Rear View Mirrors System: Other Ford Focus II

Exterior Power Mirrors

The exterior power mirrors are controlled by the exterior mirror control switch. The exterior mirror control switch is hardwired to the left and right exterior power mirrors, and either mirror can be selected by moving the mirror select switch to either the right or left exterior mirror position. The exterior mirror control switch supplies voltage and ground to the appropriate exterior rear view mirror motor to move the exterior rear view mirror glass to the desired position.

Heated Exterior Rear View Mirror

The heated exterior rear view mirror feature only functions when the rear window defrost is operating. There is no separate control for heated exterior rear view mirrors. The heated exterior rear view mirror voltage is supplied by the rear window defrost relay through a separate fuse that isolates the heated mirrors from the rear window defrost in the event of a concern. The heated exterior rear view mirrors are heated for a period of 15 minutes when the rear window defrost switch is activated.

Possible Causes

1. circuit 29-AD12 (OG/YE) open
2. circuit 31-AD12 (BK) open
3. circuit 32-ADI (WH/RD) open, short to ground, or short to voltage
4. exterior mirror control switch

Scheme 6

Scheme 7

1. A1 CHECK THE INTERIOR LIGHT OPERATION Check the interior light operation. Do the interior lights operate correctly? Yes : GO to A2 . No : REFER to «INTERIOR LIGHTING»(ref-255440) to diagnose the interior lights.
2. A2 CHECK THE VOLTAGE TO THE EXTERIOR MIRROR CONTROL SWITCH CIRCUIT Disconnect: Exterior Mirror Control Switch C527. Key in ON position. Measure the voltage between the exterior mirror control switch C527-6, circuit 29-AD12 (OG/YE), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to A3 . No : REPAIR the circuit. TEST the system for normal operation.
3. A3 CHECK THE EXTERIOR MIRROR CONTROL SWITCH GROUND CIRCUIT 31-AD12 (BK) Key in OFF position. Measure the resistance between the exterior mirror control switch C527-4, circuit 31-AD12 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to A4 . No : REPAIR the circuit. TEST the system for normal operation.
4. A4 CHECK THE EXTERIOR MIRROR CONTROL SWITCH Carry out the exterior mirror control switch component test. Refer to «EXTERIOR REAR VIEW MIRROR SWITCH (17B676)»(ref-252566-S01757347682007041800000) for component testing. Is the exterior mirror control switch OK? Yes : REPAIR circuit 32-AD1 (WH/RD). TEST the system for normal operation. No : INSTALL a new exterior mirror control switch. TEST the system for normal operation.

1. circuit 32-AD6 (WH) open
2. circuit 32-AD9 (WH/GN) open
3. exterior mirror control switch
4. exterior mirror

Scheme 8

1. B1 CHECK FOR CONTINUITY BETWEEN THE EXTERIOR MIRROR CONTROL SWITCH AND THE INOPERATIVE EXTERIOR MIRROR Disconnect: Inoperative Exterior Mirror C522 (LH) or C622 (RH). Measure the resistance between the exterior mirror control switch C527-3, circuit 32-AD1 (WH/RD), harness side and the inoperative exterior mirror: LH exterior mirror C522-1, circuit 32-AD6 (WH), harness side. RH exterior mirror C622-1, circuit 32-AD9 (WH/GN), harness side. Is the resistance less than 5 ohms? Yes : GO to B2 . No : REPAIR the circuit in question. TEST the system for normal operation.
2. B2 CHECK THE EXTERIOR MIRROR CONTROL SWITCH Carry out the exterior mirror control switch component test. Refer to «EXTERIOR REAR VIEW MIRROR SWITCH (17B676)»(ref-252566-S01757347682007041800000) for component testing. Is the exterior mirror control switch OK? Yes : INSTALL a new exterior mirror. REFER to «EXTERIOR MIRROR»(ref-255448-S10139414162007053100000) in this article. TEST the system for normal operation. No : INSTALL a new exterior mirror control switch. TEST the system for normal operation.

1. circuit 33-AD8 (YE/BU) open, short to voltage, or short to ground
2. circuit 34-AD7 (BU/RD) open, short to voltage, or short to ground
3. circuit 33-AD11 (YE/VT) open, short to voltage, or short to ground
4. circuit 34-AD 10 (BU/YE) open, short to voltage, or short to ground
5. exterior mirror control switch
6. exterior mirror

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. C1 CHECK THE EXTERIOR MIRROR CONTROL SWITCH Carry out the exterior mirror control switch component test. Refer to «EXTERIOR REAR VIEW MIRROR SWITCH (17B676)»(ref-252566-S01757347682007041800000) for component testing. Is the exterior mirror control switch OK? Yes : LH exterior mirror UP/DOWN inoperative, GO to C2 . LH exterior mirror LEFT/RIGHT inoperative, GO to RH exterior mirror UP/DOWN inoperative, GO to C4 . RH exterior mirror LEFT/RIGHT inoperative, GO to C6 . No : INSTALL a new exterior mirror control switch. TEST the system for normal operation
2. C2 CHECK CIRCUIT 34-AD7 (BU/RD) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: LH Exterior Mirror C522. Key in ON position. Measure the voltage between the LH exterior mirror C522-2, circuit 34-AD7 (BU/RD), harness side and ground. Is any voltage present? Yes : REPAIR the circuit. TEST the system for normal operation. No : GO to C3 .
3. C3 CHECK CIRCUIT 34-AD7 (BU/RD) FOR AN OPEN OR A SHORT TO GROUND Key in OFF position. Disconnect: Exterior Mirror Control Switch C527. Measure the resistance between the exterior mirror control switch C527-1, circuit 34-AD7 (BU/RD), harness side and the LH exterior mirror C522-2, circuit 34-AD7 (BU/RD), harness side; and the resistance between the LH exterior mirror C522-2, circuit 34-AD7 (BU/RD), harness side and ground. Is the resistance less than 5 ohms between the exterior mirror control switch and the LH exterior mirror, and greater than 10,000 ohms between the LH exterior mirror and ground? Yes : INSTALL a new LH exterior mirror. REFER to «EXTERIOR MIRROR»(ref-255448-S10139414162007053100000) in this article. TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.
4. C4 CHECK CIRCUIT 33-AD8 (YE/BU) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: LH Exterior Mirror C522. Key in ON position. Measure the voltage between the LH exterior mirror C522-3, circuit 33-AD8 (YE/BU), harness side and ground. Is any voltage present? Yes : REPAIR the circuit. TEST the system for normal operation. No : GO to C5 .
5. C5 CHECK CIRCUIT 33-AD8 (YE/BU) FOR AN OPEN OR A SHORT TO GROUND Key in OFF position. Disconnect: Exterior Mirror Control Switch C527. Measure the resistance between the exterior mirror control switch C527-7, circuit 33-AD8 (YE/BU), harness side and the LH exterior mirror C522-3, circuit 33-AD8 (YE/BU), harness side; and the resistance between the LH exterior mirror C522-3, circuit 33-AD8 (YE/BU), harness side and ground. Is the resistance less than 5 ohms between the exterior mirror control switch and the LH exterior mirror, and greater than 10,000 ohms between the LH exterior mirror and ground? Yes : INSTALL a new LH exterior mirror. REFER to «EXTERIOR MIRROR»(ref-255448-S10139414162007053100000) in this article. TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.
6. C6 CHECK CIRCUIT 34-AD10 (BU/YE) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: RH Exterior Mirror C622. Key in ON position. Measure the voltage between the RH exterior mirror C622-2, circuit 34-AD10 (BU/YE), harness side and ground. Is any voltage present? Yes : REPAIR the circuit. TEST the system for normal operation. No : GO to C7 .
7. C7 CHECK CIRCUIT 34-AD10 (BU/YE) FOR AN OPEN OR A SHORT TO GROUND Key in OFF position. Disconnect: Exterior Mirror Control Switch C527. Measure the resistance between the exterior mirror control switch C527-2, circuit 34-AD10 (BU/YE), harness side and the RH exterior mirror C622-2, circuit 34-AD10 (BU/YE), harness side; and the resistance between the RH exterior mirror C622-2, circuit 34-AD10 (BU/YE), harness side and ground. Is the resistance less than 5 ohms between the exterior mirror control switch and the RH exterior mirror, and greater than 10,000 ohms between the RH exterior mirror and ground? Yes : INSTALL a new RH exterior mirror. REFER to «EXTERIOR MIRROR»(ref-255448-S10139414162007053100000) in this article. TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.
8. C8 CHECK CIRCUIT 33-AD11 (YE/VT) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: RH Exterior Mirror C622. Key in ON position. Measure the voltage between the RH exterior mirror C622-3, circuit 33-AD11 (YE/VT), harness side and ground. Is any voltage present? Yes : REPAIR the circuit. TEST the system for normal operation. No : GO to C9 .
9. C9 CHECK CIRCUIT 33-AD11 (YE/VT) FOR AN OPEN OR A SHORT TO GROUND Key in OFF position. Disconnect: Exterior Mirror Control Switch C527. Measure the resistance between the exterior mirror control switch C527-5, circuit 33-AD11 (YE/VT), harness side and the RH exterior mirror C622-3, circuit 33-AD11 (YE/VT), harness side; and the resistance between the RH exterior mirror C622-3, circuit 33-AD11 (YE/VT), harness side and ground. Is the resistance less than 5 ohms between the exterior mirror control switch and the RH exterior mirror, and greater than 10,000 ohms between the RH exterior mirror and ground? Yes : INSTALL a new RH exterior mirror. REFER to «EXTERIOR MIRROR»(ref-255448-S10139414162007053100000) in this article. TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.

1. fuse
2. circuit 15S-HB2 (GN/BU) open
3. circuit 15S-HB35 (GN/BK) open
4. circuit 15S-HB36 (GN/OG) open
5. circuit 31-HB35 (BK) open
6. circuit 31-HB36 (BK) open
7. exterior mirror glass

Scheme 17

Scheme 18

1. D1 CHECK THE OPERATION OF THE HEATED REAR WINDOW Key in ON position. Press the heated rear window control switch to the ON position. Does the heated rear window operate correctly? Yes : GO to D2 . No : REFER to «GLASS FRAMES AND MECHANISMS»(ref-255396) to diagnose the heated rear window.
2. D2 CHECK THE VOLTAGE TO THE INOPERATIVE EXTERIOR MIRROR Key in OFF position. Disconnect: Inoperative Exterior Mirror C522 (LH) or C622 (RH). Key in ON position. Press the heated rear window control switch to the ON position. Measure the voltage between the: LH exterior mirror C522-4, circuit 15S-HB35 (GN/BK), harness side and ground. RH exterior mirror C622-4, circuit 15S-HB36 (GN/OG), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to D3 . No : VERIFY the central junction box (CJB) fuse 50 (7.5A) is OK. If OK, REPAIR the circuit in question. TEST the system for normal operation.
3. D3 CHECK THE INOPERATIVE EXTERIOR MIRROR GROUND CIRCUIT FOR AN OPEN Key in OFF position. Measure the resistance between: LH exterior mirror C522-5, circuit 31-HB35 (BK), harness side and ground. RH exterior mirror C622-5, circuit 31-HB36 (BK), harness side and ground.
4. Is the resistance less than 5 ohms?

Yes : INSTALL a new heated exterior mirror glass. REFER to EXTERIOR MIRROR GLASS in this article. TEST the system for normal operation.

No : REPAIR the circuit in question. TEST the system for normal operation

Exterior Mirrors - Exploded View

Note. The LH side is shown, the RH side is similar.

Scheme 19

1. For additional information, refer to the procedures in this article.

Interior Rear View Mirror

SPECIAL TOOL(S) Mirror Remover 501-D118 Installer, Rear Mirror 501-025 (T94P-17700-AH)

Scheme 20

Scheme 21

1. Remove the wire cover (if equipped).
2. Remove the compass by pulling down on the compass rearmost edge (if equipped).
3. Insert the special tool between the mirror mount and windshield bracket from the bottom.
4. Release the mirror mount from windshield bracket by pulling the tool away from the windshield.

Scheme 22

Scheme 23

1. Slide the mirror mount over the windshield bracket from the top and adjust the mirror to the up position.
2. Using the special tool, press the mirror assembly downward along the windshield until the mount is seated on windshield bracket.
3. Install compass and wire cover (if equipped).
