GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Lubricants | |
| High Performance DOT 3 Motor Vehicle Brake Fluid PM-1 or PM-1-C (US); CPM-1 or CPM-1-C (Canada) | ESA-M6C25-A or WSS-M6C62-A |
| High Temperature Nickel Anti-Seize Lubricant XL-2 (US); CXG-2-B (Canada) | ESE-M12A4-A |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Anti-lock brake system (ABS) module to hydraulic control unit (HCU) bolts | 2 |
| Brake tube fittings | 18 |
| HCU bracket-to-frame nuts | 9 |
| HCU-to-bracket bolts | 9 |
| Wheel speed sensor bolts | 9 |
TORQUE SPECIFICATIONS
Anti-Lock Control
The anti-lock brake system (ABS) consists of the following components
- Anti-lock brake system (ABS) module
- Hydraulic control unit (HCU)
- Front wheel speed sensor
- Front wheel speed sensor ring
- Rear wheel speed sensor
- Rear wheel speed sensor ring
- Red brake warning indicator
- Traction control switch
- Yellow ABS warning indicator
Special Tools Illustration Tool Name Tool Number Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool 73III Automotive Meter 105-R0057 or equivalent Flex Probe Kit 105-R025B Rotunda Active Wheel Speed Sensor Tester 105-R0110
Scheme 1
Scheme 2
Scheme 3
