TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Front impact severity sensor bolts | 11 |
| Passenger air bag module bolts | 8 |
| Passenger air bag module screws | 2 |
| Restraints control module (RCM) bolts | 11 |
| Safety belt anchor bolt | 40 |
| Side air bag module nuts | 7 |
| Side air curtain module bolts | 14 |
| Side impact sensor bolts (front door) | 2 |
| Side impact sensor bolts (second row) | 11 |
TORQUE SPECIFICATIONS
(Scheme 1)and (Scheme 2) for supplemental restraint system (SRS) components and their location.
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | 044A74 | Passenger air bag module |
| 2 | 042D94 | Passenger side air curtain |
| 3 | 611D10 | Passenger seat side air bag |
| 4 | 611D11 | Driver seat side air bag |
| 5 | 042D95 | Driver side air curtain |
| 6 | 043B13 | Driver air bag module |
| 7 | 14A664 | Clockspring |
Scheme 2
| Item | Part Number | Description |
|---|---|---|
| 1 | 14B006 | Front impact severity sensors (early production) |
| 2 | Hazard flasher switch (includes passenger air bag deactivation [PAD] indicator) | |
| 3 | 14B345 | Passenger side impact sensor, first row (located in door behind trim panel) |
| 4 | 603B02 | Occupant classification sensor (OCS) system |
| 5 | 61202 | Passenger safety belt buckle and pretensioner (includes safety belt buckle switch and belt tension sensor) |
| 6 | 61203 | Driver safety belt buckle and pretensioner (includes safety belt buckle switch) |
| 7 | Driver seat position sensor (part of 61704) | |
| 8 | 14B345 | Driver side impact sensor, first row (located in door behind trim panel) |
| 9 | 14B321 | Restraints control module (RCM) |
| 10 | 14B321 | Driver side impact sensor, second row |
| 11 | 14B006 | Front impact severity sensor (late production) |
SPECIAL TOOLS - SRS DIAGNOSTIC TESTS Illustration Tool Name Tool Number Flex Probe Kit 105-R025C or equivalent FLUKE 73III Automotive Meter 105-R0057 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
