Message Center - Clock Ford Five Hundred I

The stand-alone electric analog clock is mounted in the center of the instrument panel finish panel and is set using the knob located to the side of the clock face.

Refer to SYSTEM WIRING DIAGRAMS (Montego), SYSTEM WIRING DIAGRAMS (Five Hundred), or SYSTEM WIRING DIAGRAMS (Freestyle) for schematic and connector information.

Special Tool(s)

SPECIAL TOOL 73III Automotive Meter 105-R0057 or equivalent

Scheme 126

Inspection and Verification

1. Verify the customer concern.
2. Visually inspect for obvious signs of mechanical or electrical damage. VISUAL INSPECTION CHART Mechanical Electrical Clock Smart junction box (SJB) fuse 7 (7.5A) Circuitry
3. If an obvious cause for an observed or reported concern is found, correct the cause before proceeding to the next step.
4. If the fault is not visually evident, verify the symptom and GO to «SYMPTOM CHART»(/ford/five-hundred/i-2004-2007/remont/gauges-instrument-panels/#message-center-clock__symptom-chart) .

Symptom Chart

SYMPTOM CHART

Scheme 127

Scheme 128

Scheme 129

1. A1 CHECK CIRCUIT 483 (RD) FOR AN OPEN Key in OFF position. Disconnect: Clock C2016. Measure the voltage between the clock C2016-6, circuit 483 (RD), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to A2. No : REPAIR the circuit. TEST the system for normal operation.
2. A2 CHECK CIRCUIT 1205 (BK) FOR AN OPEN Measure the resistance between the clock C2016-3, circuit 1205 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes : INSTALL a new clock. REFER to «CLOCK»(/ford/five-hundred/i-2004-2007/remont/gauges-instrument-panels/#message-center-clock) . TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.

Scheme 130

1. Remove the clock finish panel. Disconnect the electrical connector.
2. Remove the 2 screws and the clock.
3. To install, reverse the removal procedure.
