SPECIFICATIONS
| Description | N.m | Lb. ft. | Lb. in. |
|---|---|---|---|
| Floor console front screws | 3 | 27 | |
| Floor console rear screws | 3 | 27 | |
| Instrument panel front screws | 8 | 71 | |
| Instrument panel bolts | 25 | 18 | |
| In-vehicle cross car beam to floor pan brace screw | 25 | 18 | |
| In-vehicle cross car beam to instrument panel screw | 3 | 27 | |
| Instrument panel-to-front of dash bolt | 25 | 18 | |
| LH instrument panel side bolt | 25 | 18 | |
| Exterior heater core housing nut | 8 | 71 | |
| Upper steering column shaft-to-lower steering column shaft bolt | 28 | 21 |
TORQUE SPECIFICATIONS
Scheme 51
| Item | Part Number | Description |
|---|---|---|
| 1 | 044C61 | LH instrument panel side cover |
| 2 | W714972 | LH instrument panel side cover clips (4 required) |
| 3 | 045N68 | Steering column opening trim panel |
| 4 | W714972 | Steering column opening trim panel clips (6 required) |
| 5 | W714972 | Upper finish panel clips (6 required) |
| 6 | 044D70 | Upper finish panel |
| 7 | W505142 | Front Controls Interface Module (FCIM) finish panel screws (2 required) |
| 8 | W707628 | FCIM finish panel screws (2 required) |
| 9 | 18A802 | Finish panel |
| 10 | W714972 | Lower finish panel clips (8 required) |
| 11 | 18498 | Lower finish panel |
| 12 | W714972 | RH instrument panel side cover clips (4 required) |
| 13 | 044C60 | RH instrument panel side cover |
| 14 | 06010 | Glove compartment |
| 15 | 13E002/13E726 | Close out bezel non-ambient/Ambient light pipe |
PART DESCRIPTION CHART
Scheme 52
| Item | Part Number | Description |
|---|---|---|
| 1 | W711557 | Instrument panel screw (4 required) |
| 2 | 3R827 | Steering column shaft-to-steering column bolt |
| 3 | W701096 | In-vehicle cross car beam to floor pan brace screw (2 required) |
| 4 | W711563 | LH instrument panel bolt |
| 5 | W711563 | Instrument panel-to-front of dash bolt |
| 6 | 18N316 | Exterior heater core housing nut |
PART DESCRIPTION CHART
- For additional information, refer to the appropriate procedures in this information.
