Interior Lighting System: Removal & Installation Ford Flex I

Interior/illumination Lights 2 illustrations ~146 words

Removal and Installation

Front interior lamp

Pinpoint Test M

M3 Second or third row interior lamp
  1. Replace the bulb(s) as necessary.
  2. Second or third row interior lamp
M5 All interior lamps
  1. All interior lamps

Scheme 31

Scheme 31: Ambient Lighting Module
Scheme 31: Ambient Lighting Module
ItemPart NumberDescription
1W701679Ambient lighting module screws (2 required)
2Ambient lighting module electrical connector (part of 14D375)
313C788Ambient lighting module

PARTS DESCRIPTION CHART

  1. Remove the floor console. For additional information, Refer to «INSTRUMENT PANEL AND CONSOLE»(ref-372818) .
  2. Remove the 2 screws and the ambient lighting module. Disconnect the electrical connector.
  3. To install, reverse the removal procedure.

Scheme 32

Scheme 32: Ambient Lighting Switch
Scheme 32: Ambient Lighting Switch
ItemPart NumberDescription
1Ambient lighting switch bezel
2Ambient lighting switch electrical connector (part of 14D375)
313D806Ambient lighting switch

PARTS DESCRIPTION CHART

  1. NOTE: The ambient lighting switch bezel is removed by grasping the sides and pulling upward. Remove the ambient lighting switch bezel. Disconnect the electrical connector.
  2. Squeeze the retaining tabs and remove the ambient lighting switch.
  3. To install, reverse the removal procedure.
