Valve Clearance Check

1. Remove the valve cover. For additional information, refer to «VALVE COVER»(ref-255390-S11438998312007053100000) in this article.
2. Use a feeler gauge to measure each valve's clearance and record its location.
3. Select tappets using this formula: tappet thickness = measured clearance + the base tappet thickness - most desirable thickness. Select the tappets and mark the installation location.
4. If any tappets do not measure within specifications, install new tappets in these locations. For additional information, refer to «VALVE TRAIN COMPONENTS - EXPLODED VIEW»(ref-255390-S19306729132007053100000) and «VALVE TAPPETS»(ref-255390-S18186528462007053100000) in this article.

Intake Manifold

MATERIALS

Measuring Gear Backlash. Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Scheme 125

1. With vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-255374) .
2. Remove the cooling fan motor and shroud assembly. For additional information, refer to «ENGINE COOLING»(ref-255386) .
3. Remove the lower intake manifold bolt.
4. Remove the air cleaner outlet pipe. Loosen the clamps. Disconnect the vent tube and remove the outlet pipe.
5. Remove the accelerator snow shield. Detach the evaporative emissions hose pin-type retainer. Remove the screw and pin-type retainer. Remove the snow shield.
6. Disconnect the accelerator cable and speed control cable (if equipped). Disconnect the accelerator and speed control cable (if equipped) from the throttle body. Remove the 3 bolts and position the accelerator control cables and bracket aside.
7. Disconnect the throttle position (TP) sensor electrical connector and wiring harness pin-type retainer.
8. Disconnect the idle air control (IAC) valve electrical connector and wiring harness pin-type retainer.
9. Disconnect the fuel vapor return hose.
10. Disconnect the power brake booster vacuum tube. Depress the quick release locking ring. Pull the vacuum tube out of the quick release fitting.
11. Disconnect the fuel rail pressure and temperature sensor vacuum hose.
12. Detach the wiring harness pin-type retainer.
13. Disconnect the intake manifold runner control (IMRC) actuator electrical connector.
14. Disconnect the manifold absolute pressure (MAP) sensor electrical connector.
15. If equipped, disconnect the secondary air injection (AIR) vacuum supply hose.
16. Disconnect the swirl control valve electrical connector.
17. Remove the bolt and the oil level indicator tube.
18. Remove the 7 intake manifold bolts.
19. Disconnect the swirl valve electrical connectors and pin-type retainers.
20. Remove the 2 bolts and the oil level indicator tube.
21. Remove the 7 intake manifold bolts.
22. Raise the intake manifold enough to gain clearance to disconnect the knock sensor (KS) electrical connector.
23. Disconnect the positive crankcase ventilation (PCV) hose and remove the intake manifold.
24. Remove the exhaust gas recirculation (EGR) tube.

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

1. Inspect and install new intake manifold gaskets if necessary.
2. Install the EGR tube and tighten to 55 Nm (41 lb-ft).
3. Position the intake manifold and connect the PCV hose.
4. Connect the KS electrical connector.
5. Install the intake manifold and the 7 mounting bolts. Tighten to 18 Nm (13 lb-ft).
6. Install the oil level indicator tube and 2 bolts. Tighten to 10 Nm (89 lb-in).
7. Connect the swirl valve electrical connectors and pin-type retainers.
8. Install the intake manifold and the 7 mounting bolts. Tighten to 18 Nm (13 lb-ft).
9. Install the oil level indicator tube and bolt. Tighten to 10 Nm (89 lb-in).
10. Connect the swirl control valve electrical connector.
11. If equipped, connect the AIR vacuum supply hose.
12. Install the lower intake manifold bolt. Tighten to 18 Nm (13 lb-ft).
13. Connect the MAP sensor electrical connector.
14. Connect the IMRC actuator electrical connector.
15. Attach the wiring harness pin-type retainer.
16. Connect the fuel rail pressure and temperature sensor vacuum hose.
17. Connect the power brake booster vacuum tube. Push the vacuum tube into the quick release fitting.
18. Connect the fuel vapor return hose.
19. Connect the IAC valve electrical connector and wiring harness pin-type retainer.
20. Connect the TP sensor electrical connector and wiring harness pin-type retainer.
21. Connect the accelerator cable and speed control cable (if equipped). Install the accelerator cable bracket and 3 bolts. Tighten to 10 Nm (89 lb-in). Connect the accelerator and speed control cable (if equipped) to the throttle body.
22. Install the accelerator control snow shield. Position the snow shield and tighten the retainer to 10 Nm (89 lb-in). Attach the evaporative emissions hose pin-type retainer.
23. Install the air cleaner outlet pipe. Tighten the clamps to 4 Nm (35 lb-in).
24. Install the cooling fan motor and shroud assembly. For additional information, refer to «ENGINE COOLING»(ref-255386) .

Scheme 140

Scheme 141

MATERIALS

MATERIALS

MATERIALS

Engine Front Cover

SPECIAL TOOL(S) Remover, Oil Seal 303-409 (T92C-6700-CH) Installer, Front Oil Seal 303-096 (T74P-6150-A) Steering Pump Pulley Remover 211-016 Steering Pump Pulley Installer 211-185 Installer Set, Teflon® Seal 211-D207

Scheme 142

Scheme 143

Scheme 144

MATERIALS

Scheme 145

Scheme 146

MATERIALS

MATERIALS

MATERIALS

MATERIALS

Cylinder Head

SPECIAL TOOL(S) Alignment Plate, Camshaft 303-465 (T94P-6256-CH)

MATERIALS

Scheme 147

MATERIALS

MATERIALS

MATERIALS

Scheme 148

Scheme 149

Scheme 150

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-255374) .
2. Remove the battery tray. For additional information, refer to «BATTERY MOUNTING AND CABLES»(ref-255404) .
3. Detach the 2 positive battery cable pin-type retainers and position aside.
4. Detach the transmission connector wire harness pin-type retainer and position aside.
5. Remove the 2 nuts and position the heated oxygen sensor (HO2S) and catalyst monitor sensor wire connector bracket aside.
6. Loosen the upper bellhousing-to-engine bolt and stud bolt 5 mm (0.19 in).
7. Remove the oil level indicator and tube. For additional information, refer to «OIL LEVEL INDICATOR AND TUBE»(ref-255390-S18082422762007053100000) in this article.
8. Loosen the 3 (manual transmission) or 2 (automatic transmission) front lower bellhousing-to-engine bolts 5 mm (0.19 in).
9. Loosen the rear lower engine-to-bellhousing bolt and stud bolt 5 mm (0.19 in).
10. Remove the 2 bellhousing-to-oil pan bolts.
11. Remove the 2 oil pan-to-bellhousing bolts.
12. Slide the transmission rearward 5 mm (0.19 in).
13. Remove the 2 bolts and the accessory drive belt splash shield.
14. Drain the engine oil. Install the drain plug. Tighten to 28 Nm (21 lb-ft).
15. Remove the 4 engine front cover-to-oil pan bolts.
16. Remove the 13 bolts and the oil pan.

Scheme 151

Scheme 152

Scheme 153

Scheme 154

1. Clean and inspect all mating surfaces.
2. Apply a 2.5 mm (0.09 in) bead of silicone gasket and sealant to the oil pan-to-engine block and to the oil pan-to-engine front cover mating surface.
3. Position the oil pan onto the engine and install the oil pan bolts finger-tight.
4. Install the 4 engine front cover-to-oil pan bolts. Tighten to 10 Nm (89 lb-in).
5. Tighten the oil pan bolts in the sequence shown. Tighten to 25 Nm (18 lb-ft).
6. Install the accessory drive belt splash shield and the 2 bolts. Tighten to 9 Nm (80 lb-in).
7. Alternate tightening the 1 front bellhousing-to-engine and 1 rear engine-to-bellhousing lower bolts to slide the transmission and engine together. Tighten to 48 Nm (35 lb-ft).
8. Tighten the remaining 1 (automatic transmission) or 2 (manual transmission) lower front bellhousing-to-engine bolt(s) and the remaining rear engine-to-bellhousing stud bolt. Tighten to 48 Nm (35 lb-ft).
9. Install the 2 bellhousing-to-oil pan bolt. Tighten to 48 Nm (35 lb-ft).
10. Install the 2 oil pan-to-bellhousing bolts. Tighten to 48 Nm (35 lb-ft).
11. Install the oil level indicator and tube. For additional information, refer to «OIL LEVEL INDICATOR AND TUBE»(ref-255390-S18082422762007053100000) in this article.
12. Tighten the top bellhousing-to-engine bolt and stud bolt. Tighten to 48 Nm (35 lb-ft).
13. Position the HO2S and catalyst monitor sensor wire connector bracket and install the 2 nuts. Tighten to 25 Nm (18 lb-ft).
14. Position and attach the transmission connector wire harness pin-type retainer.
15. Position and attach the 2 positive battery cable pin-type retainers.
16. Install the battery tray. For additional information, refer to «BATTERY MOUNTING AND CABLES»(ref-255404) .
17. Fill the engine with clean engine oil.

MATERIALS

Scheme 155

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-255374) .
2. Remove the oil pan. For additional information, refer to «OIL PAN»(ref-255390-S08263600652007053100000) in this article.
3. Remove the 2 bolts and the oil pump screen and pickup tube. Discard the gasket.

Oil Level Indicator and Tube

MATERIALS

Scheme 156

Engine Mount

SPECIAL TOOL(S) 3-Bar Engine Support Kit 303-F072

Scheme 157

Scheme 158

Scheme 159

Scheme 160

Scheme 161

1. Remove the expansion tank bolt. To install, tighten to 10 Nm (89 lb-in).
2. Lift the coolant expansion tank out of the retainer and position it aside.
3. Install the special tool.
4. Remove the 2 engine mount nuts. To install, tighten to 90 Nm (66 lb-ft).
5. Remove the 3 bolts and the engine mount. To install, tighten to 48 Nm (35 lb-ft).
6. To install, reverse the removal procedure.

SPECIAL TOOL(S) Heavy Duty Floor Crane 014-00071 or equivalent Spreader Bar 303-D089 (D93P-6001-A3) or equivalent Powertrain Lift with Tilting Plate 014-00765 or equivalent Universal Adapter Brackets 014-0001 Torque Converter Holding Tool 307-346 (T97T-7902-A) Lifting Bracket, Engine 303-050 (T70P-6000) Tie-Rod End Remover 211-001 (TOOL-3290-D) or equivalent Transaxle Plugs 308-152 (T88C-7025-AH) Slide Hammer 100-001 (T50T-100-A) Front Drive Halfshaft Remover 205-241 (T86P-3514-A)

Scheme 162

Scheme 163

Scheme 164

Scheme 165

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

Scheme 171

Scheme 172

Scheme 173

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Scheme 188

Scheme 189

Scheme 190

Scheme 191

Scheme 192

Scheme 193

Scheme 194

Scheme 195

Scheme 196

Scheme 197

Scheme 198

Scheme 199

Scheme 200

Scheme 201

Scheme 202

Scheme 203

Scheme 204

Scheme 205

Scheme 206

Scheme 207

Scheme 208

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

Scheme 217

Scheme 218

Scheme 219

Scheme 220

Scheme 221

Scheme 222

Scheme 223

Scheme 224

Scheme 225

Scheme 226

Scheme 227

Scheme 228

Scheme 229

Scheme 230

Scheme 231

Scheme 232

Scheme 233

Scheme 234

Scheme 235

Scheme 236

Scheme 237

Scheme 238

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-255374) .
2. Release the fuel system pressure. For additional information, refer to «FUEL SYSTEM-GENERAL INFORMATION»(ref-255426) .
3. Remove the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE»(ref-255400) .
4. Remove the battery tray. For additional information, refer to «BATTERY MOUNTING AND CABLES»(ref-255404) .
5. Remove the power steering pump. For additional information, refer to «POWER STEERING»(ref-255380) .
6. Recover the A/C system. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION AND DIAGNOSIS»(ref-255427) .
7. Drain the engine cooling system. For additional information, refer to «ENGINE COOLING»(ref-255386) .
8. Drain the engine oil. Install the drain plug and tighten to 28 Nm (21 lb-ft).
9. Remove the 2 nuts and disconnect the catalytic converter from the muffler assembly. Remove and discard the gasket.
10. Remove the 4 bolts and the catalytic converter support bracket.
11. If equipped, remove the 4 heat shield bolts and position the heat shield aside.
12. Disconnect the exhaust sensor electrical connectors.
13. If equipped, disconnect the upper exhaust sensor electrical connector and retainer.
14. If equipped, disconnect the secondary air injection (AIR) hose.
15. Remove and discard the 7 catalytic converter-to-engine nuts. Position aside the catalytic converter and support with mechanic's wire. Remove and discard the catalytic converter gasket.
16. Loosen the clamp and disconnect the vent tube from the air cleaner outlet pipe.
17. Remove the 2 bolts and detach the air intake resonator from the grommets. Remove the air intake resonator and outlet pipe.
18. Remove the accelerator control snow shield. Detach the evaporative emissions (EVAP) hose pin-type retainer. Remove the screw, the pin-type retainer and the snow shield.
19. Disconnect the accelerator cable and speed control cable (if equipped). Disconnect the accelerator and speed control cable (if equipped) from the throttle body. Remove the 3 bolts and position the accelerator control cables and bracket aside.
20. Disconnect the fuel tube quick connect coupling from the fuel rail and position the fuel tube aside. For additional information, refer to «FUEL SYSTEM-GENERAL INFORMATION»(ref-255426) .
21. Disconnect the evaporative emissions tube. For additional information, refer to «FUEL SYSTEM-GENERAL INFORMATION»(ref-255426) .
22. If equipped, disconnect the AIR hose.
23. If equipped, disconnect the AIR vacuum regulator electrical connector.
24. Disconnect the power brake booster vacuum tube. Depress the quick connect locking ring. Pull the vacuum tube out of the quick connect fitting.
25. Disconnect the exhaust gas recirculation (EGR) valve electrical connector.
26. Disconnect the upper radiator hose, the heater hose and the coolant vent hose from the coolant bypass.
27. Remove the bolt and ground eyelet.
28. Disconnect the fuel charging wiring harness electrical connector and harness retainer.
29. Disconnect the fuel charging wiring harness electrical connector.
30. Disconnect the power distribution wiring harness electrical connector.
31. Detach the wiring harness retainers.
32. Remove the nut and the power distribution wiring harness eyelet.
33. Disconnect the 3 main engine wiring harness electrical connectors and detach the connectors from the bracket.
34. Detach the gearshift cables from the transaxle. Detach the shifter cable from the shift mass. Detach the selector cable from the selector lever.
35. Detach the gearshift cables from the bracket. Detach the shifter cable from the retaining bracket, turning the abutment sleeves counterclockwise. Detach the selector cable from the retaining bracket, turning the abutment sleeves counterclockwise.
36. Remove the clutch slave cylinder supply tube. Remove the clip. Remove the supply tube and secure it to one side using cable ties.
37. Disconnect the reversing lamp switch electrical connector.
38. Disconnect the transmission shifter cable and position it aside.
39. Disconnect the transmission cooler hoses.
40. Disconnect the heater hose from the "T" fitting and position it aside.
41. Disconnect the coolant hoses from the coolant expansion tank.
42. Remove the coolant expansion tank bolt.
43. Remove the coolant expansion tank. Lift the coolant expansion tank out of the retainer.
44. Disconnect the cooling fan electrical connectors.
45. Release the top cooling fan retaining clips, lift up and remove the cooling fan.
46. Disconnect the lower radiator hose.
47. Remove the bolt and the ground cable.
48. Remove the generator cooling pipe.
49. Disconnect the starter motor electrical terminals.
50. Remove the 2 nuts and detach the PSP tube brackets from the stud bolts.
51. Disconnect the A/C compressor electrical connector.
52. Remove the 3 A/C compressor bolts.
53. Loosen the bolt and remove the A/C compressor. Lower the A/C compressor to access the manifold bolt. Discard the O-ring seals.
54. Detach the LH brake hose from the support bracket.
55. Detach the LH caliper. Remove the bolt covers. Remove the 2 bolts.
56. Support the brake caliper.
57. Loosen the LH strut and spring assembly top mount nuts by 4 turns.
58. Remove the nut and disconnect the LH stabilizer bar at the strut.
59. Remove the LH tie-rod end nut.
60. Remove the RH tie-rod end nut.
61. Using the special tool, disconnect both tie rods from the knuckles.
62. Remove the bolts and disconnect both lower control arms from the knuckles.
63. Remove the 2 nuts and the intermediate shaft bearing bracket.
64. Remove the intermediate shaft and RH front drive halfshaft assembly from the transaxle. Position it aside and support with mechanic's wire. Install a plug into the transaxle opening.
65. Using the special tools, remove the LH front drive halfshaft from the transaxle. Position it aside and support with mechanic's wire. Install a plug into the transaxle opening.
66. Remove the 2 bolts and the transaxle roll restrictor.
67. Remove the 3 bolts and the starter.
68. Remove the starter isolator.
69. Remove the 2 lower bellhousing bolts.
70. Remove the 2 oil pan-to-bellhousing bolts.
71. Using the special tools, fasten the engine to the lift table.
72. Remove the 2 engine mount nuts.
73. Remove the transaxle mount center nut.
74. Lower the engine and transaxle assembly from the vehicle.
75. Disconnect the vehicle speed sensor (VSS) electrical connector.
76. Remove the 4 torque converter nuts.
77. Disconnect the output shaft speed (OSS) sensor electrical connector.
78. Disconnect the turbine shaft speed (TSS) sensor electrical connector.
79. Disconnect the solenoid body and the transmission range (TR) sensor electrical connectors.
80. Using the engine crane, remove the engine and transaxle assembly from the lift table.
81. Remove the remaining bellhousing bolts and separate the engine and transmission.
82. Remove and discard the dowel pins.
83. Install the special tool, to prevent damage to the torque converter.

SPECIAL TOOL(S) Heavy Duty Floor Crane 014-00071 or equivalent Spreader Bar 303-D089 (D93P-6001-A3) or equivalent Locking Tool, Flywheel 303-103 (T74P-8375-A) Engine Stand 014-00232 or equivalent Alignment Plate, Camshaft 303-465 (T94P-6256-CH) Timing Peg, Crankshaft 303-507 Holding Fixture, Drive Pinion Flange 205-126 (T78P-4851-A) Adapter for 205-126 (205-072-02) Remover, Oil Seal 303-409 (T92C-6700-CH)

Scheme 239

Scheme 240

Scheme 241

Scheme 242

Scheme 243

Note. For additional information, refer to the exploded view under the assembly procedure in this article.

Scheme 244

Scheme 245

Scheme 246

Scheme 247

Scheme 248

Scheme 249

Scheme 250

Scheme 251

Scheme 252

Scheme 253

Scheme 254

Scheme 255

Scheme 256

Scheme 257

Scheme 258

Scheme 259

Scheme 260

Scheme 261

Scheme 262

Scheme 263

Scheme 264

Scheme 265

Scheme 266

Scheme 267

Scheme 268

Scheme 269

Scheme 270

Scheme 271

Scheme 272

Scheme 273

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

Scheme 279

Scheme 280

Scheme 281

Scheme 282

Scheme 283

Scheme 284

Scheme 285

Scheme 286

Scheme 287

Scheme 288

Scheme 289

Scheme 290

Scheme 291

Scheme 292

Scheme 293

Scheme 294

Scheme 295

Scheme 296

Scheme 297

Scheme 298

Scheme 299

Scheme 300

Scheme 301

Scheme 302

Scheme 303

Scheme 304

Scheme 305

Scheme 306

Scheme 307

Scheme 308

Scheme 309

Scheme 310

Scheme 311

Scheme 312

Scheme 313

Scheme 314

1. Remove the 7 bolts, clutch pressure plate and clutch disc.
2. Install the special tool and remove the flywheel or flexplate.
3. Mount the engine on a suitable engine stand.
4. Disconnect the crankshaft position (CKP) sensor and the wiring harness pin-type retainers.
5. Remove the 3 nuts and the generator heat shield.
6. Remove the nut and disconnect the generator electrical connections and wiring harness retainer.
7. Remove the nut and the wiring harness retainer.
8. Remove the bolt, the 2 stud bolts and the generator.
9. Remove the 2 bolts and the accessory drive belt tensioner.
10. Loosen the bolt and remove the accessory drivebelt idler pulley.
11. If equipped, loosen the bolt and remove the accessory drive belt idler pulley.
12. Remove the 3 bolts and the coolant pump pulley.
13. Remove the 3 bolts and the coolant pump.
14. Disconnect the heater hose from the thermostat housing.
15. Remove the 3 bolts and the thermostat housing.
16. Disconnect the oil pressure sensor electrical connector.
17. Remove the engine oil filter.
18. Remove the 4 bolts and the oil filter adapter. Discard the gasket.
19. Disconnect the knock sensor (KS) electrical connector and pin-type retainer.
20. Remove the lower intake manifold bolt.
21. Disconnect the throttle position (TP) sensor electrical connector and wiring harness pin-type retainer.
22. Disconnect the idle air control (IAC) valve electrical connector and wiring harness pin-type retainer.
23. Disconnect the fuel rail pressure and temperature sensor vacuum hose.
24. Detach the wiring harness pin-type retainer.
25. Disconnect the intake manifold runner control (IMRC) actuator electrical connector.
26. Disconnect the manifold absolute pressure (MAP) sensor electrical connector.
27. If equipped, disconnect the secondary air injection (AIR) vacuum supply hose.
28. Disconnect the swirl control valve electrical connector.
29. Remove the bolt and the oil level indicator tube.
30. Remove the 7 intake manifold bolts.
31. Disconnect the swirl valve electrical connectors and pin-type retainers.
32. Remove the 2 bolts and the oil level indicator and tube.
33. Remove the 7 intake manifold bolts.
34. Disconnect the positive crankcase ventilation (PCV) hose and remove the intake manifold.
35. Remove the exhaust gas recirculation (EGR) tube.
36. Remove the radio interference capacitor bracket bolt and position the bracket aside.
37. Disconnect the wiring harness retainers from the valve cover studs and position aside.
38. Disconnect the fuel charging wiring harness. Disconnect the fuel rail pressure and temperature sensor electrical connector. Disconnect the 4 fuel injector electrical connectors. Detach the wiring harness retainers.
39. Remove the 2 bolts and the fuel rail with the fuel injectors.
40. Disconnect the coil-on-plug and camshaft position (CMP) sensor electrical connectors.
41. Position the rubber boot aside and disconnect the cylinder head temperature (CHT) sensor electrical connector. Remove the wiring harness from the engine.
42. Disconnect and remove the coolant hose.
43. Disconnect the coolant bypass hose.
44. Remove the 4 bolts and the coolant bypass.
45. Disconnect and remove the coolant bypass hose.
46. Remove the bolt and the KS.
47. Remove the 8 bolts and the crankcase vent oil separator.
48. If equipped, remove the block heater.
49. Remove the crankcase vent tube and the coil-on-plugs.
50. Remove the spark plugs and the CHT sensor. Discard the CHT.
51. Remove the bolts and the valve cover.
52. Using the crankshaft pulley bolt, turn the crankshaft clockwise to position the No. 1 piston at TDC. The hole in the crankshaft pulley should be in the 6 o'clock position.
53. Install the special tool in the slots on the rear of both camshafts.
54. Remove the engine plug bolt.
55. Install the special tool.
56. Assemble the special tools using 4 hardened washers in the locations shown.
57. Using the special tools and an air impact wrench, remove the crankshaft pulley. Remove and discard the crankshaft pulley bolt and washer. Remove the crankshaft pulley.
58. Using the special tool, remove the crankshaft front oil seal.
59. Remove and discard the CKP sensor.
60. Remove the 22 bolts and the engine front cover.
61. Remove the timing chain tensioner. Compress the timing chain tensioner, and insert a paper clip into the hole to retain the tensioner. Remove the 2 bolts and timing chain tensioner.
62. Remove the RH timing chain guide.
63. Remove the timing chain.
64. Remove the 2 bolts and the LH timing chain guide.
65. Using the flats on the camshaft to prevent camshaft rotation, remove the bolts and the camshaft sprockets.
66. Remove the oil pump chain tensioner and guide. Release the tension on the tensioner spring. Remove the tensioner and the shoulder bolt. Remove the guide.
67. Remove the oil pump chain and sprockets. Remove the bolt. Remove the chain and sprockets.
68. Mark the position of the camshaft lobes on the No. 1 cylinder for assembly reference.
69. Remove the camshafts from the engine. Loosen the camshaft bearing bolts in the sequence shown, one turn at a time. Repeat until all the tension is released. Remove the camshaft bearing caps. Remove the camshafts.
70. Remove the cylinder head. Remove and discard the 10 cylinder head bolts. Remove the cylinder head. Remove and discard the cylinder head gasket.
71. Remove the cylinder head alignment dowels.
72. Remove the 13 bolts and the oil pan.
73. Remove the 6 bolts and the rear crankshaft seal.
74. Remove the 2 bolts, oil pump pickup tube and gasket.
75. Remove the 4 bolts and the oil pump.
76. Remove the 3 bolts and the intermediate shaft bearing bracket.
77. Make sure the Crankshaft TDC Timing Peg is still installed and the engine is still at Top Dead Center (TDC). Rotate the crankshaft slowly clockwise until the crankshaft balance weight is up against the Crankshaft TDC Timing Peg. (Scheme 314): Installing Crankshaft TDC Timing Peg
78. Mark the balancer unit and shafts on the top for reference that the balancer unit is at TDC. (Scheme 315): Locating Balancer Unit And Shafts Reference Mark
79. NOTE: Due to the precision interior construction of the balancer unit, it should not be disassembled. Remove the 4 bolts and the balancer unit. (Scheme 316): Locating Balancer Unit Bolts
80. Remove the Crankshaft TDC Timing Peg. (Scheme 317): Installing Crankshaft TDC Timing Peg
81. Before removing the pistons, inspect the top of the cylinder bores. If necessary, remove the ridge or carbon deposits from each cylinder using an abrasive pad or equivalent, following manufacturer's instructions.
82. NOTE: Clearly mark the connecting rods, connecting rod caps and connecting rod bearings in numerical order for correct orientation for reassembly. Remove the connecting rod cap bolts and cap. (Scheme 318): Locating Connecting Rod Cap Bolts
83. NOTE: Do not scratch the cylinder walls or crankshaft journals with the connecting rod. Using the Connecting Rod Installer, remove the piston/rod assembly from the engine block. Repeat the previous 2 steps until all the piston/rod assemblies are removed from the engine block. (Scheme 319): Identifying Connecting Rod Installer
84. Remove the bolts in the sequence shown. Remove the main bearing beam. Discard the bolts. (Scheme 320): Identifying Crankshaft Cap Bolts Removing Sequence
85. Remove the crankshaft from the engine block. (Scheme 321): Locating Crankshaft
86. NOTE: If the main bearings are being reused, mark them in order for correct orientation and reassembly. Remove the main bearings from the main bearing beam. (Scheme 322): Locating Main Bearings
87. NOTE: If the main bearings are being reused, mark them in order for correct orientation and reassembly. NOTE: The center bulkhead has the thrust bearing. Remove the main bearings from the cylinder block. (Scheme 323): Locating Main Bearings
88. NOTE: If the oil squirters are being reused, mark them in order for correct location during reassembly. NOTE: The front bulkhead does not have an oil squirter. Remove the 4 oil squirters. (Scheme 324): Locating Oil Squirters
89. Inspect the cylinder block, main bearing beam, pistons and connecting rods. For additional information, refer to «ENGINE SYSTEM-GENERAL INFORMATION»(ref-255392).

SPECIAL TOOL(S) Impact Hammer 307-005 (T59L-100-B) Valve Spring Compressor Set 303-300 (T87C-6565-A) Valve Stem Seal Remover 303-468 (T94P-6510-AH) Valve Stem Seal Replacer 303-470 (T94P-6510-CH) Valve Spring Compressor 303-350 (T89P-6565-A) Compressor, Valve Spring 303-472 (T94P-6565-AH)

Scheme 315

Scheme 316

Scheme 317

Scheme 318

MATERIALS

Scheme 319

Scheme 320

Scheme 321

Scheme 322

Scheme 323

Scheme 324

Scheme 325

1. Remove the bolts and the 2 lifting eyes.
2. Remove and discard the cylinder head temperature (CHT) sensor.
3. Remove the bolts and the exhaust gas recirculation (EGR) valve.
4. Remove the EGR tube.
5. Remove the spark plugs.
6. Remove the 16 tappets.
7. Using the special tools, compress the valve spring and remove the valve spring retainer keys, the valve spring retainers and the valve springs.
8. Inspect the valve spring, valve spring retainer and valve spring retainer key. For additional information, refer to «ENGINE SYSTEM-GENERAL INFORMATION»(ref-255392) .
9. Remove the valves.
10. Using the special tools, remove and discard the valve seals.
11. Inspect the valves. For additional information, refer to «ENGINE SYSTEM-GENERAL INFORMATION»(ref-255392) . Install new parts, as necessary.

Scheme 326

Scheme 327

Scheme 328

Scheme 329

Scheme 330

Scheme 331

1. Install the valves.
2. Lubricate the valve stems and guides with clean engine oil and, using the special tool, install the valve seals onto the cylinder head valve guides.
3. Place the valve spring in position over the valve and install the valve spring retainer.
4. Using the special tools, compress the valve spring and install the valve spring retainer keys.
5. Install the 16 tappets.
6. Install a new CHT sensor. Tighten to 12 Nm (9 lb-ft).
7. Install the spark plugs. Tighten to 12 Nm (9 lb-ft).
8. Install the EGR tube. Tighten to 55 Nm (41 lb-ft).
9. Install the EGR valve, gasket and 2 bolts. Tighten to 20 Nm (15 lb-ft).
10. Install the 2 lifting eyes and the bolts. Tighten to 45 Nm (33 lb-ft).

Engine Block

For engine block, crankshaft and piston assembly installation procedures, refer to ENGINE BLOCK - 2.3L .

Engine (Except Block)

SPECIAL TOOL(S) Heavy Duty Floor Crane 014-00071 or equivalent Spreader Bar 303-D089 (D93P-6001-A3) or equivalent Alignment Plate, Camshaft 303-465 (T94P-6256-CH) Timing Peg, Crankshaft 303-507 Holding Fixture, Drive Pinion Flange 205-126 (T78P-4851-A) Adapter for 205-126 (205-072-02) Installer, Front Oil Seal 303-096 (T74P-6150-A) Installer, Crankshaft Rear Main Oil Seal 303-328 (T88P-6701-B1) Aligner, Clutch Disc 308-006 (T71P-7137-H)

Scheme 332

Scheme 333

Scheme 334

Scheme 335

Scheme 336

Scheme 337

Scheme 338

Scheme 339

MATERIALS

Scheme 340

Identifying Lower Engine Block Components (View 2). Scheme 341

ITEM DESCRIPTION

Scheme 342

Scheme 343

Scheme 344

Scheme 345

Scheme 346

Scheme 347

Scheme 348

Scheme 349

Scheme 350

Scheme 351

Scheme 352

Scheme 353

Scheme 354

Scheme 355

Scheme 356

Scheme 357

Scheme 358

Scheme 359

Scheme 360

Scheme 361

Scheme 362

Scheme 363

Scheme 364

Scheme 365

Scheme 366

Scheme 367

Scheme 368

Scheme 369

Scheme 370

Scheme 371

Scheme 372

Scheme 373

Scheme 374

Scheme 375

Scheme 376

Scheme 377

Scheme 378

Scheme 379

Scheme 380

Scheme 381

Scheme 382

Scheme 383

Scheme 384

Scheme 385

Scheme 386

Scheme 387

Scheme 388

Scheme 389

Scheme 390

Scheme 391

Scheme 392

Scheme 393

Scheme 394

Scheme 395

Scheme 396

Scheme 397

Scheme 398

Scheme 399

Scheme 400

Scheme 401

Scheme 402

Scheme 403

Scheme 404

Scheme 405

Scheme 406

Scheme 407

Scheme 408

Scheme 409

Scheme 410

Scheme 411

Scheme 412

Scheme 413

Scheme 414

Scheme 415

Scheme 416

Scheme 417

Scheme 418

Scheme 419

Scheme 420

Scheme 421

Scheme 422

Scheme 423

Scheme 424

Scheme 425

Scheme 426

Scheme 427

Scheme 428

Scheme 429

Scheme 430

Scheme 431

Scheme 432

Scheme 433

Scheme 434

Scheme 435

Scheme 436

Scheme 437

Scheme 438

1. NOTE: If the oil squirters are being reused, they must be installed in the same location as marked during disassembly. NOTE: The front bulkhead does not have an oil squirter. Install the 4 oil squirters. Tighten to 4 Nm (35 lb-in). (Scheme 348): Locating Oil Squirters
2. Measure each of the crankshaft main bearing journal diameters in at least 2 directions and record the smallest diameter for each journal. (Scheme 349): Identifying Measuring Directions Of Crankshaft Main Bearing Journal Diameter
3. Position the main bearing beam in the engine block with the main bearing beam mounted flush with the rear face of the engine block. (Scheme 350): Locating Main Bearing Beam
4. Using the original main bearing beam bolts, install and tighten the 10 main bearing beam bolts. Tighten the bolts in the sequence shown in 3 stages. Stage 1: Tighten to 5 Nm (44 lb-in). Stage 2: Tighten to 25 Nm (18 lb-ft). Stage 3: Tighten an additional 90 degrees. (Scheme 351): Identifying Main Bearing Beam Bolts Tightening Sequence
5. Measure each crankshaft block main bearing bore diameter. Remove the bolts and the main bearing beam. Discard the main bearing beam bolts. (Scheme 352): Identifying Crankshaft Block Main Bearing Bore Diameter
6. Using the chart, select the crankshaft main bearings. (Scheme 353): Crankshaft Main Bearings Chart
7. NOTE: The rod cap installation must keep the same orientation as marked during disassembly or engine damage may occur. Using the original connecting rod cap bolts, install the connecting caps and bolts. Tighten the bolts in 2 stages. Stage 1: Tighten to 29 Nm (21 lb-ft). Stage 2: Tighten an additional 90 degrees.
8. Measure the connecting rod large end bore in 2 directions. Record the smallest measurement for each connecting rod. Remove the bolts and the connecting rod cap. Discard the connecting rod cap bolts. (Scheme 354): Identifying Connecting Rod Large End Bore Measuring Directions
9. Measure each of the crankshaft connecting rod bearing journal diameters in at least 2 directions. Record the smallest measurement for each connecting rod journal. (Scheme 355): Identifying Measuring Directions Of Crankshaft Connecting Rod Bearing Journal Diameters
10. Using the chart, select the correct connecting rod bearings for each crankshaft connecting rod journal. (Scheme 356): Connecting Rod Bearings Chart
11. NOTE: Before assembling the cylinder block, all sealing surfaces must be free of chips, dirt, paint and foreign material. Also, make sure the coolant and oil passages are clear. NOTE: If reusing the crankshaft main bearings, install them in their original positions and orientation as noted during disassembly. NOTE: The center bulkhead is the thrust bearing. Lubricate the upper crankshaft main bearings with clean engine oil and install the 5 crankshaft main bearings in the cylinder block. (Scheme 357): Locating Upper Crankshaft Main Bearings
12. NOTE: If reusing the crankshaft main bearings, install them in their original positions and orientation as noted during disassembly. Lubricate the crankshaft main bearings with clean engine oil and install the 5 crankshaft main bearings in the main bearing beam. (Scheme 358): Locating Crankshaft Main Bearings
13. Lubricate journals on the crankshaft with clean engine oil.
14. Position the crankshaft in the cylinder block. (Scheme 359): Locating Crankshaft
15. Lubricate the 10 main bearing beam side fit surfaces (front 2 shown) with clean engine oil. (Scheme 360): Locating Main Bearing Beam Side Fit Surfaces
16. Lubricate the crankshaft bearing journals on the main bearing beam with clean engine oil. Then position the main bearing beam in the engine block with the main bearing beam mounted flush with the rear face of the engine block. (Scheme 361): Locating Main Bearing Beam
17. NOTE: Lubricate the main bearing beam bolts threads and under the bolt heads with clean engine oil. NOTE: Position the crankshaft to the rear of the cylinder block, then position the crankshaft to the front of the cylinder block before tightening the main bearing beam bolts. Install and tighten the 10 new main bearing beam bolts. Tighten the bolts in the sequence shown in 3 stages. Stage 1: Tighten to 5 Nm (44 lb-in). Stage 2: Tighten to 25 Nm (18 lb-ft). Stage 3: Tighten an additional 90 degrees. (Scheme 362): Identifying Main Bearing Beam Bolts Tightening Sequence
18. Using the Dial Indicator Gauge with Holding Fixture, measure crankshaft end play. Position the crankshaft to the rear of the cylinder block. Zero the Dial Indicator Gauge with Holding Fixture. Move the crankshaft to the front of the cylinder block. Note and record the crankshaft end play. Acceptable crankshaft end play is 0.22-0.43 mm (0.008-0.016 in). If the crankshaft end play exceeds the specified range, install new parts as necessary. (Scheme 363): Measuring Crankshaft End Play
19. NOTE: Be sure not to scratch the cylinder wall or crankshaft journal with the connecting rod. Push the piston down until the connecting rod bearing seats on the crankshaft journal. NOTE: Lubricate the pistons, piston rings, connecting rod bearings and the entire cylinder bores with clean engine oil. NOTE: Make sure the piston arrow on top is facing toward the front of the engine. Using the Piston Ring Compressor and the Connecting Rod Installer, install the piston and connecting rod assemblies. When installing the pistons and connecting rod assemblies, the oil ring gaps must be positioned 60 degrees apart from each other and a minimum of 90 degrees from the expander gap. The position of the upper and lower compression ring gaps are not controlled for installation. (Scheme 364): Identifying Piston Ring Compressor And Connecting Rod Installer
20. NOTE: The rod cap installation must keep the same orientation as marked during disassembly or engine damage may occur. NOTE: Install connecting rod caps and bolts on the connecting rods for cylinders 1 and 4 first and tighten. Then rotate crankshaft 180 degrees and install connecting rod caps and bolts on connecting rods for cylinders 2 and 3 and tighten. NOTE: After installation of each connecting rod cap, rotate the crankshaft to verify smooth operation. Install the connecting rod caps and the new bolts. Tighten the bolts in 2 stages. Stage 1: Tighten to 29 Nm (21 lb-ft). Stage 2: Tighten an additional 90 degrees. (Scheme 365): Locating Connecting Rod Cap Bolts
21. Install the Crankshaft TDC Timing Peg and rotate the crankshaft slowly clockwise until the crankshaft balance weight is up against the Crankshaft TDC Timing Peg. The engine is now at Top Dead Center (TDC). (Scheme 366): Installing Crankshaft TDC Timing Peg
22. NOTE: Due to the precision interior construction of the balancer unit, it should not be disassembled. NOTE: The original adjustment shims must be installed in their original position. NOTE: Confirm by visual inspection that there is no damage to the balancer unit gear and verify that the shaft turns smoothly. If there is any damage or malfunction, replace the balancer unit. Install the adjustment shims in their original position on the seat faces of the balancer unit.
23. With the balancer unit shaft marks in the TDC position, slowly install the balancer unit to the cylinder block to avoid interference between the crankshaft drive gear and the balancer unit driven gear. (Scheme 367): Locating Balancer Unit And Shafts Reference Mark
24. Install the balancer unit bolts. Tighten in the sequence shown in 2 stages. Stage 1: Tighten to 25 Nm (18 lb-ft). Stage 2: Tighten to 50 Nm (37 lb-ft). (Scheme 368): Identifying Balancer Unit Bolts Tightening Sequence
25. Remove the Crankshaft TDC Timing Peg. see scheme 403: Installing Crankshaft TDC Timing Peg
26. Rotate the crankshaft to confirm that there are no meshing problems between the balancer unit gear and the crankshaft gear.
27. Install the Crankshaft TDC Timing Peg and rotate the crankshaft slowly clockwise until the crankshaft balance weight is up against the Crankshaft TDC Timing Peg. Remove the Crankshaft TDC Timing Peg. (Scheme 369): Installing Crankshaft TDC Timing Peg
28. NOTE: Measure the backlash and verify that it is within specified range at all of the following 6 positions: 10 degrees, 30 degrees, 100 degrees, 190 degrees, 210 degrees and 280 degrees. It will be necessary to reset the measuring equipment between measurements. NOTE: The measurement must be taken with the Dial Indicator Gauge with Holding Fixture, a 5-mm Allen wrench and worm clamp set up as shown. Mark the Allen wrench with a file 80 mm (3.149 in) above the driven gear shaft center. Make sure the worm clamp and Allen wrench are not touching the balance shaft housing. NOTE: For an accurate measurement while measuring the gear backlash, insert a screwdriver as shown into the crankshaft No. 1 crankweight area and set both the rotation and the thrust direction with the screwdriver, using a prying action as shown. Position the Dial Indicator Gauge with Holding Fixture as shown. Measure the gear backlash. Position the Dial Indicator Gauge with Holding Fixture (1) on the Allen wrench 80 mm (3.149 in) above the driven gear shaft center (2) on the balancer unit. Rotate the crankshaft clockwise and measure the backlash at all of the following 6 positions: 10 degrees, 30 degrees, 100 degrees, 190 degrees, 210 degrees and 280 degrees. Backlash specifications are 0.005 to 0.101 mm (0.00019 to 0.0039 in). If the backlash exceeds the specified range, carry out the balance shaft backlash procedure. For additional information, refer to the «Balance Shaft Backlash»(ref-255390-S14202306712010040500000) procedure in this section. (Scheme 370): Measuring Gear Backlash All vehicles
29. Install the intermediate shaft bearing bracket and 3 bolts. Tighten to 40 Nm (30 lb-ft).
30. Turn the crankshaft clockwise to position the No. 1 piston at TDC.
31. Remove the engine plug bolt.
32. Install the special tool.
33. Install the oil pump assembly. Tighten the 4 bolts in the sequence shown in 2 stages. Stage 1: Tighten to 10 Nm (89 lb-in). Stage 2: Tighten to 20 Nm (15 lb-ft).
34. Install a new oil pump pickup tube gasket and the pickup tube. Tighten to 10 Nm (89 lb-in).
35. Using the special tool, install the crankshaft rear main oil seal.
36. Tighten the 6 crankshaft rear main oil seal bolts in the sequence shown to 10 Nm (89 lb-in).
37. Clean and inspect all mating surfaces.
38. Apply a 2.5 mm (0.10 in) bead of silicone gasket and sealant to the oil pan. Install the oil pan. Install the 2 oil pan bolts finger-tight.
39. Using a suitable straight edge, align the front surface of the oil pan flush with the front surface of the engine block.
40. Install the remaining 13 oil pan bolts and tighten the oil pan bolts in the sequence shown to 25 Nm (18 lb-ft).
41. Install the cylinder head alignment dowels. Dowels must be fully seated in the cylinder block.
42. Clean the cylinder head-to-cylinder block mating surface of both the cylinder head and the cylinder block. Remove any large deposits of silicone or gasket material with a plastic scraper. Apply silicone gasket remover, following package directions, and allow to set for several minutes. Remove the silicone gasket remover with a plastic scraper. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep, following package directions, to remove any traces of oil or coolant, and to prepare the surfaces to bond with the new gasket. Do not attempt to make the metal shiny. Some staining of the metal surfaces is normal.
43. Apply silicone gasket and sealant to the locations shown.
44. Install a new head gasket.
45. Install 10 new cylinder head bolts. Tighten the bolts in the sequence shown in 5 stages. Stage 1: Tighten to 5 Nm (44 lb-in). Stage 2: Tighten to 15 Nm (11 lb-ft). Stage 3: Tighten to 45 Nm (33 lb-ft). Stage 4: Turn 90 degrees. Stage 5: Turn an additional 90 degrees.
46. Install the camshafts and bearing caps. Tighten the bolts in the sequence shown in 3 stages. Stage 1: Tighten one turn at a time until tight. Stage 2: Tighten to 7 Nm (62 lb-in). Stage 3: Tighten to 16 Nm (12 lb-ft).
47. Install the crankshaft sprocket, crankshaft sprocket diamond washers, oil pump chain and oil pump sprocket. The crankshaft sprocket flange must be facing away from the engine block.
48. Install the oil pump chain, sprocket and bolt. Tighten to 25 Nm (18 lb-ft).
49. Install the oil pump chain guide and the 3 shoulder bolts. Tighten to 10 Nm (89 lb-in).
50. Install the oil pump chain tensioner. Hook the tensioner spring around the shoulder bolt. Tighten to 10 Nm (89 lb-in).
51. Install the special tool in the slots on the rear of both camshafts.
52. Install the camshaft sprockets and the bolts. Do not tighten the bolts at this time.
53. Install the LH timing chain guide and the 2 bolts. Tighten to 10 Nm (89 lb-in).
54. Install the timing chain.
55. Install the RH timing chain guide.
56. Using the edge of a vise, compress the timing chain tensioner plunger.
57. Using a small pick, push back and hold the ratchet mechanism.
58. While holding the ratchet mechanism, push the ratchet arm back into the tensioner housing.
59. Install a paper clip into the hole in the tensioner housing to hold the ratchet assembly and the plunger in during installation.
60. Install the timing chain tensioner and the 2 bolts. Remove the paper clip to release the piston. Tighten to 10 Nm (89 lb-in).
61. Using the flats on the camshafts to prevent camshaft rotation, tighten the camshaft sprocket bolts to 72 Nm (53 lb-ft).
62. Clean and inspect the mounting surfaces of the engine and the front cover.
63. Apply a 2.5 mm (0.10 in) bead of silicone gasket and sealant to the cylinder head and oil pan joint areas. Apply a 2.5 mm (0.10 in) bead of silicone gasket and sealant to the front cover.
64. Install the engine front cover. Tighten the 22 bolts in the sequence shown to the following specifications: Tighten the 8 mm bolts to 10 Nm (89 lb-in). Tighten the 13 mm bolts to 48 Nm (35 lb-ft).
65. Using the special tool, install a new crankshaft front oil seal.
66. Position the crankshaft pulley onto the crankshaft with the hole in the pulley at the 6 o'clock position.
67. Install a standard 6 mm (0.23 in) x 18 mm (0.7 in) bolt through the crankshaft pulley and thread it into the front cover.
68. Assemble the special tools using 4 hardened washers in the locations shown.
69. Install a new crankshaft pulley bolt. Using the special tools to hold the crankshaft pulley in place, tighten the crankshaft pulley bolt in 2 stages: Stage 1: Tighten to 100 Nm (74 lb-ft). Stage 2: Tighten an additional 90 degrees (1/4 turn).
70. Remove the 6 mm (0.23 in) x 18 mm (0.7 in) bolt.
71. Remove the special tool.
72. Remove the special tool.
73. Turn the crankshaft clockwise 1 and 3/4 turns.
74. Install the special tool.
75. Turn the crankshaft clockwise until the crankshaft contacts the special tool.
76. Using the 6 mm (0.23 in) x 18 mm (0.7 in) bolt, check the position of the crankshaft pulley. If it is not possible to install the bolt, the engine valve timing must be corrected.
77. Using the special tool, check the position of the camshafts. If it is not possible to install the special tool, the engine valve timing must be corrected.
78. Remove the special tool.
79. Install a new CKP sensor and the 2 bolts. Do not tighten the bolts at this time.
80. Adjust the CKP sensor with the alignment tool. Tighten the 2 CKP bolts to 7 Nm (62 lb-in).
81. Remove the 6 mm (0.23 in) x 18 mm (0.7 in) bolt.
82. Remove the special tool.
83. Install the engine plug bolt. Tighten to 20 Nm (15 lb-ft).
84. Clean the valve cover gasket surface with metal surface cleaner.
85. Apply silicone gasket and sealant to the locations shown.
86. Install the valve cover. Tighten the 14 bolts in the sequence shown to 10 Nm (89 lb-in).
87. Install a new cylinder head temperature (CHT) sensor and the spark plugs. Tighten the CHT sensor to 12 Nm (9 lb-ft). Tighten the spark plugs to 12 Nm (9 lb-ft).
88. Install the 4 coil-on-plugs, 4 bolts and the crankcase vent tube. Tighten to 10 Nm (89 lb-in).
89. If equipped, install the block heater. Tighten to 21 Nm (15 lb-ft).
90. Install the crankcase vent oil separator and the KS. Tighten the 8 oil separator bolts to 10 Nm (89 lb-in). Tighten the KS to 20 Nm (15 lb-ft).
91. Install the coolant bypass hose.
92. Using a new gasket, install the coolant bypass and 4 bolts. Tighten to 10 Nm (89 lb-in).
93. Connect the coolant bypass hose.
94. Install the coolant hose.
95. Position the engine control wiring harness on the engine and connect the CHT sensor and install the rubber boot.
96. Connect the coil-on-plug and camshaft position (CMP) sensor electrical connectors.
97. Install new fuel injector O-rings. Separate the fuel injectors from the fuel rail. Remove and discard the fuel injector O-rings. Install new O-rings and lubricate with clean engine oil. Install the fuel injectors onto the fuel rail.
98. Install the fuel rail with the fuel injectors and the 2 bolts. Tighten to 25 Nm (18 lb-ft).
99. Connect the fuel charging wiring harness. Connect the fuel rail pressure and temperature sensor electrical connector. Connect the 4 fuel injector electrical connectors. Attach the wiring harness retainers.
100. Connect the wiring harness retainers to the valve cover studs.
101. Install the radio interference capacitor bracket and bolt. Tighten to 10 Nm (89 lb-in).
102. Install the EGR tube. Tighten to 55 Nm (41 lb-ft).
103. Inspect and install new intake manifold gaskets if necessary.
104. Position the intake manifold and connect the positive crankcase ventilation (PCV) hose.
105. Install the intake manifold and the 7 mounting bolts. Tighten to 18 Nm (13 lb-ft).
106. Install the oil level indicator tube assembly and 2 bolts.
107. Connect the swirl valve electrical connectors and pin-type retainers.
108. Install the intake manifold and the 7 mounting bolts. Tighten to 18 Nm (13 lb-ft).
109. Install the oil level indicator tube assembly and bolt. Tighten to 10 Nm (89 lb-in).
110. Connect the swirl control valve electrical connector.
111. If equipped, connect the secondary air injection (AIR) vacuum supply hose.
112. Connect the manifold absolute pressure (MAP) electrical connector.
113. Connect the intake manifold runner control (IMRC) actuator electrical connector.
114. Attach the wiring harness pin-type retainer.
115. Connect the fuel rail pressure and temperature sensor vacuum hose.
116. Connect the idle air control (IAC) valve electrical connector and wiring harness pin-type retainer.
117. Connect the throttle position (TP) sensor electrical connector and wiring harness pin-type retainer.
118. Install the lower intake bolt. Tighten to 18 Nm (13 lb-ft).
119. Connect the KS electrical connector and pin-type retainer.
120. Install the oil filter adapter with a new gasket. Tighten to 25 Nm (18 lb-ft).
121. Install a new oil filter. Tighten the oil filter 3/4 turn after the oil filter gasket makes contact with the oil filter adapter.
122. Connect the oil pressure sensor electrical connector.
123. Install the thermostat housing and 3 bolts. Tighten to 10 Nm (89 lb-in).
124. Connect the heater hose to the thermostat housing.
125. Position the coolant pump and install the 3 bolts. Tighten to 10 Nm (89 lb-in).
126. Install the coolant pump pulley and 3 bolts. Tighten to 20 Nm (15 lb-ft).
127. If equipped, install the accessory drive belt idler pulley. Tighten to 25 Nm (18 lb-ft).
128. Install the accessory drive belt idler pulley. Tighten to 25 Nm (18 lb-ft).
129. Install the accessory drivebelt tensioner and 2 bolts. Tighten to 25 Nm (18 lb-ft).
130. Install the generator, bolt and 2 stud bolts. Tighten to 25 Nm (18 lb-ft).
131. Install the wiring harness retainer and nut. Tighten to 25 Nm (18 lb-ft).
132. Connect the generator electrical connections, harness retainer and install the nut. Tighten to 8 Nm (71 lb-in).
133. Install the generator heat shield and 2 nuts. Tighten to 18 Nm (13 lb-ft).
134. Connect the CKP sensor and the wiring harness pin-type retainers.
135. Using the heavy duty floor crane and spreader bar, remove the engine from the engine stand.
136. Install the flexplate and the 6 bolts. Tighten the bolts in the sequence shown in 3 stages: Stage 1: Tighten to 50 Nm (37 lb-ft). Stage 2: Tighten to 80 Nm (50 lb-ft). Stage 3: Tighten to 112 Nm (83 lb-ft).
137. Lubricate the transaxle input shaft pilot bearing with front axle grease.
138. Using the special tool, position the clutch disc on the flywheel.
139. Position the clutch pressure plate and install the 7 bolts. Tighten the bolts in a star pattern sequence to 27 Nm (20 lb-ft).

SPECIAL TOOL(S) Heavy Duty Floor Crane 014-00071 or equivalent Spreader Bar 303-D089 (D93P-6001-A3) or equivalent Powertrain Lift with Tilting Plate 014-00765 or equivalent Universal Adapter Brackets 014-0001 Lifting Brackets, Engine 303-050 (T70P-6000)

Scheme 439

Scheme 440

Scheme 441

MATERIALS

Scheme 442

Scheme 443

Scheme 444

Scheme 445

Scheme 446

Scheme 447

Scheme 448

Scheme 449

Scheme 450

Scheme 451

Scheme 452

Scheme 453

Scheme 454

Scheme 455

Scheme 456

Scheme 457

Scheme 458

Scheme 459

Scheme 460

Scheme 461

Scheme 462

Scheme 463

Scheme 464

Scheme 465

Scheme 466

Scheme 467

Scheme 468

Scheme 469

Scheme 470

Scheme 471

Scheme 472

Scheme 473

Scheme 474

Scheme 475

Scheme 476

Scheme 477

Scheme 478

Scheme 479

Scheme 480

Scheme 481

Scheme 482

Scheme 483

Scheme 484

Scheme 485

Scheme 486

Scheme 487

Scheme 488

Scheme 489

Scheme 490

Scheme 491

Scheme 492

Scheme 493

Scheme 494

Scheme 495

Scheme 496

Scheme 497

Scheme 498

Scheme 499

Scheme 500

Scheme 501

Scheme 502

Scheme 503

Scheme 504

Scheme 505

Scheme 506

Scheme 507

Scheme 508

Scheme 509

Scheme 510

1. Check the installation depth of the torque converter. Lay a straightedge on the automatic transaxle flange. Check the installation depth between the transaxle flange and the torque converter centering spigot for the correct clearance.
2. Install new dowel pins in the engine block.
3. Using the engine crane, install the transaxle onto the engine. Install the 2 bolts at the dowel pins. Tighten to 48 Nm (35 lb-ft). Install the remaining bolts. Tighten to 48 Nm (35 lb-ft).
4. Using the special tools, raise the engine and transaxle assembly onto the lift cable.
5. Using the special tools, secure the engine and transaxle assembly to the lift table.
6. Connect the solenoid body and the transmission range (TR) sensor electrical connectors.
7. Connect the turbine shaft speed (TSS) sensor electrical connector.
8. Connect the output shaft speed (OSS) sensor electrical connector.
9. Install the 4 torque converter nuts. Tighten to 35 Nm (26 lb-ft).
10. Connect the vehicle speed sensor (VSS) electrical connector.
11. Using the lift table, position the engine and transaxle assembly in the vehicle.
12. Install the transaxle mount center nut. Tighten to 133 Nm (98 lb-ft).
13. Install the 2 motor mount nuts. Tighten to 90 Nm (66 lb-ft).
14. Install the 2 oil pan-to-bellhousing bolts. Tighten to 48 Nm (35 lb-ft).
15. Install the 2 lower bellhousing-to-oil pan bolts. Tighten to 48 Nm (35 lb-ft).
16. Install the starter motor isolator.
17. Install the starter motor and the 3 bolts. Tighten to 25 Nm (18 lb-ft).
18. Install the transaxle roll restrictor and 2 bolts. Tighten to 48 Nm (35 lb-ft).
19. Install the LH front drive halfshaft.
20. Install the RH front halfshaft together with the intermediate shaft.
21. Install the front drive intermediate shaft bearing mounting bracket. Tighten to 25 Nm (18 lb-ft).
22. Install both of the lower control arms to the knuckles. Connect the suspension arm ball joint. Install the bolt. Tighten to 63 Nm (46 lb-ft).
23. Install both of the tie-rod ends to the knuckles. Tighten to 40 Nm (30 lb-ft).
24. Connect the stabilizer bar to the LH strut and install the nut. Tighten to 55 Nm (41 lb-ft).
25. Tighten the LH strut and spring assembly top mount nuts. Tighten to 30 Nm (22 lb-ft).
26. Install the caliper. Position the caliper and install the bolts. Tighten to 28 Nm (21 lb-ft). Install the bolt covers.
27. Install the brake hose onto the support bracket.
28. Install the manifold and tube assembly onto the A/C compressor. Tighten to 21 Nm (15 lb-ft).
29. Install the A/C compressor and the 3 bolts. Tighten to 25 Nm (18 lb-ft).
30. Connect the A/C compressor electrical connector.
31. Install the power steering pressure (PSP) tube brackets and nuts. Tighten to 11 Nm (8 lb-ft).
32. Connect the starter motor electrical connections. Tighten the small nut to 5 Nm (44 lb-in). Tighten the large nut to 12 Nm (9 lb-ft).
33. Install the generator coolant pipe.
34. Position the ground cable and install the bolt. Tighten to 48 Nm (35 lb-ft).
35. Connect the lower radiator hose.
36. Install the cooling fan.
37. Connect the cooling fan electrical connectors.
38. Install the coolant expansion tank and the bolt. Tighten to 10 Nm (89 lb-in).
39. Connect the coolant hoses.
40. Connect the heater hose to the "T" fitting.
41. Connect the transmission cooler hoses.
42. Connect the transmission shifter cable.
43. Connect the reversing lamp switch electrical connector.
44. Connect the clutch slave cylinder supply tube. Install the clip.
45. Attach the transaxle cables to the bracket. Attach the shifter cable to the bracket, turning the abutment sleeves counterclockwise to open. Position the cables into the metal holders. Attach the selector cable to the bracket, turning the abutment sleeves counterclockwise to open. Position the cables into the metal holders.
46. Attach the gearshift cables. Attach the shifter cable to the shift mass. Attach the selector cable to the selector lever.
47. Adjust the gearshift cables and bleed the clutch system. For additional information, refer to «MANUAL TRANSAXLE-TRANSMISSION AND CLUTCH - GENERAL INFORMATION»(ref-255428) .
48. Connect the 3 main engine wiring harness connectors and attach the connectors to the bracket.
49. Connect the power distribution harness eyelet and install the nut. Tighten to 10 Nm (89 lb-in).
50. Attach the wiring harness retainers.
51. Connect the power distribution wiring harness electrical connector.
52. Connect the fuel charging wiring harness electrical connector.
53. Connect the fuel charging wiring harness electrical connector and harness retainer.
54. Install the ground eyelet and bolt. Tighten to 10 Nm (89 lb-in).
55. Connect the upper radiator hose, the heater hose and the coolant vent hose to the coolant bypass.
56. Connect the exhaust gas recirculation (EGR) valve electrical connector.
57. Install the power brake booster vacuum tube into the quick release fitting.
58. If equipped, connect the secondary air injection (AIR) vacuum regulator electrical connector.
59. If equipped, connect the AIR hose.
60. Connect the evaporative emissions tube. For additional information, refer to «FUEL SYSTEM-GENERAL INFORMATION»(ref-255426) .
61. Connect the fuel tube quick connect coupling onto the fuel rail. For additional information, refer to «FUEL SYSTEM-GENERAL INFORMATION»(ref-255426) .
62. Connect the accelerator cable and speed control cable (if equipped). Install the accelerator cable bracket and bolts. Tighten to 10 Nm (89 lb-in). Connect the accelerator and speed control cable (if equipped) to the throttle body.
63. Install the accelerator control snow shield. Position the snow shield and install the screw and pin-type retainer. Tighten to 10 Nm (89 lb-in). Attach the evaporative emissions hose pin-type retainer.
64. Install the air cleaner outlet pipe and air intake resonator into the grommets and install the bolt.
65. Tighten the air cleaner outlet pipe and connect the vent tube.
66. Clean and inspect the catalytic converter flange. Using a straightedge and a feeler gauge, place the straightedge across the catalytic converter flange surface and check for warping with the feeler gauge. If the reading is greater than the maximum specification, install a new catalytic converter, gasket and nuts.
67. Using a new gasket and nuts, install the catalytic converter. Tighten in the sequence shown to 55 Nm (41 lb-ft).
68. If equipped, connect the AIR hose.
69. If equipped, connect the upper exhaust sensor electrical connector and retainer.
70. Connect the exhaust sensor electrical connectors.
71. If removed, install the heat shield and 4 bolts. Tighten to 10 Nm (89 lb-in).
72. Install the catalytic converter support bracket and 4 bolts. Tighten to 47 Nm (35 lb-ft).
73. Using a new gasket and 2 nuts, connect the catalytic converter to exhaust system. Tighten to 47 Nm (35 lb-ft).
74. Install the battery tray. For additional information, refer to «BATTERY MOUNTING AND CABLES»(ref-255404) .
75. Fill the engine with clean engine oil.
76. Install the power steering pump. For additional information, refer to «POWER STEERING»(ref-255380) .
77. Install the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE»(ref-255400) .
78. Fill and bleed the cooling system. For additional information, refer to «ENGINE COOLING»(ref-255386) .
79. Evacuate and charge the A/C system. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION AND DIAGNOSIS»(ref-255427) .
