Automatic Transmission - Automatic Transaxle/transmission External Controls: Component Locations

Location

The BSIA is part of the selector lever assembly.

The brake shift interlock system prevents the selector lever from being moved out of PARK unless the requirements to do so are met. The ignition switch must be in the ON position and the brake pedal must be pressed. The brake pedal position is detected by the Brake Pedal Position (BPP) switch. In the event the vehicle will not come out of PARK, the manual release mechanism mechanically bypasses the electric portion of the brake shift interlock system allowing the selector lever to be moved out of PARK. The manual release mechanism is part of the selector lever assembly. If PARK is selected again, the selector lever will be locked again.

Scheme 299

Scheme 299: Drive with Grade Assist

Drive with Overdrive (O/D) cancel and grade assist is activated when the Transmission Control Switch (TCS) is pressed. The TCS is located on the selector lever knob. When the TCS is pressed, the 6th gear or O/D upshift is prevented or the transaxle shifts down to 5th gear. The TCS is meant to be used when driving conditions cause excessive shifting from 6th to other gears such as hilly terrain, mountainous areas or when engine braking is required.

Grade Assist

O/D is cancelled.
The transaxle operates in gears 1 through 5.
The Grade Assist lamp illuminates on the Instrument Cluster (IC).
Improves vehicle handling in hilly terrain or mountainous areas by providing engine braking and extending lower gear operation on uphill climbs.
Provides additional engine braking through the automatic transaxle shift strategy which reacts to vehicle inputs (vehicle acceleration, accelerator pedal, brake pedal and vehicle speed).
The transaxle selects gears that provide the desired engine braking which is based on the vehicle inputs. Engine braking increases engine rpm.

Returning to DRIVE mode on flat terrain provides the best fuel economy and transaxle performance. The transaxle returns to O/D when the TCS is pressed again or the key is turned OFF.

Special Tool(s)

SPECIAL TOOL REFERENCE CHART Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

SPECIAL TOOL REFERENCE CHART Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 300

Scheme 300: Special Tool(s)

Scheme 301

Scheme 302

Scheme 303

Scheme 304

Scheme 305

Disconnect the selector lever cable end from the manual control lever.
Place the manual control lever in the D position as indicated on the transaxle case.
Place the manual control lever in the P position as indicated on the transaxle case.
Place the manual control lever in the D position as indicated on the transaxle case.
Place the selector lever in the D position.
Unlock the selector lever cable adjuster by sliding the locking tab over.
Slide the selector lever cable end forward or backward to align it with the manual control lever.
With the selector lever cable adjuster locking tab released, connect the selector lever cable end to the manual control lever.
Slide the locking tab back to lock the selector lever cable adjuster.
Verify that the vehicle only starts in PARK and NEUTRAL and the reverse lamps illuminate in REVERSE.

Scheme 306

Scheme 306: Removal

Scheme 307

Scheme 308

Scheme 309

Scheme 310

Scheme 311

Scheme 312

Scheme 313

Scheme 314

Scheme 315

Scheme 316

Scheme 317

Scheme 318

Scheme 319

Scheme 320

Scheme 321

Scheme 322

With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-382368) .
Remove the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-382400) .
Disconnect the selector lever cable end from the selector lever ball stud.
Release the locking tab on the selector lever cable clip and remove the selector lever cable from the selector lever housing.
Using a suitable tool, cut the carpet in the center under the heater core and evaporator core housing to gain access to the selector lever cable grommet in the following sequence. Begin cutting the carpet where the selector lever cable is exposed and cut the carpet back until the tool no longer fits between the floor and the heater core and evaporator core housing. To cut the carpet further forward, access the carpet with the tool through the LH side of the heater core and evaporator core housing.
Position the carpet aside to access the selector lever cable grommet.
Remove the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-382392) .
Disconnect the 3 PCM electrical connectors.
Remove the 3 battery tray bolts and the battery tray.
Remove the selector lever cable bracket bolt.
Disconnect the selector lever cable end from the manual control lever.
Disconnect the selector lever cable from the selector lever cable bracket.
Remove and discard the 2 exhaust flange nuts and disconnect the exhaust flange. Discard the exhaust flange gasket.
Disconnect the exhaust hangers and support the exhaust with wire.
Remove the 8 bolts and remove the cross brace.
Remove the 6 exhaust heat shield fasteners (5 shown in illustration) and the exhaust heat shield.
Remove the 2 selector lever cable grommet nuts.
Remove the selector lever cable.

Scheme 323

Scheme 323: Installation

Scheme 324

Scheme 325

Scheme 326

Scheme 327

Scheme 328

Scheme 329

Scheme 330

Scheme 331

Scheme 332

Scheme 333

Scheme 334

Scheme 335

Scheme 336

Scheme 337

Position the selector lever cable grommet in place.
Install the 2 selector lever cable grommet nuts. Tighten to 9 Nm (80 lb-in).
Install the exhaust heat shield and the 6 exhaust heat shield fasteners (5 shown in illustration).
Install the cross brace and the 8 cross brace bolts. Tighten to 40 Nm (30 lb-ft).
Connect the exhaust hangers.
Using a new exhaust flange gasket and 2 new exhaust flange nuts, connect the exhaust flange. Tighten to 47 Nm (35 lb-ft).
Connect the selector lever cable to the selector lever cable bracket.
Connect the selector lever cable end to the manual control lever.
Install the selector lever cable bracket bolt. Tighten to 10 Nm (89 lb-in).
Install the battery tray and the 3 bolts. Tighten to 10 Nm (89 lb-in).
Connect the 3 PCM electrical connectors.
Install the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-382392) .
Install the selector lever cable on the selector lever housing.
Connect the selector lever cable end to the selector lever ball stud.
Position the carpet back in place under the heater core and evaporator core housing.
Install the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-382400) .
Adjust the selector lever cable. For additional information, refer to «SELECTOR LEVER CABLE ADJUSTMENT»(ref-382412-S10850248072011012300000) in this information.

Scheme 338

Scheme 338: Removal

Scheme 339

Scheme 340

Scheme 341

Scheme 342

Scheme 343

Remove the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-382400) .
Disconnect the selector lever cable end from the selector lever ball stud.
Release the locking tab on the selector lever cable clip and remove the selector lever cable from the selector lever housing.
Disconnect the selector lever electrical connector.
Using a suitable tool, remove the wiring harness from the selector lever base.
Disconnect the Restraints Control Module (RCM) electrical connector.
Remove the 4 selector lever nuts and remove the selector lever.
