Network Message Chart
| Broadcast Message | Originating Module | Message Purpose |
|---|---|---|
| RKE data | RFA module | Provides information regarding the RKE system for the BCM to activate or deactivate the illuminated entry/exit features. |
| Drivers door latch status | DDM | Provides door lock status to the BCM to activate or deactivate the illuminated entry/exit features |
| Passengers door latch status | PDM | Provides door lock status to the BCM to activate or deactivate the illuminated entry/exit features |
BCM NETWORK INPUT MESSAGES
| Broadcast Message | Originating Module | Message Purpose |
|---|---|---|
| Puddle lamp activation | BCM | Provides puddle lamp request from the BCM to activate the exterior mirror puddle lamps. |
DDM AND PDM NETWORK INPUT MESSAGES
Battery Saver
Note. Time-out is 30 seconds if the vehicle is in Factory or Transport mode.
The BCM provides automatic shut-off of the courtesy and demand lamps after a time-out period when the ignition is OFF. A timer in the BCM starts when
- the ignition transitions to OFF.
- any door or liftgate/luggage compartment lid becomes ajar.
- an UNLOCK button of the RKE transmitter is pressed.
- a door is unlocked using a key.
- the door lock switch is pressed.
When 10 minutes (30 minutes for demand lamps) have elapsed, the BCM automatically shuts off voltage to the lamps. The timer restarts (voltage is restored if the BCM is in battery saver mode) if
- the ignition transitions out of OFF.
- any door or liftgate/luggage compartment lid becomes ajar.
- the UNLOCK button of the RKE transmitter is pressed.
- a door is unlocked using a key.
- the door lock switch is pressed.
Courtesy Lamps
The BCM controls the courtesy lighting functions and timing by monitoring inputs from the following
- Door ajar switches
- Ignition state
- RKE system
For vehicles equipped with puddle lamps, the DDM and the PDM provide voltage to the left and right puddle lamps based on messaged input from the BCM over the communication network.
The BCM sends a voltage signal to each door or liftgate ajar switch. When the doors or liftgate are closed, the circuit is switched to ground and the voltage is pulled low, indicating closed doors.
For vehicles equipped with door modules, the DDM and the PDM provides ground for the door ajar switch.
The BCM monitors the ignition state and inputs from the RKE system to determine when to energize the interior light relay. When the interior light relay is energized, voltage is provided to the interior lamps. The BCM controls the ground side of the courtesy lamps for the illuminated entry and exit features.
For keyless entry, the BCM monitors input from the RKE transmitter (directly from the integrated keyhead transmitters (IKTs on vehicles without intelligent access (IA)) or from the RFA module (on vehicles with intelligent access (IA)) to determine when to activate/deactivate the illuminated entry and exit functions.
The interior courtesy lamps can also be activated from the courtesy lamp switch mounted on the front/ driver interior lamp. The front interior lamp (vehicles without a roof opening panel) or the driver interior lamp (vehicles with a roof opening panel) controls the courtesy lamp function of the remaining interior lamp(s). When the courtesy lamp button is pressed on the front/driver interior lamp, the courtesy lamp function for all the lamps is turned on/off. If any door is open, the BCM command overrides the function of the front/driver courtesy lamp switch and activates the courtesy lamps.
Illuminated Entry and Exit
The illuminated entry and exit features provide temporary illumination of the parking lamps, the dimmable backlighting, the ambient backlighting and the courtesy lamps. Refer to the chart for additional information.
Note. An arbitrator (software programming) within the BCM determines which actions take precedence over others (for example, an open door keeps the courtesy lamps on even when a command to lock the doors is received).
| Action | Parking Lamps | Courtesy Lamps | Dimmable Backlighting | Ambient Lighting |
|---|---|---|---|---|
| RKE transmitter or mechanical unlocking of the doors | On for 25 seconds | On for 25 seconds | On for 25 seconds | Off (activated when door becomes open) |
| RKE transmitter or mechanical locking of the doors | Off | Off | Off | Off after 3 seconds |
| Open a closed door after previously unlocking (no ignition state change since unlock) | Off (on for remaining time if unlocked from transmitter or mechanical unlocking of the doors) | On | On | On |
| Close all doors | Off | On for 25 seconds | On for 25 seconds | On for 25 seconds |
| Ignition changed to ON | Off | On for 25 seconds | Off | On/Off according to customer setting |
| Ignition changed out of ON | Off | On for 25 seconds | On for 25 seconds | On for 25 seconds |
| Open a door after the ignition is changed to OFF | Off | On | Off | On for 25 seconds (multi color turns RED) |
| Ignition is OFF and doors are unlocked from the door lock switch | Off | On for 25 seconds | Off | Off |
| Ignition is OFF and doors are locked from the door lock switch | Off | Off | Off | Off |
Theater Lighting
The theater lighting option ramps-up the courtesy lamps over 0.7 seconds when courtesy lamp is requested. The theater lighting feature ramps-down the courtesy lamps over 1.7 seconds when interior lighting deactivation is requested by any feature other than the panic alarm or battery saver.
Demand Lamps
When the BCM is in not in battery saver mode, the interior light relay is energized to provide voltage to the demand lamps.
Ambient Lighting
The ambient lighting subsystem consists of the ambient lighting switch, dimmer control and the ambient lighting module (all integrated into the overhead console), and the Light Emitting Diodes (LEDs) located within the floor console cup holders, front door panels and under the instrument panel footwell areas. The ambient lighting is operational when the ignition is in any state other than OFF (the exception is when it is used in conjunction with the illuminated entry/exit features), the headlamps are on and the outside ambient light level is low. The ambient lighting switch cycles the Light Emitting Diodes (LEDs) through 7 different color combinations. The brightness is changed using the dimmer control which allows the Light Emitting Diodes (LEDs) to be turned off as well.
The right search mode control switch activates all ambient light areas and all dome lamps. The search mode control switch needs to be pressed again to deactivate the dome lamps and return to the previously selected ambient light color.
The ambient lighting control module controls the color and light intensity. The ambient lighting module receives information from the BCM through a LIN circuit for illuminated entry/exit functions. The ambient lighting module provides voltage to all of the Light Emitting Diodes (LEDs). A secondary LIN circuit is routed from the ambient lighting module to all of the Light Emitting Diodes (LEDs). Each LED changes color and intensity based on the input from the ambient lighting module.
As an additional function, the ambient lighting illuminates red on any open door.
Door Ajar Switch
The door ajar switches (ground switches) each receive a voltage signal from the BCM on independent circuits. When the door is closed, the door ajar switch is closed, routing the signal to ground. When the door is opened, the door ajar switch opens.
Ground is provided to the door ajar switches from the door modules.
Interior Lamp
All of the interior lamps receive voltage from the interior lamp relay (integrated into the BCM) when the battery saver feature is not active. This is used by each interior lamp to power the LED within it.
The front interior lamp uses a private communication protocol to command the rear lamps on or off.
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
The Courtesy Lamps Do Not Illuminate With a Door Open
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to REMOTE KEYLESS ENTRY AND ALARM for schematic and connector information.
Possible Sources
- Wiring, terminals or connectors
- Door latch
- BCM
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1175:64 | Drivers Door Ajar Switch: Signal Plausibility Failure | Sets when the BCM detects a short to ground from the driver door ajar input circuit. |
DTC FAULT TRIGGER CONDITIONS
One Or More Interior Courtesy Lamps Are Inoperative
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Fuse
- Wiring, terminals or connectors
- Interior lamp
- BCM
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1D13:11 | Interior Lights Circuit "A": Circuit Short To Ground | Sets when the BCM detects an open from the courtesy lighting ground control circuit. |
| B1D13:12 | Interior Lights Circuit "A": Circuit Short To Battery | Sets when the BCM detects a short to battery voltage from the courtesy lighting ground control circuit. |
DTC FAULT TRIGGER CONDITIONS
All The Courtesy Lamps Stay On Continuously
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Wiring, terminals or connectors
- Ajar switch
- BCM
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1175:64 | Drivers Door Ajar Switch: Signal Plausibility Failure | May set when the BCM detects an open from the left front door ajar circuit. |
| B11E9:13 | Left Rear Door Ajar Switch: Circuit Open | Sets when the BCM detects an open from the left rear door ajar circuit. |
| B11EA:13 | Right Rear Door Ajar Switch: Circuit Open | Sets when the BCM detects an open from the right rear door ajar circuit. |
| B1318:13 | Right Front Door Ajar Switch: Circuit Open | Sets when the BCM detects an open from the right front door ajar circuit. |
| B131B:13 | Left Front Door Ajar Switch: Circuit Open | Sets when the BCM detects an open from the left front door ajar circuit. |
DTC FAULT TRIGGER CONDITIONS
Scheme 7
- C1: CHECK THE DOOR AJAR SWITCH PARAMETER IDENTIFICATIONS (PIDS) Ignition ON. Using a scan tool, view BCM Parameter Identifications (PIDs). Monitor the BCM DOOR_SW_DRVR, DOOR_SW_PSGR, DOOR_SW_LR and DOOR_SW_RR Parameter Identifications (PIDs) while opening and closing all the doors. Do all the door ajar switch Parameter Identification (PID) values agree with the door positions? Yes: GO to «Pinpoint Test D»(ref-516017-S42454684492012120400000) No: GO to C2
- C2 BYPASS THE SUSPECT DOOR LATCH Disconnect: Suspect Door Switch. Connect: LH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C525-3 C525-5 RH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C609-6 C609-4 LH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C705-3 C705-5 RH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C805-6 C805-4 Using a scan tool, view BCM Parameter Identifications (PIDs). Monitor the BCM DOOR_SW_DRVR, DOOR_SW_PSGR, DOOR_SW_LR and DOOR_SW_RR Parameter Identifications (PIDs). Does the Parameter Identification (PID) indicate the door in question is closed? Yes: REMOVE the jumper wire. For a front door, INSTALL a new front door latch. REFER to: «FRONT DOOR LATCH»(ref-516028-S31343318572012120400000) (Vehicles Without: One-Touch Up Door Window) ). or REFER to: «FRONT DOOR LATCH»(ref-516020-S19160901842012120400000) (Vehicles With: One-Touch Up Door Window) . REMOVE the jumper wire. For a rear door, INSTALL a new rear door latch. REFER to: «REAR DOOR LATCH»(ref-516028-S33863187322012120400000) (Vehicles Without: One-Touch Up Door Window) . or REFER to: «REAR DOOR LATCH»(ref-516020-S38365809472012120400000) (Vehicles With: One-Touch Up Door Window) . No: REMOVE the jumper wire. GO to C3
- C3 BYPASS THE DOOR LATCH GROUND CIRCUIT Connect: LH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C525-3 - RH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C609-6 - LH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C705-3 - RH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C805-6 - Monitor the BCM DOOR_SW_DRVR, DOOR_SW_PSGR, DOOR_SW_LR and DOOR_SW_RR Parameter Identifications (PIDs). Does the PID indicate the door in question is closed? Yes: REMOVE the jumper wire. For vehicles not equipped with a door module, REPAIR door latch ground circuit in question for an open. For vehicles equipped with a door module, GO to C5 No: REMOVE the jumper wire. GO to C4
- C4 CHECK THE SUSPECT DOOR AJAR SWITCH INPUT CIRCUIT FOR AN OPEN Disconnect: BCM C2280B. Measure: LH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C525-3 ohms C2280B-45 RH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C609-6 ohms C2280B-46 LH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C705-3 ohms C2280B-44 RH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C805-6 ohms C2280B-25 Is the resistance less than 3 ohms? Yes: GO to C7 No: REPAIR the door ajar input circuit in question.
- C5 CHECK THE DOOR LATCH RETURN CIRCUIT TO THE DOOR MODULE FOR AN OPEN Connect: Suspect Door Latch. Disconnect: Suspect Door Module. Connect: LH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C501A-14 - RH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C652A-14 - LH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C728-14 - RH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C832-14 - Close the door. Monitor the BCM DOOR_SW_DRVR, DOOR_SW_PSGR, DOOR_SW_LR and DOOR_SW_RR Parameter Identifications (PIDs). Does the Parameter Identification (PID) indicate the door is closed? Yes: REMOVE the jumper wire. GO to C6 No: REMOVE the jumper wire. REPAIR the door latch return circuit in question.
- C6 CHECK THE DOOR MODULE GROUND CIRCUIT FOR AN OPEN Connect: LH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C501A-14 C501A-13 RH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C652A-14 C652A-13 LH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C728-14 C728-13 RH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C832-14 C831-13 Monitor the BCM DOOR_SW_DRVR, DOOR_SW_PSGR, DOOR_SW_LR and DOOR_SW_RR Parameter Identifications (PIDs). Does the Parameter Identification (PID) indicate the door is closed? Yes: REMOVE the jumper wire. INSTALL a new door module in question. REFER to: «DOOR MODULE»(ref-515973-S26456212192012120400000) . No: REMOVE the jumper wire. REPAIR the circuit.
- C7 CHECK FOR CORRECT BODY CONTROL MODULE (BCM) OPERATION Disconnect and inspect all BCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the BCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new BCM. REFER to: «BODY CONTROL MODULE (BCM)»(ref-515973-S25219396702012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues. CLEAR the Diagnostic Trouble Codes (DTCs).
The Interior Courtesy Lamps Stay On Continuously
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Wiring, terminals or connectors
- BCM
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1D13:11 | Interior Lights Circuit "A": Circuit Short To Ground | Sets when the BCM detects a short to ground from the courtesy lighting ground control circuit. |
DTC FAULT TRIGGER CONDITIONS
The Luggage Compartment Lamp Is Inoperative Or On Continuously
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Wiring, terminals or connectors
Scheme 8
Scheme 9
- E1: DETERMINE IF THE LAMP IS ON WITH THE LIFTGATE/LUGGAGE COMPARTMENT LID CLOSED Ignition ON. Make sure the liftgate is fully latched and observe the luggage compartment lamp(s). Is the luggage compartment lamp illuminated? Yes: GO to E2 No: GO to E3
- E2 CHECK THE LUGGAGE COMPARTMENT LAMP GROUND CIRCUIT FOR A SHORT TO GROUND Disconnect: Liftgate/Luggage Compartment Lid Latch C4223. Does the luggage compartment lamp continue to illuminate? Yes: REPAIR the circuit. No: For a 4-door vehicle, INSTALL a new luggage compartment lid latch. REFER to: «LUGGAGE COMPARTMENT LID LATCH»(ref-516028-S26753971612012120400000) (Vehicles Without: One-Touch Up Door Window) . or REFER to: «LUGGAGE COMPARTMENT LID LATCH»(ref-516020-S41744578292012120400000) (Vehicles With: One-Touch Up Door Window) . For a 5-door vehicle, INSTALL a new liftgate latch. REFER to: «LIFTGATE LATCH»(ref-516028-S09378943992012120400000) (Vehicles Without: One-Touch Up Door Window) . or REFER to: «LIFTGATE LATCH»(ref-516020-S37610904482012120400000) (Vehicles With: One-Touch Up Door Window) .
- E3 CHECK THE OPERATION OF THE COURTESY LAMPS Ignition OFF. Open any door. Do the interior courtesy lamps illuminate? Yes: GO to E4 No: GO to «Pinpoint Test B»(ref-516017-S11661127912012120400000)
- E4 CHECK FOR VOLTAGE TO THE LUGGAGE COMPARTMENT LAMP Disconnect: Inoperative Luggage Compartment Lamp. Ignition ON. Measure: LUGGAGE COMPARTMENT LAMP (4-DOOR) Positive Lead Measurement / Action Negative Lead C428-1 - LH LUGGAGE COMPARTMENT LAMP (5-DOOR) Positive Lead Measurement / Action Negative Lead C4198-1 - RH LUGGAGE COMPARTMENT LAMP (5-DOOR) Positive Lead Measurement / Action Negative Lead C4403-1 - Is the voltage greater than 11 volts? Yes: GO to E5 No: REPAIR the luggage compartment lamp voltage supply circuit for an open.
- E5 ISOLATE THE LUGGAGE COMPARTMENT LAMP BULB Measure: LUGGAGE COMPARTMENT LAMP (4-DOOR) Positive Lead Measurement / Action Negative Lead C428-1 C428-2 LH LUGGAGE COMPARTMENT LAMP (5-DOOR) Positive Lead Measurement / Action Negative Lead C4198-1 C4198-2 RH LUGGAGE COMPARTMENT LAMP (5-DOOR) Positive Lead Measurement / Action Negative Lead C4403-1 C4403-2 Is the voltage greater than 11 volts? Yes: INSTALL a new luggage compartment lamp bulb. No: GO to E6
- E6 CHECK THE LUGGAGE COMPARTMENT LAMP GROUND CIRCUIT FOR AN OPEN Ignition OFF. Connect: Inoperative Luggage Compartment Lamp. Disconnect: Liftgate/Luggage Compartment Lid Latch C4223. Ignition ON. Connect: Positive Lead Measurement / Action Negative Lead C4223-4 - Does the luggage compartment lamp illuminate? Yes: REMOVE the jumper wire. GO to E7 No: REMOVE the jumper wire. REPAIR the circuit.
- E7 CHECK THE LIFTGATE LATCH GROUND CIRCUIT FOR AN OPEN Connect: Positive Lead Measurement / Action Negative Lead C4223-4 C4223-2 Does the luggage compartment lamp illuminate? Yes: REMOVE the jumper wire. For a 4-door vehicle, INSTALL a new luggage compartment lid latch. REFER to: «LUGGAGE COMPARTMENT LID LATCH»(ref-516028-S26753971612012120400000) (Vehicles Without: One-Touch Up Door Window) . or REFER to: «LUGGAGE COMPARTMENT LID LATCH»(ref-516020-S41744578292012120400000) (Vehicles With: One-Touch Up Door Window) . REMOVE the jumper wire. For a 5-door vehicle, INSTALL a new liftgate latch. REFER to: «LIFTGATE LATCH»(ref-516028-S09378943992012120400000) (Vehicles Without: One-Touch Up Door Window) . or REFER to: «LIFTGATE LATCH»(ref-516020-S37610904482012120400000) (Vehicles With: One-Touch Up Door Window) . No: REMOVE the jumper wire. REPAIR the circuit.
One Or More Demand Lamps Are Inoperative
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Wiring, terminals or connectors
- Demand lamp
The Battery Saver Does Not Deactivate After Timeout
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Wiring, terminals or connectors
- BCM
The Ambient Lighting Is Inoperative
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Wiring, terminals or connectors
- Ambient lighting LED
- BCM
- Ambient lighting module
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1088:86 | LIN Bus "B": Signal Invalid | Sets when the BCM loses communication with the ambient lighting module over the LIN circuit. |
| B1088:88 | LIN Bus "B": Bus Off | Sets when the BCM loses communication with the ambient lighting module over the LIN circuit. |
| B1390:87 | Ambient Light Control Module: Missing Message | Sets when the BCM loses communication with the ambient lighting module over the LIN circuit. |
DTC FAULT TRIGGER CONDITIONS
A Puddle Lamp Is Inoperative Or Always On
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Wiring, terminals or connectors
- Puddle lamp
- Exterior mirror
- DDM
- PDM
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B12C2:11 | Puddle Lamp: Circuit Short To Ground | Sets when the DDM or the PDM detects a short to ground from the puddle lamp output circuit. |
| B12C2:15 | Puddle Lamp: Circuit Short To Battery Or Open | Sets when the DDM or the PDM detects an open or a short to battery voltage from the puddle lamp output circuit. |
DTC FAULT TRIGGER CONDITIONS
An Individual Ambient Light Is Inoperative or Does Not Change Color
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Wiring, terminals or connectors
- Ambient lighting LED
- Ambient lighting module
Scheme 10
- J1: CHECK FOR VOLTAGE TO THE LIGHT EMITTING DIODE (LED) Ignition OFF. Disconnect: Inoperative Ambient Lighting LED. Ignition ON. Turn the parking lamps on. Measure: OVERHEAD CONSOLE Positive Lead Measurement / Action Negative Lead C9046-1 - CUPHOLDER Positive Lead Measurement / Action Negative Lead C3349-1 - LH FRONT FOOTWELL Positive Lead Measurement / Action Negative Lead C2056-1 - RH FRONT FOOTWELL Positive Lead Measurement / Action Negative Lead C2057-1 - LH FRONT DOOR MAP POCKET Positive Lead Measurement / Action Negative Lead C572-1 - LH FRONT DOOR HANDLE Positive Lead Measurement / Action Negative Lead C556-1 - RH FRONT DOOR MAP POCKET Positive Lead Measurement / Action Negative Lead C672-1 - RH FRONT DOOR HANDLE Positive Lead Measurement / Action Negative Lead C620-1 - Is the voltage greater than 11 volts? Yes: GO to J2 No: REPAIR the LED voltage supply circuit in question.
- J2 CHECK THE LIGHT EMITTING DIODE (LED) GROUND CIRCUIT FOR AN OPEN Measure: OVERHEAD CONSOLE Positive Lead Measurement / Action Negative Lead C9046-1 C9046-3 CUPHOLDER Positive Lead Measurement / Action Negative Lead C3349-1 C3349-3 LH FRONT FOOTWELL Positive Lead Measurement / Action Negative Lead C2056-1 C2056-3 RH FRONT FOOTWELL Positive Lead Measurement / Action Negative Lead C2057-1 C2057-3 LH FRONT DOOR MAP POCKET Positive Lead Measurement / Action Negative Lead C572-1 C572-3 LH FRONT DOOR HANDLE Positive Lead Measurement / Action Negative Lead C556-1 C556-3 RH FRONT DOOR MAP POCKET Positive Lead Measurement / Action Negative Lead C672-1 C672-3 RH FRONT DOOR HANDLE Positive Lead Measurement / Action Negative Lead C620-1 C620-3 Is the voltage greater than 11 volts? Yes: GO to J3 No: REPAIR the ground circuit in question.
- J3 CHECK THE AMBIENT LIGHTING LOCAL INTERCONNECT NETWORK (LIN) CIRCUIT FOR AN OPEN Ignition OFF. Turn the parking lamps off. Disconnect: Overhead Console C912. Measure: OVERHEAD CONSOLE Positive Lead Measurement / Action Negative Lead C9046-2 ohms C912-15 CUPHOLDER Positive Lead Measurement / Action Negative Lead C3349-2 ohms C912-15 LH FRONT FOOTWELL Positive Lead Measurement / Action Negative Lead C2056-2 ohms C912-15 RH FRONT FOOTWELL Positive Lead Measurement / Action Negative Lead C2057-2 ohms C912-15 LH FRONT DOOR MAP POCKET Positive Lead Measurement / Action Negative Lead C572-2 ohms C912-15 LH FRONT DOOR HANDLE Positive Lead Measurement / Action Negative Lead C556-2 ohms C912-15 RH FRONT DOOR MAP POCKET Positive Lead Measurement / Action Negative Lead C672-2 ohms C912-15 RH FRONT DOOR HANDLE Positive Lead Measurement / Action Negative Lead C620-2 ohms C912-15 Is the resistance less than 3 ohms? Yes: INSTALL a new ambient lighting LED in question. No: REPAIR the circuit.
