REMOVAL AND INSTALLATION
- Remove the footwell trim panel.
- Disconnect the accelerator cable from the pedal.
- Remove the 3 nuts and the pedal assembly. To install, tighten to 9 Nm (80 lb-in).
- To install, reverse the removal procedure.
Scheme 2
| Item | Part Number | Description |
|---|---|---|
| 1 | W505140 | Snow shield mounting screw |
| 2 | Snow shield pin-type retainer (part of 9E766) | |
| 3 | W709420 | Evaporative emissions hose pin-type retainer |
| 4 | 9E766 | Snow shield |
| 5 | 9C799 | Accelerator cable assembly |
- Remove the air cleaner outlet pipe. Loosen the clamps. Disconnect the vent tube and remove the outlet pipe.
- Remove the accelerator control snow shield. Detach the evaporative emissions hose pin-type retainer. Remove the screw and pin-type retainer. Remove the snow shield. To install, tighten to 6 Nm (53 lb-in).
- Disconnect the accelerator cable from the throttle body.
- Rotate the cable grommet counterclockwise and release the cable from the throttle body bracket.
- Detach the cable from the retainer clip.
- Remove the footwell trim panel.
- Disconnect the accelerator cable pedal grommet from the accelerator pedal.
- Remove the cable grommet from the bulkhead.
- Attach a draw cord to the accelerator cable to assist with installation. Remove the accelerator cable.
- To install, reverse the removal procedure. The rubber grommets must be installed in the bulkhead and throttle body bracket before the accelerator cable pedal grommet is installed in the pedal.
