GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| High Temperature Nickel Anti-Seize Lubricant F6AZ-9L494-AA (in Canada CXG-2-B) | ESE-M12A4-A |
| Catalytic converter flange surface warpage (maximum) | 0.76 mm (0.0295 in) |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS CHART
| Description | Nm |
|---|---|
| Manifold to catalytic converter nuts (2.0L) | 47 |
| Catalytic converter nuts (2.3L) | 55 |
| Catalytic converter-to-flex pipe nuts | 47 |
| Muffler assembly flange nuts | 47 |
| Clamp nuts | 47 |
| HO2S | 47 |
| Lower support bracket nuts | 22 |
| Manifold heat shield bolts | 10 |
| Rear support strap to bracket bolts | 47 |
TORQUE SPECIFICATIONS CHART
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Note. The exhaust systems shown are production systems.
The exhaust systems are of a two-piece construction for production and five-piece construction for service.
