sensor/Switch C Circuit Range/Performance	TCM - CVT Transmission	REFER to PINPOINT TEST A: TRANSMISSION FLUID PRESSURE SENSORS .
P0882	TCM Power Input Signal Low	TCM - CVT Transmission	REFER to CHARGING SYSTEM .
P0883	TCM Power Input Signal High	TCM - CVT Transmission	REFER to CHARGING SYSTEM .
P0900	Clutch Actuator Circuit/Open	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0902	Clutch Actuator Circuit Low	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0903	Clutch Actuator Circuit High	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0932	Hydraulic Pressure Sensor Circuit	DEM	REFER to PINPOINT TEST A: NO COMMUNICATION WITH THE DEM .
P0937	Hydraulic Oil Temperature Sensor Circuit	DEM	REFER to PINPOINT TEST A: NO COMMUNICATION WITH THE DEM .
P0939	Hydraulic Oil Temperature Sensor Circuit Low Input	DEM	REFER to PINPOINT TEST A: NO COMMUNICATION WITH THE DEM .
P0940	Hydraulic Oil Temperature Sensor Circuit High Input	DEM	REFER to PINPOINT TEST A: NO COMMUNICATION WITH THE DEM .
P0942	Hydraulic Pressure Unit	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0960	Pressure Control Solenoid A Control Circuit Insert Forward Slash Open	DEM	REFER to DRIVELINE SYSTEM - GENERAL INFORMATION .
P0960	Pressure Control Solenoid A Control Circuit Open	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0961	Pressure Control Solenoid A Control Circuit Range/Performance	DEM	REFER to PINPOINT TEST A: NO COMMUNICATION WITH THE DEM .
P0961	Pressure Control Solenoid A Control Circuit Range/Performance	TCM - CVT Transmission	REFER to PINPOINT TEST A: TRANSMISSION FLUID PRESSURE SENSORS .
P0961	Pressure Control Solenoid A Control Circuit Range/Performance	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0962	Pressure Control Solenoid A Control Circuit Low	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0962	Pressure Control Solenoid A Control Circuit Low	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0963	Pressure Control Solenoid A Control Circuit High	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0963	Pressure Control Solenoid A Control Circuit High	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0964	Pressure Control Solenoid B Control Circuit/Open	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0966	Pressure Control Solenoid B Control Circuit Low	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0967	Pressure Control Solenoid B Control Circuit High	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0968	Pressure Control Solenoid C Control Circuit/Open	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0970	Pressure Control Solenoid C Control Circuit Low	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0971	Pressure Control Solenoid C Control Circuit High	TCM - CVT Transmission	REFER to MECHATRONIC ASSEMBLY .
P0973	Shift Solenoid A Control Circuit Low	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0974	Shift Solenoid A Control Circuit High	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0976	Shift Solenoid B Control Circuit Low	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0977	Shift Solenoid B Control Circuit High	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0978	Shift Solenoid C Control Circuit Range/Performance	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0979	Shift Solenoid C Control Circuit Low	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0980	Shift Solenoid C Control Circuit High	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0981	Shift Solenoid D Control Circuit Range/Performance	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0982	Shift Solenoid D Control Circuit Low	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0983	Shift Solenoid D Control Circuit High	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0984	Shift Solenoid E Control Circuit Range/Performance	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0985	Shift Solenoid E Control Circuit Low	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0986	Shift Solenoid E Control Circuit High	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0997	Shift Solenoid F Control Circuit Range/Performance	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0998	Shift Solenoid F Control Circuit Low	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P0999	Shift Solenoid F Control Circuit High	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P1270	Engine RPM or Vehicle Speed Limiter Reached	TCM - CVT Transmission	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - CVT .
P1572	Brake On/Off Failure	PCM	REFER to PINPOINT TEST B: DTC P1703 OR DTC P1572 - BRAKE ON/OFF CIRCUIT FAILURE .
P1573	Throttle Position Not Available	TCM - AISIN Transmission	REFER to AUTOMATIC TRANSAXLE - 6 SPEED .
P1657	CAN Link Chip Malfunction	TCM - AISIN Transmission	REFER to TRANSMISSION CONTROL MODULE (TCM) .
P1700	Transmission Indeterminate Failure (Failed to Neutral)	TCM - AISIN Transmission	REFER to DIAGNOSIS BY SYMPTOM .
P1701	Reverse Engagement Error	TCM - AISIN Transmission	REFER to DIAGNOSIS BY SYMPTOM .
P1703	Brake On/Off Failure	PCM	REFER to PINPOINT TEST B: DTC P1703 OR DTC P1572 - BRAKE ON/OFF CIRCUIT FAILURE .
P1719	Engine Torque Signal	TCM - AISIN Transmission	REFER to ROAD TESTING VEHICLE , ON-BOARD DIAGNOSTIC WITH SCAN TOOL .
P1919	Engine Coolant Temperature Signal	TCM - AISIN Transmission	REFER to AUTOMATIC TRANSAXLE - 6 SPEED .
P1920	Engine Speed Signal	TCM - AISIN Transmission	REFER to AUTOMATIC TRANSAXLE - 6 SPEED .
P2544	Torque Management Request Input Signal A	TCM - AISIN Transmission	REFER to AUTOMATIC TRANSAXLE - 6 SPEED .
P2637	Torque Management Feedback Signal A	TCM - CVT Transmission	REFER to DIAGNOSTICS .
P2757	Torque Converter Clutch Pressure Control Solenoid Control Circuit Performance	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P2758	Torque Converter Clutch Pressure Control Solenoid Stuck On	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P2762	Torque Converter Clutch Pressure Control Solenoid Control Circuit	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P2763	Torque Converter Clutch Pressure Control Solenoid Control Circuit High	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P2764	Torque Converter Clutch Pressure Control Solenoid Control Circuit Low	TCM - AISIN Transmission	REFER to PINPOINT TEST A: SHIFT SOLENOIDS .
P2765	Input/Turbine Speed Sensor B Circuit	TCM - CVT Transmission	REFER to PINPOINT TEST I: PRIMARY PULLEY SPEED SENSOR .
P2766	Input/Turbine Speed Sensor B Circuit Range/Performance	TCM - CVT Transmission	REFER to PINPOINT TEST I: PRIMARY PULLEY SPEED SENSOR .
U0001	High Speed Communication Bus	DEM	REFER to PINPOINT TEST A: THE DIFFERENTIAL ELECTRONIC MODULE (DEM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
U0001	High Speed CAN Communication Bus	TCM - CVT Transmission	REFER to PINPOINT TEST M: NO HIGH SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION .
U0002	High Speed CAN Communication Bus Performance	Instrument Cluster	REFER to PINPOINT TEST M: NO HIGH SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION .
U0002	High Speed CAN Communication Bus Performance	TCM - CVT Transmission	REFER to PINPOINT TEST M: NO HIGH SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION .
U0020	Low Speed CAN Communication Bus Performance	Instrument Cluster	REFER to PINPOINT TEST N: NO MEDIUM SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION .
U0073	CAN Bus Off - Transmit Error	Audio Control Module	REFER to PINPOINT TEST A: NO COMMUNICATION WITH THE AUDIO UNIT .
U0073	Control Module Communication Bus Off	ABS Module	REFER to PINPOINT TEST A: NO COMMUNICATION WITH THE ANTI-LOCK BRAKE SYSTEM (ABS) MODULE .
U0073	Control Module Communication Bus Off	DSM	Refer to DRIVER SEAT MODULE (DSM) .
U0073	Control Module Communication Bus Off	EATC Module	REFER to ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) MODULE DIAGNOSTIC TROUBLE CODE (DTC) INDEX .
U0073	Control Module Communication Bus Off	RCM	REFER to PINPOINT TEST AL: DTC U0073 - CONTROL MODULE COMMUNICATION BUS OFF .
U0073	Control Module Communication Bus Off	SJB	CARRY OUT the SJB self-test.
U0073	Control Module Communication Bus Off	TCM - AISIN Transmission	CARRY OUT the TCM AISIN Transmission self-test.
U0073	Control Module Communication Bus Off	TCM - CVT Transmission	CARRY OUT the TCM CVT Transmission self-test.
U0100	Lost Communication With ECM/PCM A	TCM - CVT Transmission	REFER to PINPOINT TEST C: THE TRANSMISSION CONTROL MODULE (TCM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL - CONTINUOUSLY VARIABLE TRANSAXLE (CVT) .
U0100	Lost Communication With ECM/PCM A	TCM - AISIN Transmission	REFER to PINPOINT TEST C: THE TRANSMISSION CONTROL MODULE (TCM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL - CONTINUOUSLY VARIABLE TRANSAXLE (CVT) .
U0121	Lost Communication With Anti-Lock Brake System (ABS) Control Module	DEM	REFER to PINPOINT TEST A: NO COMMUNICATION WITH THE ANTI-LOCK BRAKE SYSTEM (ABS) MODULE .
U0121	Lost Communication With Anti-Lock Brake System (ABS) Control Module	TCM - CVT Transmission	REFER to DIAGNOSTIC TROUBLE CODE (DTC) TABLES .
U0121	Lost Communication With Anti-Lock Brake System (ABS) Control Module	TCM - AISIN Transmission	REFER to DIAGNOSTIC TROUBLE CODE (DTC) TABLES .
U0301	Software Incompatibility With Engine/Powertrain Control Module	TCM - CVT Transmission	REFER to INTRODUCTION - GASOLINE article.
U0401	Invalid Data Received From Engine/Powertrain Control Module	TCM - CVT Transmission	REFER to INTRODUCTION - GASOLINE article.
U0414	Invalid Data Received From For-Wheel Drive Clutch Control Module	TCM - CVT Transmission	REFER to COMMUNICATIONS NETWORK .
U0415	Invalid Data Received From Anti-Lock Brake System Control Module	TCM - CVT Transmission	REFER to DIAGNOSTIC TROUBLE CODE (DTC) TABLES .
U0415	Wheel Speed Signal Fault	TCM - AISIN Transmission	REFER to DIAGNOSTIC TROUBLE CODE (DTC) TABLES .
U1900	CAN Communication Bus Fault - Receive Error	ABS Module	REFER to PINPOINT TEST M: NO HIGH SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION or PINPOINT TEST N: NO MEDIUM SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION .
U1900	CAN Communication Bus Fault- Receive Error	Audio Control Module	REPAIR all other DTCs first. CLEAR the DTCs. CYCLE the key OFF then ON and wait 10 seconds. REPEAT the self-test. If DTC U1900 is still present, REFER to PINPOINT TEST M: NO HIGH SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION or PINPOINT TEST N: NO MEDIUM SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION .
U1900	CAN Communication Bus Fault - Receive Error	DSM	REPAIR all other DTCs first. CLEAR the DTCs. CYCLE the key OFF then ON and wait 10 seconds. REPEAT the self-test. If DTC U1900 is still present, REFER to PINPOINT TEST M: NO HIGH SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION or PINPOINT TEST N: NO MEDIUM SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION .
U1900	CAN Communication Bus Fault - Receive Error	RCM	REPAIR all other DTCs first. CLEAR the DTCs. CYCLE the key OFF then ON and wait 10 seconds. REPEAT the self-test. If DTC U1900 is still present, REFER to PINPOINT TEST M: NO HIGH SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION or PINPOINT TEST N: NO MEDIUM SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION .
U1900	CAN Communication Bus Fault - Receive Error	SJB	REPAIR all other DTCs first. CLEAR the DTCs. CYCLE the key OFF then ON and wait 10 seconds. REPEAT the self-test. If DTC U1900 is still present, REFER to PINPOINT TEST M: NO HIGH SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION or PINPOINT TEST N: NO MEDIUM SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION .
U1900	CAN Communication Bus Fault - Receive Error	Instrument Cluster	REPAIR all other DTCs first. CLEAR the DTCs. CYCLE the key OFF then ON and wait 10 seconds. REPEAT the self-test. If DTC U1900 is still present, REFER to PINPOINT TEST M: NO HIGH SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION or PINPOINT TEST N: NO MEDIUM SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION .
U1901	CAN Network #2 Communication Bus Fault - Receive Error	Instrument Cluster	REPAIR all other DTCs first. CLEAR the DTCs. CYCLE the key OFF then ON and wait 10 seconds. REPEAT the self-test. If DTC U1900 is still present, REFER to PINPOINT TEST M: NO HIGH SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION or PINPOINT TEST N: NO MEDIUM SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION .
U2013	Compass Module Not Responding	Instrument Cluster	REFER to PINPOINT TEST B: THE COMPASS IS INOPERATIVE .
U2023	Fault Received From External Node	ABS Module	REFER to PINPOINT TEST B: THE ANTI-LOCK BRAKE SYSTEM (ABS) MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
U2023	Fault Received From External Node	Instrument Cluster	REFER to PINPOINT TEST E: THE INSTRUMENT CLUSTER DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
U2026	Family Entertaining System is Not Responding	Audio Control Module	REFER to PINPOINT TEST H: THE AUDIO/AUDIO NAVIGATION UNIT DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
U2029	DVD Unit is Not Responding	Audio Control Module	REFER to PINPOINT TEST K: THE DIGITAL VERSATILE DISC (DVD) PLAYER DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
U2050	No Application Present	ABS Module	REFER to PINPOINT TEST A: NO COMMUNICATION WITH THE ANTI-LOCK BRAKE SYSTEM (ABS) MODULE .
U2050	No Application Code Present	DSM	CONFIGURE the DSM. refer to MODULE CONFIGURATION . CLEAR the DTCs. RETRIEVE the DTCs, and verify successful module configuration. If DTC U2050 is retrieved again, INSTALL a new DSM module. REFER to DRIVER SEAT MODULE (DSM) . REPEAT the self-test.
U2050	No Application Present	EATC Module	REFER to PINPOINT TEST F: NO COMMUNICATION WITH THE ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) MODULE .
U2050	No Application Present	RCM	REFER to PINPOINT TEST AO: NO COMMUNICATION WITH THE RESTRAINTS CONTROL MODULE (RCM) .
U2050	No Application Present	SJB	CONFIGURE the SJB. REFER to MODULE CONFIGURATION . CLEAR the DTCs. RETRIEVE the DTCs, and verify successful module configuration. If DTC U2050 is retrieved again, INSTALL a new SJB module. REFER to SMART JUNCTION BOX (SJB) . REPEAT the self-test.
U2050	No Application Present	Instrument Cluster	REFER to PINPOINT TEST A: NO COMMUNICATION WITH THE INSTRUMENT CLUSTER .
U2050	No Application Present	TCM - CVT Transmission	REFER to PINPOINT TEST H: TRANSMISSION CONTROL MODULE SIGNAL .
U2050	No Application Present	TCM - AISIN Transmission	REFER to TRANSMISSION CONTROL MODULE (TCM) INITIAL LEARNING .
U2051	One or More Calibration Files Missing/Corrupt	Parking Aid Module	REFER to MODULE CONFIGURATION .
U2064	Warning Indicator Requested By Another Control Module	DEM	REFER to PINPOINT TEST A: THE DIFFERENTIAL ELECTRONIC MODULE (DEM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .

DIAGNOSTIC TROUBLE CODE (DTC) CHART

Inspection and Verification

Verify the customer concern.
Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION TABLE Electrical Battery junction box (BJB) fuse(s): 1 (80A) 18 (40A) 28 (80A) Circuitry SJB
If an obvious cause of an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
If the cause is not visually evident, connect the diagnostic tool to the data link connector (DLC) and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool operating manual.
Carry out the diagnostic tool data link test. If the diagnostic tool responds with: ISO or CAN circuits fault; all electronic control units no response/not equipped, refer to «PINPOINT TEST L: NO INTERNATIONAL STANDARDS ORGANIZATION (ISO) 9141 COMMUNICATIONS NETWORK COMMUNICATION»(ref-255276-S15108795192007053000000) . No response/not equipped for the SJB, GO to «PINPOINT TEST A»(ref-255282-S21463350462007053000000) . System passed, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs, and carry out self-test diagnostics for the SJB.
If the DTCs retrieved are related to the concern, go to the «DIAGNOSTIC TROUBLE CODE CHART»(ref-255282-S36837434302007053000000) .
If no DTCs related to the concern are retrieved, refer to the appropriate procedure to continue diagnosis.

Symptom Chart

Condition	Possible Sources	Action
No communication with the smart junction box (SJB)	Fuse(s) Circuitry SJB	GO to PINPOINT TEST A .

SYMPTOM CHART

PINPOINT TEST A: NO COMMUNICATION WITH THE SMART JUNCTION BOX (SJB)

CAUTION

Use the correct probe adaptor(s) when making measurements. Failure to use the correct probe adaptor(s) may damage the connector.

Scheme 34

Scheme 35

A1 CHECK THE SJB VOLTAGE SUPPLY CIRCUITS FOR AN OPEN Key in OFF position. Disconnect: SJB C2280a. Disconnect: SJB C2280g. Using «SJB VOLTAGE SUPPLY CIRCUITS SPECIFICATION TABLE»(ref-255282-S25612342192007053000000) , measure the voltage between the SJB, harness side and ground: SJB VOLTAGE SUPPLY CIRCUITS SPECIFICATION TABLE SJB Connector-pin Circuit C2280a-29 1231 (RD/WH) C2280g-1 906 (RD/OG) C2280g-2 905 (GY/LB) Are the voltages greater than 10 volts? Yes: GO to A2 . No: VERIFY the battery junction box (BJB) fuses 1 (80A), 18 (40A) and 28 (80A) are OK. If OK, REPAIR the circuit in question. CLEAR the DTCs. REPEAT the self-test.
A2 CHECK THE SJB GROUND CIRCUIT FOR AN OPEN Connect: SJB C2280g. Disconnect: SJB C2280e. Measure the resistance between the SJB C2280a-30, circuit 1203 (BK/LB), harness side and ground; and between the SJB C2280e-3, circuit 1205 (BK), harness side and ground. Are the resistances less than 5 ohms? Yes: REFER to «COMMUNICATIONS NETWORK»(ref-255276-S38150639192007053000000) to continue communication diagnosis. No: REPAIR the circuit in question. CLEAR the DTCs. REPEAT the self-test.

Verify the customer concern.
Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION TABLE Electrical Battery junction box (BJB) fuse 32 (30A) Smart junction box (SJB) fuse 10 (7.5A) Circuitry DSM
If an obvious cause of an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
If the cause is not visually evident, connect the diagnostic tool to the data link connector (DLC) and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool operating manual.
Carry out the diagnostic tool data link test. If the diagnostic tool responds with: ISO or CAN circuits fault; all electronic control units no response/not equipped, refer to «PINPOINT TEST L: NO INTERNATIONAL STANDARDS ORGANIZATION (ISO) 9141 COMMUNICATIONS NETWORK COMMUNICATION»(ref-255276-S15108795192007053000000) . No response/not equipped for DSM, GO to «PINPOINT TEST B»(ref-255282-S38499446452007053000000) . System passed, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs, and carry out self-test diagnostics for the DSM.
If the DTCs retrieved are related to the concern, go to the «DIAGNOSTIC TROUBLE CODE CHART»(ref-255282-S36837434302007053000000) .
If no DTCs related to the concern are retrieved, refer to the appropriate procedure to continue diagnosis.

Condition	Possible Sources	Action
No communication with the driver seat module (DSM)	Fuse(s) Circuitry DSM	GO to PINPOINT TEST B .

SYMPTOM CHART

PINPOINT TEST B: NO COMMUNICATION WITH THE DRIVER SEAT MODULE (DSM)

CAUTION

Use the correct probe adaptor(s) when making measurements. Failure to use the correct probe adaptor(s) may damage the connector.

Scheme 36

Scheme 37

B1 CHECK THE DSM VOLTAGE SUPPLY CIRCUITS FOR AN OPEN Key in OFF position. Disconnect: DSM C341a. Disconnect: DSM C341c. Measure the voltage between the DSM C341a-2, circuit 566 (DG), harness side and ground; and between the DSM C341c-1, circuit 956 (OG/LG), harness side and ground. Are the voltages greater than 10 volts? Yes: GO to B2 . No: VERIFY the battery junction box (BJB) fuse 32 (30A) and smart junction box (SJB) fuse 10 (7.5) are OK. If OK, REPAIR the circuit in question. CLEAR the DTCs. REPEAT the self-test.
B2 CHECK THE DSM GROUND CIRCUIT FOR AN OPEN Measure the resistance between the DSM C341a-1, circuit 1205 (BK), harness side and ground; and between the DSM C341c-13, circuit 1203 (BK/LB), harness side and ground. Are the resistances less than 5 ohms? Yes: REFER to «COMMUNICATIONS NETWORK»(ref-255276-S38150639192007053000000) to continue communication diagnosis. No: REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test.

Scheme 38

Scheme 38: Smart Junction Box (SJB)

Multifunction Electronic Modules System: Diagnosis Ford Freestyle I
