Bumper System: Specifications Ford Flex I

Exterior Body Panels 1 illustration

TORQUE SPECIFICATIONS

DescriptionNm
Front bumper bolts23
Front bumper cover bolts6
Front bumper cover bracket bolt9
Rear bumper double-ended studs12
Rear bumper nuts23

TORQUE SPECIFICATIONS

Scheme 6

Scheme 6: Bumper - Exploded View, Front
Scheme 6: Bumper - Exploded View, Front
ItemPart NumberDescription
117C831Front bumper cover
2W706350Front bumper cover pin-type retainers (4 required)
3W711685Front bumper cover bolt
4W710763Fender splash shield screw
5W711676Front bumper cover bracket bolt
617D959 LH/17D958 RHFront bumper cover mounting reinforcement
738B407Lower air deflector
8W712196Lower air deflector screw
9W706350Lower air deflector pin-type retainer

PARTS DESCRIPTION CHART

  1. For additional information, refer to the appropriate procedure(s).
