Charging System - Generators & Regulators: Specifications Ford Focus II facelift

Charging System 1 illustration ~216 words

GENERAL SPECIFICATIONS

ItemSpecification
Generator
Generator pulley ratio2.40:1
Rating88/150 amps (max) @ 1,800-6,000 generator RPM, approximately 500-2,000 engine RPM
Voltage regulator typeElectronic internal with generator

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

DescriptionNm
Accessory drive splash shield screws5
Center support bracket bolts30
Generator air duct bolts/nuts12
Generator B+ terminal nut12
Generator mounting bolts/nuts47
Generator studs24

TORQUE SPECIFICATIONS

The charging system is a negative ground system consisting of

  1. a generator.
  2. an internal voltage regulator.
  3. a charging system warning indicator.
  4. a battery.
  5. circuitry and cables.

The generator has an internal voltage regulator that is not repairable separately. A new generator and the voltage regulator must be installed as an assembly.

All manual transaxle applications are equipped with a one-way clutch (OWC) in the generator pulley. The OWC pulley temporarily disengages the generator rotor from the front engine accessory drive (FEAD) system during high deceleration rates on the engine, which may increase belt life and decrease belt chirp. A new OWC pulley and generator/voltage regulator must be installed as an assembly.

The generator is belt-driven by the FEAD system. Refer to ACCESSORY DRIVE article. When the engine is started, the generator begins to generate AC which is internally converted to DC. This current is then supplied to the vehicle electrical system through the output (B+) terminal of the generator.

The generator and voltage regulator

  1. supply current to the electrical system.
  2. charge the battery.
  3. adjust the generator field current to increase or decrease the generator output.

Refer to CHARGING SYSTEM - GENERAL INFORMATION article.

Scheme 10

Scheme 10: Generator
ItemPart NumberDescription
1Center support bracket
26C301Front end accessory drive (FEAD) belt
310C392Generator lower air duct
4Center support bracket bolt (3 required)
5W711953Generator B+ terminal nut (part of 10300)
6Generator B+ terminal (part of 14A280)
7W500130Generator bolt
8W520414Generator nuts (2 required)
910300Generator
10W709489Generator studs (2 required)
1110C392Generator upper air duct
