GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Generator | |
| Rating | 75/120 amp (max) @ 1,800-6,000 generator RPM, approximately 500-2,000 engine RPM |
| Generator pulley ratio | 2.70:1 |
| Voltage regulator type | Electronic internal with generator |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Generator nuts/bolts | 47 |
| Generator B+ nut | 8 |
| Generator stud bolts | 8 |
TORQUE SPECIFICATIONS
The generator on this vehicle has an internally mounted voltage regulator that is not replaced separately. A new voltage regulator and generator must be installed as an assembly. The red radial adapter can be replaced as a separate component.
Refer to CHARGING SYSTEM - GENERAL INFORMATION .
Scheme 1
Scheme 2
Scheme 3
- With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/five-hundred/i-2004-2007/remont/hoistjack/#jacking-lifting) .
- Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/five-hundred/i-2004-2007/remont/charging-system/#battery-mounting-and-cables) .
- Rotate the accessory drive belt tensioner counterclockwise and position the accessory drive belt aside.
- Remove the 8 pin-type retainers and the right lower splash shield.
- Disconnect the crankshaft position sensor and release the 2 wiring harness locators from the generator splash shield.
- Remove the lower generator boot pin-type retainer, fold the boot upward and disconnect the generator electrical connector.
- With the generator boot folded upward, position the protective cover aside and remove the generator B+ nut and terminal. To install, tighten to 8 Nm (71 lb-in).
- Remove the 3 generator nuts and stud bolts. To install, tighten the generator stud bolts to 8 Nm (71 lb-in). To install, tighten the new generator bolts or generator nuts to 47 Nm (35 lb-ft).
- Remove the generator shield and the generator.
- To install, reverse the removal procedure.
