Speed Control System: Removal & Installation Ford Focus I рестайлинг

Installation

1. To install, reverse the removal procedure.

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

1. Remove the watershield, if equipped. Remove the screw. Remove the pin-type retainers.
2. Disconnect the speed control cable from the throttle body linkage. Rotate the throttle body linkage and disconnect the speed control cable end by pushing forward.
3. Position the speed control cable away from the throttle body bracket retaining ring.
4. Remove the speed control cable from the throttle body bracket. Using a suitable tool remove the retaining ring from the throttle body bracket.
5. Remove the speed control cable from the retaining clips.
6. Disconnect the speed control actuator electrical connector.
7. Remove the speed control actuator. Remove the bolts.
8. Press the locking tab and rotate the speed control cable cover to remove.
9. Remove the speed control cable from the speed control actuator pulley.

1. To install, reverse the removal procedure.

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. Remove the dust cover from the throttle body.
2. Remove the speed control cable. Disconnect the inner cable from the throttle body. Detach the speed control cable from the throttle body.
3. Remove the speed control cable from the clip.
4. Remove the speed control actuator cable cover.
5. Disconnect the speed control cable from the speed control actuator pulley.

1. To install, reverse the removal procedure.

Scheme 43

Scheme 44

1. Remove the driver air bag module. For additional information, refer to «DRIVER-SIDE AIR BAG MODULE»(ref-170306-S33804196642005011000000) .
2. Disconnect the speed control switch electrical connector.
3. Remove the speed control switches.

Scheme 45

1. To install, reverse the removal procedure.
