Special Tool(s)
SPECIAL TOOLS DESCRIPTION CHART Flex Probe Kit 300-NUD105-R025DE or equivalent Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
Scheme 223
Scheme 224
Scheme 225
Retainer and Connector Location View, Cushion Frame From Underneath
Note. See supporting views for missing numbers.
Scheme 226
| Item | Description |
|---|---|
| 1 | Occupant Classification System Module (OCSM) electrical connector |
| 2 | Occupant Classification Sensor (OCS) weight sensor bolt A electrical connector and wire harness |
| 3 | OCS weight sensor bolt A and B wire harness retainer |
| 4 | OCS weight sensor bolt B electrical connector and wire harness |
| 5 | Belt Tension Sensor (BTS) wire harness retainers |
| 6 | BTS wire harness retainer |
| 7 | BTS wire harness electrical connector and retainer |
| 8 | Side air bag module electrical connector and wire harness retainer |
| 9 | Safety belt buckle and pretensioner wire harness retainer |
| 10 | Safety belt buckle and pretensioner wire harness retainer |
| 11 | Safety belt buckle and pretensioner electrical connector |
| 12 | OCS weight sensor bolt D electrical connector |
| 13 | OCS weight sensor bolt C wire harness retainer |
| 14 | OCS weight sensor bolt C electrical connector (1) |
| 15 | Seat wire harness main electrical connector and retainer |
| (1) Make sure the wire harness passes on the correct side of seat track lever as shown in illustration. | |
| (1) | Make sure the wire harness passes on the correct side of seat track lever as shown in illustration. |
PARTS DESCRIPTION CHART
Scheme 227
Scheme 228
- Make sure the passenger seat cushion wire harness is correctly routed and attached.
Scheme 229
| Item | Description |
|---|---|
| 1 | DVD player coaxial cable connector retainers |
| 2 | DVD player electrical connector and retainer |
| 3 | DVD player wire harness retainer |
| 4 | DVD player wire harness retainer |
| 5 | DVD player wire harness retainer |
| 6 | DVD player wire harness retainer |
| 7 | DVD player wire harness retainer |
| 8 | Cushion cover J-clip |
| 9 | Cushion cover pin-type retainer |
PARTS DESCRIPTION CHART
Scheme 230
Retainer and Connector Location View, Cushion Frame From The Front
Note. The DVD player wire harness must route under the front height motor wire harness.
Scheme 231
Scheme 232
SPECIAL TOOL DESCRIPTION CHART Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
Note. Refer to the installation steps for tightening sequence and torque specification.
Note. Passenger seat shown in illustration, driver seat similar.
Scheme 233
| Item | Part Number | Description |
|---|---|---|
| 1 | 61692 | Cushion side shield cover |
| 2 | Safety belt anchor bolt (part of 612D64) | |
| 3 | Belt Tension Sensor (BTS) electrical connector (part of 612D64) (passenger seat only) | |
| 4 | W714018 | Rear mounting bolts |
| 5 | 61736 | Manual recliner handle (if equipped) |
| 6 | Passenger seat assembly | |
| 7 | W709428 | Front mounting bolts |
| 8 | 61748 | Front inboard cover |
| 9 | 61748 | Front outboard cover |
| 10 | Electrical connector(s) (part of 14A005) | |
| 11 | Side Protection and Cabin Enhancement (SPACE®) tube locator pin holes |
PARTS DESCRIPTION CHART
SPECIAL TOOL DESCRIPTION CHART Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
SPECIAL TOOL DESCRIPTION CHART Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
SPECIAL TOOL DESCRIPTION CHART Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
SPECIAL TOOL DESCRIPTION CHART Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
SPECIAL TOOL DESCRIPTION CHART Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
SPECIAL TOOL DESCRIPTION CHART Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
SPECIAL TOOL DESCRIPTION CHART Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
Scheme 234
Scheme 235
Scheme 236
- Remove the seat backrest. For additional information, refer to «SEAT BACKREST - FRONT, WITH FOLD FLAT»(ref-372788-S34933157292010093000000) .
- Remove the outboard upper recliner cover. Pull at the front and release the clip. Pivot the top of the outboard upper recliner cover back and remove. Pull the fold-flat release strap out through the opening.
- Separate the cables and wire harness from the outboard recliner. Separate the fold-flat cable retainer and cover from the outboard recliner. Separate the side air bag module wire harness pin-type retainer from the outboard recliner. If equipped, separate the manual lumbar cable retainer from the outboard recliner.
- Remove the inboard upper recliner cover. Pull at the front and release the clip. Pivot the top of the inboard upper recliner cover back and remove.
- Separate the fold-flat cable retainer, cover and DVD player wire harness pin-type retainers (if equipped) from the inboard recliner.
- Separate the backrest cover lower J-clips.
- Release the backrest cover clips and open the zippers.
- Position the backrest cover aside and remove the 4 recliner-to-backrest frame bolts (2 shown in illustration). Remove the recliner assembly. To install, tighten to 63 Nm (46 lb-ft).
- Remove 2 screws from each and the inner recliner covers from the inboard and outboard recliners.
- To install, reverse the removal procedure.
