MATERIAL SPECIFICATIONS
| Item | Specification | Fill Capacity |
|---|---|---|
| High Performance DOT 3 Motor Vehicle Brake Fluid PM-1-C (US); CPM-1-C (Canada) | WSS-M6C62-A or WSS-M6C65-A1 | 1000 ml (2.11 pt) |
| High Temperature Nickel Anti-Seize Lubricant XL-2 | ESE-M12A4-A | |
| Metal Brake Parts Cleaner PM-4-A or PM-4-B (US); CPM-4 (Canada) | ||
| Molykote® M77 AG1Z-2C135-AA |
MATERIAL SPECIFICATIONS
GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Brake Disc | |
| Brake disc minimum thickness | 28.5 mm (1.122 in) |
| Brake Pads | |
| Brake pad maximum taper wear (in any direction) | 3.0 mm (0.118 in) |
| Brake pad minimum thickness | 3.0 mm (0.118 in) |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Bleeder screw | 11 |
| Brake caliper anchor plate bolts | 150 |
| Brake caliper flow bolt | 47 |
| Brake caliper guide pin bolts | 72 |
| Brake disc screw | 20 |
| Brake disc shield bolts | 15 |
| Brake flexible hose bracket bolt | 30 |
| Brake tube fittings | 17 |
TORQUE SPECIFICATIONS
The front brake disc system consists of the following components
- Brake pads
- Brake caliper anchor plate
- Brake caliper
- Brake disc
- Brake disc shield
- Brake flexible hose
When mechanical force is applied by the driver to the brake pedal, the force is converted into hydraulic pressure by the master cylinder. The hydraulic force is directed to the disc brake calipers and transferred to the brake pads. The brake pads are then forced against the brake friction surfaces by the brake caliper pistons. The friction of the brake pads on the brake disc causes the slowing of wheel rotation and the vehicle.
Refer to BRAKE SYSTEM - GENERAL INFORMATION .
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | Brake caliper guide pin bolt (part of 2386 service kit) (2 required) | |
| 2 | 2B120 RH/2B121 LH | Brake caliper |
| 3 | Brake pad (part of 2001 service kit) | |
| 4 | Spring clips (part of 2001 service kit) (2 required) | |
| 5 | W715091 | Brake caliper anchor plate bolts (2 required) |
| 6 | 2B292 RH/2B293 LH | Brake caliper anchor plate |
| 7 | W708733 | Brake disc screw |
| 8 | 1125 | Brake disc |
| 9 | W505255 | Brake disc shield bolt (3 required) |
| 10 | 2K004 RH/2K005 LH | Brake disc shield |
| 11 | 385116 | Brake caliper flow bolt |
| 12 | 388949 | Copper washers (2 required) |
| 13 | 2078 RH/2B557 LH | Brake flexible hose |
| 14 | Brake tube fitting (part of 2C296) | |
| 15 | W704911 | Brake flexible hose bracket bolt |
| 16 | Bleeder screw cap (part of 2208) | |
| 17 | 2208 | Bleeder screw |
PARTS DESCRIPTION CHART
- For additional information, refer to the appropriate procedure(s).
