TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Center bearing bracket inner bolts | 20 |
| Center bearing bracket outer bolts | 30 |
| Pinion flange bolts | 25 |
| Power Transfer Unit (PTU) flange bolts | 70 |
TORQUE SPECIFICATIONS
Note. All driveshaft assemblies are balanced. If undercoating the vehicle, protect the driveshaft to prevent overspray of any undercoating material.
The driveshaft assembly consists of the following
- Rubber isolated center support bearings
- CV joints at each end of the shaft
- U-joints at the center supports
- Assembly balanced with traditional balance weights
- Lubed for life joints requiring no periodic lubrication
- Unique bolt and washer assembly for the rear CV joint
The driveshaft transfers torque from the Power Transfer Unit (PTU)) to the rear axle. It is attached to the PTU flange with a CV joint. The 3-piece shaft is connected by staked U-joints located between the center bearings and attached to the Rear Drive Unit (RDU) at the Active Torque Coupling (ATC). The driveshaft joints allow the smooth continuous rotation of the driveshaft through the allowable angle planes and length variations required in normal vehicle operation. The driveshaft is always turning at front wheel speed. The driveshaft is not serviceable. A new driveshaft must be installed if worn or damaged.
Refer to DRIVELINE SYSTEM - GENERAL INFORMATION .
Scheme 19
| Item | Part Number | Description |
|---|---|---|
| 1 | 4R602 | Driveshaft assembly |
| 2 | W790063 | Pinion flange bolt and washer assemblies (3 required) |
| 3 | W711918 | Power Transfer Unit (PTU) flange bolts (4 required) |
| 4 | W701834 | Front center bearing bracket outer bolts (2 required) |
| 5 | W500220 | Center bearing bracket inner bolts (4 required) |
| 6 | 4B403 | Front center bearing bracket (part of 4602) |
| 7 | Center bearings (2 required) (part of 4602) | |
| 8 | 4B403 | Rear center bearing bracket (part of 4602) |
| 9 | W701834 | Rear center bearing bracket outer bolts (4 required) |
PARTS DESCRIPTION CHART
See also:
• JACKING AND LIFTING
