Module Controlled Functions
Note. The time-out for the battery saver relay and the accessory delay relay (both are controlled by the SJB) is 1 minute if the vehicle has less than 80 km (50 miles). Once the vehicle passes the approximate mileage threshold of 80 km (50 miles), the time-out for both relays is 10 minutes, as described in the Owner's Literature. For battery saver relay, refer to INTERIOR LIGHTING article. For the accessory delay relay, refer to GLASS, FRAMES AND MECHANISMS article.
Note. The smart junction box (SJB) is also known as the generic electronic module (GEM).
The SJB is located under the instrument panel on the driver side and it controls the following functions
- Battery saver
- Door ajar warning indicator
- Exterior lighting
- Front and rear wipers
- Interior lighting
- Perimeter anti-theft alarm
- Power door lock system
- Remote keyless entry (RKE) system
- Tire pressure monitoring system (TPMS)
- Warning chimes and warning lamps
Smart Junction Box (SJB)
SPECIAL TOOLS - SMART JUNCTION BOX DIAGNOSTIC TESTS Illustration Tool Name Tool Number 73III Automotive Meter 105-R0057 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool - Flex Probe Kit 105-R025C or equivalent
Scheme 68
Scheme 69
SPECIAL TOOLS - SMART JUNCTION BOX REMOVAL/INSTALLATION Illustration Tool Name Tool Number Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
Scheme 70
| Item | Part Number | Description |
|---|---|---|
| 1 | Electrical connectors (2 required) (part of 14A005) | |
| 2 | Electrical connectors (3 required) (part of 14290) | |
| 3 | Electrical connectors (2 required) (part of 14401) | |
| 4 | W701152-S | Smart junction box (SJB) nuts (3 required) |
| 5 | 15604 | SJB |
