Engine Controls - Reference Values (Except Diesel & Hybrid): Diagnosis Ford Focus II facelift

Reference Value Symptom Chart

The Reference Value Symptom Chart provides guidance in selecting the appropriate parameter identification (PID) or measured signal related to the fault area. Select a symptom from the symptom chart along with the category number and go to the Reference Value Parameter Identification (PID)/Measured Signal Chart . For multiple symptoms, select the symptom that is the most evident.

SYMPTOM CHART

Typical Diagnostic Reference Values

Note. Footnotes are referenced throughout the Typical Diagnostic Reference Value Charts. A letter in parentheses next to a value indicates supplemental information is applicable. An attempt is made to provide as much information as possible; some vehicles may not display all input and output signals. The Typical Diagnostic Reference Value Charts do not display fault parameter identifications (PIDs). These are PIDs which indicate a hard fault with the circuit. They display a value of YES or NO and are PIDs ending with the letter F. Reference values may vary 20% depending on operating conditions, altitude, and other factors. RPM values are axle and tire dependent. Values are taken at an altitude of approximately 55.7 meters (600 ft) above sea level. Refer to the appropriate Introduction Information, Acronyms and Definitions for technical terms applicable to Ford Motor Company products. Refer to PARAMETER IDENTIFICATION (PID) , for PID descriptions. For detailed transmission diagnostics, refer to the appropriate Service Information . Transmission signals may be referred to in either alpha or numeric form. For example, 1=A, 2=B, 3=C.

1. A/C on.
2. Cooling fan on (single, low or high speed).
3. Heated oxygen sensors (HO2S) should switch from rich to lean at least once every 3 seconds. HO2S voltage should toggle above and below 0.450 DCV and never be a negative value. Valid HO2S switching occurs only during closed loop fuel control operation.
4. Downstream HO2S(s) stay close to a constant voltage when the catalyst monitor is off (positive value only). When the catalyst monitor is on, the HO2S switches rich to lean above and below 0.450 DCV and never be a negative value. For downstream HO2S(s) (12, 13, 22) greater activity results when the catalyst monitor is active.
5. Brake pedal applied.
6. The electric vapor management valve (VMV) commanded current varies from 0 mA - 1000 mA depending on the powertrain control module (PCM) command to purge the EVAP system.
7. While pressing the transmission control switch (TCS) or switching to manual drive mode.
8. Value is dependent on fuel tank level. Typical operating range is 15% (empty) to 90% (full).
9. Steering wheel turned.
10. Clutch pedal applied.
11. Value is dependent upon ambient air temperature and may fall outside of range.
12. Value is not useful under this condition.
13. If equipped.
14. Transmission in selected range.
15. May change state under this condition.
16. While pressing switch.
17. Value may cycle 5-6 times every 5 seconds.
18. Canister vent duty cycles to 100% (close) when EVAP monitor test is running.
19. Refer to appropriate Service Information .
20. Exhaust gas recirculation (EGR) voltage and duty cycle varies from 0-VBAT or 0-100% depending on EGR demand.
21. RPM dependent. If signal is 0 Hz at idle, check signal at 900 RPM.
22. Crank position.
23. Value may vary 20% depending on altitude, operating conditions, weather, and other factors.
24. The normal operation value is from -1.5 to 3.5 degrees.

Scheme 105

SENSORS/INPUTS - 2.0L 4V FOCUS

ACTUATORS/OUTPUTS - 2.0L 4V FOCUS

OTHER - 2.0L 4V FOCUS

Scheme 106

SENSORS/INPUTS - 2.3L 4V FUSION/MILAN

ACTUATORS/OUTPUTS - 2.3L 4V FUSION/MILAN

OTHER - 2.3L 4V FUSION/MILAN
