Climate Control System -- Electric Ford Focus ST III

Specifications

LUBRICANTS, FLUIDS, SEALERS AND ADHESIVES

CAPACITIES

REFRIGERANT OIL ADDING (WHEN NEW COMPONENTS ARE INSTALLED)

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Overview

The Dual Automatic Temperature Control (DATC) system maintains the selected vehicle interior temperature by heating and/or cooling the air depending on the HVAC control panel selection.

1. The driver may override the automatic mode of operation.
2. The temperature control setting is the desired cabin air temperature.
3. The blower motor control override buttons vary the blower motor speed.
4. The driver side and passenger side temperature settings can be individually controlled.
5. During A/C operation, the system reduces the relative humidity of the air inside the vehicle.

HEV is equipped with an Exhaust Manifold and Catalytic Converter Assembly with coolant passages to heat engine coolant more rapidly, speeding up passenger compartment heating in cold temperatures.

Scheme 6

Network Message Chart

MODULE NETWORK INPUT MESSAGES - ACCESSORY PROTOCOL INTERFACE MODULE (APIM)

MODULE NETWORK INPUT MESSAGES - POWERTRAIN CONTROL MODULE (PCM)

MODULE NETWORK INPUT MESSAGES - HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) MODULE

MODULE NETWORK INPUT MESSAGES - AIR CONDITIONING CONTROL MODULE (ACCM)

Scheme 7

During stabilized conditions ( A/C system shutdown), the refrigerant pressures are equal throughout the system. When the electric A/C compressor is in operation, it increases pressure on the refrigerant vapor, raising its temperature. The high-pressure and high-temperature vapor is then released into the top of the Air Conditioning A/C condenser core.

The A/C condenser, being close to ambient temperature, causes the refrigerant vapor to condense into a liquid when heat is removed from the refrigerant by ambient air passing over the fins and tubing. The now liquid refrigerant, still at high pressure, exits from the bottom of the A/C condenser and enters the inlet side of the A/C receiver/drier. The receiver/drier is designed to remove moisture and contaminants from the refrigerant system.

The outlet of the receiver/drier is connected to the Thermostatic Expansion Valve (TXV). The Thermostatic Expansion Valve (TXV) provides the orifice, which is the restriction in the refrigerant system which separates the high and low pressure sides of the A/C system. As the liquid refrigerant passes across this restriction, its pressure and boiling point are reduced.

The liquid refrigerant is now at its lowest pressure and temperature. As it passes through the A/C evaporator, it absorbs heat from the airflow passing over the plate/fin sections of the A/C evaporator. This addition of heat causes the refrigerant to boil (convert to gas). The now cooler air can no longer support the same humidity level of the warmer air and this excess moisture condenses on the exterior of the evaporator coils and fins and drains outside the vehicle.

The refrigerant cycle is now repeated with the A/C compressor again increasing the pressure and temperature of the refrigerant.

A thermistor monitors the temperature of the air that has passed through the evaporator core and controls electric A/C compressor speed. If the temperature of the evaporator core discharge air is low enough to cause the condensed water vapor to freeze, the electric A/C compressor reduces it speed.

The high-side line pressure is also monitored so that electric A/C compressor operation will be interrupted if the system pressure becomes too high.

The low-side line pressure is also monitored so that electric A/C compressor operation will be interrupted if the system pressure is determined to be too low (low charge condition).

The electric A/C compressor thermal protection switch will interrupt compressor operation if the compressor housing exceeds temperature limits.

The A/C compressor relief valve opens and vents refrigerant to relieve unusually high system pressure.

Control System Logic

The controls for the climate control system are in one or more locations depending on vehicle option content

1. Dual Automatic Temperature Control (DATC) module
2. Front Display Interface Module (FDIM) (part of Accessory Protocol Interface Module (APIM))

When the Front Display Interface Module (FDIM) touchscreen or voice commands are used and A/C is selected, the Accessory Protocol Interface Module (APIM) sends a function request message over the Infotainment Controller Are Network (I-CAN) to the Instrument Panel Cluster (IPC). The Instrument Panel Cluster (IPC) relays the requests to the Gateway Module (GWM), Body Control Module (BCM) and the Heating, Ventilation, and Air Conditioning (HVAC) module over the Medium Speed Controller Area Network (MS-CAN). The Gateway Module (GWM) sends the requests to the Powertrain Control Module (PCM) over the High Speed Controller Area Network (HS-CAN). The Powertrain Control Module (PCM) sends the request over the High Speed Controller Area Network (HS-CAN) to the Air Conditioning Control Module (ACCM).

When the customer inputs are directly inputted in to the Dual Automatic Temperature Control (DATC) module and A/C is selected, the Heating, Ventilation, and Air Conditioning (HVAC) module sends the request to the Gateway Module (GWM) over the Medium Speed Controller Area Network (MS-CAN). The Gateway Module (GWM) sends the request to the Powertrain Control Module (PCM) over the High Speed Controller Area Network (HS-CAN). The Powertrain Control Module (PCM) sends the request over the High Speed Controller Area Network (HS-CAN) to the Air Conditioning Control Module (ACCM).

Controls and Compressor Cycling

Climate control commands are inputted through the Heating, Ventilation, and Air Conditioning (HVAC) module and on vehicles equipped with Sony® Sound inputs can also be commanded through voice commands or the touch screen.

When the A/C is requested, the Heating, Ventilation, and Air Conditioning (HVAC) module sends the message over the Medium Speed Controller Area Network (MS-CAN) to the Gateway Module (GWM). The Gateway Module (GWM) then forwards the message to the Powertrain Control Module (PCM) over the High Speed Controller Area Network (HS-CAN).

An A/C demand message is sent from the Powertrain Control Module (PCM) over the High Speed Controller Area Network (HS-CAN) to the Air Conditioning Control Module (ACCM) if all of the following conditions are met

1. The Powertrain Control Module (PCM) does not detect excessively high or low refrigerant pressure from the A/C pressure sensors.
2. The Powertrain Control Module (PCM) does not detect an ambient air temperature below approximately 4°C (39.2°F).
3. The Powertrain Control Module (PCM) does not receive a message from the Body Control Module (BCM) detecting an evaporator discharge air temperature below approximately 2°C (36°F).

When the Air Conditioning Control Module (ACCM) receives the A/C demand message, it will engage. Instead of cycling ON and OFF like a traditional A/C compressor, the Powertrain Control Module (PCM) monitors the evaporator discharge temperature from the Heating, Ventilation, and Air Conditioning (HVAC) module to raise or lower the electric A/C compressor speed as required.

The Heating, Ventilation, and Air Conditioning (HVAC) module adjusts the air inlet door depending on the humidity measured by the in-vehicle temperature and humidity sensor. If the vehicle cabin becomes too humid and recirculated air is selected, the Heating, Ventilation, and Air Conditioning (HVAC) module adjusts the air inlet door to allow more fresh air. When the humidity level drops, it may adjust back to partial recirculated air. The Heating, Ventilation, and Air Conditioning (HVAC) module also adjusts the system based on in-vehicle temperature.

The autolamp/sunload sensor supplies information to the Heating, Ventilation, and Air Conditioning (HVAC) module indicating the intensity of the sun on the vehicle and the Heating, Ventilation, and Air Conditioning (HVAC) module adjusts the system based on the intensity.

Air Handling

The defrost mode door, panel/floor mode door, temperature blend door and air inlet mode door actuators are stepper motors. There is no feedback circuit or potentiometer for these actuators. The pins labeled A, B, C and D are for the different phases (coils) of the motor. All the phases for a given motor are fed from a common power lead, the pin labeled Power and the Heating, Ventilation, and Air Conditioning (HVAC) module controls each phase by turning on/off a low side output for the different phases. The motor turns or "steps" through a series of motions to position the actuator. The Heating, Ventilation, and Air Conditioning (HVAC) module tracks the actuator positions by counting steps and periodically calibrates itself so it knows how many steps there are for the full range movement of the actuator. The Heating, Ventilation, and Air Conditioning (HVAC) module sets Diagnostic Trouble Codes (DTCs) by monitoring the current flow through a given phase. If it sees too much current it identifies it as a short circuit. If it does not see any current it identifies it as an open circuit.

When an airflow mode, desired driver or passenger temperature or fresh air or recirculation mode is selected the Heating, Ventilation, and Air Conditioning (HVAC) module drives the actuator motor in the direction necessary to make the actuator position agree with the expected Heating, Ventilation, and Air Conditioning (HVAC) module position to be obtained.

The Heating, Ventilation, and Air Conditioning (HVAC) module sends a Pulse Width Modulated (PWM) signal to the blower motor speed control to control the blower speed. The blower speed control provides variable ground feed for the blower motor. A delay function provides a gradual increase or decrease in blower motor speed under all conditions.

AUTO

When AUTO is selected

1. the Heating, Ventilation, and Air Conditioning (HVAC) system operates in a manner to achieve and maintain the temperature set by the operator.
2. the air inlet door is automatically controlled by the Heating, Ventilation, and Air Conditioning (HVAC) module based on the temperature setting.
3. the mode door is automatically controlled by the Heating, Ventilation, and Air Conditioning (HVAC) module based on the temperature setting.
4. the temperature blend doors are automatically controlled by the Heating, Ventilation, and Air Conditioning (HVAC) module, based on the temperature setting.
5. the A/C compressor is automatically controlled by the PCM , based on target evaporator temperature request sent from the Heating, Ventilation, and Air Conditioning (HVAC) module. The A/C compressor does not operate if the outside temperature is below approximately 4°C (39.2°F).
6. the blower motor speed is automatically controlled by the Heating, Ventilation, and Air Conditioning (HVAC) module based on the temperature setting, but can be manually overridden.

OFF

When OFF is selected

1. the air inlet door closes, preventing outside air and allowing only recirculated air.
2. the blower motor is off.

MAX AC

When MAX A/C is selected

1. the air inlet door closes, preventing outside air and admits only recirculated air.
2. the recirculated air indicator is illuminated (recirculated air forced on).
3. the mode doors direct airflow to the instrument panel registers.
4. the temperature blend doors move to the full cool position. Air temperature can be manually overridden.
5. the A/C button is illuminated.
6. the A/C compressor operates if the outside temperature is above approximately 4°C (39.2°F).
7. the blower motor is commanded to the highest speed. The blower motor speed is adjustable.

PANEL

When PANEL mode is selected

1. the recirculated air request button is enabled. If the recirculated air request button is selected (indicator on), the air inlet door closes, preventing outside air from entering the passenger compartment. If the recirculated air request button is not selected (indicator off), the air inlet door opens, allowing only outside air into the passenger compartment.
2. the mode doors direct airflow to the instrument panel registers.
3. blended air temperature is available. Only when A/C compressor operation has been selected by pressing the A/C button (indicator on) can the airflow temperature be cooled below the outside air temperature.
4. the blower motor is on and the speed is adjustable.

PANEL-FLOOR

When PANEL/FLOOR mode is selected

1. the recirculated air request button is enabled. If the recirculated air request button is selected (indicator on), the air inlet door closes, preventing outside air from entering the passenger compartment. If the recirculated air request button is not selected (indicator off), the air inlet door opens, allowing only outside air into the passenger compartment.
2. the mode doors direct airflow to the floor duct and the instrument panel registers. A small amount of airflow from the side window demisters and defrost duct is present.
3. blended air temperature is available. Only when A/C compressor operation has been selected by pressing the A/C button (indicator on) can the airflow temperature be cooled below the outside air temperature.
4. the blower motor is on and the speed is adjustable. the blower motor is on and the speed is adjustable.

FLOOR

When FLOOR mode is selected

1. the recirculated air request button is enabled. If the recirculated air request button is selected (indicator on), the air inlet door closes, preventing outside air from entering the passenger compartment. If the recirculated air request button is not selected (indicator off), the air inlet door opens, allowing only outside air into the passenger compartment.
2. the mode doors direct airflow to the floor duct. A small amount of airflow from the defroster duct and side window demisters is present.
3. blended air temperature is available. Only when A/C compressor operation has been selected by pressing the A/C button (indicator on) can the airflow temperature be cooled below the outside air temperature.
4. the blower motor is on and the speed is adjustable.

FLOOR-DEFROST

When FLOOR/DEFROST mode is selected

1. the recirculated air request button is enabled. If the recirculated air request button is selected (indicator on), the air inlet door closes, preventing outside air from entering the passenger compartment. If the recirculated air request button is not selected (indicator off), the air inlet door opens, allowing only outside air into the passenger compartment.
2. the mode doors direct airflow to the floor duct, the defroster duct and the side window demisters.
3. blended air temperature is available. Only when A/C compressor operation has been selected by pressing the A/C button (indicator on) can the airflow temperature be cooled below the outside air temperature.
4. the blower motor is on and the speed is adjustable.

DEFROST

When DEFROST mode is selected

1. the recirculated air request button is disabled. The air inlet door opens, allowing only outside air into the passenger compartment.
2. the mode doors direct airflow to the defroster duct and side window demisters. A small amount of airflow from the floor duct is present.
3. the A/C is turned on in defrost. The A/C compressor operates as long as the outside temperature is above approximately 4°C (39.2°F).
4. blended air temperature is available.
5. the blower motor is on and the speed is adjustable.

Heating Ventilation Air Conditioning (HVAC) Module - Dual Automatic Temperature Control (DATC)

For vehicles equipped with Sony® sound, the Dual Automatic Temperature Control (DATC) system uses voice commands or the touchscreen to control the system. For vehicles without Sony® sound, the Heating, Ventilation, and Air Conditioning (HVAC) module is the only control interface. For details on the Heating, Ventilation, and Air Conditioning (HVAC) module communication, refer to CONTROL SYSTEM LOGIC .

The Heating, Ventilation, and Air Conditioning (HVAC) module requires Programmable Module Installation (PMI) when it is replaced.

A/C Low Pressure Sensor

The Powertrain Control Module (PCM) monitors the suction pressure measured by the A/C low pressure sensor. As the refrigerant pressure changes, the resistance of the A/C low pressure sensor changes. It is not necessary to recover the refrigerant before removing the A/C low pressure sensor.

A/C High Pressure Sensor

The Powertrain Control Module (PCM) monitors the discharge pressure measured by the A/C high pressure sensor. As the refrigerant pressure changes, the resistance of the A/C high pressure sensor changes. It is not necessary to recover the refrigerant before removing the A/C high pressure sensor.

In-Vehicle Temperature and Humidity Sensor

The in-vehicle temperature and humidity sensor contains a thermistor and a sensing element which separately measure the in-vehicle air temperature and humidity and sends those readings to the Heating, Ventilation, and Air Conditioning (HVAC) module. The in-vehicle temperature and humidity sensor has an electric fan within the sensor that draws in-vehicle air across the two sensing elements.

The humidity sensor is used by the Heating, Ventilation, and Air Conditioning (HVAC) module to optimize the Air Conditioning Compressor Module (ACCM) operation for reduced electrical system load while maintaining passenger comfort.

Autolamp-Sunload Sensor

The autolamp/sunload sensor supplies information to the Heating, Ventilation, and Air Conditioning (HVAC) module indicating the intensity of the sun on the vehicle.

Evaporator Temperature Sensor

The evaporator discharge air temperature sensor contains a thermistor. The sensor varies its resistance with the temperature. As the temperature rises, the resistance falls. As the temperature falls, the resistance rises.

Blower Motor Speed Control

The blower motor speed control uses a Pulse Width Modulated (PWM) signal from the Heating, Ventilation, and Air Conditioning (HVAC) module to determine the desired blower speed and varies the ground feed for the blower motor to control the speed.

ACCM (Air Conditioning Control Module)

Note. Motorcraft® Electric Compressor Oil YN-32 only must be used as a refrigerant system lubricant for electric vehicles. Addition of any oil other than Motorcraft® Electric Compressor Oil YN-32 to the refrigerant system will damage the electric A/C compressor and contaminate the refrigerant system. Use the oil adding procedure specified for this vehicle when installing a new Air Conditioning Control Module (ACCM) Electric A/C compressor.

Refer to: REFRIGERANT OIL ADDING .

The Air Conditioning Control Module (ACCM) is an integral part of the electric A/C compressor and cannot be removed from or serviced separately from the A/C compressor. The variable-speed electric A/C compressor is powered by the high-voltage battery system.

A/C Condenser

The A/C condenser is an aluminum fin-and-tube design heat exchanger. It cools compressed refrigerant gas by allowing air to pass over fins and tubes to extract heat, and condenses gas to liquid refrigerant as it is cooled.

Cabin Coolant Heater

The cabin coolant heater has both low voltage and high voltage electrical connections. The low voltage circuits are used for controlling the unit, while the high voltage circuits are used for heating the coolant. The cabin coolant heater uses electricity, or more accurately, the heat for resistance in electrical circuits to quickly raise the temperature of the coolant to normal operating temperature.

Cabin A/C Isolator Solenoid Valve

The cabin A/C isolator solenoid valve is controlled by the Powertrain Control Module (PCM) during A/C compressor operation. If the A/C request is for cooling of the passenger compartment, the cabin A/C isolator solenoid valve allows refrigerant flow to the cabin Thermostatic Expansion Valve (TXV) and evaporator. If the A/C request is only for cooling of the high voltage battery system, the cabin A/C isolator solenoid valve stops refrigerant flow to the cabin Thermostatic Expansion Valve (TXV) and evaporator.

Cabin Thermostatic Expansion Valve (TXV)

The cabin Thermostatic Expansion Valve (TXV) provides a restriction to the flow of refrigerant and separates the low-pressure and high-pressure sides of the refrigerant system. Refrigerant entering and exiting the evaporator core passes through the cabin Thermostatic Expansion Valve (TXV) through 2 separate flow paths. An internal temperature sensing bulb senses the temperature of the refrigerant flowing out of the evaporator core and adjusts an internal pin-type valve to meter the refrigerant flow into the evaporator core. The internal pin-type valve decreases the amount of refrigerant entering the evaporator core at lower temperatures and increases the amount of refrigerant entering the evaporator core at higher temperatures.

High Voltage Battery Coolant Cooler Thermostatic Expansion Valve and Isolator Solenoid Valve Assembly

The high voltage battery coolant cooler Thermostatic Expansion Valve (TXV) and isolator solenoid valve assembly contains a Thermostatic Expansion Valve (TXV) with an integrated isolator solenoid valve. The isolator solenoid valve allows refrigerant flow to the Thermostatic Expansion Valve (TXV) and is controlled by the Powertrain Control Module (PCM) during A/C compressor operation requested by the Battery Energy Control module (BECM). The Thermostatic Expansion Valve (TXV) provides a restriction to the flow of refrigerant and separates the low-pressure and high-pressure sides of the refrigerant system to the high voltage battery coolant cooler, used to cool the coolant which regulates the high voltage battery system temperature.

Evaporator Core

The evaporator core is an aluminum plate/fin type and is located in the heater core and evaporator core housing. A mixture of liquid refrigerant and oil enters the bottom of the evaporator core through the evaporator core inlet tube and continues out of the evaporator core through the evaporator core outlet tube as a vapor. During A/C compressor operation, airflow from the blower motor is cooled and dehumidified as it flows through the evaporator core fins.

Receiver Drier

The receiver drier is integral to the A/C condenser. It stores high-pressure liquid refrigerant after it leaves the condenser core.

The receiver drier is incorporated onto the Left Hand (LH) side of the A/C condenser. The receiver drier desiccant bag is a separate component and can be separately removed and installed with the A/C condenser removed from the vehicle.

Scheme 8

The service gauge port fitting is an integral part of the refrigerant line or component.

1. Special couplings are required for both the high-side and low-side service gauge ports.
2. A very small amount of leakage is always detectable around the Schrader-type valve with the service gauge port valve cap removed, and is considered normal. A new Schrader-type valve core can be installed if the seal leaks excessively.
3. The A/C service gauge port valve caps are used as primary seals in the refrigerant system to prevent leakage through the Schrader-type valves from reaching the atmosphere. Always install and tighten the A/C service gauge port valve caps to the correct torque after they are removed.

Mode Door Actuator - Panel-Floor Door

The panel-floor mode door actuator is a stepper motor style actuator. The Heating, Ventilation, and Air Conditioning (HVAC) module monitors the position of the actuator mode door by counting the motor steps as it rotates. The Heating, Ventilation, and Air Conditioning (HVAC) module drives the actuator motor in the direction necessary to move the mode doors to the position set by the vehicle occupants.

Mode Door Actuator - Defrost Door

The defrost mode door actuator is a stepper motor style actuator. The Heating, Ventilation, and Air Conditioning (HVAC) module monitors the position of the actuator mode door by counting the motor steps as it rotates. The Heating, Ventilation, and Air Conditioning (HVAC) module drives the actuator motor in the direction necessary to move the mode door to the position set by the vehicle occupants.

Mode Door Actuator - Air Inlet Door

The air inlet mode door actuator is a stepper motor style actuator. The Heating, Ventilation, and Air Conditioning (HVAC) module monitors the position of the air inlet mode door by counting the motor steps as it rotates. The Heating, Ventilation, and Air Conditioning (HVAC) module drives the actuator motor in the direction necessary to move the air inlet mode door to the position set by the recirculation button and the in-vehicle and humidity sensor information.

Temperature Blend Door Actuator - LH

The LH temperature blend door actuator is a stepper motor style actuator. The Heating, Ventilation, and Air Conditioning (HVAC) module monitors the position of the LH temperature blend door by counting the motor steps as it rotates. The Heating, Ventilation, and Air Conditioning (HVAC) module drives the temperature blend door actuator motor in the direction necessary to move the temperature blend door based on the temperature set by the vehicle occupant.

Temperature Blend Door Actuator - RH

The RH temperature blend door actuator is a stepper motor style actuator. The Heating, Ventilation, and Air Conditioning (HVAC) module monitors the position of the RH temperature blend door by counting the motor steps as it rotates. The Heating, Ventilation, and Air Conditioning (HVAC) module drives the temperature blend door actuator motor in the direction necessary to move the temperature blend door based on the temperature set by the vehicle occupant.

DTC Chart: Heating Ventilation Air Conditioning (HVAC) Control Module - Dual Automatic Temperature Control (DATC)

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices. For information about these practices, REFER to: DIAGNOSTIC METHODS .

Network Diagnostic Trouble Codes (DTCs) (U-codes) are often a result of intermittent concerns such as damaged wiring or low battery voltage occurrences. Additionally, vehicle repair procedures, such as module reprogramming, often set network Diagnostic Trouble Codes (DTCs). Replacing a module to resolve a network DTC is unlikely to resolve the concern. To prevent repeat network DTC concerns, inspect all network wiring, especially connectors. Test the vehicle battery. REFER to: BATTERY .

HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE - DATC DTC CHART

DTC Chart: Air Conditioning Control Module (ACCM)

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices. For information about these practices, REFER to: DIAGNOSTIC METHODS .

AIR CONDITIONING CONTROL MODULE (ACCM) DTC CHART

DTC Chart: Powertrain Control Module (PCM)

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices. For information about these practices, REFER to: DIAGNOSTIC METHODS .

POWERTRAIN CONTROL MODULE (PCM) DTC CHART

DTC Chart: Body Control Module (BCM)

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices. For information about these practices, REFER to: DIAGNOSTIC METHODS .

BODY CONTROL MODULE (BCM) DTC CHART

Symptom Chart: Climate Control - Dual Automatic Temperature Control (DATC)

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices. For information about these practices, REFER to: DIAGNOSTIC METHODS .

SYMPTOM CHART

Symptom Chart: Noise, Vibration, and Harshness (NVH)

Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices. For information about these practices, REFER to: DIAGNOSTIC METHODS (100-00 General Information, Description and Operation).

SYMPTOM CHART

P0562:00

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Normal Operation and Fault Conditions

The Air Conditioning Control Module (ACCM) requires an operating voltage between 9 and 16 volts. The Air Conditioning Control Module (ACCM) receives this voltage from the BJB . The Air Conditioning Control Module (ACCM) has a single ground circuit located in the engine compartment wiring harness. Excessive resistance or an open in one or more of these circuits, a discharged battery or an inoperative charging system results in the Air Conditioning Control Module (ACCM) setting a DTC .

DTC FAULT TRIGGER CONDITIONS

Possible Sources

1. Fuse(s)
2. Wiring, terminals or connectors
3. Air Conditioning Control Module (ACCM)

PINPOINT TEST A: P0562:00

1. A1 CHECK THE AIR CONDITIONING CONTROL MODULE (ACCM) VOLTAGE SUPPLY CIRCUIT Ignition OFF. Disconnect Air Conditioning Control Module (ACCM) C1803. Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C1803-1 Ground Is the voltage greater than 11 volts? Yes : GO to A2 No : VERIFY the BJB fuse 33 (10A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the «SYSTEM WIRING DIAGRAMS»(ref-541405) to identify the possible causes of the circuit short.
2. A2 CHECK THE AIR CONDITIONING CONTROL MODULE (ACCM) GROUND CIRCUIT Ignition OFF. Measure: Positive Lead Measurement/Action Negative Lead C1803-4 Ground Is the resistance less than 3 ohms? Yes : GO to A3 No : REPAIR the circuit.
3. A3 CHECK FOR CORRECT AIR CONDITIONING CONTROL MODULE (ACCM) OPERATION Ignition OFF. Disconnect and inspect all the Air Conditioning Control Module (ACCM) connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Air Conditioning Control Module (ACCM) connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, DISCONTINUE this test and FOLLOW Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Air Conditioning (A/C) Electric Compressor. REFER to: «AIR CONDITIONING (A/C) ELECTRIC COMPRESSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

U0140:00 - Heating, Ventilation, and Air Conditioning (HVAC) Control Module

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

DTC FAULT TRIGGER CONDITIONS

1. Wiring, terminals or connectors

PINPOINT TEST B: U0140:00 - HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE

1. B1 CHECK THE COMMUNICATION NETWORK Ignition ON. Using a scan tool, perform network test. Does the Body Control Module (BCM) pass the network test? Yes : GO to B2 No : DIAGNOSE the no communication with the Body Control Module (BCM). REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .
2. B2 CHECK THE HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE CONTINUOUS MEMORY DIAGNOSTIC TROUBLE CODES (CMDTCS) Using a scan tool, carry out the Heating, Ventilation, and Air Conditioning (HVAC) control module self-test. Retrieve and record all Heating, Ventilation, and Air Conditioning (HVAC) control module Diagnostic Trouble Codes (DTCs). Clear the Diagnostic Trouble Codes (DTCs). Ignition OFF. Ignition ON. Repeat the Heating, Ventilation, and Air Conditioning (HVAC) control module self-test. Is DTC U0140:00 retrieved again? Yes : GO to B3 No : The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
3. B3 RETRIEVE THE RECORDED DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE SELF-TEST Using a scan tool, perform Heating, Ventilation, and Air Conditioning (HVAC) control module self-test. Check for recorded Diagnostic Trouble Codes (DTCs) from the Heating, Ventilation, and Air Conditioning (HVAC) control module self-test. Is DTC U3006:16 or DTC U3006:17 recorded? Yes : GO to «PINPOINT TEST R»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-r-u300616-u300617) No : GO to B4
4. B4 RETRIEVE ANY DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE BODY CONTROL MODULE (BCM) SELF-TEST Using a scan tool, perform Body Control Module (BCM) self-test. Check for recorded Diagnostic Trouble Codes (DTCs) from the Body Control Module (BCM) self-test. Is DTC U3003:16 or DTC U3003:17 recorded? Yes : For DTC U3003:16, REFER to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#multifunction-electronic-modules-electric) . For DTC U3003:17, REFER to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#multifunction-electronic-modules-electric) . No : GO to B5
5. B5 CHECK FOR DIAGNOSTIC TROUBLE CODE (DTC) U0140:00 SET IN OTHER MODULES Clear all Diagnostic Trouble Codes (DTCs). Ignition OFF. Ignition ON. Wait 10 seconds. Using a scan tool, retrieve all Continuous Memory Diagnostic Trouble Codes (CMDTCs). Is DTC U0140:00 set in any other modules? Yes : INSTALL a new Body Control Module (BCM). REFER to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#multifunction-electronic-modules-electric) . No : INSTALL a new Heating, Ventilation, and Air Conditioning (HVAC) control module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) .

U0140:00 - Air Conditioning Control Module (ACCM)

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

DTC FAULT TRIGGER CONDITIONS

1. Wiring, terminals or connectors

PINPOINT TEST C: U0140:00 - AIR CONDITIONING CONTROL MODULE (ACCM)

1. C1 CHECK THE COMMUNICATION NETWORK Ignition ON. Using a scan tool, perform network test. Does the Body Control Module (BCM) pass the network test? Yes : GO to C2 No : DIAGNOSE the no communication with the Body Control Module (BCM). REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .
2. C2 CHECK THE AIR CONDITIONING CONTROL MODULE (ACCM) CONTINUOUS MEMORY DIAGNOSTIC TROUBLE CODES (CMDTCS) Using a scan tool, carry out the Air Conditioning Control Module (ACCM) self-test. Retrieve and record all Air Conditioning Control Module (ACCM) Diagnostic Trouble Codes (DTCs). Clear the Diagnostic Trouble Codes (DTCs). Ignition OFF. Ignition ON. Repeat the Air Conditioning Control Module (ACCM) self-test. Is DTC U0140:00 retrieved again? Yes : GO to C3 No : The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
3. C3 RETRIEVE THE RECORDED DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE AIR CONDITIONING CONTROL MODULE (ACCM) SELF-TEST Using a scan tool, perform Air Conditioning Control Module (ACCM) self-test. Check for recorded Diagnostic Trouble Codes (DTCs) from the Air Conditioning Control Module (ACCM) self-test. Is DTC P0562:00 or DTC P0563:00 recorded? Yes : For DTC P0562:00, GO to «PINPOINT TEST A»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-a-p056200) For DTC P0563:00, REFER to: «DIRECT CURRENT/DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#voltage-converterinverter-electric) . No : GO to C4
4. C4 RETRIEVE ANY DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE BODY CONTROL MODULE (BCM) SELF-TEST Using a scan tool, perform Body Control Module (BCM) self-test. Check for recorded Diagnostic Trouble Codes (DTCs) from the Body Control Module (BCM) self-test. Is DTC U3003:16 or DTC U3003:17 recorded? Yes : REFER to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#multifunction-electronic-modules-electric) . No : GO to C5
5. C5 CHECK FOR DIAGNOSTIC TROUBLE CODE (DTC) U0140:00 SET IN OTHER MODULES Clear all Diagnostic Trouble Codes (DTCs). Ignition OFF. Ignition ON. Wait 10 seconds. Using a scan tool, retrieve all continuous memory Diagnostic Trouble Codes (DTCs). Is DTC U0140:00 set in any other modules? Yes : INSTALL a new Body Control Module (BCM). REFER to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#multifunction-electronic-modules-electric) . No : INSTALL a new Air Conditioning (A/C) Electric Compressor. REFER to: «AIR CONDITIONING (A/C) ELECTRIC COMPRESSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) .

Climate Control System Functional Test

The functional test tests the functions of the Heating, Ventilation, and Air Conditioning (HVAC) system and identifies the correct Heating, Ventilation, and Air Conditioning (HVAC) symptom pinpoint test.

System Operation

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

PINPOINT TEST D: CLIMATE CONTROL SYSTEM FUNCTIONAL TEST

1. D1 CHECK THE POWERTRAIN CONTROL MODULE (PCM) FOR DIAGNOSTIC TROUBLE CODES (DTCS) Ignition ON. Using a scan tool, perform PCM self-test. Are any climate control related Diagnostic Trouble Codes (DTCs) present? Yes : REFER to the «PCM DTC CHART»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__dtc-chart-powertrain-control-module-pcm) . No : GO to D2
2. D2 CHECK THE BODY CONTROL MODULE (BCM) FOR DIAGNOSTIC TROUBLE CODES (DTCS) Ignition ON. Using a scan tool, perform Body Control Module (BCM) self-test. Are any climate control related Diagnostic Trouble Codes (DTCs) present? Yes : REFER to the «BODY CONTROL MODULE (BCM) DTC CHART»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__dtc-chart-body-control-module-bcm) . No : GO to D3
3. D3 CHECK THE HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE FOR DIAGNOSTIC TROUBLE CODES (DTCS) Ignition ON. Using a scan tool, perform Heating, Ventilation, and Air Conditioning (HVAC) control module self-test. Are any Diagnostic Trouble Codes (DTCs) present? Yes : REFER to the «Heating, Ventilation, and Air Conditioning (HVAC) control module DTC chart»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : GO to D4
4. D4 CHECK THE BLOWER MOTOR OPERATION Ignition ON. Select panel mode. Observe blower motor operation and select each blower motor speed. Does the blower motor operate in all ranges? Yes : GO to D5 No : If the blower motor does not operate in any setting, GO to «PINPOINT TEST M»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-m-the-blower-motor) If the blower motor does not correctly change speeds or turn off when the system is turned off, GO to «PINPOINT TEST N»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-n-the-blower-motor)
5. D5 CHECK AIRFLOW OPERATION Select the highest blower motor setting. While observing the airflow, select each of the airflow positions (panel, panel/floor, floor, floor/defrost, defrost). Is the airflow directed to the correct outlets? Yes : GO to D6 No : GO to «PINPOINT TEST F»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-f-incorrect-or-erratic)
6. D6 VERIFY TEMPERATURE CONTROL OPERATION Start the vehicle and allow it to reach normal operating temperature. With the A/C off, select panel mode. Change the driver and passenger temperature settings from the coldest to the warmest and back to the coldest. Does the temperature change between very warm to cool? Yes : GO to D7 No : If the temperature does not get very warm, GO to «PINPOINT TEST G»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-g-insufficient-erratic-or) If the Left Hand (LH) temperature does not change at all, GO to «PINPOINT TEST K»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-k-the-temperature-control) If the Right Hand (RH) temperature does not change at all, GO to «PINPOINT TEST L»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-l-the-temperature-control)
7. D7 VERIFY THE ELECTRIC AIR CONDITIONING COMPRESSOR DOES NOT ENGAGE WITH AIR CONDITIONING (A/C) OFF With the engine running and the Air Conditioning (A/C) off, select panel mode. Select the coldest temperature setting. Is the outlet temperature close to ambient air temperature? Yes : GO to D8 No : If the Left Hand (LH) temperature is warmer than ambient air temperature, GO to «PINPOINT TEST K»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-k-the-temperature-control) If the Right Hand (RH) temperature is warmer than ambient air temperature, GO to «PINPOINT TEST L»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-l-the-temperature-control) If the outlet temperature is significantly colder than ambient air temperature and the electric A/C compressor clutch cycles normally, GO to «PINPOINT TEST I»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-i-the-air-conditioning) If the outlet temperature is significantly colder than ambient air temperature and the electric A/C compressor clutch is engaged and does not cycle, GO to «PINPOINT TEST J»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-j-the-air-conditioning)
8. D8 VERIFY THE ELECTRIC AIR CONDITIONING (A/C) COMPRESSOR IS OPERATIONAL IN THE AIR CONDITIONING (A/C) MODE Make sure the ambient air temperature is above 2°C (36°F). With the electric motor running, select panel mode. Press the A/C button (indicator on). Is the electric A/C compressor operational when the panel and A/C button (indicator on) is pressed? Yes : GO to D9 No : GO to «PINPOINT TEST H»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-h-the-air-conditioning)
9. D9 CHECK THE RECIRCULATED AIR OPERATION With the electric motor running, press the recirculated air button (indicator off). Select panel mode. Select the highest blower motor setting. Observe airflow noise. Press the recirculated air button (indicator on). Does the airflow noise increase when the recirculated air mode is selected (indicator on)? Yes : GO to D10 No : GO to «PINPOINT TEST E»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-e-the-air-inlet)
10. D10 CHECK THE LDFTEMP PARAMETER IDENTIFICATION (PID) Using a scan tool, view the Heating, Ventilation, and Air Conditioning (HVAC) control module Parameter Identifications (PIDs). Monitor Heating, Ventilation, and Air Conditioning (HVAC) control module Parameter Identification (PID) LDFTEMP. Is the temperature coming out of the driver footwell vent similar to the Parameter Identification (PID)? Yes : GO to D11 No : GO to «PINPOINT TEST O»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-o-b10b300-b10b400-b10b500)
11. D11 CHECK THE LDPT PARAMETER IDENTIFICATION (PID) Using a scan tool view the Heating, Ventilation, and Air Conditioning (HVAC) control module Parameter Identifications (PIDs). Monitor Heating, Ventilation, and Air Conditioning (HVAC) control module Parameter Identification (PID) LDPT. Is the temperature coming out of the driver side register similar to the Parameter Identification (PID)? Yes : GO to D12 No : GO to «PINPOINT TEST O»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-o-b10b300-b10b400-b10b500)
12. D12 CHECK THE AIRTEMP_RF PARAMETER IDENTIFICATION (PID) Using a scan tool view the Heating, Ventilation, and Air Conditioning (HVAC) control module Parameter Identifications (PIDs). Monitor Heating, Ventilation, and Air Conditioning (HVAC) control module Parameter Identification (PID) AIRTEMP_RF. Is the temperature coming out of the passenger footwell vent similar to the Parameter Identification (PID)? Yes : GO to D13 No : GO to «PINPOINT TEST O»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-o-b10b300-b10b400-b10b500)
13. D13 CHECK THE AIRTEMP_RP PARAMETER IDENTIFICATION (PID) Using a scan tool view the Heating, Ventilation, and Air Conditioning (HVAC) control module Parameter Identifications (PIDs). Monitor Heating, Ventilation, and Air Conditioning (HVAC) control module Parameter Identification (PID) AIRTEMP_RP. Is the temperature coming out of the passenger side register similar to the Parameter Identification (PID)? Yes : GO to D14 No : GO to «PINPOINT TEST O»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-o-b10b300-b10b400-b10b500)
14. D14 CHECK THE INT_TEMP PARAMETER IDENTIFICATION (PID) Using a scan tool view the Heating, Ventilation, and Air Conditioning (HVAC) control module Parameter Identifications (PIDs). Monitor Heating, Ventilation, and Air Conditioning (HVAC) control module Parameter Identification (PID) INT_TEMP. Is the air temperature at the cabin temperature sensor similar to the Parameter Identification (PID)? Yes : GO to D15 No : GO to «PINPOINT TEST P»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric)
15. D15 CHECK THE TOUCHSCREEN CONTROLS OPERATION Using the touchscreen controls, select each climate control function. Using the touchscreen controls, select each audio control function. Do all touchscreen controls operate? Yes : The system is operating correctly. No : REFER to: «INFORMATION AND ENTERTAINMENT SYSTEM»(/ford/focus-st/iii-2012-2015/remont/entertainment-systems/#information-entertainment-systems-with-o-touchscreen-electric) . (Sony® Sound)

The Air Inlet Blend Door Is Inoperative

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Mode Door Actuator - Air Inlet Blend Door

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

During an actuator calibration cycle, the Heating, Ventilation, and Air Conditioning (HVAC) control module drives the air inlet blend door until the door reaches both internal stops in the Heating, Ventilation, and Air Conditioning (HVAC) case. If the air inlet mode door is temporarily obstructed or binding during a calibration cycle, the Heating, Ventilation, and Air Conditioning (HVAC) control module may interpret this as the actual end of travel for the door. When this condition occurs and the Heating, Ventilation, and Air Conditioning (HVAC) control module commands the actuator to its end of travel, the air intake may not be from the expected source.

DTC FAULT TRIGGER CONDITIONS

1. Wiring, terminals or connectors
2. Air Inlet Blend Door Actuator
3. Heating, Ventilation, and Air Conditioning (HVAC) control module

PINPOINT TEST E: THE AIR INLET BLEND DOOR IS INOPERATIVE

1. E1 CHECK THE AIR INLET BLEND DOOR ACTUATOR CIRCUITS FOR AN OPEN Ignition OFF. Disconnect Heating, Ventilation, and Air Conditioning (HVAC) control module C228A. Disconnect Air Inlet Blend Door Actuator. Measure: Positive Lead Measurement/Action Negative Lead C228A-1 C282-1 C228A-13 C282-2 C228A-2 C282-3 C228A-14 C282-4 C228A-15 C282-6 Are the resistances less than 3 ohms? Yes : GO to E2 No : REPAIR the circuit in question.
2. E2 CHECK THE AIR INLET BLEND DOOR ACTUATOR CIRCUITS FOR A SHORT TO GROUND Measure: Positive Lead Measurement/Action Negative Lead C228A-1 Ground C228A-13 Ground C228A-2 Ground C228A-14 Ground C228A-15 Ground Are the resistances greater than 10, 000 ohms? Yes : GO to E3 No : REPAIR the circuit in question.
3. E3 CHECK THE AIR INLET BLEND DOOR ACTUATOR CIRCUITS FOR A SHORT TO POWER Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C228A-1 Ground C228A-13 Ground C228A-2 Ground C228A-14 Ground C228A-15 Ground Is there any voltage present? Yes : REPAIR the circuit in question. No : INSTALL a new air inlet blend door actuator, REFER to: «AIR INLET DOOR ACTUATOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) .
4. E4 CHECK FOR CORRECT HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE OPERATION Ignition OFF. Disconnect and inspect all the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, DISCONTINUE this test and FOLLOW Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Heating, Ventilation, and Air Conditioning (HVAC) control module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. Address the root cause of any connector or pin issues.

Incorrect or Erratic Direction of Airflow From Outlets

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

During an actuator calibration cycle, the Heating, Ventilation, and Air Conditioning (HVAC) control module drives the defrost vent/register blend door or the footwell vent/duct blend door until the door reaches the internal stops in the Heating, Ventilation, and Air Conditioning (HVAC) case. If either mode door is temporarily obstructed or binding during a calibration cycle, the Heating, Ventilation, and Air Conditioning (HVAC) control module may interpret this as the actual end of travel for the door. When this condition occurs and the Heating, Ventilation, and Air Conditioning (HVAC) control module commands the actuator to its end of travel, the airflow may not be from the expected outlets.

DTC FAULT TRIGGER CONDITIONS

1. Wiring, terminals or connectors
2. Defrost vent/register blend door actuator
3. Footwell vent/duct blend door actuator
4. Heating, Ventilation, and Air Conditioning (HVAC) control module

PINPOINT TEST F: INCORRECT OR ERRATIC DIRECTION OF AIRFLOW FROM OUTLETS

1. F1 CHECK THE DEFROST VENT/REGISTER BLEND DOOR ACTUATOR OR FOOTWELL VENT/DUCT BLEND DOOR ACTUATOR CIRCUITS FOR AN OPEN Ignition OFF. Disconnect Heating, Ventilation, and Air Conditioning (HVAC) control module C228A. Disconnect Defrost vent/register blend door actuator or footwell vent/duct blend door actuator. For the defrost vent/register blend door, measure: Positive Lead Measurement/Action Negative Lead C228A-7 C232-1 C228A-11 C232-2 C228A-8 C232-3 C228A-20 C232-4 C228A-21 C232-6 For the footwell vent/duct blend door, measure: Positive Lead Measurement/Action Negative Lead C228A-5 C236-1 C228A-26 C236-2 C228A-6 C236-3 C228A-18 C236-4 C228A-19 C236-6 Are the resistances less than 3 ohms? Yes : GO to F2 No : REPAIR the circuit.
2. F2 CHECK THE DEFROST VENT/REGISTER BLEND DOOR ACTUATOR OR FOOTWELL VENT/DUCT BLEND DOOR ACTUATOR CIRCUITS FOR A SHORT TO GROUND For the defrost vent/register blend door, measure: Positive Lead Measurement/Action Negative Lead C228A-7 Ground C228A-11 Ground C228A-8 Ground C228A-20 Ground C228A-21 Ground For the footwell vent/duct blend door, measure: Positive Lead Measurement/Action Negative Lead C228A-5 Ground C228A-26 Ground C228A-6 Ground C228A-18 Ground C228A-19 Ground Are the resistances greater than 10, 000 ohms? Yes : GO to F3 No : REPAIR the circuit in question.
3. F3 CHECK THE DEFROST VENT/REGISTER BLEND DOOR ACTUATOR OR FOOTWELL VENT/DUCT BLEND DOOR ACTUATOR CIRCUITS FOR A SHORT TO POWER Ignition ON. For the defrost vent/register blend door, measure: Positive Lead Measurement/Action Negative Lead C228A-7 Ground C228A-11 Ground C228A-8 Ground C228A-20 Ground C228A-21 Ground For the footwell vent/duct blend door, measure: Positive Lead Measurement/Action Negative Lead C228A-5 Ground C228A-26 Ground C228A-6 Ground C228A-18 Ground C228A-19 Ground Is there any voltage present? Yes : REPAIR the circuit in question. No : INSTALL a new defrost vent/register blend door actuator or footwell vent/duct blend door actuator, REFER to: «DEFROST VENT/REGISTER DOOR ACTUATOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . REFER to: «FOOTWELL VENT DOOR ACTUATOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) .
4. F4 CHECK FOR CORRECT HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE OPERATION Ignition OFF. Disconnect and inspect all the Heating, Ventilation, and Air Conditioning (HVAC) control Module connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Heating, Ventilation, and Air Conditioning (HVAC) control Module connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, DISCONTINUE this test and FOLLOW Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Heating, Ventilation, and Air Conditioning (HVAC) control module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. Address the root cause of any connector or pin issues.

When the engine is at operating temperature hot coolant flows from the electric motor through the heater core and back to the electric motor. Correct coolant temperatures are critical for good heater performance.

1. Wiring, terminals or connectors
2. temperature blend door actuator(s)
3. heater core

Visual Inspection and Diagnostic Pre-checks

1. Inspect for low engine coolant level.

PINPOINT TEST G: INSUFFICIENT, ERRATIC, OR NO HEAT

1. G1 CHECK FOR CORRECT ENGINE COOLANT LEVEL Ignition OFF. Check the engine coolant level. Is the engine coolant at the correct level as indicated on the engine coolant recovery reservoir? Yes : GO to G2 No : REFER to: «ELECTRIC POWERTRAIN COOLING»(/ford/focus-st/iii-2012-2015/remont/cooling-system-mechanical/#electric-powertrain-cooling) .
2. G2 CHECK FOR COOLANT FLOW TO THE HEATER CORE Run the motor until it reaches normal operating temperature. Select the floor position on the control assembly. Set the temperature control to full warm and the blower to the lowest setting. Using a suitable temperature measuring device, check the heater core inlet hose to see if it is hot. Is the heater core inlet hose hot? Yes : GO to G3 No : REFER to: «ELECTRIC POWERTRAIN CONTROL»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) .
3. G3 CHECK FOR A PLUGGED OR RESTRICTED HEATER CORE Using a suitable temperature measuring device, measure the heater core outlet hose temperature. Is the heater core outlet hose temperature similar to the inlet hose temperature (within approximately 6-17°C [10-30°F])? Yes : DIAGNOSE for a blend door actuator. For inadequate temperature out of the Left Hand (LH) side, GO to «PINPOINT TEST K»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-k-the-temperature-control) For inadequate temperature out of the Right Hand (RH) side, GO to «PINPOINT TEST L»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-l-the-temperature-control) No : INSTALL a new heater core. REFER to: «HEATER CORE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) .

The Air Conditioning (A/C) Is Inoperative

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Control System Logic

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

Controls and Compressor Cycling

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

A/C Low Pressure Sensor

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

A/C High Pressure Sensor

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

Evaporator Temperature Sensor

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

DTC FAULT TRIGGER CONDITIONS

1. Wiring, terminals or connectors
2. A/C pressure sensor(s)
3. Evaporator temperature sensor
4. Air Conditioning Control Module (ACCM)
5. PCM
6. Heating, Ventilation, and Air Conditioning (HVAC) control Module

1. Inspect BJB fuse 33 (10A).

PINPOINT TEST H: THE AIR CONDITIONING (A/C) IS INOPERATIVE

1. H1 CHECK THE AIR CONDITIONING (A/C) PRESSURE SENSOR (ACP_PRESS) PARAMETER IDENTIFICATIONS (PIDS) Using a scan tool, view PCM Parameter Identifications (PIDs). With a manifold gauge set connected, compare the pressure readings of the manifold gauge set and the PCM Parameter Identification (PID) ACP_PRESS. Are the pressure values of the manifold gauge set and the Parameter Identifications (PIDs) similar? Yes : GO to H2 No : INSTALL a new A/C low pressure sensor or high pressure sensor. REFER to: «AIR CONDITIONING (A/C) LOW PRESSURE SENSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . or REFER to: «AIR CONDITIONING (A/C) HIGH PRESSURE SENSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) .
2. H2 COMPARE THE EVAPORATOR TEMPERATURE SENSOR TO THE POWERTRAIN CONTROL MODULE (PCM) AMBIENT AIR TEMPERATURE (AAT) PARAMETER IDENTIFICATION (PID) Allow the vehicle exterior and interior to stabilize to ambient temperature. Disconnect Evaporator Temperature Sensor. Measure: Positive Lead Measurement/Action Negative Lead C296-1 C296-3 Compare the resistance values to the table below: Ambient Temperature °F (°C) Resistance -39.9°F (-40°C) 832, 519 - 1, 017, 523 ohms -4.0°F (-20°C) 263, 111 - 290, 807 ohms 32.0°F (°C) 91, 058 - 100, 644 ohms 68.0°F (20°C) 35, 473 - 39, 207 ohms 77.0°F (25°C) 28, 500 - 31, 500 ohms 103.9°F (40°C) 15, 307 - 16, 919 ohms 139.9°F (60°C) 7, 171 - 7, 925 ohms 175.9°F (80°C) 3, 630 - 4, 042 ohms Ignition ON. Using a scan tool, view PCM Parameter Identifications (PIDs). Monitor the PCM Parameter Identification (PID) AAT. Are the temperature values similar? Yes : GO to H3 No : INSTALL a new evaporator temperature sensor. REFER to: «EVAPORATOR TEMPERATURE SENSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__evaporator-temperature-sensor)
3. H3 CHECK THE AIR CONDITIONING (A/C) SWITCH (CC_SW_AC) HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE PID WITH THE AIR CONDITIONING (A/C) ON Using a scan tool, view Heating, Ventilation, and Air Conditioning (HVAC) control Module Parameter Identifications (PIDs). Monitor the Heating, Ventilation, and Air Conditioning (HVAC) control Module Parameter Identification (PID) CC_SW_AC. Does the Parameter Identification (PID) read ON? Yes : GO to H4 No : GO to H6
4. H4 CHECK THE AIR CONDITIONING COMPRESSOR COMMANDED STATE (ACC_CMD) POWERTRAIN CONTROL MODULE (PCM) PID WITH THE AIR CONDITIONING (A/C) ON Using a scan tool, view PCM Parameter Identifications (PIDs). Monitor the PCM Parameter Identification (PID) ACC_CMD. Does the Parameter Identification (PID) read ON? Yes : GO to H5 No : GO to H7
5. H5 CHECK FOR CORRECT AIR CONDITIONING CONTROL MODULE (ACCM) OPERATION Ignition OFF. Disconnect and inspect the Air Conditioning Control Module (ACCM) connectors. Repair: corrosion (replace connector or terminals - clean module pins) damaged or bent pins - replace terminals/pins pushed-out pins - replace pins as necessary Reconnect the Air Conditioning Control Module (ACCM) connectors. Make sure they seat and latch correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, discontinue this test and follow Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Air Conditioning (A/C) Electric Compressor. REFER to: «AIR CONDITIONING (A/C) ELECTRIC COMPRESSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
6. H6 CHECK FOR CORRECT HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE OPERATION Ignition OFF. Disconnect and inspect the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Repair: corrosion (replace connector or terminals - clean module pins) damaged or bent pins - replace terminals/pins pushed-out pins - replace pins as necessary Reconnect the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Make sure they seat and latch correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, discontinue this test and follow Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Heating, Ventilation, and Air Conditioning (HVAC) control module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
7. H7 CHECK FOR CORRECT POWERTRAIN CONTROL MODULE (PCM) OPERATION Ignition OFF. Disconnect and inspect the PCM connectors. Repair: corrosion (replace connector or terminals - clean module pins) damaged or bent pins - replace terminals/pins pushed-out pins - replace pins as necessary Reconnect the PCM connectors. Make sure they seat and latch correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, discontinue this test and follow Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

The Air Conditioning (A/C) Is Always On - Air Conditioning (A/C) Mode Always Commanded On

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Control System Logic

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

Controls and Compressor Cycling

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

A/C Low Pressure Sensor

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

A/C High Pressure Sensor

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

Evaporator Temperature Sensor

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

1. Wiring, terminals or connectors
2. PCM
3. Heating, Ventilation, and Air Conditioning (HVAC) control module

PINPOINT TEST I: THE AIR CONDITIONING (A/C) IS ALWAYS ON - AIR CONDITIONING (A/C) MODE ALWAYS COMMANDED ON

1. I1 CHECK THE AIR CONDITIONING (A/C) SWITCH STATUS (CC_SW_AC) PID Ignition ON. Using a scan tool, view Heating, Ventilation, and Air Conditioning (HVAC) control module Parameter Identifications (PIDs). Monitor the Heating, Ventilation, and Air Conditioning (HVAC) control module Parameter Identification (PID) CC_SW_AC. Select panel mode, press and release the air conditioning (A/C) button (indicator off) on the Heating, Ventilation, and Air Conditioning (HVAC) controls. Does the Parameter Identification (PID) read read Active when pressed and Inactive when released? Yes : GO to I2 No : GO to I4
2. I2 CHECK THE AIR CONDITIONING (A/C) REQUEST SIGNAL (AC_REQ) PID WITH THE AIR CONDITIONING (A/C) OFF Using a scan tool, view PCM Parameter Identifications (PIDs). Monitor the PCM Parameter Identification (PID) AC_REQ. While in panel mode, release the air conditioning (A/C) button (indicator off) on the Heating, Ventilation, and Air Conditioning (HVAC) controls. Does the Parameter Identification (PID) read off? Yes : GO to I5 No : GO to I3
3. I3 CHECK THE AIR CONDITIONING (A/C) REQUEST SIGNAL (AC_REQ) PID WITH HVAC MODULE DISCONNECTED Ignition OFF. Disconnect Heating, Ventilation, and Air Conditioning (HVAC) control module C228A. Ignition ON. Using a scan tool, view PCM Parameter Identifications (PIDs). Monitor the PCM Parameter Identification (PID) AC_REQ. Does the Parameter Identification (PID) read off? Yes : GO to I5 No : GO to I4
4. I4 CHECK FOR CORRECT HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE OPERATION Ignition OFF. Disconnect and inspect the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Repair: corrosion (replace connector or terminals - clean module pins) damaged or bent pins - replace terminals/pins pushed-out pins - replace pins as necessary Reconnect the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Make sure they seat and latch correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, discontinue this test and follow Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Heating, Ventilation, and Air Conditioning (HVAC) control module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
5. I5 CHECK FOR CORRECT POWERTRAIN CONTROL MODULE (PCM) OPERATION Ignition OFF. Disconnect and inspect the PCM connectors. Repair: corrosion (replace connector or terminals - clean module pins) damaged or bent pins - replace terminals/pins pushed-out pins - replace pins as necessary Reconnect the PCM connectors. Make sure they seat and latch correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, discontinue this test and follow Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

The Air Conditioning (A/C) Is Always On - Electric A/C Compressor Does Not Cycle

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Control System Logic

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

Controls and Compressor Cycling

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

A/C Low Pressure Sensor

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION

A/C High Pressure Sensor

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

Evaporator Temperature Sensor

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

1. Wiring, terminals or connectors
2. A/C pressure sensor(s)
3. Evaporator temperature sensor
4. Electric Air Conditioning (A/C) Compressor
5. Heating, Ventilation, and Air Conditioning (HVAC) control module

PINPOINT TEST J: THE AIR CONDITIONING (A/C) IS ALWAYS ON - ELECTRIC AIR CONDITIONING (A/C) COMPRESSOR DOES NOT CYCLE

1. J1 COMPARE THE EVAPORATOR TEMPERATURE SENSOR TO THE POWERTRAIN CONTROL MODULE (PCM) AMBIENT AIR TEMPERATURE (AAT) PARAMETER IDENTIFICATION (PID) Allow the vehicle exterior and interior to stabilize to ambient temperature. Disconnect Evaporator Temperature Sensor. Measure: Positive Lead Measurement/Action Negative Lead C296-1 C296-3 Compare the resistance values to the table below: Ambient Temperature °F (°C) Resistance -39.9°F (-40°C) 832, 519 - 1, 017, 523 ohms -4.0°F (-20°C) 263, 111 - 290, 807 ohms 32.0°F (°C) 91, 058 - 100, 644 ohms 68.0°F (20°C) 35, 473 - 39, 207 ohms 77.0°F (25°C) 28, 500 - 31, 500 ohms 103.9°F (40°C) 15, 307 - 16, 919 ohms 139.9°F (60°C) 7, 171 - 7, 925 ohms 175.9°F (80°C) 3, 630 - 4, 042 ohms Ignition ON. Using a scan tool, view PCM Parameter Identifications (PIDs). Monitor the PCM Parameter Identification (PID) AAT. Are the temperature values similar? Yes : GO to J2 No : INSTALL a new evaporator temperature sensor. REFER to: «EVAPORATOR TEMPERATURE SENSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__evaporator-temperature-sensor) .
2. J2 CHECK THE AIR CONDITIONING (A/C) SWITCH (CC_SW_AC) HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE PID WITH THE AIR CONDITIONING (A/C) OFF Using a scan tool, view Heating, Ventilation, and Air Conditioning (HVAC) control module Parameter Identifications (PIDs). Monitor the CC_SW_AC, Heating, Ventilation, and Air Conditioning (HVAC) control module Parameter Identification (PID). Does the Parameter Identification (PID) read ON? Yes : GO to J3 No : GO to J5
3. J3 CHECK THE AIR CONDITIONING COMPRESSOR COMMANDED STATE (ACC_CMD) POWERTRAIN CONTROL MODULE (PCM) PARAMETER IDENTIFICATION (PID) WITH THE AIR CONDITIONING (A/C) OFF Using a scan tool, view PCM Parameter Identifications (PIDs). Monitor the ACC_CMD PCM Parameter Identification (PID). Does the Parameter Identification (PID) read OFF? Yes : GO to J4 No : GO to J6
4. J4 CHECK FOR CORRECT AIR CONDITIONING CONTROL MODULE (ACCM) OPERATION Ignition OFF. Disconnect and inspect the Air Conditioning Control Module (ACCM) connectors. Repair: corrosion (replace connector or terminals - clean module pins) damaged or bent pins - replace terminals/pins pushed-out pins - replace pins as necessary Reconnect the Air Conditioning Control Module (ACCM) connectors. Make sure they seat and latch correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, discontinue this test and follow Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Air Conditioning (A/C) Electric Compressor. REFER to: «AIR CONDITIONING (A/C) ELECTRIC COMPRESSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
5. J5 CHECK FOR CORRECT HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE OPERATION Ignition OFF. Disconnect and inspect the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Repair: corrosion (replace connector or terminals - clean module pins) damaged or bent pins - replace terminals/pins pushed-out pins - replace pins as necessary Reconnect the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Make sure they seat and latch correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, discontinue this test and follow Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Heating, Ventilation, and Air Conditioning (HVAC) control module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
6. J6 CHECK FOR CORRECT POWERTRAIN CONTROL MODULE (PCM) OPERATION Ignition OFF. Disconnect and inspect the PCM connectors. Repair: corrosion (replace connector or terminals - clean module pins) damaged or bent pins - replace terminals/pins pushed-out pins - replace pins as necessary Reconnect the PCM connectors. Make sure they seat and latch correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, discontinue this test and follow Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues. The Temperature Control Is Inoperative or Does Not Operate Correctly - LH Refer to «SYSTEM WIRING DIAGRAMS»(ref-541405) for schematic and connector information.

Temperature Blend Door Actuator - LH

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

During an actuator calibration cycle, the Heating, Ventilation, and Air Conditioning (HVAC) control module drives the temperature blend door until the door reaches both internal stops in the Heating, Ventilation, and Air Conditioning (HVAC) case. If the temperature blend door is temporarily obstructed or binding during a calibration cycle, the Heating, Ventilation, and Air Conditioning (HVAC) control module may interpret this as the actual end of travel for the door. When this condition occurs and the Heating, Ventilation, and Air Conditioning (HVAC) control module commands the actuator to its end of travel, the airflow may not be the expected temperature.

DTC FAULT TRIGGER CONDITIONS

1. Wiring, terminals or connectors
2. LH temperature blend door actuator
3. Heating, Ventilation, and Air Conditioning (HVAC) control module

PINPOINT TEST K: THE TEMPERATURE CONTROL IS INOPERATIVE OR DOES NOT OPERATE CORRECTLY - LH

1. K1 CHECK THE LEFT HAND (LH) TEMPERATURE BLEND DOOR ACTUATOR CIRCUITS FOR AN OPEN Ignition OFF. Disconnect Heating, Ventilation, and Air Conditioning (HVAC) control module C228A. Disconnect Left Hand (LH) Temperature Blend Door Actuator. Measure: Positive Lead Measurement/Action Negative Lead C228A-3 C2091-1 C228A-12 C2091-2 C228A-4 C2091-3 C228A-16 C2091-4 C228A-17 C2091-6 Are the resistances less than 3 ohms? Yes : GO to K2 No : REPAIR the circuit in question.
2. K2 CHECK THE LEFT HAND (LH) TEMPERATURE BLEND DOOR ACTUATOR CIRCUITS FOR A SHORT TO GROUND Measure: Positive Lead Measurement/Action Negative Lead C228A-3 Ground C228A-12 Ground C228A-4 Ground C228A-16 Ground C228A-17 Ground Are the resistances greater than 10, 000 ohms? Yes : GO to K3 No : REPAIR the circuit in question.
3. K3 CHECK THE LEFT HAND (LH) TEMPERATURE BLEND DOOR ACTUATOR CIRCUITS FOR A SHORT TO POWER Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C228A-3 Ground C228A-12 Ground C228A-4 Ground C228A-16 Ground C228A-17 Ground Is any voltage present? Yes : REPAIR the circuit in question. No : INSTALL a new Left Hand (LH) temperature blend door actuator. REFER to: «TEMPERATURE DOOR ACTUATOR LH»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . TEST the system for normal operation. If the concern is still present, GO to K4
4. K4 CHECK FOR CORRECT HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE OPERATION Ignition OFF. Disconnect and inspect all the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, DISCONTINUE this test and FOLLOW Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Heating, Ventilation, and Air Conditioning (HVAC) control module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

The Temperature Control Is Inoperative or Does Not Operate Correctly - RH

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Temperature Blend Door Actuator - RH

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

During an actuator calibration cycle, the Heating, Ventilation, and Air Conditioning (HVAC) control module drives the temperature blend door until the door reaches both internal stops in the Heating, Ventilation, and Air Conditioning (HVAC) case. If the temperature blend door is temporarily obstructed or binding during a calibration cycle, the Heating, Ventilation, and Air Conditioning (HVAC) control module may interpret this as the actual end of travel for the door. When this condition occurs and the Heating, Ventilation, and Air Conditioning (HVAC) control module commands the actuator to its end of travel, the airflow may not be the expected temperature.

DTC FAULT TRIGGER CONDITIONS

1. Wiring, terminals or connectors
2. RH temperature blend door actuator
3. Heating, Ventilation, and Air Conditioning (HVAC) control module

PINPOINT TEST L: THE TEMPERATURE CONTROL IS INOPERATIVE OR DOES NOT OPERATE CORRECTLY - RH

1. L1 CHECK THE RIGHT HAND (RH) TEMPERATURE BLEND DOOR ACTUATOR CIRCUITS FOR AN OPEN Ignition OFF. Disconnect Heating, Ventilation, and Air Conditioning (HVAC) control module C228A. Disconnect Right Hand (RH) Temperature Blend Door Actuator. Measure: Positive Lead Measurement/Action Negative Lead C228A-9 C2092-1 C228A-25 C2092-2 C228A-10 C2092-3 C228A-22 C2092-4 C228A-23 C2092-6 Are the resistances less than 3 ohms? Yes : GO to L2 No : REPAIR the circuit in question.
2. L2 CHECK THE RIGHT HAND (RH) TEMPERATURE BLEND DOOR ACTUATOR CIRCUITS FOR A SHORT TO GROUND Measure: Positive Lead Measurement/Action Negative Lead C228A-9 Ground C228A-25 Ground C228A-10 Ground C228A-22 Ground C228A-23 Ground Are the resistances greater than 10, 000 ohms? Yes : GO to L3 No : REPAIR the circuit in question.
3. L3 CHECK THE RIGHT HAND (RH) TEMPERATURE BLEND DOOR ACTUATOR CIRCUITS FOR A SHORT TO POWER Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C228A-9 Ground C228A-25 Ground C228A-10 Ground C228A-22 Ground C228A-23 Ground Is any voltage present? Yes : REPAIR the circuit in question. No : INSTALL a new Right Hand (RH) temperature blend door actuator. REFER to: «TEMPERATURE DOOR ACTUATOR RH»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . TEST the system for normal operation. If the concern is still present, GO to L4
4. L4 CHECK FOR CORRECT HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE OPERATION Ignition OFF. Disconnect and inspect all the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, DISCONTINUE this test and FOLLOW Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Heating, Ventilation, and Air Conditioning (HVAC) control module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

The Blower Motor Is Inoperative

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Voltage is supplied to the blower motor relay from the BJB . When the blower motor relay coil receives a ground from the Body Control Module (BCM), the relay coil is energized and voltage is delivered to the blower motor control module. Power and ground for the blower motor is provided by the blower motor speed control. The Heating, Ventilation, and Air Conditioning (HVAC) control module sends a Pulse Width Modulated (PWM) signal to the blower motor speed control to control the blower speed.

DTC FAULT TRIGGER CONDITIONS

1. Wiring, terminals or connectors
2. Fuse(s)
3. Blower motor relay
4. Blower motor
5. Blower motor speed control
6. Body Control Module (BCM)
7. Heating, Ventilation, and Air Conditioning (HVAC) control module

1. Inspect BJB fuses 10 (40A) and 23 (5A).

PINPOINT TEST M: THE BLOWER MOTOR IS INOPERATIVE

1. M1 CHECK THE BODY CONTROL MODULE (BCM) FOR DIAGNOSTIC TROUBLE CODES (DTCS) Ignition ON. Using a scan tool, perform Body Control Module (BCM) self-test. Is DTC B10AF:13 or B10AF:19 received? Yes : For DTC B10AF:13, GO to M2 For DTC B10AF:19, GO to M3 For DTC B10B9:00, GO to M12 No : GO to M4
2. M2 CHECK THE BLOWER MOTOR RELAY CONTROL CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Body Control Module (BCM) C2280A. Disconnect Blower Motor Relay. Measure: Positive Lead Measurement/Action Negative Lead Blower Motor Relay Socket Pin 2 C2280A-28 Is the resistance less than 3 ohms? Yes : CONNECT Body Control Module (BCM) C2280A. GO to M4 No : REPAIR the circuit.
3. M3 CHECK THE BLOWER MOTOR RELAY CONTROL CIRCUIT FOR A SHORT TO POWER Ignition OFF. Disconnect Body Control Module (BCM) C2280A. Disconnect Blower Motor Relay. Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead Blower Motor Relay Socket Pin 2 Ground Is any voltage present? Yes : REPAIR the circuit. No : CONNECT Body Control Module (BCM) C2280A. GO to M4
4. M4 CHECK THE BLOWER MOTOR RELAY SUPPLY VOLTAGES Measure: Positive Lead Measurement/Action Negative Lead Blower Motor Relay Socket Pin 1 Ground Blower Motor Relay Socket Pin 3 Ground Are the voltages greater than 11 volts? Yes : GO to M5 No : VERIFY BJB fuses 23 (5A) and 10 (40A) are OK. If OK, REPAIR the circuit in question. If not OK, REFER to the «SYSTEM WIRING DIAGRAMS»(ref-541405) to identify the possible causes of the circuit short.
5. M5 CHECK THE OPERATION OF THE BLOWER MOTOR WITH THE BLOWER MOTOR RELAY BYPASSED Ignition OFF. Connect a fused jumper wire: Positive Lead Measurement/Action Negative Lead Blower Motor Relay Socket Pin 3 Blower Motor Relay Socket Pin 5 Ignition ON. Does the blower motor operate correctly? Yes : REPLACE the blower motor relay. No : REMOVE fused jumper wire. GO to M6
6. M6 CHECK FOR POWER AT THE BLOWER MOTOR SPEED CONTROL Ignition OFF. Disconnect Blower Motor Speed Control C297A. Connect Blower Motor Relay. Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C297A-4 Ground Is the voltage greater than 11 volts? Yes : GO to M8 No : GO to M7
7. M7 CHECK THE POWER CIRCUIT BETWEEN THE BATTERY JUNCTION BOX (BJB) BLOWER MOTOR SPEED CONTROL MODULE FOR AN OPEN Ignition OFF. Disconnect Blower Motor Relay. Measure: Positive Lead Measurement/Action Negative Lead C297A-4 Blower Motor Relay Socket Pin 5 Is the resistance less than 3 ohms? Yes : GO to M8 No : REPAIR the circuit.
8. M8 CHECK BLOWER MOTOR SPEED CONTROL GROUND FOR AN OPEN Ignition OFF. Measure: Positive Lead Measurement/Action Negative Lead C297A-2 Ground Is the resistance less than 3 ohms? Yes : GO to M9 No : REPAIR the circuit.
9. M9 CHECK THE OUTPUTS TO THE BLOWER MOTOR Ignition OFF. Disconnect Blower Motor. Connect Blower Motor Speed Control C297A. Ignition ON. Select the highest blower motor setting. Measure: Positive Lead Measurement/Action Negative Lead C2004-1 C2004-2 Is the voltage greater than 11 volts? Yes : INSTALL a new blower motor. REFER to: «BLOWER MOTOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : GO to M10
10. M10 CHECK THE CIRCUITS TO THE BLOWER MOTOR FOR AN OPEN Ignition OFF. Disconnect Blower Motor Speed Control C297B. Measure: Positive Lead Measurement/Action Negative Lead C297B-1 C2004-1 C297B-2 C2004-2 Are the resistances less than 3 ohms? Yes : GO to M11 No : REPAIR the circuit in question.
11. M11 CHECK THE BLOWER MOTOR CIRCUITS FOR A SHORT TOGETHER Measure: Positive Lead Measurement/Action Negative Lead C297B-1 C297B-2 Is the resistance greater than 10, 000 ohms? Yes : GO to M12 No : REPAIR the circuits.
12. M12 CHECK THE BLOWER MOTOR CONTROL CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Blower Motor Speed Control C297A. Disconnect Heating, Ventilation, and Air Conditioning (HVAC) control module C228B. Measure: Positive Lead Measurement/Action Negative Lead C228B-15 C297A-3 Is the resistance less than 3 ohms? Yes : GO to M13 No : REPAIR the circuit.
13. M13 CHECK THE BLOWER MOTOR CONTROL CIRCUIT FOR A SHORT TO GROUND Measure: Positive Lead Measurement/Action Negative Lead C228B-4 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to M14 No : REPAIR the circuit.
14. M14 CHECK THE BLOWER MOTOR CONTROL CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C228B-4 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new blower motor speed control. REFER to: «BLOWER MOTOR SPEED CONTROL»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__blower-motor-speed-control) . TEST the system for normal operation. If the concern is still present, GO to M16
15. M15 CHECK FOR CORRECT BODY CONTROL MODULE (BCM) OPERATION Ignition OFF. Disconnect and inspect all the Body Control Module (BCM) connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Body Control Module (BCM) connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, DISCONTINUE this test and FOLLOW Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Body Control Module (BCM). REFER to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#multifunction-electronic-modules-electric) . No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.
16. M16 CHECK FOR CORRECT HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE OPERATION Ignition OFF. Disconnect and inspect all the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, DISCONTINUE this test and FOLLOW Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Heating, Ventilation, and Air Conditioning (HVAC) control module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

The Blower Motor Does Not Operate Correctly

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Voltage is supplied to the blower motor relay from the BJB . When the blower motor relay coil receives a ground from the Body Control Module (BCM), the relay coil is energized and voltage is delivered to the blower motor control module. Power and ground for the blower motor is provided by the blower motor speed control. The Heating, Ventilation, and Air Conditioning (HVAC) control module sends a Pulse Width Modulated (PWM) signal to the blower motor speed control to control the blower speed.

DTC FAULT TRIGGER CONDITIONS

1. Wiring, terminals or connectors
2. Blower motor relay
3. Blower motor speed control
4. Body Control Module (BCM)
5. Heating, Ventilation, and Air Conditioning (HVAC) control module

PINPOINT TEST N: THE BLOWER MOTOR DOES NOT OPERATE CORRECTLY

1. N1 VERIFY THE BLOWER MOTOR OPERATION Ignition ON. Press the panel button on the Heating, Ventilation, and Air Conditioning (HVAC) control module. Adjust the blower motor setting to the minimum and maximum settings. Does the blower motor operate at any setting? Yes : If the blower motor is always ON, GO to N5 For all other blower motor concerns, GO to N2 No : GO to «PINPOINT TEST M»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-m-the-blower-motor)
2. N2 CHECK THE BLOWER MOTOR CONTROL CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Heating, Ventilation, and Air Conditioning (HVAC) control module C228B. Disconnect Blower Motor Speed Control C297A. Measure: Positive Lead Measurement/Action Negative Lead C228B-15 C297A-3 Is the resistance less than 3 ohms? Yes : GO to N3 No : REPAIR the circuit.
3. N3 CHECK THE BLOWER MOTOR CONTROL CIRCUIT FOR A SHORT TO GROUND Measure: Positive Lead Measurement/Action Negative Lead C228B-15 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to N4 No : REPAIR the circuit.
4. N4 CHECK THE BLOWER MOTOR CONTROL CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C228B-15 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new blower motor speed control. REFER to: «BLOWER MOTOR SPEED CONTROL»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__blower-motor-speed-control) . TEST the system for normal operation. If the concern is still present, GO to N7
5. N5 CHECK THE BLOWER MOTOR OPERATION WITH THE BLOWER MOTOR RELAY DISCONNECTED Ignition OFF Disconnect Blower Motor Relay. Does the fan still operate all the time? Yes : REPAIR circuit SBB47 (WH/RD) for a short to power. No : INSTALL a new blower motor relay. TEST the system for normal operation. If the concern is still present, GO to N6
6. N6 CHECK THE BLOWER MOTOR RELAY CONTROL CIRCUIT FOR A SHORT TO GROUND Disconnect Blower Motor Relay. Disconnect Body Control Module (BCM) C2280A. Measure: Positive Lead Measurement/Action Negative Lead Blower Motor Relay Socket Pin 2 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to N8 No : REPAIR the circuit.
7. N7 CHECK FOR CORRECT HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE OPERATION Ignition OFF. Disconnect and inspect all the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, DISCONTINUE this test and FOLLOW Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Heating, Ventilation, and Air Conditioning (HVAC) control module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.
8. N8 CHECK FOR CORRECT BODY CONTROL MODULE (BCM) OPERATION Ignition OFF. Disconnect and inspect all the Body Control Module (BCM) connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Body Control Module (BCM) connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, DISCONTINUE this test and FOLLOW Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Body Control Module (BCM). REFER to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#multifunction-electronic-modules-electric) . No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

B10B3:00, B10B4:00, B10B5:00, B10B6:00

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The 4 air discharge temperature sensors contain a thermistor. The sensor varies its resistance with the temperature. As the temperature rises, the resistance falls. As the temperature falls, the resistance rises.

DTC FAULT TRIGGER CONDITIONS

1. Wiring, terminals or connectors
2. Air discharge temperature sensor(s)
3. Heating, Ventilation, and Air Conditioning (HVAC) control module

PINPOINT TEST O: B10B3:00, B10B4:00, B10B5:00, B10B6:00

1. O1 CHECK THE AIR DISCHARGE TEMPERATURE SENSOR OUTPUT VOLTAGE Ignition ON. Turn the Heating, Ventilation, and Air Conditioning (HVAC) system on. Disconnect: the appropriate air discharge temperature sensor: LH center register air discharge temperature sensor C2438 LH footwell air discharge temperature sensor C2436 RH center register air discharge temperature sensor C2439 RH footwell air discharge temperature sensor C2437 Measure: Positive Lead Measurement/Action Negative Lead C2436-1 C2436-3 C2437-1 C2437-3 C2438-1 C2438-3 C2439-1 C2439-3 Is the voltage between 4.7 and 5.1 volts? Yes : INSTALL a new air discharge temperature sensor. REFER to: «FOOTWELL AIR DISCHARGE TEMPERATURE SENSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . REFER to: «CENTER REGISTER AIR DISCHARGE TEMPERATURE SENSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . CLEAR the Diagnostic Trouble Codes (DTCs). REPEAT the self-test. If Diagnostic Trouble Code (DTC) returns, GO to O7 No : GO to O2
2. O2 CHECK THE AIR DISCHARGE TEMPERATURE SENSOR SIGNAL CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Heating, Ventilation, and Air Conditioning (HVAC) control module C228B. Measure: Positive Lead Measurement/Action Negative Lead C2439-1 C228B-8 C2438-1 C228B-10 C2437-1 C228B-7 C2436-1 C228B-9 Are the resistances less than 3 ohms? Yes : GO to O3 No : REPAIR the circuit in question.
3. O3 CHECK THE AIR DISCHARGE TEMPERATURE SENSOR SIGNAL RETURN CIRCUIT FOR AN OPEN Measure: Positive Lead Measurement/Action Negative Lead C2436-3 C228B-17 C2437-3 C228B-17 C2438-3 C228B-17 C2439-3 C228B-17 Is the resistance less than 3 ohms? Yes : GO to O4 No : REPAIR the circuit in question.
4. O4 CHECK THE AIR DISCHARGE TEMPERATURE SENSOR SIGNAL CIRCUIT FOR A SHORT TO GROUND Measure: Positive Lead Measurement/Action Negative Lead C2439-1 Ground C2438-1 Ground C2437-1 Ground C2436-1 Ground Are the resistances greater than 10, 000 ohms? Yes : GO to O5 No : REPAIR the circuit in question.
5. O5 CHECK THE AIR DISCHARGE TEMPERATURE SENSOR SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C2439-1 Ground C2438-1 Ground C2437-1 Ground C2436-1 Ground Is any voltage present? Yes : REPAIR the circuit in question. No : GO to O6
6. O6 CHECK AIR DISCHARGE TEMPERATURE SENSOR SIGNAL CIRCUIT AND THE SIGNAL RETURN FOR A SHORT TO TOGETHER Ignition OFF. Measure: Positive Lead Measurement/Action Negative Lead C2439-1 C2439-3 C2438-1 C2438-3 C2437-1 C2437-3 C2436-1 C2436-3 Are the resistances greater than 10, 000 ohms? Yes : GO to O7 No : REPAIR the circuits in question.
7. O7 CHECK FOR CORRECT HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE OPERATION Ignition OFF. Disconnect and inspect all the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, DISCONTINUE this test and FOLLOW Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Heating, Ventilation, and Air Conditioning (HVAC) control module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

B1A61:00, B105A:00

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

In-Vehicle Temperature and Humidity Sensor

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

DTC FAULT TRIGGER CONDITIONS

1. Wiring, terminals or connectors
2. In-vehicle temperature and humidity sensor
3. Heating, Ventilation, and Air Conditioning (HVAC) control module

Scheme 9

1. P1 CHECK THE HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE DIAGNOSTIC TROUBLE CODES (DTCS) Ignition ON. Using a scan tool, perform Heating, Ventilation, and Air Conditioning (HVAC) control module self-test. Is DTC B1A61:00 received? Yes : GO to P2 No : GO to P7
2. P2 CHECK THE HVAC MODULE OUTPUT VOLTAGE Disconnect In-vehicle Temperature Sensor. Ignition ON. Turn the Heating, Ventilation, and Air Conditioning (HVAC) system on. Measure: Positive Lead Measurement/Action Negative Lead C2247-4 C2247-6 Is the voltage between 4.7 and 5.1 volts? Yes : INSTALL a new in-vehicle temperature and humidity sensor. REFER to: «IN-VEHICLE TEMPERATURE SENSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . TEST the system for normal operation. If the DTC returns, GO to P11 No : GO to P3
3. P3 CHECK THE IN-VEHICLE TEMPERATURE SENSOR FEEDBACK CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Heating, Ventilation, and Air Conditioning (HVAC) control module C228B. Measure: Positive Lead Measurement/Action Negative Lead C228B-21 C2247-4 Is the resistance less than 3 ohms? Yes : GO to P4 No : REPAIR the circuit.
4. P4 CHECK THE IN-VEHICLE TEMPERATURE SENSOR FEEDBACK CIRCUIT FOR SHORT TO GROUND Measure: Positive Lead Measurement/Action Negative Lead C228B-21 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to P7 No : REPAIR the circuit.
5. P5 CHECK THE IN-VEHICLE TEMPERATURE SENSOR FEEDBACK CIRCUIT FOR SHORT TO POWER Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C228B-21 Ground Is any voltage present? Yes : REPAIR the circuit. No : GO to P6
6. P6 CHECK THE SIGNAL RETURN CIRCUIT FOR AN OPEN Measure: Positive Lead Measurement/Action Negative Lead C228B-20 C2247-6 Is the resistance less than 3 ohms? Yes : GO to P11 No : REPAIR the circuit.
7. P7 CHECK THE ASPIRATOR FAN POWER CIRCUIT FOR VOLTAGE Disconnect Blower Motor Relay. Disconnect In-vehicle Temperature Sensor. Connect a fused jumper wire: Positive Lead Measurement/Action Negative Lead Blower Motor Relay Socket Pin 3 Blower Motor Relay Socket Pin 5 Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C2247-1 Ground Is the voltage greater than 11 volts? Yes : REMOVE fused jumper wire. GO to P8 No : VERIFY the BJB fuse 47 (5A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the «SYSTEM WIRING DIAGRAMS»(ref-541405) to identify the possible causes of the circuit short.
8. P8 CHECK THE ASPIRATOR FAN GROUND CIRCUIT FOR AN OPEN Ignition OFF. Connect Blower Motor Relay. Disconnect Heating, Ventilation, and Air Conditioning (HVAC) control module C228B. Measure: Positive Lead Measurement/Action Negative Lead C228B-2 C2247-3 Is the resistance less than 3 ohms? Yes : GO to P9 No : REPAIR the circuit.
9. P9 CHECK THE ASPIRATOR FAN GROUND CIRCUIT FOR A SHORT TO GROUND Measure: Positive Lead Measurement/Action Negative Lead C228B-2 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to P10 No : REPAIR the circuit.
10. P10 CHECK THE ASPIRATOR FAN GROUND CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C228B-2 Ground Is any voltage present? Yes : REPAIR the circuit. No : INSTALL a new in-vehicle temperature sensor. REFER to: «IN-VEHICLE TEMPERATURE SENSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . TEST the system for normal operation. If the DTC returns, GO to P11
11. P11 CHECK FOR CORRECT HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE OPERATION Ignition OFF. Disconnect and inspect the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Repair: corrosion (replace connector or terminals - clean module pins) damaged or bent pins - replace terminals/pins pushed-out pins - replace pins as necessary Reconnect the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Make sure they seat and latch correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, discontinue this test and follow Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Heating, Ventilation, and Air Conditioning (HVAC) control module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

B1A63:00, B1A64:00

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Sunload Sensor

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

DTC FAULT TRIGGER CONDITIONS

1. Wiring, terminals or connectors
2. Sunload sensor
3. Heating, Ventilation, and Air Conditioning (HVAC) control module

PINPOINT TEST Q: B1A63:00, B1A64:00

1. Q1 CHECK THE HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE FOR DIAGNOSTIC TROUBLE CODES (DTCS) Ignition ON. Using a scan tool, perform Heating, Ventilation, and Air Conditioning (HVAC) control module self-test. Are both Diagnostic Trouble Codes (DTCs) B1A63:00 and B1A64:00 received . Yes : GO to Q10 No : For DTC B1A63:00, GO to Q2 For DTC B1A64:00, GO to Q6
2. Q2 CHECK THE RIGHT SUNLOAD SENSOR REFERENCE VOLTAGE Ignition OFF. Disconnect Sunload Sensor. Ignition ON. Press the AUTO button. Measure: Positive Lead Measurement/Action Negative Lead C286-2 C286-3 Is the voltage between 4.7 and 5.1 volts? Yes : INSTALL a new sunload sensor. REFER to: «SUNLOAD SENSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : GO to Q3
3. Q3 CHECK THE RIGHT SUNLOAD FEEDBACK CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Heating, Ventilation, and Air Conditioning (HVAC) control module C228B. Measure: Positive Lead Measurement/Action Negative Lead C228B-23 C286-2 Is the resistance less than 3 ohms? Yes : GO to Q4 No : REPAIR the circuit.
4. Q4 CHECK THE RIGHT SUNLOAD SENSOR FEEDBACK CIRCUIT FOR A SHORT TO GROUND Measure: Positive Lead Measurement/Action Negative Lead C228B-23 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to Q5 No : REPAIR the circuit.
5. Q5 CHECK THE RIGHT SUNLOAD SENSOR FEEDBACK CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C228B-23 Ground Is any voltage present? Yes : REPAIR the circuit. No : GO to Q11
6. Q6 CHECK THE LEFT SUNLOAD SENSOR REFERENCE VOLTAGE Ignition OFF. Disconnect Sunload Sensor. Ignition ON. Press the AUTO button. Measure: Positive Lead Measurement/Action Negative Lead C286-1 C286-3 Is the voltage between 4.7 and 5.1 volts? Yes : INSTALL a new sunload sensor. REFER to: «LIGHT SENSOR»(/ford/focus-st/iii-2012-2015/remont/exterior-lights/#exterior-lighting-electric) . No : GO to Q7
7. Q7 CHECK THE LEFT SUNLOAD FEEDBACK CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Heating, Ventilation, and Air Conditioning (HVAC) control module C228B. Measure: Positive Lead Measurement/Action Negative Lead C228B-22 C286-1 Is the resistance less than 3 ohms? Yes : GO to Q8 No : REPAIR the circuit.
8. Q8 CHECK THE LEFT SUNLOAD SENSOR FEEDBACK CIRCUIT FOR A SHORT TO GROUND Measure: Positive Lead Measurement/Action Negative Lead C228B-22 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to Q9 No : REPAIR the circuit.
9. Q9 CHECK THE LEFT SUNLOAD SENSOR FEEDBACK CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C228B-22 Ground Is any voltage present? Yes : REPAIR the circuit. No : GO to Q11
10. Q10 CHECK THE SENSOR GROUND CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Heating, Ventilation, and Air Conditioning (HVAC) control module C228B. Disconnect Sunload Sensor. Measure: Positive Lead Measurement/Action Negative Lead C228B-20 C286-3 Is the resistance less than 3 ohms? Yes : INSTALL a new sunload sensor. REFER to: «SUNLOAD SENSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . If the DTC returns, GO to Q11 No : REPAIR the circuit.
11. Q11 CHECK FOR CORRECT HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE OPERATION Ignition OFF. Disconnect and inspect all the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, DISCONTINUE this test and FOLLOW Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Heating, Ventilation, and Air Conditioning (HVAC) control module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

U3006:16, U3006:17

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

The Heating, Ventilation, and Air Conditioning (HVAC) control module requires an operating voltage that is between 9 and 16 volts. The Heating, Ventilation, and Air Conditioning (HVAC) control module receives this voltage from the BJB . The Heating, Ventilation, and Air Conditioning (HVAC) control module has a single ground circuit located in the engine compartment wiring harness. Excessive resistance or an open in one or more of these circuits, a discharged battery or an inoperative charging system will result in the Heating, Ventilation, and Air Conditioning (HVAC) control module setting a DTC .

DTC FAULT TRIGGER CONDITIONS

1. Wiring, terminals or connectors
2. Direct Current/Direct Current (DC/DC) Converter control Module
3. Heating, Ventilation, and Air Conditioning (HVAC) control module

PINPOINT TEST R: U3006:16, U3006:17

1. R1 CARRY OUT THE HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE SELF-TEST Ignition ON Using a scan tool, clear Diagnostic Trouble Codes (DTCs). Wait 10 seconds. Using a scan tool, perform Heating, Ventilation, and Air Conditioning (HVAC) control module self-test. Is DTC U3006:16 or U3006:17 still present? Yes : GO to R2 No : The system is operating correctly at this time. The DTC may have been set due to a previous low battery voltage condition.
2. R2 RETRIEVE DIRECT CURRENT/DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE DIAGNOSTIC TROUBLE CODES (DTCS) Using a scan tool, perform Direct Current/Direct Current (DC/DC) Converter control Module self-test. Are any battery voltage Diagnostic Trouble Codes (DTCs) present in the Direct Current/Direct Current (DC/DC) Converter Control Module? Yes : REFER to: «DIRECT CURRENT/DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#voltage-converterinverter-electric) . No : GO to R3
3. R3 CHECK 12 VOLT BATTERY CONDITION Ignition OFF. Carry out the battery condition test. REFER to: «BATTERY»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#battery-mounting-cables-electric) . Does the battery pass the condition test? Yes : For DTC U3006:16, GO to R4 For DTC U3006:17, GO to R6 No : INSTALL a new battery. REFER to: «BATTERY»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#battery-mounting-cables-electric) .
4. R4 CHECK THE HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE VOLTAGE SUPPLY CIRCUIT FOR HIGH RESISTANCE Ignition OFF. Disconnect Heating, Ventilation, and Air Conditioning (HVAC) control module C228B. Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C228B-14 Ground Is the voltage greater than 11 volts? Yes : GO to R5 No : REPAIR the circuit.
5. R5 CHECK THE HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE GROUND CIRCUIT FOR HIGH RESISTANCE Ignition OFF. Measure: Positive Lead Measurement/Action Negative Lead C228B-6 Ground Is the resistance less than 3 ohms? Yes : GO to R6 No : REPAIR the circuit.
6. R6 CHECK FOR CORRECT HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE OPERATION Ignition OFF. Disconnect and inspect all the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Heating, Ventilation, and Air Conditioning (HVAC) control module connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, DISCONTINUE this test and FOLLOW Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Heating, Ventilation, and Air Conditioning (HVAC) control module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) . No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

U0155:00

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Control System Logic

REFER to: CLIMATE CONTROL SYSTEM - COMPONENT LOCATION .

DTC FAULT TRIGGER CONDITIONS

1. Wiring, terminals or connectors
2. IPC
3. Heating, Ventilation, and Air Conditioning (HVAC) control module

PINPOINT TEST S: U0155:00

1. S1 CHECK THE COMMUNICATION NETWORK Ignition ON. Using a scan tool, perform network test. Does the IPC pass the network test? Yes : GO to S2 No : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .
2. S2 RETRIEVE THE RECORDED DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE INSTRUMENT PANEL CLUSTER (IPC) SELF-TEST Using a scan tool, perform IPC self-test. Check for Diagnostic Trouble Codes (DTCs) from the IPC self-test. Is DTC U3006:16 or DTC U3006:17 recorded? Yes : REFER to: «INSTRUMENTATION, MESSAGE CENTER AND WARNING CHIMES»(/ford/focus-st/iii-2012-2015/remont/gauges-instrument-panels/#instrumentation-message-center-warning-chimes-electric) . No : GO to S3
3. S3 RETRIEVE THE RECORDED DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE SELF-TEST Using a scan tool, perform Heating, Ventilation, and Air Conditioning (HVAC) control module self-test. Check for recorded Diagnostic Trouble Codes (DTCs) from the Heating, Ventilation, and Air Conditioning (HVAC) control module self-test. Is DTC U3006:16 or DTC U3006:17 recorded? Yes : GO to «PINPOINT TEST R»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-r-u300616-u300617) No : GO to S4
4. S4 RECHECK THE HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) CONTROL MODULE DIAGNOSTIC TROUBLE CODES (DTCS) NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during the Programmable Module Installation (PMI) or the Programmable Module Installation (PMI) may not have been carried out. Clear the Diagnostic Trouble Codes (DTCs). Wait 10 seconds. Using a scan tool, perform Heating, Ventilation, and Air Conditioning (HVAC) control module self-test. Is DTC U0155:00 still present? Yes : GO to S5 No : The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
5. S5 CHECK FOR DIAGNOSTIC TROUBLE CODE (DTC) U0155:00 SET IN OTHER MODULES Clear all Diagnostic Trouble Codes (DTCs). Ignition OFF. Ignition ON. Wait 10 seconds. Using a scan tool, retrieve all continuous memory Diagnostic Trouble Codes (DTCs). Is DTC U0155:00 set in any other module? Yes : INSTALL a new IPC. REFER to: «INSTRUMENT PANEL CLUSTER (IPC)»(/ford/focus-st/iii-2012-2015/remont/gauges-instrument-panels/#instrumentation-message-center-warning-chimes-electric) . No : INSTALL a new Heating, Ventilation, and Air Conditioning (HVAC) control module. REFER to: «HEATING, VENTILATION AND AIR CONDITIONING (HVAC) CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) .

B1B71:21, B1B71:22, B1B71:2F

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Evaporator Temperature Sensor

REFER to: CLIMATE CONTROL SYSTEM - SYSTEM OPERATION AND COMPONENT DESCRIPTION .

DTC FAULT TRIGGER CONDITIONS

1. Wiring, terminals or connectors
2. Evaporator temperature sensor
3. Body Control Module (BCM)

PINPOINT TEST T: B1B71:21, B1B71:22, B1B71:2F

1. T1 CHECK THE BODY CONTROL MODULE (BCM) OUTPUT VOLTAGE TO THE EVAPORATOR TEMPERATURE SENSOR Ignition OFF. Disconnect Evaporator Temperature Sensor. Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C296-1 C296-3 Is the voltage between 4.7 and 5.1 volts? Yes : INSTALL a new evaporator temperature sensor. REFER to: «EVAPORATOR TEMPERATURE SENSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__evaporator-temperature-sensor) . No : For DTC B1B71:22, GO to T2 For DTC B1B71:21, GO to T5
2. T2 CHECK THE EVAPORATOR TEMPERATURE SENSOR CIRCUIT FOR AN OPEN Ignition OFF. Disconnect Body Control Module (BCM) C2280C. Measure: Positive Lead Measurement/Action Negative Lead C296-1 C2280C-9 Is the resistance less than 3 ohms? Yes : GO to T3 No : REPAIR the circuit.
3. T3 CHECK THE EVAPORATOR TEMPERATURE SENSOR SIGNAL RETURN CIRCUIT FOR AN OPEN Measure: Positive Lead Measurement/Action Negative Lead C296-3 C2280C-29 Is the resistance less than 3 ohms? Yes : GO to T4 No : REPAIR the circuit.
4. T4 CHECK THE EVAPORATOR TEMPERATURE SENSOR SIGNAL RETURN CIRCUIT FOR A SHORT TO POWER Ignition ON. Measure: Positive Lead Measurement/Action Negative Lead C2280C-29 Ground Is any voltage present? Yes : REPAIR the circuit. No : GO to T7
5. T5 CHECK THE EVAPORATOR TEMPERATURE SENSOR SIGNAL AND SIGNAL RETURN CIRCUITS FOR A SHORT TOGETHER Ignition OFF. Disconnect Body Control Module (BCM) C2280C. Disconnect Evaporator Temperature Sensor. Measure: Positive Lead Measurement/Action Negative Lead C296-1 C296-3 Is the resistance greater than 10, 000 ohms? Yes : GO to T6 No : REPAIR the circuits.
6. T6 CHECK THE EVAPORATOR TEMPERATURE SENSOR SIGNAL CIRCUIT FOR A SHORT TO GROUND Disconnect Sunload Sensor. Measure: Positive Lead Measurement/Action Negative Lead C296-1 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to T7 No : REPAIR the circuit.
7. T7 CHECK FOR CORRECT BODY CONTROL MODULE (BCM) OPERATION Ignition OFF. Disconnect and inspect all the Body Control Module (BCM) connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Body Control Module (BCM) connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK On-Line Automotive Service Information System (OASIS) for any applicable Technical Service Bulletins (TSBs). If a Technical Service Bulletin (TSB) exists for this concern, DISCONTINUE this test and FOLLOW Technical Service Bulletin (TSB) instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Body Control Module (BCM). REFER to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#multifunction-electronic-modules-electric) . No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

U0293:00

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Control System Logic

REFER to: CLIMATE CONTROL SYSTEM - COMPONENT LOCATION .

DTC FAULT TRIGGER CONDITIONS

1. Wiring, terminals or connectors
2. PCM
3. Air Conditioning Control Module (ACCM)

PINPOINT TEST U: U0293:00

1. U1 CHECK THE COMMUNICATION NETWORK Ignition ON. Using a scan tool, perform network test. Does the PCM pass the network test? Yes : GO to U2 No : REFER to: «COMMUNICATIONS NETWORK»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#module-communications-network-electric) .
2. U2 CHECK THE AIR CONDITIONING CONTROL MODULE (ACCM) CONTINUOUS MEMORY DIAGNOSTIC TROUBLE CODES (CMDTCS) Using a scan tool, carry out the Air Conditioning Control Module (ACCM) self-test. Retrieve and record all Air Conditioning Control Module (ACCM) Diagnostic Trouble Codes (DTCs). Clear the Diagnostic Trouble Codes (DTCs). Ignition OFF. Ignition ON. Repeat the Air Conditioning Control Module (ACCM) self-test. Is DTC U0293:00 retrieved again? Yes : GO to U3 No : The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
3. U3 RETRIEVE THE RECORDED DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE AIR CONDITIONING CONTROL MODULE (ACCM) SELF-TEST Using a scan tool, perform Air Conditioning Control Module (ACCM) self-test. Check for recorded Diagnostic Trouble Codes (DTCs) from the Air Conditioning Control Module (ACCM) self-test. Is DTC P0562:00 or DTC P0563:00 recorded? Yes : For DTC P0562:00, GO to «PINPOINT TEST A»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__pinpoint-test-a-p056200) For DTC P0563:00, REFER to: «DIRECT CURRENT/DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#voltage-converterinverter-electric) . No : GO to U4
4. U4 RETRIEVE ANY DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE POWERTRAIN CONTROL MODULE (PCM) SELF-TEST NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during the Programmable Module Installation (PMI) or the Programmable Module Installation (PMI) may not have been carried out. Using a scan tool, perform PCM self-test. Check for recorded Diagnostic Trouble Codes (DTCs) from the PCM self-test. Is DTC P0560:16 or P0560:17 recorded? Yes : REFER to: «ELECTRIC POWERTRAIN CONTROL»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : GO to U5
5. U5 CHECK FOR DIAGNOSTIC TROUBLE CODE (DTC) U0293:00 SET IN OTHER MODULES Clear all Diagnostic Trouble Codes (DTCs). Ignition OFF. Ignition ON. Wait 10 seconds. Using a scan tool, retrieve all continuous memory Diagnostic Trouble Codes (DTCs). Is DTC U0293:00 set in any other module? Yes : INSTALL a new PCM . REFER to: «POWERTRAIN CONTROL MODULE (PCM)»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electric-powertrain-control) . No : INSTALL a new Air Conditioning (A/C) Electric Compressor. REFER to: «AIR CONDITIONING (A/C) ELECTRIC COMPRESSOR»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) .

Component Test-Heater Core

Note. If a heater core leak is suspected, test the heater core by following the plugged heater core component test before the heater core pressure test. Carry out a system inspection by checking the heater system thoroughly as follows

1. Inspect for evidence of coolant leakage at the heater hose to heater core attachments. A coolant leak in the heater hose could follow the heater core tube to the heater core and appear as a leak in the heater core. NOTE: Spring-type clamps are installed as original equipment. Installation and overtightening of non-specified clamps can cause leakage at the heater hose connection and damage the heater core.
2. Check the integrity of the heater hose clamps.

Heater Core - Plugged

1. Check to see the engine coolant is at the correct level.
2. Start the engine and turn on the heater.
3. When the engine coolant reaches operating temperature, check the heater core inlet and outlet hoses to see if they are hot.
4. If the outlet only is not hot: the heater core may have an air pocket. the heater core may be plugged.
5. If the inlet only is not hot, the thermostat may not be working correctly.

Heater Core - Pressure Test

Note. Due to space limitations, a bench test may be necessary for pressure testing.

1. Drain the coolant from the cooling system.
2. Disconnect the heater hoses from the heater core.
3. Install a short piece of heater hose, approximately 101 mm (4 in) long on each heater core tube.
4. Fill the heater core and heater hoses with water and install the plug BT-7422-B and the adapter BT-7422-A from the Pressure Test Kit. Secure the heater hoses, plug and adapter with hose clamps.
5. Attach the pump and gauge assembly from the Pressure Test Kit to the adapter.
6. Close the bleed valve at the base of the gauge. Pump 138 kPa (20 psi) of air pressure into the heater core.
7. Observe the pressure gauge for a minimum of 3 minutes.
8. If the pressure drops, check the heater hose connections to the core tubes for leaks. If the heater hoses do not leak, remove the heater core from the vehicle and carry out the bench test.

Heater Core - Bench Test

1. Remove the heater core from the vehicle.
2. Drain all of the coolant from the heater core.
3. Connect the 101 mm (4 in) test heater hoses with plug and adapter to the core tubes. Then connect the Pressure Test Kit to the adapter.
4. Apply 138 kPa (20 psi) of air pressure to the heater core. Submerge the heater core in water.
5. If a leak is observed, install a new heater core.

Component Test-Evaporator or Condenser Core On-Vehicle Leak Test

Component Test-Air Conditioning (A/C) Compressor External Leak Test

Activation

1. NOTE: An A/C refrigerant analyzer must be used before the recovery of any vehicle's A/C refrigerant. Failure to do so puts the shop's bulk refrigerant at risk of contamination. If the vehicle's A/C refrigerant is contaminated, refer the customer to the service facility that carried out the last A/C service. If the customer wishes to pay the additional cost, use the A/C recovery equipment that is designated for recovering contaminated A/C refrigerant. All contaminated A/C refrigerant must be disposed of as hazardous waste. For all equipment, follow the equipment manufacturer procedures and instructions. NOTE: Suction accumulator or receiver/drier, TXV and/or evaporator core orifice, and hoses with mufflers, should be removed when flushing the A/C system. Internal plumbing of these devices makes it impossible to correctly remove any residual-flushing agent. These components are typically discarded after A/C system contamination. Hoses without mufflers can normally be reused unless they are clogged with foreign material. NOTE: Only the listed A/C Flush and Purge Machine, A/C Flush and Purge Fitting Kit, A/C Flush Adapter Kit and Motorcraft® A/C System Flushing Solvent are approved for use on Ford vehicles. No other flushing device or solvent is approved for flushing heat exchangers (A/C condenser, A/C evaporator). Use of any other flusher or solvent may cause damage to the A/C system and the flushing unit. NOTE: Specialized equipment to flush debris and contaminates from the A/C refrigeration system is currently not available. After a compressor or receiver dryer (desiccant) failure, the condenser, evaporator, thermostatic expansion valve with tube, evaporator-to-compressor suction line and compressor to condenser discharge line must be replaced. Once the special flushing equipment is made available, this procedure will be revised. Please continue to reference the online service manual on each repair for any updates or revisions to this procedure.

Air Conditioning (A/C) System Recovery, Evacuation and Charging

Special Tool(s)/General Equipment

Air Conditioning Service Unit

Recovery

Evacuation

1. Connect the tool to the low- and high-pressure service gauge port valves following the operating instructions provided by the equipment manufacturer. General Equipment: Air Conditioning Service Unit
2. NOTE: Never attempt to recover from only the low side service gauge port valve (Solenoid valves in the system will not allow for full recovery). Evacuate the system until the low-pressure gauge reads at least 99.4 kPa (29.5 in-Hg) of vacuum and as close to 101.1 kPa (30 in-Hg) as possible. Continue to operate the Vacuum Pump for a minimum of 45 minutes.
3. Turn OFF the vacuum pump. Observe the low-pressure gauge for 5 minutes to make sure that the system vacuum is held.

Charging

1. Lubricate the refrigerant system with the correct amount of clean Polyelester (POE) YN-32 oil. Refer to: «REFRIGERANT OIL ADDING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__refrigerant-oil-adding) .
2. Connect the tool to the low-side and high-side service gauge port valves following the operating instructions provided by the equipment manufacturer. General Equipment: Air Conditioning Service Unit
3. Set the refrigerant charge amount, and charge the refrigerant system following the instructions provided by the equipment manufacturer.

Filling

Note. Motorcraft® Electric A/C Compressor POE YN-32 oil only must be used as a refrigerant system lubricant for HEV (Hybrid Electric Vehicles). Addition of any oil other than Motorcraft® Electric A/C Compressor POE YN-32 oil to the High Voltage Battery Electric vehicle refrigerant system will damage the electric A/C compressor and contaminate the refrigerant system.

Note. Do not use the R-134a Refrigerant Management Machine built-in oil injection system to inject Motorcraft Electric A/C Compressor POE YN-32 oil to the refrigerant system on HEV (Hybrid Electric Vehicles) equipped with an electric A/C ) compressor if it has been previously used to inject PAG oil. For HEV (Hybrid Electric Vehicles), use only clean manual injection tools. Injection of Motorcraft Electric A/C Compressor POE YN-32 oil into a HEV (Hybrid Electric Vehicles) with equipment previously used with PAG oil will contaminate and damage the High Voltage Battery Electric A/C system.

Note. During normal A/C operation, oil is circulated through the system with the refrigerant, and a small amount is retained in each component. If certain components of the system are removed, some of the refrigerant oil will go with the component. To maintain the original total oil charge, it is necessary to compensate for the oil lost by adding oil to the system with the new part.

Refrigerant Oil Adding

Oil Injection Using a Dye/Lubricant Injector

1. NOTE: 2. If fluorescent leak detection dye is also to be added during A/C charging, the dye may be added to the dye/lubricant injector, from the R-134a Loop/Add On Injector Kit-Set, along with the POE YN-32 oil. Evacuate the refrigerant system. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__air-conditioning-ac-system-recovery-evacuation) .
2. 3. Assemble the dye/lubricant injector and the correct adapters to match the amount of refrigerant compressor oil to be injected.
3. 4. Verify that all the valves on the dye/lubricant injector are closed.
4. 5. Fill the dye/lubricant injector with the correct amount of clean, new POE YN-32 oil.
5. 6. Install the dye/lubricant injector between the low-side service gauge port valve and the refrigerant service station or manifold gauge set.
6. 7. Open all valves and charge the refrigerant system. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__air-conditioning-ac-system-recovery-evacuation) .

Inspection

1. NOTE: Good ventilation is necessary in the area where electronic A/C leak testing is to be carried out. If the surrounding air is contaminated with refrigerant gas, the leak detector will indicate this gas all the time. Odors from other chemicals such as antifreeze, disc brake cleaner or other cleaning solvents can cause the same problem. Using a fan to ventilate the area to be tested before proceeding with the leak detection procedure is helpful in removing small traces of contamination from the air, but the fan should be turned off during actual testing. NOTE: R-134a is heavier than air, and will tend to move downward from the source of the leak if present. It is possible that a leak may not be detected if the leak detector tip is held above the leaking fitting, line or component. Always be sure to thoroughly leak test below the fitting, line or component for the presence of R-134a as well as leak testing above and around. NOTE: The system pressure should be between 413 kPa (59.9 psi) to 551 kPa (79.91 psi) at 24 C (75.2 F) with the electric motor off and cool. The pressure reading may be higher if the electric motor is hot. Leak test the refrigerant system using a general Electronic Leak Detector. Follow the instructions included with the general Electronic Leak Detector tool for handling and operation techniques.

Scheme 10

Scheme 11

1. NOTE: Ambient Temperature at or Below 38C (100F) Drive the vehicle or run the electric motor until it reaches normal operating temperature.
2. Connect the air conditioning service unit to the refrigerant system.
3. Set the climate controls.
4. Set temperature to (lowest possible temp setting) with the dual function disabled (if equipped). Manually set blower on HI. If the vehicle has a fresh air/recirc button, set it to FRESH. If the vehicle has an Air Conditioning (A/C) switch or compressor on switch, set it to Air Conditioning (A/C) ON.
5. Open all vehicle windows and leave the hood open for the test. Open the rear doors.
6. Confirm the compressor is operating and the engine cooling fan(s) are operating or engaged. Allow the vehicle to idle until the suction (low-side) and discharge (high-side) pressures are stable or fluctuate in a range that repeats.
7. Record the ambient (shop) temperature.
8. Record the discharge pressure. If the pressure is fluctuating, record the average value.
9. Determine if the discharge pressure falls within the normal operating limits using the Normal Refrigerant Discharge Pressures chart.
10. Record the suction pressure. If the pressure is fluctuating, record the average value.
11. Determine if the suction pressure falls between normal operating limits using the Normal Refrigerant Suction Pressures chart.
12. Proceed to the Diagnostic Table.

Scheme 12

Scheme 13

1. NOTE: Ambient Temperature Above 38C (100F) Drive the vehicle or run the electric motor until it reaches normal operating temperature.
2. Connect the air conditioning service unit to the refrigerant system.
3. Set the climate controls.
4. Set temperature to (lowest possible temp setting) with the dual function disabled (if equipped). Manually set blower on HI. If the vehicle has a fresh air/recirc button, set it to FRESH. If the vehicle has an Air Conditioning (A/C) switch or compressor on switch, set it to Air Conditioning (A/C) ON.
5. Open all vehicle windows and leave the hood open for the test. Open the rear hatch and/or rear doors (if equipped).
6. Confirm the compressor is operating and the engine cooling fan(s) are operating or engaged. Allow the vehicle to idle until the suction (low-side) and discharge (high-side) pressures are stable or fluctuate in a range that repeats.
7. Record the ambient (shop) temperature.
8. Record the discharge pressure. If the pressure is fluctuating, record the average value.
9. Determine if the discharge pressure falls within the normal operating limits using the Normal Refrigerant Discharge Pressures chart.
10. Record the suction pressure. If the pressure is fluctuating, record the average value.
11. Determine if the suction pressure falls between normal operating limits using the Normal Refrigerant Suction Pressures chart.
12. Proceed to the Diagnostic Table.

Cleaning

Note. There are typically 4 types of objectionable odors found in a vehicle: Chemical odors, environmental odors, human and other interior-generated odors, microbiological odors Before determining that A/C odor treatment is required, the source and the circumstances under which the odor occurs must be determined.

Note. Chemical odors are usually constant regardless of the climate control system setting although they may be enhanced by A/C operation. Most chemical odors are caused by fluid leaks or incorrectly cured adhesives. Chemical odors can be eliminated by repairing the leaking component and removing any residue.

Note. Environmental odors usually occur for a short time and diminish after the vehicle passes through the affected area. These odors are typically only detected when the vehicle windows are open, or when the climate control system is operating in a mode that allows for fresh air. Environmental odors cannot be eliminated because they are external in source, but they may be minimized by switching to a climate control setting that uses recirculated air.

Note. Human and other interior-generated odors occur while the source is present and may linger for a short time after. These odors may be more noticeable during A/C operation. Human odors may be eliminated by removing the source and cleaning the affected area.

Note. Microbiological odors, if in the A/C system, usually last for about 30 seconds after the system is turned on. They will be detected while the A/C is turned on and using either outside or recirculated air. Microbiological odors that occur in areas other than the A/C system (for example, water in doors or wet carpeting) may last indefinitely and will be more intense when recirculated air is used. Microbiological odors will not be present at temperatures at or below 10 C (50 F).

1. Microbiological odors can be eliminated by removing the source and treating the affected area. Standing water must be allowed to drain and dry out. A/C systems may be treated by using A/C Cooling Coil Coating as described in the service procedure below. Microbiological odors result from microbial growth supported by warm temperatures and moisture. Microbiological odors are described as musty/mildew type smells and may occur on/in: foam seals, rubber seals, adhesives, standing water, water soaked carpet/trim.
2. NOTE: Identify the type of odor present in the vehicle. Do not proceed with A/C odor treatment if the odor source is found to be outside of the A/C system. Refer to the following list for examples. Transmission Fluid - Oil type or burning smell Washer Fluid - Alcohol type smell Gear Lube - Garlic/sulfur smell Refrigerant Oil - Ether type smell Carpet/Trim Adhesives - Fishy, urine or sweet smell Evaporator Core Coating - Wet cement type smell Industrial Pollutants - Various smells Dust - Musty, mildew or wet cement type smell Pollen - Sweet smell Tobacco - Burning, tar smell Body Secretions - Body odor Perfuming Agents - Sweet or fragrance smell Clothing - Musty, mildew or body odors Food/Beverage Microbiological Odors Occurring Inside of A/C System - Musty, mildew smell lasting about 30 seconds after A/C is turned on Microbiological Odors Occurring Outside of A/C System - Musty, mildew smell lasting indefinitely and possibly more pronounced when using recirculated air
3. NOTE: Identify the source of the odor. Check the evaporator core drain tube for restriction. Check the passenger and driver side carpet for moisture. If moisture is found, A/C odor treatment is not necessary. Diagnose for a water leak as needed. Check the blower motor and blower motor cover (if equipped) for moisture resulting from water bypassing the cowl baffling system. If moisture is found, A/C odor treatment is not necessary. Diagnose for a water leak as needed. Check the cowl top panel and air inlet screen for standing water or foreign material. If possible, remove any standing water and clean the air inlet screen using a wet/dry vacuum.
4. Open all vehicle windows and doors.
5. Make sure that the A/C is off.
6. Set the following
7. Select REGISTER mode (A/C off).
8. Adjust the temperature setting to full warm.
9. Adjust the blower motor speed to HI.
10. Run the electric motor for 25 minutes to dry out the A/C system.
11. Turn the ignition OFF.
12. Remove the blower motor.
13. NOTE: Blower motor speed controls that are mounted outside of the evaporator core housing and not exposed to the blower motor airflow do not need to be removed. Remove the blower motor speed control (if equipped and exposed to the inside of the evaporator core housing).
14. NOTE: To avoid damage to the vehicle interior, do not spill or spray this product on any interior surface. Add one full bottle of A/C Cooling Coil Coating to the Flexible Applicator Tool.
15. Insert the nozzle into the evaporator housing and direct the spray toward the evaporator core face. Spray the entire evaporator core face until empty.
16. Install the blower motor and blower motor speed control.
17. Repeat Steps 5 through 10 to cure the evaporator core coating.

Removal

Note. Removal steps in this procedure may contain installation details.

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. Refer to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#multifunction-electronic-modules-electric) .
2. Torque: 15 Nm
3. Disconnect the air inlet door actuator electrical connector, and remove the front air inlet duct retainer.
4. Install the ratchet, extension and socket as shown in illustration. Remove the upper air inlet duct retainer.
5. Install the ratchet, extension and socket as shown in illustration. Remove the lower air inlet duct retainer and the air inlet duct.
6. Release the retaining clip holding the blower motor while an assistant from the passenger side compartment reaches through the blower motor cage and turns the blower motor housing 45 degrees clockwise to release and remove the blower motor.

Installation

1. With the blower motor on the bench make a reference mark 180 degrees from the labelled TOP on the blower motor to aid in alignment during installation.
2. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. WARNING: Before beginning any service procedure, refer to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Failure to follow this instruction may result in serious personal injury. Refer to: «CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric__climate-control-system-health-and-safety) .
2. Refer to: «INSTRUMENT PANEL»(/ford/focus-st/iii-2012-2015/remont/gauges-instrument-panels/#instrument-panel-console-electric) .
3. Torque: 10 Nm

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. WARNING: Before beginning any service procedure, refer to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Failure to follow this instruction may result in serious personal injury. Refer to: «CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric__climate-control-system-health-and-safety) .
2. NOTE: To prevent setting Diagnostic Trouble Codes (DTCs), make sure the ignition switch is in the OFF position prior to disconnecting the accelerator pedal electrical connector. Torque: 8 Nm

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 19

Scheme 20

1. WARNING: Before beginning any service procedure, refer to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Failure to follow this instruction may result in serious personal injury. Refer to: «CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric__climate-control-system-health-and-safety) .
2. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__air-conditioning-ac-system-recovery-evacuation) .
3. Torque: 16 Nm 15 Nm

1. To install, reverse the removal procedure.
2. Refer to: «REFRIGERANT OIL ADDING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__refrigerant-oil-adding) .

Note. Removal steps in this procedure may contain installation details.

1. WARNING: Before beginning any service procedure, refer to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Failure to follow this instruction may result in serious personal injury. Refer to: «CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric__climate-control-system-health-and-safety) .
2. Refer to: «HEATER CORE»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) .

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 21

Scheme 22

1. WARNING: Before beginning any service procedure, refer to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Failure to follow this instruction may result in serious personal injury. Refer to: «CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric__climate-control-system-health-and-safety) .
2. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__air-conditioning-ac-system-recovery-evacuation) .
3. Refer to: «FRONT BUMPER COVER»(/ford/focus-st/iii-2012-2015/remont/exterior-body-panels/#bumper-system-electric) .
4. Torque: 15 Nm

1. To install, reverse the removal procedure.
2. Refer to: «REFRIGERANT OIL ADDING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__refrigerant-oil-adding) .

Note. Removal steps in this procedure may contain installation details.

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. WARNING: Before beginning any service procedure, refer to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Failure to follow this instruction may result in serious personal injury. Refer to: «CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric__climate-control-system-health-and-safety) .
2. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__air-conditioning-ac-system-recovery-evacuation) .
3. Refer to: «JACKING AND LIFTING - OVERVIEW»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#jacking-lifting-electric) .
4. Both sides. Torque: 25 Nm
5. Torque: 25 Nm

1. To install, reverse the removal procedure.
2. Refer to: «REFRIGERANT OIL ADDING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__refrigerant-oil-adding) .

Note. Removal steps in this procedure may contain installation details.

1. NOTE: The Ambient Air Temperature Sensor is serviced with the passenger side exterior mirror. Remove the exterior mirror on passenger side. Refer to: «EXTERIOR MIRROR»(/ford/focus-st/iii-2012-2015/remont/mirrors/#rear-view-mirrors-electric) .

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. If equipped, remove the driver knee airbag. Refer to: «DRIVER KNEE AIRBAG - VEHICLES BUILT FROM: 11-JUNE-2012»(/ford/focus-st/iii-2012-2015/remont/airbag/#supplemental-restraint-system-electric) .
2. NOTE: Steering column opening trim panel without driver knee air bag shown in illustration, with driver knee air bag similar.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. WARNING: Before beginning any service procedure, refer to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Failure to follow this instruction may result in serious personal injury. Refer to: «CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric__climate-control-system-health-and-safety) .
2. Refer to: «HEATER CORE AND EVAPORATOR CORE HOUSING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric) .
3. Refer to: «INSTRUMENT PANEL»(/ford/focus-st/iii-2012-2015/remont/gauges-instrument-panels/#instrument-panel-console-electric) .
4. Torque: 10 Nm
5. Torque: 25 Nm

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. Refer to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#multifunction-electronic-modules-electric) .

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. If equipped, remove the driver knee airbag. Refer to: «DRIVER KNEE AIRBAG - VEHICLES BUILT FROM: 11-JUNE-2012»(/ford/focus-st/iii-2012-2015/remont/airbag/#supplemental-restraint-system-electric) .
2. NOTE: Steering column opening trim panel without driver knee air bag shown in illustration, with driver knee air bag similar.
3. Torque: 2.5 Nm
4. Torque: 3 Nm

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. Torque: 3 Nm

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. Refer to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/communication-devices/#multifunction-electronic-modules-electric) .
2. Torque: 15 Nm

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 29

1. Torque: 7 Nm

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 30

1. Refer to: «JACKING AND LIFTING - OVERVIEW»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#jacking-lifting-electric) .
2. Torque: 7 Nm

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 31

Scheme 32

1. WARNING: Before beginning any service procedure, refer to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Failure to follow this instruction may result in serious personal injury. Refer to: «CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric__climate-control-system-health-and-safety) .
2. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__air-conditioning-ac-system-recovery-evacuation) .
3. Torque: 17 Nm
4. Torque: 5 Nm

1. To install, reverse the removal procedure.
2. Refer to: «REFRIGERANT OIL ADDING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__refrigerant-oil-adding) .

Note. Removal steps in this procedure may contain installation details.

1. Refer to: «FRONT CONTROLS INTERFACE MODULE (FCIM)»(/ford/focus-st/iii-2012-2015/remont/entertainment-systems/#information-entertainment-systems-with-o-touchscreen-electric) .
2. If equipped, remove the driver knee airbag. Refer to: «DRIVER KNEE AIRBAG - VEHICLES BUILT FROM: 11-JUNE-2012»(/ford/focus-st/iii-2012-2015/remont/airbag/#supplemental-restraint-system-electric) .
3. NOTE: Steering column opening trim panel without driver knee air bag shown in illustration, with driver knee air bag similar.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. WARNING: Before beginning any service procedure, refer to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Failure to follow this instruction may result in serious personal injury. Refer to: «CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric__climate-control-system-health-and-safety) .
2. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__air-conditioning-ac-system-recovery-evacuation) .
3. NOTE: Necessary to remove the cabin thermostatic expansion valve manifold and tube assembly.
4. Torque: 11 Nm 15 Nm 3 Nm

1. To install, reverse the removal procedure.
2. Refer to: «REFRIGERANT OIL ADDING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__refrigerant-oil-adding) .

Note. Removal steps in this procedure may contain installation details.

Scheme 33

Scheme 34

Scheme 35

Scheme 36

1. WARNING: Before beginning any service procedure, refer to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Failure to follow this instruction may result in serious personal injury. Refer to: «CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric__climate-control-system-health-and-safety) .
2. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__air-conditioning-ac-system-recovery-evacuation) .
3. Refer to: «JACKING AND LIFTING - OVERVIEW»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#jacking-lifting-electric) .
4. Torque: 10 Nm 13 Nm
5. Torque: 15 Nm
6. Torque: 8 Nm

1. To install, reverse the removal procedure.
2. Refer to: «REFRIGERANT OIL ADDING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__refrigerant-oil-adding) .
3. Refer to: «COOLING SYSTEM FILLING AND BLEEDING»(/ford/focus-st/iii-2012-2015/remont/cooling-system-mechanical/#electric-powertrain-cooling) .

Scheme 37

Scheme 38

Scheme 39

1. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__air-conditioning-ac-system-recovery-evacuation) .
2. Torque: 11 Nm 15 Nm
3. Torque: 15 Nm
4. Torque: 8 Nm

1. To install, reverse the removal procedure. Refer to: «REFRIGERANT OIL ADDING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__refrigerant-oil-adding) .

Note. Removal steps in this procedure may contain installation details.

Scheme 40

1. WARNING: Before beginning any service procedure, refer to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Failure to follow this instruction may result in serious personal injury. Refer to: «CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric__climate-control-system-health-and-safety) .
2. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__air-conditioning-ac-system-recovery-evacuation) .
3. Torque: 11 Nm 15 Nm
4. Torque: 8 Nm

1. To install, reverse the removal procedure.
2. Refer to: «REFRIGERANT OIL ADDING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__refrigerant-oil-adding) .

Note. Removal steps in this procedure may contain installation details.

Scheme 41

Scheme 42

1. WARNING: Before beginning any service procedure, refer to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) Failure to follow this instruction may result in serious personal injury. Refer to: «CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric__climate-control-system-health-and-safety) .
2. Refer to: «HIGH VOLTAGE BATTERY DISCONNECT AND CONNECT»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#high-voltage-battery-mounting-cables-electric) .
3. Refer to: «JACKING AND LIFTING - OVERVIEW»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#jacking-lifting-electric) .
4. Torque: 15 Nm 10 Nm

1. To install, reverse the removal procedure.
2. Refer to: «COOLING SYSTEM FILLING AND BLEEDING»(/ford/focus-st/iii-2012-2015/remont/cooling-system-mechanical/#electric-powertrain-cooling) .

Note. Removal steps in this procedure may contain installation details.

1. If equipped, remove the driver knee airbag. Refer to: «DRIVER KNEE AIRBAG - VEHICLES BUILT FROM: 11-JUNE-2012»(/ford/focus-st/iii-2012-2015/remont/airbag/#supplemental-restraint-system-electric) .
2. NOTE: Steering column opening trim panel without driver knee air bag shown in illustration, with driver knee air bag similar.
3. Torque: 3 Nm

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 43

Scheme 44

1. WARNING: Before beginning any service procedure, refer to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Failure to follow this instruction may result in serious personal injury. Refer to: «CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric__climate-control-system-health-and-safety) .
2. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__air-conditioning-ac-system-recovery-evacuation) .
3. Refer to: «JACKING AND LIFTING - OVERVIEW»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#jacking-lifting-electric) .
4. Torque: 10 Nm 13 Nm
5. Torque: 15 Nm

1. To install, reverse the removal procedure.
2. Refer to: «REFRIGERANT OIL ADDING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__refrigerant-oil-adding) .

Note. Removal steps in this procedure may contain installation details.

Scheme 45

Scheme 46

Scheme 47

1. WARNING: Before beginning any service procedure, refer to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Failure to follow this instruction may result in serious personal injury. Refer to: «CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric__climate-control-system-health-and-safety) .
2. Refer to: «HIGH VOLTAGE BATTERY DISCONNECT AND CONNECT»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#high-voltage-battery-mounting-cables-electric) .
3. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__air-conditioning-ac-system-recovery-evacuation) .
4. Refer to: «JACKING AND LIFTING - OVERVIEW»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#jacking-lifting-electric) .
5. Torque: 16 Nm
6. Torque: 16 Nm 25 Nm

1. To install, reverse the removal procedure.
2. Refer to: «REFRIGERANT OIL ADDING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__refrigerant-oil-adding) .

Note. Removal steps in this procedure may contain installation details.

Scheme 48

1. WARNING: Before beginning any service procedure, refer to Safety Warnings in «GENERAL INFORMATION -- FOCUS ELECTRIC»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric) . Failure to follow this instruction may result in serious personal injury. Refer to: «CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#general-information-electric__climate-control-system-health-and-safety) .
2. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__air-conditioning-ac-system-recovery-evacuation) .
3. Refer to: «JACKING AND LIFTING - OVERVIEW»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#jacking-lifting-electric) .
4. Torque: 10 Nm 13 Nm
5. Torque: 15 Nm 16 Nm

1. To install, reverse the removal procedure.
2. Refer to: «REFRIGERANT OIL ADDING»(/ford/focus-st/iii-2012-2015/remont/automatic-hvac-system/#climate-control-system-electric__refrigerant-oil-adding) .

See also:
• DIAGNOSTIC METHODS
• BATTERY
• BODY CONTROL MODULE (BCM)
• MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION
• DIRECT CURRENT/DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE
• HIGH VOLTAGE BATTERY, MOUNTING AND CABLES
• ELECTRIC POWERTRAIN CONTROL
• TRANSMISSION CONTROL MODULE (TCM)
• COMMUNICATIONS NETWORK
• INFORMATION AND ENTERTAINMENT SYSTEM
• ELECTRIC POWERTRAIN COOLING
• LIGHT SENSOR
• INSTRUMENTATION, MESSAGE CENTER AND WARNING CHIMES
• CLIMATE CONTROL SYSTEM HEALTH AND SAFETY PRECAUTIONS
• INSTRUMENT PANEL
• FRONT BUMPER COVER
• JACKING AND LIFTING - OVERVIEW
• EXTERIOR MIRROR
• DRIVER KNEE AIRBAG - VEHICLES BUILT FROM: 11-JUNE-2012
• CONTROL SYSTEM LOGIC
• REFRIGERANT OIL ADDING
• PINPOINT TEST O
• PINPOINT TEST K
• PINPOINT TEST L
• PINPOINT TEST E
• PINPOINT TEST F
• PINPOINT TEST M
• PINPOINT TEST N
• PINPOINT TEST P
• PINPOINT TEST Q
• PINPOINT TEST B
• PINPOINT TEST S
• PINPOINT TEST R
• PINPOINT TEST A
• SPECIFICATIONS
• PINPOINT TEST H
• PINPOINT TEST C
• PINPOINT TEST U
• PINPOINT TEST T
• PINPOINT TEST D
• PCM DTC CHART
• BODY CONTROL MODULE (BCM) DTC CHART
• PINPOINT TEST G
• PINPOINT TEST I
• PINPOINT TEST J
• EVAPORATOR TEMPERATURE SENSOR
• BLOWER MOTOR SPEED CONTROL
• AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING
