TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Accessory drive belt tensioner bolts | 25 |
| Accessory drive belt splash shield bolts | 9 |
| Accessory drive belt idler pulley bolt | 48 |
TORQUE SPECIFICATIONS
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | 19A216 | Accessory drive belt idler pulley |
| 2 | 3A733 | Power steering pump pulley |
| 3 | 19D784 | Air conditioning (A/C) compressor pulley |
| 4 | 6316 | Crankshaft pulley |
| 5 | 8509 | Coolant pump pulley |
| 6 | 6A228 | Belt tensioner |
| 7 | 10344 | Generator pulley |
Scheme 2
| Item | Part Number | Description |
|---|---|---|
| 1 | 19A216 | Accessory drive belt idler pulley |
| 2 | 3A733 | Power steering pump pulley |
| 3 | 19A216 | Accessory drive belt idler pulley |
| 4 | 6316 | Crankshaft pulley |
| 5 | 8509 | Coolant pump pulley |
| 6 | 6A228 | Belt tensioner |
| 7 | 10344 | Generator pulley |
Belt Tensioner - Automatic tensioners are calibrated to provide the correct amount of tension to the belt for a given accessory drive system. Unless a spring or damping band within the tensioner assembly breaks or some other mechanical part of the tensioner fails, there is no need to check the tensioner for correct tension.
