Drum Brake System: Component Locations Ford Fiesta Mk6

Special Tool(s)

SPECIAL TOOL REFERENCE CHART Brake Adjustment Gauge 206-D002 (D81L-1103-A) or equivalent

Scheme 7

Scheme 8

1. Remove the brake drum. For additional information, refer to «DRUM BRAKE SYSTEM - EXPLODED VIEW»(ref-382386-S29073295802011012300000) in this information.
2. Using the Brake Adjustment Gauge, measure the inside diameter of the brake drum.
3. Position the Brake Adjustment Gauge on the brake shoes and linings and adjust accordingly.
4. Install the brake drum. For additional information, refer to «DRUM BRAKE SYSTEM - EXPLODED VIEW»(ref-382386-S29073295802011012300000) in this information.
