Overview
The acceleration controls consist of the accelerator pedal and sensor assembly.
The throttle is controlled by an APP sensor on the accelerator pedal assembly. The APP sensor sends a signal to the PCM in response to throttle pedal movements initiated by the driver. The PCM sends a signal to the electronic throttle control which increases and decreases throttle position.
The engine management system electronically operates the throttle of the engine in response to throttle pedal movements initiated by the driver. In the event of a system failure, the engine management system provides a "limp home" mode which allows the car to be driven with limited performance.
Symptom Chart(s)
REFER to ENGINE CONTROLS - SYMPTOM CHARTS (EXCEPT DIESEL & HYBRID) .
Removal
Note. Removal steps in this procedure may contain installation details.
Note. To prevent setting Diagnostic Trouble Codes (DTCs), make sure the ignition switch is in the OFF position prior to disconnecting the accelerator pedal electrical connector.
Note. The sport metallic accelerator pedal pad is not to be re-used. If the sport metallic accelerator pedal pad is removed it should be discarded and replaced with a new sport metallic accelerator pedal pad.
Scheme 1
- Torque : 8 Nm
Installation
- To install, reverse the removal procedure.
