Special Tool(s)
SPECIAL TOOL(S) SPECIFICATION Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
SPECIAL TOOL(S) SPECIFICATION Fuel Pressure Test Kit 310-D009 (D95L-7211A)
Scheme 4
Scheme 4: Special Tool(s)
| WARNING | Do not smoke, carry lighted tobacco or have an open flame of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury. |
| WARNING | Do not carry personal electronic devices such as cell phones, pagers or audio equipment of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury. |
| WARNING | Before working on or disconnecting any of the fuel tubes or fuel system components, relieve the fuel system pressure to prevent accidental spraying of fuel. Fuel in the fuel system remains under high pressure, even when the engine is not running. Failure to follow this instruction may result in serious personal injury. |
| WARNING | Always disconnect the battery ground cable at the battery when working on an evaporative emission (EVAP) system or fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury. |
| WARNING | When handling fuel, always observe fuel handling precautions and be prepared in the event of fuel spillage. Spilled fuel may be ignited by hot vehicle components or other ignition sources. Failure to follow these instructions may result in serious personal injury. |
- Release the fuel system pressure. For additional information, refer to «FUEL SYSTEM PRESSURE RELEASE»(ref-382416-S31114422582011012300000) in this Information.
- Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-382392) .
- Disconnect the fuel supply tube-to-fuel rail spring lock coupling. For additional information, refer to «SPRING LOCK COUPLINGS»(ref-382416-S13167351752011012300000) in this information.
- Install the Fuel Pressure Test Kit between the fuel supply tube and the fuel rail.
- Connect the fuel pump control module electrical connector.
- Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-382392) .
- Test the fuel system pressure to make sure it is within the specified range. For additional information, refer to «SPECIFICATIONS»(ref-382416-S33262103412011012300000) in this information.
SPECIAL TOOL(S) SPECIFICATION Fuel Storage Tanker 164-R3202 or equivalent
Scheme 5
Scheme 5: Special Tool(s)
| WARNING | Do not smoke, carry lighted tobacco or have an open flame of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury. |
| WARNING | Do not carry personal electronic devices such as cell phones, pagers or audio equipment of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury. |
| WARNING | When handling fuel, always observe fuel handling precautions and be prepared in the event of fuel spillage. Spilled fuel may be ignited by hot vehicle components or other ignition sources. Failure to follow these instructions may result in serious personal injury. |
| WARNING | Remove the fuel filler cap slowly. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap. Otherwise, fuel may spray out. Failure to follow these instructions may result in serious personal injury. |
- Refer to «Special Tool(s)»(ref-382416-S09596068752011012300000) and all Warnings, Notices, Notes, Materials, Specifications, and Special Tools included in this information. NOTE: In order to ensure the most accurate information, some procedural and pinpoint test steps may be under development and not immediately available at vehicle introduction.
