Module Communications Network - Except Electric: Diagnosis Ford Focus III

Communication Devices 6 illustrations ~15671 words

Symptom Chart: Communication Network

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

ConditionPossible SourcesActions
The vehicle does not start with the scan tool connected to the DLC and/or multiple malfunction indicators are only on when the scan tool is connected to the DLCRefer to the Diagnostic RoutineGO to Pinpoint Test Z
The PCM does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test A
The ABS module does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test B
The RCM does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test C
The FCDIM does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test D
The OCSM does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test E
The SASM does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test F
The IPC does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test G
The Information Center Module (ICM) does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test H
The BCM does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test I
The HVAC module does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test J
The ACM does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test K
The DSP does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test L
The DDM does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test M
The PDM does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test N
The Image Processing Module - B (IPM-B) does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test O
The GPSM does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test P
The Parking Aid Module (PAM) does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test Q
The APIM does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test R
The FCIM does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test S
The RFA module does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test T
The TCM does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test U
The PSCM does not respond to the scan toolRefer to the Diagnostic RoutineGO to Pinpoint Test V
No High Speed Controller Area Network (HS-CAN) communication, all modules are not respondingRefer to the Diagnostic RoutineGO to Pinpoint Test W
No Medium Speed Controller Area Network (MS-CAN) communication, all modules are not respondingRefer to the Diagnostic RoutineGO to Pinpoint Test X
No Infotainment Controller Area Network (I-CAN) communication, all modules are not respondingRefer to the Diagnostic RoutineIf the IPC does not pass a network test, DIAGNOSE the IPC first. GO to Pinpoint Test G If the IPC does pass a network test, GO to Pinpoint Test Y
No power to the DLCRefer to the Diagnostic RoutineGO to Pinpoint Test Z

SYMPTOM CHART

PINPOINT TEST A: THE POWERTRAIN CONTROL MODULE (PCM) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

  1. A1 VERIFY WHETHER OTHER HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) MODULES PASS THE NETWORK TEST Using a scan tool, perform the network test. Is the text "pass" or a DTC listed next to any of the following modules (if equipped): APIM, ABS module, BCM, OCSM, Parking Aid Module (PAM), PSCM, RCM, SASM or TCM? Yes: If "pass" or a DTC was listed next to the Powertrain Control Module (PCM), a network fault is not currently present. To diagnose an intermittent High Speed Controller Area Network (HS-CAN) fault condition, GO to «Pinpoint Test W»(ref-515972-S37082673432012120400000) If "pass" or a DTC was listed next to one or more modules other than the PCM, GO to A2 No: No modules are currently communicating on the High Speed Controller Area Network (HS-CAN). GO to «Pinpoint Test W»(ref-515972-S37082673432012120400000)
  2. A2 PINPOINT TEST QA VERIFICATION CHECK Verify that PINPOINT TESTS QA: UNABLE TO ACTIVATE SELF-TEST/NETWORK COMMUNICATION ERROR has been performed. Has the VREF test been performed? Yes: GO to A3 No: Go to A2.
  3. A3 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) TERMINATION RESISTANCE Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-6 ohms C251-14 Is the resistance between 54 and 66 ohms? Yes: GO to A5 No: GO to A4
  4. A4 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) CIRCUITS BETWEEN THE PCM (POWERTRAIN CONTROL MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Disconnect: PCM C175B. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C175B-54 ohms C251-6 C175B-41 ohms C251-14 Are the resistances less than 3 ohms? Yes: GO to A5 No: REPAIR the circuit in question.
  5. A5 CHECK FOR CORRECT PCM (POWERTRAIN CONTROL MODULE) OPERATION Ignition OFF. Disconnect and inspect all the PCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the PCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new PCM. REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(ref-515938-S13817209062012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Visual Inspection and Diagnostic Pre-checks

Verify BJB fuses 7 (40A), 8 (30A) and 19 (5A) are OK.

PINPOINT TEST B: THE ABS (ANTI-LOCK BRAKE SYSTEM) MODULE DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

  1. B1 CHECK THE ABS (ANTI-LOCK BRAKE SYSTEM) MODULE VOLTAGE SUPPLY CIRCUITS FOR AN OPEN Ignition OFF. Disconnect: ABS Module. Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C135-8 - C135-1 - C135-32 - Are the voltages greater than 11 volts? Yes: GO to B2 No: VERIFY the BJB fuses 7 (40A), 8 (30A) and 19 (5A) are OK. If OK, REPAIR the circuit in question. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. B2 CHECK THE ABS (ANTI-LOCK BRAKE SYSTEM) MODULE GROUND CIRCUIT FOR AN OPEN Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C135-47 ohms - Is the resistance less than 3 ohms? Yes: GO to B3 No: REPAIR the circuit.
  3. B3 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) CIRCUITS BETWEEN THE ABS (ANTI-LOCK BRAKE SYSTEM) MODULE AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C135-12 ohms C251-6 C135-13 ohms C251-14 Are the resistances less than 3 ohms? Yes: GO to B4 No: REPAIR the circuit in question.
  4. B4 CHECK FOR CORRECT ABS (ANTI-LOCK BRAKE SYSTEM) MODULE OPERATION Ignition OFF. Disconnect and inspect the ABS module connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the ABS module connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new ABS module. No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify BCM fuse 86 (10A) is OK.

PINPOINT TEST C: THE RESTRAINTS CONTROL MODULE (RCM) DOES NOT RESPOND TO THE SCAN TOOL

WARNINGNever probe the electrical connectors on air bag, Safety Canopy® or side air curtain modules. Failure to follow this instruction may result in the accidental deployment of these modules, which increases the risk of serious personal injury or death.
WARNINGNever disassemble or tamper with seat belt deployable components, including pretensioners, load limiters and inflators. Never back probe deployable device electrical connectors. Tampering or back probing may cause an accidental deployment and result in personal injury or death.

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

Note. The Supplemental Restraint System (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

  1. C1 CHECK THE RCM (RESTRAINTS CONTROL MODULE) CONNECTION Ignition OFF. Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(ref-515937-S12193001332012120400000) . Disconnect: RCM C310A. Are RCM C310A pin 19, 20 and 24 OK? Yes: GO to C2 No: INSTALL a new wiring harness. REPOWER the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(ref-515937-S12193001332012120400000) .
  2. C2 CHECK THE RCM (RESTRAINTS CONTROL MODULE) VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Repower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(ref-515937-S12193001332012120400000) . Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C310A-24 - Is the voltage greater than 11 volts? Yes: GO to C3 No: VERIFY the BCM fuse 86 (10A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  3. C3 CHECK THE RCM (RESTRAINTS CONTROL MODULE) CASE GROUND Ignition OFF. Measure the resistance between the RCM case and a good chassis ground. Is the resistance less than 3 ohms? Yes: GO to C4 No: REPAIR the RCM case ground as necessary.
  4. C4 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) CIRCUITS BETWEEN THE RCM (RESTRAINTS CONTROL MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Depower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(ref-515937-S12193001332012120400000) . Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C310A-19 ohms C251-6 C310A-20 ohms C251-14 Are the resistances less than 3 ohms? Yes: GO to C5 No: REPAIR the circuit in question.
  5. C5 CHECK FOR CORRECT RCM (RESTRAINTS CONTROL MODULE) OPERATION Ignition OFF. Disconnect and inspect all the RCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the RCM connectors. Make sure they seat and latch correctly. Repower the SRS. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(ref-515937-S12193001332012120400000) . Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new RCM. GO to RCM PPT. No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify Body Control Module (BCM) fuse 67 (7.5A) is OK.

PINPOINT TEST D: THE FCDIM (FRONT CONTROL/DISPLAY INTERFACE MODULE) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

Scheme 2

Scheme 2: PINPOINT TEST D: THE FCDIM (FRONT CONTROL/DISPLAY INTERFACE MODULE) DOES NOT RESPOND TO THE SCAN TOO
Scheme 2: PINPOINT TEST D: THE FCDIM (FRONT CONTROL/DISPLAY INTERFACE MODULE) DOES NOT RESPOND TO THE SCAN TOO
  1. D1 CHECK THE FCDIM (FRONT CONTROL/DISPLAY INTERFACE MODULE) VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: FCDIM. Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2123-1 - Is the voltage greater than 11 volts? Yes: GO to D2 No: VERIFY the BCM fuse 67 (7.5A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. D2 CHECK THE FCDIM (FRONT CONTROL/DISPLAY INTERFACE MODULE) GROUND CIRCUIT FOR AN OPEN Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2123-9 ohms - C2123-11 ohms - Are the resistances less than 3 ohms? Yes: GO to D3 No: REPAIR the circuit in question.
  3. D3 CHECK THE INFOTAINMENT CONTROLLER AREA NETWORK (I-CAN) CIRCUITS BETWEEN THE FCDIM (FRONT CONTROL/DISPLAY INTERFACE MODULE) AND THE IPC (INSTRUMENT PANEL CLUSTER) FOR AN OPEN Disconnect: IPC. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2123-4 ohms C220-5 C2123-5 ohms C220-4 Are the resistances less than 3 ohms? Yes: GO to D4 No: REPAIR the circuit in question.
  4. D4 CHECK FOR CORRECT FCDIM (FRONT CONTROL/DISPLAY INTERFACE MODULE) OPERATION Ignition OFF. Disconnect and inspect the FCDIM connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the FCDIM connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new FCDIM. If equipped with AM/FM/CD, REFER to: «FRONT CONTROL/DISPLAY INTERFACE MODULE (FCDIM)»(ref-515931-S02313177982012120400000) . If equipped with SYNC/AM/FM/CD, REFER to: «FRONT CONTROL/DISPLAY INTERFACE MODULE (FCDIM)»(ref-515932-S25274859672012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify BCM fuse 86 (10A) is OK.

PINPOINT TEST E: THE OCSM (OCCUPANT CLASSIFICATION SYSTEM MODULE) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

  1. E1 CHECK THE OCSM (OCCUPANT CLASSIFICATION SYSTEM MODULE) VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Ignition OFF. Wait one minute. Disconnect: OCSM. Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C3159-1 - Is the voltage greater than 11 volts? Yes: GO to E2 No: VERIFY the BCM fuse 86 (10A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. E2 CHECK THE OCSM (OCCUPANT CLASSIFICATION SYSTEM MODULE) GROUND CIRCUIT FOR AN OPEN Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C3159-4 ohms - Is the resistance less than 3 ohms? Yes: GO to E3 No: REPAIR the circuit.
  3. E3 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) CIRCUITS BETWEEN THE OCSM (OCCUPANT CLASSIFICATION SYSTEM MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C3159-2 ohms C251-6 C3159-3 ohms C251-14 Are the resistances less than 3 ohms? Yes: GO to E4 No: REPAIR the circuit in question.
  4. E4 CHECK FOR CORRECT OCSM (OCCUPANT CLASSIFICATION SYSTEM MODULE) OPERATION Ignition OFF. Disconnect and inspect the OCSM connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the OCSM connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new OCSM. Refer to OCSM R& I. No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify BCM fuse 72 (7.5A) is OK.

PINPOINT TEST F: THE SASM (STEERING ANGLE SENSOR MODULE) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

  1. F1 CHECK THE SASM (STEERING ANGLE SENSOR MODULE) VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: SASM C226A Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C226A-1 - Is the voltage greater than 11 volts? Yes: GO to F2 No: VERIFY the BCM fuse 72 (7.5A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. F2 CHECK THE SASM (STEERING ANGLE SENSOR MODULE) GROUND CIRCUIT FOR AN OPEN Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C226A-14 ohms - Is the resistance less than 3 ohms? Yes: GO to F3 No: REPAIR the circuit.
  3. F3 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) CIRCUITS BETWEEN THE SASM (STEERING ANGLE SENSOR MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C226A-4 ohms C251-6 C226A-5 ohms C251-14 Are the resistances less than 3 ohms? Yes: GO to F4 No: REPAIR the circuit in question.
  4. F4 CHECK FOR CORRECT SASM (STEERING ANGLE SENSOR MODULE) OPERATION Ignition OFF. Disconnect and inspect all the SASM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the SASM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new SASM. Refer to «STEERING ANGLE SENSOR MODULE (SASM)»(ref-515974-S23767162602012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify BCM fuse 69 (5A) is OK.

PINPOINT TEST G: THE IPC (INSTRUMENT PANEL CLUSTER) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

Scheme 3

Scheme 3: PINPOINT TEST G: THE IPC (INSTRUMENT PANEL CLUSTER) DOES NOT RESPOND TO THE SCAN TOOL
Scheme 3: PINPOINT TEST G: THE IPC (INSTRUMENT PANEL CLUSTER) DOES NOT RESPOND TO THE SCAN TOOL
  1. G1 CHECK THE IPC (INSTRUMENT PANEL CLUSTER) VOLTAGE SUPPLY CIRCUIT Disconnect: IPC. Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C220-3 - Is the voltage greater than 11 volts? Yes: GO to G2 No: VERIFY the BCM fuse 69 (5A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. G2 CHECK THE IPC (INSTRUMENT PANEL CLUSTER) GROUND CIRCUIT Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C220-10 ohms - Is the resistance less than 3 ohms? Yes: GO to G3 No: REPAIR the circuit.
  3. G3 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) CIRCUITS BETWEEN THE IPC (INSTRUMENT PANEL CLUSTER) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C220-2 ohms C251-3 C220-1 ohms C251-11 Are the resistances less than 3 ohms? Yes: GO to G4 No: REPAIR the circuit in question.
  4. G4 CHECK FOR CORRECT IPC (INSTRUMENT PANEL CLUSTER) OPERATION Ignition OFF. Disconnect and inspect the IPC connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the IPC connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new IPC. REFER to: «INSTRUMENT PANEL CLUSTER (IPC)»(ref-515970-S21450118112012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify BCM fuse 69 (5A) is OK.

PINPOINT TEST H: THE INFORMATION CENTER MODULE (ICM) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

  1. H1 CHECK THE INFORMATION CENTER MODULE (ICM) VOLTAGE SUPPLY CIRCUIT Disconnect: Information Center Module (ICM). Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2487-1 - Is the voltage greater than 11 volts? Yes: GO to H2 No: VERIFY the BCM fuse 69 (5A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. H2 CHECK THE INFORMATION CENTER MODULE (ICM) GROUND CIRCUIT Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2487-3 ohms - Is the resistance less than 3 ohms? Yes: GO to H3 No: REPAIR the circuit.
  3. H3 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) CIRCUITS BETWEEN THE INFORMATION CENTER MODULE (ICM) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2487-4 ohms C251-6 C2487-5 ohms C251-14 Are the resistances less than 3 ohms? Yes: GO to H4 No: REPAIR the circuit in question.
  4. H4 CHECK FOR CORRECT INFORMATION CENTER MODULE (ICM) OPERATION Ignition OFF. Disconnect and inspect the Information Center Module (ICM) connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Information Center Module (ICM) connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Information Center Module (ICM). REFER to: «INFORMATION CENTER MODULE (ICM)»(ref-515970-S12240003322012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify BJB MEGA fuses 4 (50A) and 9 (50A) are OK.

PINPOINT TEST I: THE BCM (BODY CONTROL MODULE) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

  1. I1 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) TERMINATION RESISTANCE Ignition OFF. Disconnect the scan tool cable from the DLC. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-6 ohms C251-14 Is the resistance between 54 and 66 ohms? Yes: GO to I3 No: GO to I2
  2. I2 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) CIRCUITS BETWEEN THE BCM (BODY CONTROL MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Disconnect: BCM C2280C. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2280C-7 ohms C251-6 C2280C-8 ohms C251-14 Are the resistances less than 3 ohms? Yes: GO to I7 No: REPAIR the circuit in question.
  3. I3 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) TERMINATION RESISTANCE Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-3 ohms C251-11 Is the resistance between 54 and 66 ohms? Yes: GO to I5 No: GO to I4
  4. I4 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) CIRCUITS BETWEEN THE BCM (BODY CONTROL MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Disconnect: BCM C2280A. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2280A-41 ohms C251-3 C2280A-40 ohms C251-11 Are the resistances less than 3 ohms? Yes: GO to I7 No: REPAIR the circuit in question.
  5. I5 CHECK THE BCM (BODY CONTROL MODULE) VOLTAGE SUPPLY CIRCUIT FOR AN OPEN NOTE: Measurements are taken with the fuse installed and probes placed at the terminals on the back of the fuse blade. Ignition ON. Disconnect: BCM C2280G. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2280G-2 - C2280G-1 - Are the voltages greater than 11 volts? Yes: Connect: BCM C2280G. GO to I6 No: VERIFY the BJB MEGA fuses 4 (50A) and 9 (50A) are OK. If OK, repair the circuit in question. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  6. I6 CHECK THE BCM (BODY CONTROL MODULE) GROUND CIRCUITS FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2280E-2 ohms - Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2280A-3 ohms - Are the resistances less than 3 ohms? Yes: GO to I7 No: REPAIR the circuit in question.
  7. I7 CHECK FOR CORRECT BCM (BODY CONTROL MODULE) OPERATION Ignition OFF. Disconnect and inspect the BCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the BCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new BCM. Refer to «BODY CONTROL MODULE (BCM)»(ref-515973-S25219396702012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify BCM fuse 71 (10A) is OK.

PINPOINT TEST J: THE HVAC (HEATING, VENTILATION AND AIR CONDITIONING) MODULE DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

  1. J1 CHECK THE HVAC (HEATING, VENTILATION AND AIR CONDITIONING) MODULE VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Disconnect: HVAC Module C228B. Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C228B-14 - Is the voltage greater than 11 volts? Yes: GO to J2 No: VERIFY the BCM fuse 71 (10A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. J2 CHECK THE HVAC (HEATING, VENTILATION AND AIR CONDITIONING) MODULE GROUND CIRCUIT FOR AN OPEN Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C228B-6 ohms - Is the resistance less than 3 ohms? Yes: GO to J3 No: REPAIR the circuit.
  3. J3 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) CIRCUITS BETWEEN THE HVAC (HEATING, VENTILATION AND AIR CONDITIONING) MODULE AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C228B-18 ohms C251-3 C228B-19 ohms C251-11 Are the resistances less than 3 ohms? Yes: GO to J4 No: REPAIR the circuit in question.
  4. J4 CHECK FOR CORRECT HVAC (HEATING, VENTILATION AND AIR CONDITIONING) MODULE OPERATION Ignition OFF. Disconnect and inspect all the HVAC module connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the HVAC module connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new HVAC module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(ref-515934-S14778149862012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify BCM fuse 79 (15A) is OK.

PINPOINT TEST K: THE ACM (AUDIO FRONT CONTROL MODULE) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

  1. K1 CHECK THE INFOTAINMENT CONTROLLER AREA NETWORK (I-CAN) TERMINATION RESISTANCE Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-1 ohms C251-8 Is the resistance between 54 and 66 ohms? Yes: GO to K3 No: GO to K2
  2. K2 CHECK THE INFOTAINMENT CONTROLLER AREA NETWORK (I-CAN) CIRCUITS BETWEEN THE ACM (AUDIO FRONT CONTROL MODULE) AND THE INSTRUMENT PANEL CLUSTER (IPC) FOR AN OPEN Disconnect: Instrument Panel Cluster (IPC) C220. Disconnect: ACM C240A. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C240A-14 ohms C220-5 C240A-15 ohms C220-4 Are the resistances less than 3 ohms? Yes: GO to K3 No: REPAIR the circuit in question.
  3. K3 CHECK THE ACM (AUDIO FRONT CONTROL MODULE) VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Ignition OFF. Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C240A-1 - Is the voltage greater than 11 volts? Yes: GO to K4 No: VERIFY the BCM fuse 79 (15A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  4. K4 CHECK THE ACM (AUDIO FRONT CONTROL MODULE) GROUND CIRCUIT FOR AN OPEN Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C240A-13 ohms - Is the resistance less than 3 ohms? Yes: GO to K5 No: REPAIR the circuit.
  5. K5 CHECK FOR CORRECT ACM (AUDIO FRONT CONTROL MODULE) OPERATION Ignition OFF. Disconnect and inspect all the ACM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the ACM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new ACM. If equipped with AM/FM/CD, REFER to: «AUDIO FRONT CONTROL MODULE (ACM)»(ref-515931-S22291225992012120400000) . If equipped with SYNC/AM/FM/CD, REFER to: «AUDIO FRONT CONTROL MODULE (ACM)»(ref-515932-S19859685552012120400000) . If equipped with Sony AM/FM/CD/SYNC, REFER to: «AUDIO FRONT CONTROL MODULE (ACM)»(ref-515933-S34397221142012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify RJB fuse 23 (25A) is OK.

PINPOINT TEST L: THE DSP (AUDIO DIGITAL SIGNAL PROCESSING MODULE) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

  1. L1 CHECK THE DSP (AUDIO DIGITAL SIGNAL PROCESSING MODULE) VOLTAGE SUPPLY CIRCUITS FOR AN OPEN Ignition OFF. Disconnect: DSP C4326C. Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4326C-5 - C4326C-6 - Are the voltages greater than 11 volts? Yes: GO to L2 No: VERIFY the RJB fuse 23 (25A) is OK. If OK, REPAIR the circuit in question. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. L2 CHECK THE DSP (AUDIO DIGITAL SIGNAL PROCESSING MODULE) GROUND CIRCUITS FOR AN OPEN Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4326C-13 ohms - C4326C-14 ohms - Are the resistances less than 3 ohms? Yes: GO to L3 No: REPAIR the circuit in question.
  3. L3 CHECK THE INFOTAINMENT CONTROLLER AREA NETWORK (I-CAN) CIRCUITS BETWEEN THE DSP (AUDIO DIGITAL SIGNAL PROCESSING MODULE) AND THE IPC (INSTRUMENT PANEL CLUSTER) FOR AN OPEN Disconnect: IPC. Disconnect: DSP C4326A. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4326A-1 ohms C220-5 C4326A-11 ohms C220-4 Are the resistances less than 3 ohms? Yes: GO to L4 No: REPAIR the circuit in question.
  4. L4 CHECK FOR CORRECT DSP (AUDIO DIGITAL SIGNAL PROCESSING MODULE) OPERATION Ignition OFF. Disconnect and inspect all the DSP connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the DSP connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new DSP. REFER to: «AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE»(ref-515933-S31695947082012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify RJB fuse 4 (25A) is OK.

PINPOINT TEST M: THE DDM (DRIVER DOOR MODULE) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

  1. M1 CHECK THE DDM (DRIVER DOOR MODULE) VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: DDM C501A. Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C501A-2 - Is the voltage greater than 11 volts? Yes: GO to M2 No: VERIFY the RJB fuse 4 (25A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. M2 CHECK THE DDM (DRIVER DOOR MODULE) GROUND CIRCUIT FOR AN OPEN Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C501A-13 ohms - Is the resistance less than 3 ohms? Yes: GO to M3 No: REPAIR the circuit.
  3. M3 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) CIRCUITS BETWEEN THE DDM (DRIVER DOOR MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C501B-1 ohms C251-3 C501B-13 ohms C251-11 Are the resistances less than 3 ohms? Yes: GO to M4 No: REPAIR the circuit in question.
  4. M4 CHECK FOR CORRECT DDM (DRIVER DOOR MODULE) OPERATION Ignition OFF. Disconnect and inspect all the DDM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the DDM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new DDM. No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify RJB fuse 5 (25A) is OK.

PINPOINT TEST N: THE PDM (PASSENGER DOOR MODULE) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

  1. N1 CHECK THE PDM (PASSENGER DOOR MODULE) VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: PDM C652A. Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C652A-2 - Is the voltage greater than 11 volts? Yes: GO to N2 No: VERIFY the RJB fuse 5 (25A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. N2 CHECK THE PDM (PASSENGER DOOR MODULE) GROUND CIRCUIT FOR AN OPEN Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C652A-13 ohms - Is the resistance less than 3 ohms? Yes: GO to N3 No: REPAIR the circuit.
  3. N3 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) CIRCUITS BETWEEN THE PDM (PASSENGER DOOR MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C652B-1 ohms C251-3 C652B-13 ohms C251-11 Are the resistances less than 3 ohms? Yes: GO to N4 No: REPAIR the circuit in question.
  4. N4 CHECK FOR CORRECT PDM (PASSENGER DOOR MODULE) OPERATION Ignition OFF. Disconnect and inspect all the PDM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the PDM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new PDM. No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify RJB fuse 29 (5A) is OK.

PINPOINT TEST O: THE IMAGE PROCESSING MODULE B (IPM-B) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

Scheme 4

Scheme 4: PINPOINT TEST O: THE IMAGE PROCESSING MODULE B (IPM-B) DOES NOT RESPOND TO THE SCAN TOOL
Scheme 4: PINPOINT TEST O: THE IMAGE PROCESSING MODULE B (IPM-B) DOES NOT RESPOND TO THE SCAN TOOL
  1. O1 CHECK THE IMAGE PROCESSING MODULE - B (IPM-B) VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: Image Processing Module - B (IPM-B) C4402 Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4402-4 - Is the voltage greater than 11 volts? Yes: GO to O2 No: VERIFY the RJB fuse 29 (5A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. O2 CHECK THE IMAGE PROCESSING MODULE - B (IPM-B) GROUND CIRCUIT FOR AN OPEN Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4402-1 ohms - Is the resistance less than 3 ohms? Yes: GO to O3 No: REPAIR the circuit.
  3. O3 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) CIRCUITS BETWEEN THE IMAGE PROCESSING MODULE - B (IPM-B) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4402-2 ohms C251-3 C4402-3 ohms C251-11 Are the resistances less than 3 ohms? Yes: GO to O4 No: REPAIR the circuit in question.
  4. O4 CHECK FOR CORRECT IMAGE PROCESSING MODULE - B (IPM-B) OPERATION Ignition OFF. Disconnect and inspect the Image Processing Module - B (IPM-B) connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Image Processing Module - B (IPM-B) connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Image Processing Module - B (IPM-B). REFER to: «IMAGE PROCESSING MODULE B (IPMB) - 4-DOOR»(ref-515935-S24393370542012120400000) . REFER to: «IMAGE PROCESSING MODULE B (IPMB) - 5-DOOR»(ref-515935-S19518492372012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify BCM fuse 67 (7.5A) is OK.

PINPOINT TEST P: THE GPSM (GLOBAL POSITIONING SYSTEM MODULE) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

  1. P1 CHECK THE GPSM (GLOBAL POSITIONING SYSTEM MODULE) VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: GPSM. Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2398-1 - Is the voltage greater than 11 volts? Yes: GO to P2 No: VERIFY the BCM fuse 67 (7.5A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. P2 CHECK THE GPSM (GLOBAL POSITIONING SYSTEM MODULE) GROUND CIRCUIT FOR AN OPEN Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2398-6 ohms - Is the resistance less than 3 ohms? Yes: GO to P3 No: REPAIR the circuit.
  3. P3 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) CIRCUITS BETWEEN THE GPSM (GLOBAL POSITIONING SYSTEM MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2398-2 ohms C251-3 C2398-3 ohms C251-11 Are the resistances less than 3 ohms? Yes: GO to P4 No: REPAIR the circuit in question.
  4. P4 CHECK FOR CORRECT GPSM (GLOBAL POSITIONING SYSTEM MODULE) OPERATION Ignition OFF. Disconnect and inspect the GPSM connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the GPSM connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new GPSM. If equipped with SYNC/AM/FM/CD, REFER to: «GLOBAL POSITIONING SYSTEM MODULE (GPSM)»(ref-515932-S34596461812012120400000) . If equipped with Sony AM/FM/CD/SYNC, REFER to: «GLOBAL POSITIONING SYSTEM MODULE (GPSM)»(ref-515933-S11142139822012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify RJB fuse 30 (5A) is OK.

PINPOINT TEST Q: THE PARKING AID MODULE (PAM) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

Scheme 5

Scheme 5: PINPOINT TEST Q: THE PARKING AID MODULE (PAM) DOES NOT RESPOND TO THE SCAN TOOL
Scheme 5: PINPOINT TEST Q: THE PARKING AID MODULE (PAM) DOES NOT RESPOND TO THE SCAN TOOL
  1. Q1 CHECK THE PARKING AID MODULE (PAM) VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: Parking Aid Module (PAM) C4014A. Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4014A-1 - Is the voltage greater than 11 volts? Yes: GO to Q2 No: VERIFY the RJB fuse 30 (5A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. Q2 CHECK THE PARKING AID MODULE (PAM) GROUND CIRCUIT FOR AN OPEN Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4014A-8 ohms - Is the resistance less than 3 ohms? Yes: GO to Q3 No: REPAIR the circuit.
  3. Q3 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) CIRCUITS BETWEEN THE PARKING AID MODULE (PAM) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4014A-6 ohms C251-6 C4014A-15 ohms C251-14 Are the resistances less than 3 ohms? Yes: GO to Q4 No: REPAIR the circuit in question.
  4. Q4 CHECK FOR CORRECT PARKING AID MODULE (PAM) OPERATION Ignition OFF. Disconnect and inspect the Parking Aid Module (PAM) connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Parking Aid Module (PAM) connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Parking Aid Module (PAM). REFER to: «PARKING ASSIST CONTROL MODULE (PAM) - 4-DOOR»(ref-515935-S18282733842012120400000) . REFER to: «PARKING ASSIST CONTROL MODULE (PAM) - 5-DOOR»(ref-515935-S31149311112012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify BCM fuse 67 (7.5A) is OK.

PINPOINT TEST R: THE APIM (ACCESSORY PROTOCOL INTERFACE MODULE) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

  1. R1 CHECK THE APIM (ACCESSORY PROTOCOL INTERFACE MODULE) VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: APIM. Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2383-1 - Is the voltage greater than 11 volts? Yes: GO to R2 No: VERIFY the BCM fuse 67 (7.5A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. R2 CHECK THE APIM (ACCESSORY PROTOCOL INTERFACE MODULE) GROUND CIRCUITS FOR AN OPEN Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2383-37 ohms - C2383-38 ohms - Are the resistances less than 3 ohms? Yes: GO to R3 No: REPAIR the circuit in question.
  3. R3 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) CIRCUITS BETWEEN THE APIM (ACCESSORY PROTOCOL INTERFACE MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2383-53 ohms C251-6 C2383-54 ohms C251-14 Are the resistances less than 3 ohms? Yes: GO to R4 No: REPAIR the circuit in question.
  4. R4 CHECK THE INFOTAINMENT CONTROLLER AREA NETWORK (I-CAN) CIRCUITS BETWEEN THE APIM (ACCESSORY PROTOCOL INTERFACE MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors SYNC/AM/FM/CD Positive Lead Measurement / Action Negative Lead C2383-16 ohms C251-1 C2383-17 ohms C251-8 Measure: Click to display connectors Sony/AM/FM/CD/SYNC Positive Lead Measurement / Action Negative Lead C2383-19 ohms C251-1 C2383-20 ohms C251-8 Are the resistances less than 3 ohms? Yes: For SYNC/AM/FM/CD only, GO to R6 For Sony AM/FM/CD/SYNC, GO to R5 No: REPAIR the circuit in question.
  5. R5 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) CIRCUITS BETWEEN THE APIM (ACCESSORY PROTOCOL INTERFACE MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2383-16 ohms C251-3 C2383-17 ohms C251-11 Are the resistances less than 3 ohms? Yes: GO to R6 No: REPAIR the circuit in question.
  6. R6 CHECK FOR CORRECT APIM (ACCESSORY PROTOCOL INTERFACE MODULE) OPERATION Ignition OFF. Disconnect and inspect the APIM connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the APIM connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new APIM. If equipped with SYNC/AM/FM/CD, REFER to: «ACCESSORY PROTOCOL INTERFACE MODULE (APIM)»(ref-515932-S32782240822012120400000) . If equipped with Sony AM/FM/CD/SYNC, REFER to: «ACCESSORY PROTOCOL INTERFACE MODULE (APIM)»(ref-515933-S13494101232012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify BCM fuse 79 (15A) is OK.

PINPOINT TEST S: THE FCIM (FRONT CONTROLS INTERFACE MODULE) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

  1. S1 CHECK THE FCIM (FRONT CONTROLS INTERFACE MODULE) VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: FCIM. Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2402-8 - Is the voltage greater than 11 volts? Yes: GO to S2 No: VERIFY the BCM fuse 79 (15A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. S2 CHECK THE FCIM (FRONT CONTROLS INTERFACE MODULE) GROUND CIRCUIT FOR AN OPEN Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2402-5 ohms - Is the resistance less than 3 ohms? Yes: GO to S3 No: REPAIR the circuit.
  3. S3 CHECK THE INFOTAINMENT CONTROLLER AREA NETWORK (I-CAN) CIRCUITS BETWEEN THE FCIM (FRONT CONTROLS INTERFACE MODULE) AND THE IPC (INSTRUMENT PANEL CLUSTER) FOR AN OPEN Disconnect: IPC. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2402-7 ohms C220-5 C2402-4 ohms C220-4 Are the resistances less than 3 ohms? Yes: GO to S4 No: REPAIR the circuit in question.
  4. S4 CHECK FOR CORRECT FCIM (FRONT CONTROLS INTERFACE MODULE) OPERATION Ignition OFF. Disconnect and inspect the FCIM connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the FCIM connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new FCIM. If equipped with AM/FM/CD, REFER to: «FRONT CONTROLS INTERFACE MODULE (FCIM)»(ref-515931-S01842134582012120400000) . If equipped with SYNC/AM/FM/CD, REFER to: «FRONT CONTROLS INTERFACE MODULE (FCIM)»(ref-515932-S30979992462012120400000) . If equipped with Sony AM/FM/CD/SYNC, REFER to: «FRONT CONTROLS INTERFACE MODULE (FCIM)»(ref-515933-S41535852092012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify RJB fuse 2 (10A) is OK.

PINPOINT TEST T: THE RFA (REMOTE FUNCTION ACTUATOR) MODULE DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

Scheme 6

Scheme 6: PINPOINT TEST T: THE RFA (REMOTE FUNCTION ACTUATOR) MODULE DOES NOT RESPOND TO THE SCAN TOOL
Scheme 6: PINPOINT TEST T: THE RFA (REMOTE FUNCTION ACTUATOR) MODULE DOES NOT RESPOND TO THE SCAN TOOL
  1. T1 CHECK THE RFA (REMOTE FUNCTION ACTUATOR) MODULE VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: RFA module C4392C (blue hardshell). Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4392C-5 - Is the voltage greater than 11 volts? Yes: GO to T2 No: VERIFY the RJB fuse 2 (10A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. T2 CHECK THE RFA (REMOTE FUNCTION ACTUATOR) MODULE GROUND CIRCUIT FOR AN OPEN Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4392C-4 ohms - Is the resistance less than 3 ohms? Yes: GO to T3 No: REPAIR the circuit.
  3. T3 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) CIRCUITS BETWEEN THE RFA (REMOTE FUNCTION ACTUATOR) MODULE AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Disconnect: RFA module C4392D (natural hardshell). Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4392D-3 ohms C251-3 C4392D-4 ohms C251-11 Are the resistances less than 3 ohms? Yes: GO to T4 No: REPAIR the circuit in question.
  4. T4 CHECK FOR CORRECT RFA (REMOTE FUNCTION ACTUATOR) MODULE OPERATION Ignition OFF. Disconnect and inspect all the RFA module connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the RFA module connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new RFA module. No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify BJB fuse 15 (25A), 26 (15A) and 38 (15A) are OK.

PINPOINT TEST U: THE TCM (TRANSMISSION CONTROL MODULE) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

Scheme 7

Scheme 7: PINPOINT TEST U: THE TCM (TRANSMISSION CONTROL MODULE) DOES NOT RESPOND TO THE SCAN TOOL
Scheme 7: PINPOINT TEST U: THE TCM (TRANSMISSION CONTROL MODULE) DOES NOT RESPOND TO THE SCAN TOOL
  1. U1 CHECK THE TCM (TRANSMISSION CONTROL MODULE) VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: TCM C1750A. Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C1750A-1 - C1750A-2 - C1750A-18 - C1750A-31 - Are the voltages greater than 11 volts? Yes: GO to U2 No: VERIFY the BJB fuse 15 (25A), 26 (15A) and 38 (15A) are OK. If OK, REPAIR the circuit in question. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. U2 CHECK THE TCM (TRANSMISSION CONTROL MODULE) GROUND CIRCUIT FOR AN OPEN Ignition OFF. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C1750A-3 ohms - C1750A-4 ohms - C1750A-5 ohms - C1750A-6 ohms - Are the resistances less than 3 ohms? Yes: GO to U3 No: REPAIR the circuit in question.
  3. U3 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) CIRCUITS BETWEEN THE TCM (TRANSMISSION CONTROL MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C1750A-34 ohms C251-6 C1750A-35 ohms C251-14 Are the resistances less than 3 ohms? Yes: GO to U4 No: REPAIR the circuit in question.
  4. U4 CHECK FOR CORRECT TCM (TRANSMISSION CONTROL MODULE) OPERATION Ignition OFF. Disconnect and inspect all the TCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the TCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new TCM. REFER to: «TRANSMISSION CONTROL MODULE (TCM)»(ref-515940-S41897048382012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify BJB fuse 40 (5A) is OK.

PINPOINT TEST V: THE PSCM (POWER STEERING CONTROL MODULE) DOES NOT RESPOND TO THE SCAN TOOL

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

  1. V1 CHECK THE PSCM (POWER STEERING CONTROL MODULE) VOLTAGE SUPPLY CIRCUITS FOR AN OPEN Ignition OFF. Disconnect: PSCM C1463B. Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C1463B-3 - Is the voltage greater than 11 volts? Yes: GO to V2 No: VERIFY the BJB fuse 40 (5A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  2. V2 CHECK THE PSCM (POWER STEERING CONTROL MODULE) GROUND CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: PSCM C1463A. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C1463A-2 ohms - Is the resistance less than 3 ohms? Yes: GO to V3 No: REPAIR the circuit.
  3. V3 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) CIRCUITS BETWEEN THE PSCM (POWER STEERING CONTROL MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C1463B-1 ohms C251-6 C1463B-2 ohms C251-14 Are the resistances less than 3 ohms? Yes: GO to V4 No: REPAIR the circuit in question.
  4. V4 CHECK FOR CORRECT PSCM (POWER STEERING CONTROL MODULE) OPERATION Ignition OFF. Disconnect and inspect all the PSCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the PSCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new PSCM. REFER to: «STEERING GEAR»(ref-515947-S17880110562012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

PINPOINT TEST W: NO HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) COMMUNICATION, ALL MODULES ARE NOT RESPONDING

Note. Various modules set network DTCs during this test procedure. Clear DTCs from all modules after completing the diagnostic procedure.

Note. Failure to disconnect the battery when instructed will result in false resistance readings.

  1. W1 CHECK THE DLC (DATA LINK CONNECTOR) PINS FOR DAMAGE Ignition OFF. Disconnect the scan tool cable from the DLC. Inspect the DLC pins 6 and 14 for damage. Are DLC pins 6 and 14 OK? Yes: GO to W2 No: REPAIR the DLC as necessary.
  2. W2 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) TERMINATION RESISTANCE Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-6 ohms C251-14 Is the resistance between 54 and 66 ohms? Yes: GO to W3 No: GO to W5
  3. W3 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) (+) AND HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) (-) CIRCUITS FOR A SHORT TO GROUND Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-6 ohms - C251-14 ohms - Are the resistances greater than 10, 000 ohms? Yes: GO to W4 No: GO to W12
  4. W4 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) (+) AND HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) (-) CIRCUITS FOR A SHORT TO VOLTAGE Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-6 - C251-14 - Is the voltage greater than 6 volts on either circuit? Yes: REPAIR the circuit in question. No: GO to W13
  5. W5 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) TERMINATION RESISTOR Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-6 ohms C251-14 Is the resistance between 108 and 132 ohms? Yes: GO to W6 No: GO to W9
  6. W6 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) TERMINATION RESISTOR WITH THE PCM (POWERTRAIN CONTROL MODULE) DISCONNECTED Disconnect: PCM C175B. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-6 ohms C251-14 Is the resistance between 108 and 132 ohms? Yes: GO to W7 No: GO to W8
  7. W7 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) CIRCUITS BETWEEN THE PCM (POWERTRAIN CONTROL MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C175B-54 ohms C251-6 C175B-41 ohms C251-14 Are the resistances less than 3 ohms? Yes: GO to W26 No: REPAIR the circuit in question.
  8. W8 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) CIRCUITS BETWEEN THE BCM (BODY CONTROL MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Disconnect: BCM C2280C. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2280C-7 ohms C251-6 C2280C-8 ohms C251-14 Are the resistances less than 3 ohms? Yes: GO to W22 No: REPAIR the circuit in question.
  9. W9 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) (+) AND HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) (-) CIRCUITS FOR A SHORT TOGETHER Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-6 ohms C251-14 Is the resistance less than 3 ohms? Yes: GO to W11 No: GO to W10
  10. W10 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) CIRCUITS BETWEEN THE PCM (POWERTRAIN CONTROL MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-6 ohms C251-14 Is the resistance greater than 10, 000 ohms? Yes: REPAIR the DLC or REPAIR the circuit in question. No: A capacitor internal to a module can still be draining, causing irregular resistance readings. WAIT 5 minutes. REPEAT the pinpoint test.
  11. W11 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) (+) AND HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) (-) CIRCUITS FOR A SHORT TOGETHER WITH MODULES DISCONNECTED Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-6 ohms C251-14 Disconnect modules one at a time until the resistance is greater than 3 ohms. APIM (if equipped) ABS module BCM C2280C Information Center Module (ICM) OCSM Parking Aid Module (PAM) C4014A (if equipped) PSCM C1463A PCM C175B RCM C310A SASM C226A TCM C1750A (if equipped) Did the resistance change to greater than 3 ohms with one of the modules disconnected? Yes: For the APIM, GO to W19 For the ABS module, GO to W20 For the BCM, GO to W21 For the Information Center Module (ICM), GO to W29 For the OCSM, GO to W23 For the Parking Aid Module (PAM), GO to W24 For the PSCM, GO to W22 For the PCM, GO to W25 For the RCM, GO to W26 For the SASM, GO to W27 For the TCM, GO to W28 No: REPAIR the circuits.
  12. W12 CHECK THE HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) (+) AND HIGH SPEED CONTROLLER AREA NETWORK (HS-CAN) (-) CIRCUITS FOR A SHORT TO GROUND WITH MODULES DISCONNECTED Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-6 ohms - C251-14 ohms - Disconnect modules one at a time until the resistance to ground is greater than 10, 000 ohms. APIM (if equipped) ABS module BCM C2280C Information Center Module (ICM) OCSM Parking Aid Module (PAM) C4014A (if equipped) PSCM C1463A PCM C175B RCM C310A SASM C226A TCM C1750A (if equipped) Did the resistance change to greater than 10, 000 ohms with one of the modules disconnected? Yes: For the APIM, GO to W19 For the ABS module, GO to W20 For the BCM, GO to W21 For the Information Center Module (ICM), GO to W29 For the OCSM, GO to W23 For the Parking Aid Module (PAM), GO to W24 For the PSCM, GO to W22 For the PCM, GO to W25 For the RCM, GO to W26 For the SASM, GO to W27 For the TCM, GO to W28 No: REPAIR the circuit in question. CONNECT all modules.
  13. W13 CHECK FOR RESTORED COMMUNICATION WITH THE PCM (POWERTRAIN CONTROL MODULE) DISABLED NOTE: Establish an IDS session prior to disabling the PCM in this test step. If the PCM has failed communication during multiple attempts to identify the vehicle, first identify the vehicle manually by entering a PCM part number, calibration number or tear tag when prompted by IDS. When a vehicle is manually identified by a PCM part number, calibration number or tear tag, the IDS does not automatically run a network test. Manually select and run the network test. When re-running the network test, close the network test application first or the screen display reverts back to the prior network test results. Disconnect: BJB fuses 38 (15A) and 36 (10A). Using a scan tool, perform the network test. Do all other modules pass the network test? Yes: INSTALL the removed fuses. GO to «Pinpoint Test A»(ref-515972-S22381727612012120400000) No: INSTALL the removed fuses. GO to W14
  14. W14 CHECK FOR RESTORED NETWORK COMMUNICATION WITH THE ABS (ANTI-LOCK BRAKE SYSTEM) MODULE AND THE TCM (TRANSMISSION CONTROL MODULE) DISABLED NOTE: When re-running the network test, close the network test application first or the screen display reverts back to the prior network test results. Disconnect: BJB fuses 7 (40A), 8 (30A) and 19 (5A) to disable the ABS module. Using a scan tool, perform the network test. Install the removed fuses. Disconnect: BJB fuses 15 (25A), 26 (15A) and 38 (15A) to disable the TCM (if equipped). Using a scan tool, perform the network test. Do all other modules pass the network test? Yes: INSTALL the removed fuses. For restored operation with the ABS module disabled, GO to «Pinpoint Test B»(ref-515972-S00269403872012120400000) For restored operation with the TCM disabled, GO to «Pinpoint Test U»(ref-515972-S33031281732012120400000) No: GO to W15
  15. W15 CHECK FOR RESTORED NETWORK COMMUNICATION WITH THE SASM (STEERING ANGLE SENSOR MODULE), PSCM (POWER STEERING CONTROL MODULE), APIM (ACCESSORY PROTOCOL INTERFACE MODULE) AND THE PARKING AID MODULE (PAM) DISABLED NOTE: When re-running the network test, close the network test application first or the screen display reverts back to the prior network test results. Disable module one at a time until other High Speed Controller Area Network (HS-CAN) modules pass the network test. Skip to the end once network operation is restored. Disconnect: BCM fuse 72 (7.5A) to disable the SASM. Using a scan tool, perform the network test. Install the removed fuse. Disconnect: BJB fuse 40 (5A) to disable the PSCM. Using a scan tool, perform the network test. Install the removed fuse. Disconnect: BCM fuses 67 (7.5A) to disable the APIM (if equipped). Using a scan tool, perform the network test. Install the removed fuse. Disconnect: RJB fuse 30 (5A) to disable the Parking Aid Module (PAM) (if equipped). Using a scan tool, perform the network test. Do all other High Speed Controller Area Network (HS-CAN) modules pass the network test? Yes: INSTALL the removed fuse. For restored operation with the SASM disabled, GO to «Pinpoint Test F»(ref-515972-S07818448042012120400000) For restored operation with the PSCM disabled, GO to «Pinpoint Test V»(ref-515972-S27044850562012120400000) For restored operation with the APIM disabled, GO to «Pinpoint Test R»(ref-515972-S40555143972012120400000) For restored operation with the Parking Aid Module (PAM) disabled, GO to «Pinpoint Test Q»(ref-515972-S20947464782012120400000) No: INSTALL the removed fuse. GO to W16
  16. W16 CHECK FOR RESTORED NETWORK COMMUNICATION WITH THE RCM (RESTRAINTS CONTROL MODULE) AND OCSM (OCCUPANT CLASSIFICATION SYSTEM MODULE) DISABLED NOTE: When re-running the network test, close the network test application first or the screen display reverts back to the prior network test results. Disconnect: BCM fuses 86 (10A) Using a scan tool, perform the network test. Do all other modules pass the network test? Yes: INSTALL the removed fuses. GO to W17 No: INSTALL the removed fuse. If equipped with an Information Center Module (ICM), GO to W18 If not equipped with an Information Center Module (ICM), the High Speed Controller Area Network (HS-CAN) tests within specification. VERIFY correct operation of the scan tool on a known good vehicle.
  17. W17 CHECK FOR RESTORED NETWORK COMMUNICATION WITH THE RCM (RESTRAINTS CONTROL MODULE) DISCONNECTED NOTE: When re-running the network test, close the network test application first or the screen display reverts back to the prior network test results. Disconnect: RCM C310A. Using a scan tool, perform the network test. Do all other modules pass the network test? Yes: CONNECT the RCM C310A, GO to «Pinpoint Test C»(ref-515972-S02985927592012120400000) No: CONNECT the RCM C310A. GO to «Pinpoint Test E»(ref-515972-S17422232142012120400000)
  18. W18 CHECK FOR RESTORED NETWORK COMMUNICATION WITH THE INFORMATION CENTER MODULE (ICM) DISABLED NOTE: When re-running the network test, close the network test application first or the screen display reverts back to the prior network test results. Disconnect: BCM fuse 69 (5A). Using a scan tool, perform the network test. Do all other modules pass the network test? Yes: INSTALL the removed fuse. GO to «Pinpoint Test H»(ref-515972-S04123610282012120400000) No: The High Speed Controller Area Network (HS-CAN) tests within specification. VERIFY correct operation of the scan tool on a known good vehicle.
  19. W19 CHECK FOR CORRECT APIM (ACCESSORY PROTOCOL INTERFACE MODULE) OPERATION Ignition OFF. Disconnect and inspect the APIM connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the APIM connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Accessory Protocol Interface Module (APIM). If equipped with SYNC/AM/FM/CD, REFER to: «ACCESSORY PROTOCOL INTERFACE MODULE (APIM)»(ref-515932-S32782240822012120400000) . If equipped with Sony AM/FM/CD/SYNC, REFER to: «ACCESSORY PROTOCOL INTERFACE MODULE (APIM)»(ref-515933-S13494101232012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  20. W20 CHECK FOR CORRECT ABS (ANTI-LOCK BRAKE SYSTEM) MODULE OPERATION Ignition OFF. Disconnect and inspect the ABS module connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the ABS module connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new ABS module. No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  21. W21 CHECK FOR CORRECT BCM (BODY CONTROL MODULE) OPERATION Ignition OFF. Disconnect and inspect all the BCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the BCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new BCM. No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  22. W22 CHECK FOR CORRECT PSCM (POWER STEERING CONTROL MODULE) OPERATION Ignition OFF. Disconnect and inspect all the PSCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the PSCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Power Steering Control Module (PSCM). REFER to: «STEERING GEAR»(ref-515947-S17880110562012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  23. W23 CHECK FOR CORRECT OCSM (OCCUPANT CLASSIFICATION SYSTEM MODULE) OPERATION Ignition OFF. Disconnect and inspect the OCSM connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the OCSM connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new OCSM. No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  24. W24 CHECK FOR CORRECT PARKING AID MODULE (PAM) OPERATION Ignition OFF. Disconnect and inspect the Parking Aid Module (PAM) connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Parking Aid Module (PAM) connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB nstructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Parking Aid Module (PAM). REFER to: «PARKING ASSIST CONTROL MODULE (PAM) - 4-DOOR»(ref-515935-S18282733842012120400000) . REFER to: «PARKING ASSIST CONTROL MODULE (PAM) - 5-DOOR»(ref-515935-S31149311112012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  25. W25 CHECK FOR CORRECT PCM (POWERTRAIN CONTROL MODULE) OPERATION Ignition OFF. Disconnect and inspect all the PCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the PCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new PCM. REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(ref-515938-S13817209062012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  26. W26 CHECK FOR CORRECT RCM (RESTRAINTS CONTROL MODULE) OPERATION Ignition OFF. Disconnect and inspect all the RCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the RCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new RCM. No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  27. W27 CHECK FOR CORRECT SASM (STEERING ANGLE SENSOR MODULE) OPERATION Ignition OFF. Disconnect and inspect all the SASM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the SASM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new SASM. No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  28. W28 CHECK FOR CORRECT TCM (TRANSMISSION CONTROL MODULE) OPERATION Ignition OFF. Disconnect and inspect all the TCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the TCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new TCM. REFER to: «TRANSMISSION CONTROL MODULE (TCM)»(ref-515940-S41897048382012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  29. W29 CHECK FOR CORRECT INFORMATION CENTER MODULE (ICM) OPERATION Ignition OFF. Disconnect and inspect all the Information Center Module (ICM) connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Information Center Module (ICM) connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Information Center Module (ICM). REFER to: «INFORMATION CENTER MODULE (ICM)»(ref-515970-S12240003322012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

PINPOINT TEST X: NO MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) COMMUNICATION, ALL MODULES ARE NOT RESPONDING

  1. X1: CHECK THE DLC (DATA LINK CONNECTOR) PINS FOR DAMAGE Ignition OFF. Disconnect the scan tool cable from the DLC. Inspect the DLC pins 3 and 11 for damage. Are DLC pins 3 and 11 OK? Yes: GO to X2 No: REPAIR the DLC as necessary.
  2. X2 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) TERMINATION RESISTANCE Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-3 ohms C251-11 Is the resistance between 54 and 66 ohms? Yes: GO to X3 No: GO to X5
  3. X3 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) (+) AND MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) (-) CIRCUITS FOR A SHORT TO GROUND Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-3 ohms - C251-11 ohms - Are the resistances greater than 10, 000 ohms? Yes: GO to X4 No: GO to X12
  4. X4 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) (+) AND MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) (-) CIRCUITS FOR A SHORT TO VOLTAGE Ignition ON. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-3 - C251-11 - Are the voltages greater than 6 volts? Yes: REPAIR the circuit in question. No: GO to X13
  5. X5 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) TERMINATION RESISTOR Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-3 ohms C251-11 Is the resistance between 108 and 132 ohms? Yes: GO to X6 No: GO to X9
  6. X6 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) TERMINATION RESISTOR WITH THE BCM (BODY CONTROL MODULE) DISCONNECTED Disconnect: BCM C2280A. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-3 ohms C251-11 Is the resistance between 108 and 132 ohms? Yes: GO to X7 No: GO to X8
  7. X7 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) CIRCUITS BETWEEN THE BCM (BODY CONTROL MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C2280A-41 ohms C251-3 C2280A-40 ohms C251-11 Are the resistances less than 3 ohms? Yes: GO to X18 No: REPAIR the circuit in question.
  8. X8 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) CIRCUITS BETWEEN THE IPC (INSTRUMENT PANEL CLUSTER) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Disconnect: IPC. Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C220-2 ohms C251-3 C220-1 ohms C251-11 Are the resistances less than 3 ohms? Yes: GO to X23 No: REPAIR the circuit in question.
  9. X9 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) (+) AND MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) (-) CIRCUITS FOR A SHORT TOGETHER Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-3 ohms C251-11 Is the resistance less than 3 ohms? Yes: GO to X11 No: GO to X10
  10. X10 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) CIRCUITS BETWEEN THE BCM (BODY CONTROL MODULE) AND THE DLC (DATA LINK CONNECTOR) FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-3 ohms C251-11 Is the resistance greater than 10, 000 ohms? Yes: REPAIR the DLC or REPAIR the circuit in question. No: A capacitor internal to a module can still be draining, causing irregular resistance readings. WAIT 5 minutes. REPEAT the pinpoint test.
  11. X11 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) (+) AND MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) (-) CIRCUITS FOR A SHORT TOGETHER Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-3 ohms C251-11 Disconnect modules one at a time until the resistance is greater than 5 ohms. APIM (if equipped) BCM C2280A DDM C501B (if equipped) GPSM (if equipped) HVAC module C228B Image Processing Module - B (IPM-B) (if equipped) IPC PDM C652B (if equipped) RFA module C4392D (if equipped) Did the resistance change to greater than 5 ohms with one of the modules disconnected? Yes: For the APIM, GO to X21 For the BCM, GO to X22 For the DDM, GO to X23 For the GPSM, GO to X24 For the HVAC module, GO to X25 For the Image Processing Module - B (IPM-B), GO to X26 For the IPC, GO to X27 For the PDM, GO to X28 For the RFA module, GO to X29 No: REPAIR the circuits.
  12. X12 CHECK THE MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) (+) AND MEDIUM SPEED CONTROLLER AREA NETWORK (MS-CAN) (-) CIRCUITS FOR A SHORT TO GROUND WITH THE MODULES DISCONNECTED Measure Click to display connectors Positive Lead Measurement / Action Negative Lead C251-3 ohms - C251-11 ohms - Disconnect modules one at a time until the resistance to ground is greater than 10, 000 ohms. APIM (if equipped) BCM C2280A DDM C501B (if equipped) GPSM (if equipped) HVAC module C228B Image Processing Module - B (IPM-B) (if equipped) IPC PDM C652B (if equipped) RFA module C4392D (if equipped) Did the resistance change to greater than 10, 000 ohms with one of the modules disconnected? Yes: For the APIM, GO to X21 For the BCM, GO to X22 For the DDM, GO to X23 . For the GPSM, GO to X24 For the HVAC module, GO to X25 For the Image Processing Module - B (IPM-B), GO to X26 For the IPC, GO to X27 For the PDM, GO to X28 For the RFA module, GO to X29 No: REPAIR the circuit in question.
  13. X13 CHECK FOR RESTORED NETWORK COMMUNICATION WITH THE IPC (INSTRUMENT PANEL CLUSTER), HVAC (HEATING, VENTILATION AND AIR CONDITIONING) MODULE, DDM (DRIVER DOOR MODULE), AND THE PDM (PASSENGER DOOR MODULE) DISABLED NOTE: When re-running the network test, close the network test application first or the screen display reverts back to the prior network test results. Disable modules one at a time until other Medium Speed Controller Area Network (MS-CAN) modules pass the network test. Skip to the end once network operation is restored. Disconnect: Body Control Module (BCM) fuse 69 (5A) to disable the IPC. Using a scan tool, perform the network test. Install the removed fuses. Disconnect: Body Control Module (BCM) fuse 73 (5A) to disable the HVAC module (if equipped). Using a scan tool, perform the network test. Install the removed fuses. Disconnect: Body Control Module (BCM) fuses 4 (25A) to disable the DDM (if equipped). Using a scan tool, perform the network test. Install the removed fuse. Disconnect: Body Control Module (BCM) fuse 5 (25A) to disable the PDM (if equipped). Using a scan tool, perform the network test. Do all other Medium Speed Controller Area Network (MS-CAN) modules pass the network test? Yes: INSTALL the removed fuse. If communication was restored with the IPC disabled, GO to «Pinpoint Test G»(ref-515972-S06384597172012120400000) If communication was restored with the HVAC module disabled, GO to «Pinpoint Test J»(ref-515972-S25472465332012120400000) If communication was restored with the DDM disabled, GO to «Pinpoint Test M»(ref-515972-S12451060112012120400000) If communication was restored with the PDM disabled, GO to «Pinpoint Test N»(ref-515972-S23732000032012120400000) No: GO to X14.
  14. X14 VERIFY VEHICLE EQUIPMENT - APIM (ACCESSORY PROTOCOL INTERFACE MODULE) AND GPSM (GLOBAL POSITIONING SYSTEM MODULE) Inspect the vehicle for an APIM or GPSM. Is the vehicle equipped with an APIM or GPSM? Yes: GO to X15 No: GO to X17
  15. X15 CHECK FOR RESTORED COMMUNICATION WITH THE GPSM (GLOBAL POSITIONING SYSTEM MODULE) AND THE APIM (ACCESSORY PROTOCOL INTERFACE MODULE) DISABLED NOTE: When re-running the network test, close the network test application first or the screen display reverts back to the prior network test results. Disconnect: BCM fuse 67 (7.5A) to disable the GPSM and APIM. Using a scan tool, perform the network test. Do all other Medium Speed Controller Area Network (MS-CAN) modules pass the network test? Yes: INSTALL the removed fuse. GO to X16 No: INSTALL the removed fuse. GO to X17
  16. X16 CHECK FOR RESTORED COMMUNICATION WITH THE GPSM (GLOBAL POSITIONING SYSTEM MODULE) DISCONNECTED NOTE: When re-running the network test, close the network test application first or the screen display reverts back to the prior network test results. Disconnect: GPSM (if equipped). Using a scan tool, perform the network test. Do all other Medium Speed Controller Area Network (MS-CAN) modules pass the network test? Yes: CONNECT the GPSM. GO to «Pinpoint Test P»(ref-515972-S27744924872012120400000) No: CONNECT the GPSM. GO to «Pinpoint Test R»(ref-515972-S40555143972012120400000)
  17. X17 VERIFY VEHICLE EQUIPMENT - RFA (REMOTE FUNCTION ACTUATOR) MODULE Inspect the vehicle for an RFA module. Is the vehicle equipped with an RFA module? Yes: GO to X18 No: GO to X19
  18. X18 CHECK FOR RESTORED NETWORK COMMUNICATION WITH THE RFA (REMOTE FUNCTION ACTUATOR) MODULE DISABLED NOTE: When re-running the network test, close the network test application first or the screen display reverts back to the prior network test results. Disconnect: RJB Fuse 2 (10A) to disable the RFA module (if equipped). Using a scan tool, perform the network test. Do all other modules pass the network test? Yes: INSTALL the removed fuse. GO to «Pinpoint Test T»(ref-515972-S10222062932012120400000) No: GO to X19
  19. X19 VERIFY VEHICLE EQUIPMENT - IMAGE PROCESSING MODULE - B (IPM-B) Inspect the vehicle for an Image Processing Module - B (IPM-B). Is the vehicle equipped with an Image Processing Module - B (IPM-B)? Yes: GO to X20 No: GO to «Pinpoint Test I»(ref-515972-S36934978872012120400000)
  20. X20 CHECK FOR RESTORED NETWORK COMMUNICATION WITH THE IMAGE PROCESSING MODULE - B (IPM-B) DISABLED NOTE: When re-running the network test, close the network test application first or the screen display reverts back to the prior network test results. Disconnect: RJB Fuse 29 (5A) to disable the Image Processing Module - B (IPM-B) (if equipped). Using a scan tool, perform the network test. Do all other modules pass the network test? Yes: INSTALL the removed fuse. GO to «Pinpoint Test O»(ref-515972-S13040150982012120400000) No: GO to «Pinpoint Test I»(ref-515972-S36934978872012120400000)
  21. X21 CHECK THE APIM (ACCESSORY PROTOCOL INTERFACE MODULE) FOR CORRECT OPERATION Ignition OFF. Disconnect and inspect the APIM connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the APIM connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new APIM. If equipped with SYNC/AM/FM/CD, REFER to: «ACCESSORY PROTOCOL INTERFACE MODULE (APIM)»(ref-515932-S32782240822012120400000) . If equipped with Sony AM/FM/CD/SYNC, REFER to: «ACCESSORY PROTOCOL INTERFACE MODULE (APIM)»(ref-515933-S13494101232012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  22. X22 CHECK THE BCM (BODY CONTROL MODULE) FOR CORRECT OPERATION Ignition OFF. Disconnect and inspect all the BCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the BCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new BCM. No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  23. X23 CHECK THE DDM (DRIVER DOOR MODULE) FOR CORRECT OPERATION Ignition OFF. Disconnect and inspect all the DDM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the DDM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new DDM. No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  24. X24 CHECK THE GPSM (GLOBAL POSITIONING SYSTEM MODULE) FOR CORRECT OPERATION Ignition OFF. Disconnect and inspect the GPSM connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the GPSM connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new GPSM. If equipped with SYNC/AM/FM/CD, REFER to: «GLOBAL POSITIONING SYSTEM MODULE (GPSM)»(ref-515932-S34596461812012120400000) . If equipped with Sony AM/FM/CD/SYNC, REFER to: «GLOBAL POSITIONING SYSTEM MODULE (GPSM)»(ref-515933-S11142139822012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  25. X25 CHECK THE HVAC (HEATING, VENTILATION AND AIR CONDITIONING) MODULE FOR CORRECT OPERATION Ignition OFF. Disconnect and inspect all the HVAC module connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the HVAC module connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new HVAC module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(ref-515934-S14778149862012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  26. X26 CHECK THE IMAGE PROCESSING MODULE - B (IPM-B) FOR CORRECT OPERATION Ignition OFF. Disconnect and inspect the Image Processing Module - B (IPM-B) connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Image Processing Module - B (IPM-B) connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Image Processing Module - B (IPM-B). REFER to: «IMAGE PROCESSING MODULE B (IPMB) - 4-DOOR»(ref-515935-S24393370542012120400000) . REFER to: «IMAGE PROCESSING MODULE B (IPMB) - 5-DOOR»(ref-515935-S19518492372012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  27. X27 CHECK THE IPC (INSTRUMENT PANEL CLUSTER) FOR CORRECT OPERATION Ignition OFF. Disconnect and inspect the IPC connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the IPC connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new IPC. REFER to: «INSTRUMENT PANEL CLUSTER (IPC)»(ref-515970-S21450118112012120400000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  28. X28 CHECK THE PDM (PASSENGER DOOR MODULE) FOR CORRECT OPERATION Ignition OFF. Disconnect and inspect the PDM connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the PDM connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new PDM. No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
  29. X29 CHECK THE RFA (REMOTE FUNCTION ACTUATOR) MODULE FOR CORRECT OPERATION Ignition OFF. Disconnect and inspect all the RFA module connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the RFA module connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new RFA module. No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Verify BCM fuse 73 (5A) is OK.

PINPOINT TEST Z: NO POWER TO THE DLC (DATA LINK CONNECTOR)

  1. Z1: CHECK THE DLC (DATA LINK CONNECTOR) PINS FOR DAMAGE Ignition OFF. Disconnect the scan tool cable from the DLC. Inspect DLC pins 4, 5 and 16 for damage. Are DLC pins 4, 5 and 16 OK? Yes: GO to Z2 No: REPAIR the DLC as necessary.
  2. Z2 CHECK THE DLC (DATA LINK CONNECTOR) VOLTAGE SUPPLY FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-16 - Is the voltage greater than 11 volts? Yes: GO to Z3 No: VERIFY the BCM fuse 73 (5A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short.
  3. Z3 CHECK THE DLC (DATA LINK CONNECTOR) GROUND CIRCUITS FOR AN OPEN Measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C251-4 ohms - C251-5 ohms - Are the resistances less than 3 ohms? Yes: REPAIR the scan tool. No: REPAIR the circuit in question.

No Communication Between the Integrated Diagnostic System (IDS) and the Vehicle

  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S17418754162012120400000) .
  2. Establish a scan tool session.
  3. Turn ignition to RUN.
  4. The scan tool first attempts to communicate with the PCM. After establishing communication with the PCM, the scan tool then attempts to communicate with all other modules on the vehicle.
  5. If an IDS session cannot be established with the vehicle, IDS may state "No communication can be established with the Powertrain Control Module (PCM)."
  6. Choose "NO" when the scan tool prompts whether or not to retry communication.
  7. Enter a PCM part number, tear tag or calibration number to identify the vehicle and start a session. The PCM part number and 4-character tear tag number are printed on the PCM label. If the PCM part number cannot be found, a base part number search on the HVBOM application (under the OASIS tab on the technician service publication website) retrieves the PCM part number.
  8. If the scan tool cannot communicate with the vehicle after manually entering the PCM part number, diagnose the PCM does not respond to the scan tool. Refer to: «Communications Network»(ref-515972-S05756060702012120400000) .

More articles — Module Communications Network - Except Electric
