Fuse and Relay Information Ford Five Hundred I

Body Electrical 2 illustrations

IDENTIFICATION

CAUTIONWhen battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery.

Battery Junction Box (BJB)

Note. For component location, see appropriate ELECTRICAL COMPONENT LOCATIONS article.

Battery Junction Box Components. Scheme 290

Scheme 290: Battery Junction Box Components
Scheme 290: Battery Junction Box Components
FuseAmpsCircuits protected
F1.0180F2.01, F2.02, F2.03, F2.04
F1.02Not used
F1.03Not used
F1.0450Windshield wiper relay
F1.05Not used
F1.0620Roof opening panel module (502D70)
F1.07Not used
F1.0860Engine cooling fan motor
F1.09Not used
F1.1040ABS control module (2C219)
F1.1130Starter relay (11450)
F1.1230PCM power relay
F1.1320ABS control module (2C219)
F1.14Not used
F1.1520Power point, rear (19G247)
F1.1615CVT module (7000), 6 speed automatic transaxle module
F1.1720Power point, console (19N236)
F1.1810Generator (10346)
F1.1940Smart Junction Box (SJB) (14A068/15604)
F1.2020Headlamp, right (13008)
F1.2140Heated backlight relay
F1.2230Seat adjust switch, passenger side front (14A701)
F1.2330Heated seal module, driver side front (14C724), Heated seat module, passenger side front (14C724)
F1.2415Fog lamp relay
F1.2510A/C clutch relay
F1.26Not used
F1.27Not used
F1.2815Fuel pump relay
F1.2980F2.06, F2.07, F2.09, F2.10, F2.11, F2.25
F1.3030Power window motor, driver side front (23395)
F1.3120Headlamp, left (13008)
F1.3230Auxiliary relay box 1, Auxiliary coolant pump relay
F1.3330Driver seat module (14C724), Seat adjust switch, passenger side front (14A701)
F1.3430Ignition switch (11572)
F1.35Not used
F1.3640Blower motor relay
F1.3730Windshield wiper motor (17508)
F1.385Heated Positive Crankcase Ventilation (PCV) valve (6A666)
F1.3925Rear wiper motor assembly (17508)
F1.4010Vapor management valve, EVAP canister vent control solenoid (9F945), A/C clutch relay, Heated Oxygen Sensor (HO2S) #11 (9F472), Heated Oxygen Sensor (HO2S) #12 (9G444), Heated Oxygen Sensor (HO2S) #21 (9F472), Heated Oxygen Sensor (HO2S) #22 (9G444), EGR system module, CVT module (7000), 6 speed automatic transaxle module
F1.4115Mass Air Flow (MAF) sensor (12B579), Powertrain Control Module (PCM) (12A650), Fuel injector 1 (9F593), Fuel injector 2 (9F593), Fuel injector 3 (9F593), Fuel injector 4 (9F593), Fuel injector 5 (9F593), Fuel injector 6 (9F593), Coil On Plug (COP) 1 (12029), Coil On Plug (COP) 2 (12029), Coil On Plug (COP) 3 (12029), Coil On Plug (COP) 4 (12029), Coil On Plug (COP) 5 (12029), Coil On Plug (COP) 6 (12029), Ignition transformer capacitor (18801)
F1.42Not used
F1.43Not used
F1.44Not used
F1.45Not used
F1.46Not used

BATTERY JUNCTION BOX COMPONENTS LEGEND

Smart Junction Box (SJB)

Note. For component location, see appropriate ELECTRICAL COMPONENT LOCATIONS article.

Smart Junction Box Components. Scheme 291

Scheme 291: Smart Junction Box Components
Scheme 291: Smart Junction Box Components
FuseAmpsCircuits protected
F2.0120High beam relay
F2.0215Courtesy lamp relay, Battery saver relay, Accessory delay relay
F2.0325Door lock relay, Door unlock relay, Driver door unlock relay, Decklid relay
F2.0415Adjustable pedal switch (9G604)
F2.0520Horn (13A803)
F2.0620Subwoofer amplifier (18B849)
F2.077.5Electronic Automatic Temperature Control (EATC) module (19980), Function selector switch assembly (19980) (manual A/C), Powertrain Control Module (PCM) (12A650), Clock (15000), Instrument cluster
F2.0815Park/turn lamp, left front (13411), Park/turn lamp, right front (13411), Side lamp, left front (13411), Side lamp, right front (13411), Lamp assembly, left rear (13405), Lamp assembly, right rear (13404), License lamps (13412), License plate lamp, left (13550), License plate lamp, right
F2.0920Data Link Connector (DLC) (14489), Power point, instrument panel (19N236)
F2.107.5Exterior rear view mirror switch (17B676), Seat adjust switch, driver side front (14A701), Driver seat module (14C724)
F2.1120Rear Seat Entertainment (RSE) module (10E947), Radio (18806)
F2.1210Lamp assembly, left rear (13405), Lamp assembly, right rear (13404), Electrochromatic inside mirror unit (17700), Parking Aid Module (PAM) (15K866)
F2.137.5Radio (18806)
F2.147.5Starter relay (11450), Powertrain Control Module (PCM) (12A650)
F2.1510Door lock switch, driver side (14028), Door lock switch, passenger side (14028), Power window motor, driver side front (23395), Auxiliary function selector switch assembly, rear (19980), Roof opening panel module (502D70), Radio (18806)
F2.1610Function selector switch assembly (19980), Exterior rear view mirror, right (17682), Exterior rear view mirror, left (17683)
F2.1730Rear window defrost grid (18C618)
F2.1810Passive anti-theft transceiver (15607), Brake pedal position switch (13480), Redundant pedal switch, PCM power diode, Fuel pump relay, F1.38
F2.1910Parking Aid Module (PAM) (15K866), Heated seat module, driver side front (14C724), Heated seat module, passenger side front (14C724), Traction assist/Parking aid disable switch, Differential Electronic Module (DEM), ABS control module (2C346)
F2.207.5Function selector switch assembly (19980), Electronic Automatic Temperature Control (EATC) module (19980), Instrument cluster (10849)
F2.217.5Restraints control module (14B321)
F2.227.5Electronic compass (19A548), Electrochromatic inside mirror unit (17700), Auxiliary relay box 1, Auxiliary relay box 2, Auxiliary relay box 3
F2.237.5Instrument cluster, Blower motor relay, Windshield wiper relay
F2.247.5Passenger Air bag Deactivation (PAD) indicator (14B268), Occupant Classification Sensor (OCS) (14B463)
F2.2530Accessory delay relay

SMART JUNCTION BOX COMPONENTS LEGEND
