Engine Controls - Reference Values (Except Diesel & Hybrid) (Section 6): Other

2.5L 4V Fusion

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
APP1	B28	0.77	0.77	0.93	0.77	VOLTS
APP2	B29	0.38	0.38	0.47	0.39	VOLTS
FPM	B32	60.35	60.35	60.35	59.71	%
MAF (A/T)	B40	0.01	0.73	1.77	1.66	VOLTS
MAF (M/T)	B40	0.01	0.41	0.73	1.97	VOLTS
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	2.11/42 (107.6)	2.36/37 (98.6)	3.16/21 (69.8)	3.58/13 (55.4)	VOLTS/DEG C (DEG F)
FTP	B65	2.6/0	2.56/0	2.29/0	2.17/-0.11	VOLTS/PSI
FTP_H2O	B65	0.13	0.44	2.34	3.2	In-H 2 O
O2S11	E8	(I)	Switching (C)	Switching (C)	Switching (C)	VOLTS
CHT	E39	0.54/94 (201.2)	0.6/90 (194)	3.81/88 (190.4)	3.52/97 (206.6)	VOLTS/DEG C (DEG F)
MAP	E40	4/98.93/14.3/29.11	1.2/27.99/4.06/8.26	2.25/53.98/7.83/15.94	2.13/51.98/7.54/15.35	VOLTS/kPa/PSI/inHg
KNOCK_1	E43	288	216	221	227	N/A
HTRCM11	E69	0	0	0	1.41	Amps
TSS_SRC (A/T)	T16	0	716.5	1235.25	1708.5	RPM
TFT (A/T)	T19	46 (114.8)	44 (111.2)	80 (176)	89 (192.2)	DEG C (DEG F)
TFTV (A/T)	T19	1.99	2.04	0.8	0.64	VOLTS
OSS_SRC (A/T)	T25	0	0	1153	2290	RPM
CPP_BOT (M/T)	T26	NO	NO	NO	NO	YES/NO
CPP_TOP (M/T)	T27	NO	NO	NO	NO	YES/NO
O2S12	T29	(I)	(D)	(D)	(D)	VOLTS
HTRCM12	T49	0	0	0	571	MA
APP	PID	0	0	5	0	%
BARO	PID	14.35/156.1	14.35/156.1	14.35/156.1	14.21/155.2	PSI/Hz
B+	PID	12.47	13-14	13-14	13-14	VOLTS
DECHOKE	PID	NO	NO	NO	NO	YES/NO
ETC_TRIM	PID	0.13 (J)	0.15 (J)	0.14 (J)	0.07 (J)	DEG
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR (A/T)	PID	1	1	5	6	GEAR
LOAD (A/T)	PID	0 (I)	20.78	30.98	54.51	%
LOAD (M/T)	PID	0 (I)	22.74	54.51	46.66	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	YES	YES	YES	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	754.75	1659	1708.75	RPM
SYNC	PID	NO	YES	YES	YES	YES/NO
VCT1_F	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 2.5L 4V FUSION

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	75/OFF	40.04/ON	41.2/ON	40.92/ON	%/ON/OFF
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
EVAPCP	E32	0	41.56	72.94	79.6	%
VCTDC	E67	0	0	0	0	%
HTR11	E69	OFF	ON	ON	ON	ON/OFF
HTR12	T49	OFF	ON	ON	ON	ON/OFF
CAT_EVAL	PID	YES	YES	YES	YES	YES/NO
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
EVAP_EVAL	PID	NO	NO	NO	YES	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
HFC	PID	OFF	ON (B)	OFF	OFF	ON/OFF
LFC	PID	OFF	ON (B)	OFF	OFF	ON/OFF
LONGFT1	PID	20 TO +20	20 TO +20	20 TO +20	20 TO +20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/DISABLED
RPMDSD	PID	750	750	650	650	RPM
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV (A/T)	PID	12.25	14-20	35-44	30-40	DEG
SPARKADV (M/T)	PID	10	14.25	45.25	53	DEG
STRT_RLY	PID	DISABLED	DISABLED	DISABLED	DISABLED	ENABLED/DISABLED
TCC (A/T)	PID	0	0	25.52	41.18	PSI
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
TQ_CNTRL	PID	NONE	NONE	NONE	NONE	_
VCTADV	PID	0	0.25	0.25	0.25	DEG
VCTADVERR	PID	0	0.25	0.25	0.25	DEG
VCT_DSD	PID	0	0	0	0	DEG
VCTSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP

ACTUATORS/OUTPUTS - 2.5L 4V FUSION

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52/E35	5	5	5	5	VOLTS
VPWR	B67/68	12.39	13-14	13-14	13-14	VOLTS

OTHER - 2.5L 4V FUSION

3.0L 4V Fusion

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
APP1	B28	0.76	0.76	1.05	0.76	VOLTS
APP2	B29	0.37	0.37	0.51	0.37	VOLTS
FPM	B32	43.18	59.71	60.35	59.71	%
MAF	B40	0	0.68	1.27	1.83	VOLTS
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	1.75/48.8 (120)	2.02/42.7 (109)	3.16/17.7 (64)	3.22/17.2 (63)	VOLTS/DEG C (DEG F)
FTP	B65	2.6/-0	2.6/-0	2.57/-0.01	2.5/-0.03	VOLTS/PSI
FTP_H2O	B65	0.07	0.69	0	0.03	In-H 2 O
O2S21_CUR	E10	(I)	Switching	Switching	Switching	MA/uA
O2S11_CUR	E27	(I)	Switching	Switching	Switching	MA/uA
CHT	E39	0.54/94 (201.2)	0.6/90 (194)	3.81/88 (190.4)	3.52/97 (206.6)	VOLTS/DEG C (DEG F)
MAP	E40	4.02/98.93/14.35/28.93	1.28/30.95/4.49/9.15	1.35/32.95/4.78/9.73	2.33/57.98/8.41/17.12	VOLTS/kPa/PSI/inHg
KNOCK_1	E43	117	112	256	447	N/A
KNOCK_2	E60	168	178	280	409	N/A
O2S11_HTR	E69	20	32.54	31.76	34.11	%
O2S21_HTR	E70	20	32.54	30.98	31.76	%
O2S12	T29	(I)	(D)	(D)	(D)	VOLTS
O2S22	T40	(I)	(D)	(D)	(D)	VOLTS
HTRCM22	T48	605	605	605	605	MA
HTRCM12	T49	617	617	617	617	MA
APP	PID	0	0	8.5	0	%
BARO	PID	14.48/157.4	14.48/157.4	14.48/157.4	14.48/157.4	PSI/Hz
B+	PID	12.87	13-14	13-14	13-14	VOLTS
DECHOKE	PID	NO	NO	NO	NO	YES/NO
FLI	PID	58.43 (H)	58.43 (H)	56.86 (H)	55.29 (H)	%
LOAD	PID	0 (I)	25.88	29.41	54.51	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	YES	YES	YES	YES/NO
O2_DS1_ERR	PID	0	0	0.06	0.03	VOLTS
O2_DS2_ERR	PID	5	0.09	0.09	0.09	VOLTS
O2S11_IMPED	PID	5	0.09	0.09	0.09	VOLTS
O2S21_IMPED RPM	PID	0	766	1203	1700	RPM
SYNC	PID	NO	YES	YES	YES	YES/NO
VCT1_F	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
VCT2_F	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 3.0L 4V FUSION

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	OFF	ON	ON	ON	ON/OFF
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
PCVHC	E6	0	0	0	0	%
EVAPCP	E32	0	39.21	0	0	%
VCTDC	E67	0	0	47.62	0	%
VCTDC2	E68	0	0	49.18	0	%
HTR11	E69	OFF	ON	ON	ON	ON/OFF
HTR21	E70	OFF	ON	ON	ON	ON/OFF
HTR22	T48	OFF	ON	ON	ON	ON/OFF
HTR12	T49	OFF	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPCV	PID	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
MIL_DIS	PID	0	0	0	0	Miles
O2S_EVAL	PID	NO	NO	NO	YES	YES/NO
O2SHTR_EVAL	PID	NO	NO	NO	YES	YES/NO
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	33	15	39.5	44	DEG
VCTADV	PID	0	0.37	14.68	0.25	DEG
VCTADV2	PID	0	1	15	0	DEG
VCTADVERR	PID	0	0.68	0.81	1.25	DEG
VCTADVERR2	PID	0	0	0.68	1.18	DEG

ACTUATORS/OUTPUTS - 3.0L 4V FUSION

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52/E35	5	5	5	5	VOLTS
VPWR	B67/68	12.77	13-14	13-14	13-14	VOLTS

OTHER - 3.0L 4V FUSION

Scheme 115

Scheme 115: 3.5L 4V Fusion/MKZ

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
APP1	B25	4.06	4.06	3.8	3.67	VOLTS
APP2	B26	1.48	1.47	1.69	1.78	VOLTS
APP3	B27	0.92	0.92	1.14	1.23	VOLTS
FPM	B30	OFF	ON	ON	ON	ON/OFF
MAF	B41	0	0.65	1.26	1.6	VOLTS
IAT	B43	1.44/57.77 (136)	1.54/53 (127.4)	2.28/37 (98.6)	2.45/34 (93.2)	VOLTS/DEG C (DEG F)
FTP	B44	2.61/0.61	2.56/0.61	2.54/0.61	2.56/0.61	VOLTS/PSI
BOO	B46	OFF	ON (E)	OFF	OFF	ON/OFF
BPA	B47	OFF	ON (E)	OFF	OFF	ON/OFF
O2S12	E3	(I)	(D)	(D)	(D)	VOLTS
O2S22	E4	(I)	(D)	(D)	(D)	VOLTS
HTRCM12	E23	727 (mA)	727 (mA)	1.29 (A)	570 (mA)	MA/A
HTRCM22	E24	758 (mA)	758 (mA)	1.25 (A)	602 (mA)	MA/A
O2S11	E28	(I)	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
O2S21	E29	(I)	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
KNOCK_2	E31	250	249	287	422	N/A
CHT	E41	3.29/103 (217.4)	3.39/100 (212)	3.39/100 (212)	3.53/96 (204.8)	VOLTS/DEG C (DEG F)
KNOCK_1	E49	310	345	379	562	N/A
PSP	E65	LOW	HIGH	LOW	LOW	HIGH/LOW
HTRCM11	E69	1.58	1.58	2.13	1.54	AMPS
HTRCM21	E70	1.65	1.65	2.08	1.52	AMPS
APP	PID	0	0	10	16.5	%
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.24/155.8	PSI/Hz
B+	PID	12.56	13-14	13-14	13-14	VOLTS
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/DRIVE
DECHOKE	PID	NO	NO	NO	NO	YES/NO
FLI	PID	30.96 (H)	31.11 (H)	27.59 (H)	24.09 (H)	%
LOAD	PID	50.15 (I)	16.01	30.54	35.63	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	774.5	1216	1621	RPM
SYNC	PID	NO	YES	YES	YES	YES/NO
VCT1_F	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
VCT2_F	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 3.5L 4V FUSION/MKZ

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
EVMV	B4	0/OFF	588/VARYING	661/OFF	589/ON	MA/OFF-VARYING
EVAPCV	B61	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
FP	B62	OFF	ON	ON	ON	ON/OFF
SPKDUR_6	E10	0	2.25	1.56	1.0	Ms
SPKDUR_5	E11	0	2.06	1.56	1.62	Ms
SPKDUR_4	E12	0	2.21	1.62	1.81	Ms
SPKDUR_3	E15	0	2.21	1.87	1.53	Ms
SPKDUR_2	E16	0	2.15	1.71	1.34	Ms
SPKDUR_1	E17	0	2.15	1.68	1.75	Ms
HTR12	E23	OFF	ON	ON	ON	ON/OFF
HTR22	E24	OFF	ON	ON	ON	ON/OFF
VCTADV	E67	0	0.06	30.56	29.63	DEG
VCTADV2	E68	0	0	31.31	30.13	DEG
HTR11	E69	OFF	ON	ON	ON	ON/OFF
HTR21	E70	OFF	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
EVAP_EVAL	PID	NO	NO	NO	YES	YES/NO
FANDC	PID	4.99	4.99	4.99	4.99	%
FANVAR	PID	0	0	0	0	%
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	10	13.5	37.25	41.5	DEG
STRT_RLY	PID	DISABLED	DISABLED	DISABLED	DISABLED	ENABLED/DISABLED
VCTADVERR	PID	0	0.06	1.18	0.25	DEG
VCTADVERR2	PID	0	0	1.43	0.68	DEG
VCTDC	PID	0	0	42.01	48.56	%
VCTDC2	PID	0	0	41.67	49.78	%

ACTUATORS/OUTPUTS - 3.5L 4V FUSION/MKZ

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B51/52	12.31	13-14	13-14	13-14	VOLTS
VREF	B33	5	5	5	5	VOLTS

OTHER - 3.5L 4V FUSION/MKZ

3.5L 4V Flex/Taurus

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PSP	B17	LOW	HIGH	LOW	LOW	HIGH/LOW
GENMON	B23	0	42.97	34.38	30.47	%
APP3	B27	0.88	0.88	0.99	1.28	VOLTS
APP1	B28 (GTDI) B25 (All Others)	0.76	0.76	1.19	1.25	VOLTS
APP2	B29 (GTDI) B26 (All Others)	0.38	0.38	0.60	0.63	VOLTS
FPM	B32 (GTDI) B30 (All Others)	OFF/0	ON/0	ON/0	ON/0	%/ON/OFF
ACP_PRESS	B37	1.42/113.97	1.36/107.98	1.10/73.97	1.12/75.98	VOLTS/PSI
BPA	B47	OFF	OFF	OFF	OFF	ON/OFF
MAF	B47	0.01	0.52	1.57	1.8	VOLTS
IAT	B47 (GTDI) B43 (All Others)	1.69/50 (122)	2.67/29 (84.2)	3.39/13 (55.4)	3.95/-5.22 (22.6)	VOLTS/DEG C (DEG F)
FTP	B65 (GTDI) B44 (All Others)	2.62/0.6	2.47/0.6	2.56/0.6	2.38/0.6	VOLTS/PSI
O2S11_CUR	E11 (GTDI) E18 (All Others)	(I)	Switching	Switching	Switching	MA/uA
O2S21_CUR	E13 (GTDI) E20 (All Others)	(I)	Switching	Switching	Switching	MA/uA
CAC_T	E24	3.01/25 (77)	3.52/13.8 (57)	4.06/1.11 (34)	4.12/0 (32)	VOLTS/DEG C (DEG F)
FRP	E29	1.35/5.55	0.74/1.57	0.81/2.05	0.93/2.91	VOLTS/MPa
TIP_PRS_BOOST	E38	101.82/14.6	101.82/14.6	103.49/15	105.16/15.2	KPa/PSI
TIP_PRES_V	E38	1.59	1.59	1.62	1.64	VOLTS
CHT	E39 (GTDI) E41 (All Others)	3.49/97 (206.6)	3.54/96 (204.8)	3.68/91 (195.8)	3.73/89 (192.2)	VOLTS/DEG C (DEG F)
MAP	E40	14.6/2.44	4.6/0.92	5.7/1.09	8.01/1.44	PSI/VOLTS
TSS	T15	0	580.8	1427	1413	RPM
O2S12	T29 (GTDI) E23 (All Others)	(I)	(D)	(D)	(D)	VOLTS
ACCS	PID	OFF	OFF	OFF	OFF	ON/OFF
APP	PID	0 (GTDI) 0 (All Others)	0 (GTDI) 0 (All Others)	13 (GTDI) 4.5 (All Others)	14 (GTDI) 17 (All Others)	%
B+	PID	12.31	13.81	14.06	14.06	VOLTS
BARO	PID	14.12/155.1	14.12/155.1	14.12/155.1	14.12/155.1	PSI/Hz
BOO	PID	OFF	ON (E)	OFF	OFF	ON/OFF
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
EONV_RDY	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EQ_RAT11	PID	0	2 TO +2	2 TO +2	2 TO +2	RATIO
EQ_RAT21	PID	0	2 TO +2	2 TO +2	2 TO +2	RATIO
ETC_TRIM	PID	0.15 (J) (GTDI) -0.01 (J) (All Others)	0.19 (J) (GTDI) -0.01 (J) (All Others)	0 (J) (GTDI) -0.02 (J) (All Others)	0 (J) (GTDI) -0.05 (J) (All Others)	DEG
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FLI	PID	57 (H)	54.59 (H)	58.48 (H)	51.32 (H)	%
GEAR	PID	1	1	5	6	GEAR
INJPWR_M	PID	12.28	13.99	13.79	13.97	VOLTS
LOAD	PID	50.85 (I)	16.48	27.32	46.08	%
MIL_DIS	PID	0	0	0	0	Miles
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	YES	YES	YES	YES/NO
NM	PID	0	0	0	0	COUNT
O2S11_IMPED	PID	4.94	1.0	0.93	1.03	VOLTS
O2S21_IMPED	PID	4.94	1.01	1.04	0.95	VOLTS
OSS	PID	0	0	997.8	1859	RPM
OSS_SRC	PID	0	0	997.3	1865	RPM
RPM	PID	0	619.5	1415	1358	RPM
STRT_RLY	PID	DISABLED	DISABLED	DISABLED	DISABLED	ENABLED/DISABLED
SYNC	PID	NO	YES	YES	YES	YES/NO
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
TFT	PID	73 (163.4)	50 (122)	64 (147.2)	80 (176)	DEG C (DEG F)
TFTV	PID	0.98	1.75	1.24	0.82	VOLTS
TIP_PRS_DSD	PID	100.53/14.5	100.53/14.5	101.49/14.6	105.16/15.2	KPa/PSI
TORQUE	PID	142.9	4	110.9	142.9	Nm
TR	PID	PARK	PARK	OVERDRIVE	OVERDRIVE	POSITION
TR2	PID	OPEN	OPEN	CLOSED	CLOSED	OPEN/CLOSED
TSS/ISS	PID	0	576.3	1501	1428	RPM
TSS_SRC	PID	0	578	1503	1428	RPM
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 3.5L 4V FLEX/TAURUS

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
EVMV	B50	0/OFF	736/VARYING	655/OFF 910/VARYING	MA / OFF / ON	/VARYING
FP	B19 (GTDI) B62 (All Others)	OFF	ON	ON	ON	ON/OFF
HTR12	E1	OFF	ON	ON	ON	ON/OFF
HTRCM12	E1	1.3 (Amps)	1.3 (Amps)	1.3 (Amps)	543 (mA)	MA/Amps
HTR22	E2	OFF	ON	ON	ON	ON/OFF
HTRCM22	E2	1.3 (Amps)	1.3 (Amps)	1.3 (Amps)	598 (mA)	MA/Amps
PCVHC	E7	0	0	100	100	%
PCVHC_B	E8	0	0	100	100	%
TURBO_WGATE	E16	0	0	0	0	%
EVAPCP	E32	0	0	0	0	%
VCTADV	E67	0	0.37	38.69	37.88	DEG
VCTADV2	E68	0	0	38.56	38.94	DEG
O2S11_HTR	E70 (GTDI) E69 (All Others)	0	36.4	34.02	35.22	%
HTR11	E70 (GTDI) E69 (All Others)	OFF	ON	ON	ON	ON/OFF
HTRCM11	E70 (GTDI) E69 (All Others)	1.40	1.40	1.44	1.44	Amps
O2S21_HTR	E69 (GTDI) E70 (All Others)	0	36.48	33.62	34.18	%
HTR21	E69 (GTDI) E70 (All Others)	OFF	ON	ON	ON	ON/OFF
HTRCM21	E69 (GTDI) E70 (All Others)	2	2	2	1.47	Amps
O2S11_HTR	E70 (GTDI) E69 (All Others)	0	36.8	36.08	35.32	%
R11 E70 (GTDI)	E69 (All Others)	OFF	ON	ON	ON	ON/OFF
HTRCM11	E70 (GTDI) E69 (All Others)	1.4	1.43	1.43	1.43	Amps
HTR12	T48 (GTDI) E1 (All Others)	OFF	ON	ON	ON	ON/OFF
HTRCM12	T48 (GTDI) E1 (All Others)	0	765	957	860	A/mA
HTR22	T49 (GTDI) E2 (All Others)	OFF	ON	ON	ON	ON/OFF
HTRCM21	T69 (GTDI) E70 (All Others)	0	1.60	1.74	676	A/mA
CAT_EVAL	PID	YES	NO	NO	YES	YES/NO
CLRDIST	PID	1.85	1.85	1.85	12.41	MILES
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPCV	PID	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
FANDC	PID	7.99	7.99	42	7.99	%
FAN_DSD	PID	0	0	0	0	%
FANVAR	PID	0	0	38.71	0	%
FTP_H20	PID	0.1	1	0.24	0.61	In-H 2 O
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
F_VCV	PID	0	6.90	22.97	23.21	%-VARYING
IGN_R/S	PID	ON	ON	ON	ON	ON/OFF
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
O2S_EVAL	PID	YES	YES	YES	YES	YES/NO
O2SHTR_EVAL	PID	YES	YES	YES	YES	YES/NO
RPMDSD	PID	800	608	608	608	RPM
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	10	12	43	25.25	DEG
TRIP_CNT	PID	0	0	0	0	COUNT
TURBO_BPASS	PID	0	0	100	0	%-VARYING
TURBO_BPASS_2	PID	0	0	100	0	%-VARYING
TURBO_BP1_STAT	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
TURBO_BP2_STAT	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
TURBO_OVER	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
TURBO_UNDER	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
TWGATE_STAT	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
VCTADV	PID	0	0.06	23.81	34	DEG
VCTADVERR	PID	0	0.37	0.93	0.18	DEG
VCTADVERR2	PID	0	0.06	0.93	0.06	DEG
VCTDC2	PID	0	0	47.93	49.45	%
VCTDC	PID	0	0	80	44.84	%
VCTDC2	PID	0	0	80	45.72	%
VCTSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP

ACTUATORS/OUTPUTS - 3.5L 4V FLEX/TAURUS

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36/B51 (GTDI) B51/52/53 (All Others)	12	13-14	13-14	13-14	VOLTS
VREF	B52/E35/T7 (GTDI) B64 (All Others)	5	5	5	5	VOLTS

OTHER - 3.5L 4V FLEX/TAURUS

3.5L 4V MKS/MKT

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
APP1	B28	0.78	0.78	1.19	1.27	VOLTS
APP2	B29	0.39	0.39	0.60	0.64	VOLTS
FPM	B32	60.31	59.59	59.57	59.67	%
IAT	B47	1.94/45 (113)	2.01/43 (109.4)	3.65/7 (44.6)	3.99/-4 (24.8)	VOLTS/DEG C (DEG F)
FTP	B65	2.62/0.61	2.43/0.61	2.62/0.61	2.32/0.61	VOLTS/Pa
O2S11_CUR	E11	(I)	Switching	Switching	Switching	MA/uA
O2S21_CUR	E13	(I)	Switching	Switching	Switching	MA/uA
CAC_T	E24	3.01/25 (77)	3.52/13.8 (57)	4.06/1.11 (34)	4.12/0 (32)	VOLTS/DEG C (DEG F)
FRP	E29	1.35/5.55	0.74/1.57	0.81/2.05	0.93/2.91	VOLTS/MPa
TIP_PRS_BOOST	E38	101.82/14.6	101.82/14.6	103.49/15	105.16/15.2	KPa/PSI
TIP_PRES_V	E38	1.59	1.59	1.62	1.64	VOLTS
CHT	E39	3.46/92 (197.6)	3.12/93 (199.4)	3.68/91 (195.8)	3.73/89 (192.2)	VOLTS/DEG C (DEG F)
MAP	E40	14.6/2.44	4.6/0.92	5.7/1.09	8.01/1.44	PSI/VOLTS
O2S12	T29	(I)	(D)	(D)	(D)	VOLTS
O2S22	T49	(I)	(D)	(D)	(D)	VOLTS
APP	PID	0	0	13	14	%
B+	PID	12.19	13.94	14.0	13.94	VOLTS
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.3/156.2	PSI/Hz
BOO1	PID	OFF	ON (E)	OFF	OFF	ON/OFF
DECHOKE	PID	YES	NO	NO	NO	YES/NO
EQ_RAT11	PID	0	1.03	1.02	1.0	RATIO
EQ_RAT21	PID	0	1.02	0.98	0.97	RATIO
ETC_TRIM	PID	0.15 (J)	0.19 (J)	0 (J)	0 (J)	DEG
FLI	PID	40.7 (H)	56.42 (H)	54.81 (H)	51.34 (H)	%
INJPWR_M	PID	12.31	13.94	13.94	13.99	VOLTS
LOAD	PID	51.3 (I)	16.97	27.92	32.57	%
MIL_DIS	PID	0	0	0	0	Miles
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	NO	YES	YES	YES/NO
O2S11_IMPED	PID	4.95	1.01	1.03	0.99	VOLTS
O2S21_IMPED	PID	4.95	1.0	1.05	1.02	VOLTS
OSS	PID	0	0	1224	2163	RPM
OSS_SRC	PID	0	0	1220	2159	RPM
RPM	PID	0	616.5	1514	1605	RPM
STRT_RLY	PID	DISABLED	DISABLED	DISABLED	DISABLED	ENABLED/DISABLED
SYNC	PID	NO	YES	YES	YES	YES/NO
TFT	PID	85 (185)	49 (120.2)	74 (165.2)	76 (168.8)	DEG C (DEG F)
TFTV	PID	0.7	1.79	0.95	0.89	VOLTS
TIP_PRS_DSD	PID	100.53/14.5	100.53/14.5	101.49/14.6	105.16/15.2	KPa/PSI
TR	PID	PARK	PARK	OVERDRIVE	OVERDRIVE	POSITION
TSS_SRC	PID	0	585.8	1136	1614	RPM
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 3.5L 4V FLEX/TAURUS

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	75	37.78	36.35	37.92	%
PCVHC	E7	0	0	100	100	%
PCVHC_B	E8	0	0	100	100	%
TURBO_WGATE	E16	0	0	0	0	%
EVAPCP	E32	0	0	0	0	%
O2S21_HTR	E69	23	44.09	40.35	39.89	%
HTR21	E69	OFF	ON	ON	ON	ON/OFF
HTRCM21	E69	1.45	1.46	1.46	1.46	Amps
O2S11_HTR	E70	0	36.8	36.08	35.32	%
HTR11	E70	OFF	ON	ON	ON	ON/OFF
HTRCM11	E70	1.4	1.43	1.43	1.43	Amps
HTR12	T48	OFF	ON	ON	ON	ON/OFF
HTRCM12	T48	0	765	957	860	A/mA
HTR22	T49	OFF	ON	ON	ON	ON/OFF
HTRCM21	T49	0	1.60	1.74	676	A/mA
CAT_EVAL	PID	YES	NO	NO	YES	YES/NO
CLRDIST	PID	54.04	1.86	3.72	11.18	MILES
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPCV	PID	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FANDC	PID	0	0	0	0	%
FAN_DSD	PID	0	0	0	0	%
FTP_H20	PID	0.03	1.3	0	2.13	In-H 2 O
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
F_VCV	PID	0	6.90	22.97	23.21	%-VARYING
LONGFT1	PID	2.73 (I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	4.29 (I)	20 TO +20	20 TO +20	20 TO +20	%
O2S_EVAL	PID	YES	NO	NO	YES	YES/NO
O2SHTR_EVAL	PID	YES	NO	NO	YES	YES/NO
RPMDSD	PID	870	770	600	600	RPM
SHRTFT1	PID	0 (I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	0 (I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	10	13.25	43.50	35.5	DEG
TRIP_CNT	PID	0	0	0	0	COUNT
TURBO_BPASS	PID	0	0	100	0	%-VARYING
TURBO_BPASS_2	PID	0	0	100	0	%-VARYING
TURBO_BP1_STAT	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
TURBO_BP2_STAT	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
TURBO_OVER	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
TURBO_UNDER	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
TWGATE_STAT	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
VCTADV	PID	0	0.06	23.81	34	DEG
VCTADVERR	PID	0	0.06	0.31	1.87	DEG
VCTADVERR2	PID	0	0.12	0	1.62	DEG
VCTADV2	PID	0	0.12	23.87	34	DEG
VCTDC	PID	0	0	47.32	48.56	%
VCTDC2	PID	0	0	47.93	49.45	%
VCTSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP

ACTUATORS/OUTPUTS - 3.5L 4V FLEX/TAURUS

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36/51	12	13-14	13-14	13-14	VOLTS
VREF	B52/E35/T7	5	5	5	5	VOLTS

OTHER - 3.5L 4V FLEX/TAURUS

3.7L 4V MKS/MKT

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PSP	B17	LOW	HIGH	LOW	LOW	HIGH/LOW
GENMON	B23	0	42.19	33.59	24.22	%
APP1	B25	4.07	4.07	3.86	3.66	VOLTS
APP2	B26	1.42	1.42	1.57	1.73	VOLTS
APP3	B27	0.88	0.88	1.08	1.22	VOLTS
FPM	B30	0	0	0	0	%
ACP_PRESS	B37	1.26/93.97	1.47/119.97	1.06/69.99	1.04/65.99	VOLTS/PSI
MAF	B41	0.01	0.56	1.34	1.56	VOLTS
IAT	B43	1.94/45 (113)	2.01/43 (109.4)	3.65/7 (44.6)	3.99/-4 (24.8)	VOLTS/DEG C (DEG F)
FTP	B44	2.62/0.61	2.43/0.61	2.62/0.61	2.32/0.61	VOLTS/PSI
BPA	B47	OFF	OFF	OFF	OFF	ON/OFF
O2S11_CUR	E18	(I)	Switching	Switching	Switching	MA/uA
O2S21_CUR	E20	(I)	Switching	Switching	Switching	MA/uA
O2S12	E23	(I)	(D)	(D)	(D)	VOLTS
O2S22	E24	(I)	(D)	(D)	(D)	VOLTS
CHT	E41	0.56/92 (197.6)	0.54/93 (199.4)	3.68/91 (195.8)	3.73/89 (192.2)	VOLTS/DEG C (DEG F)
TSS	T15	0	585.8	1136	1612	RPM
ACCS	PID	OFF	OFF	OFF	OFF	ON/OFF
APP	PID	0	0	7	14	%
B+	PID	12.19	13.94	14.0	13.94	VOLTS
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.3/156.2	PSI/Hz
BOO	PID	OFF	OFF	OFF	OFF	ON/OFF
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
EONV_RDY	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EQ_RAT11	PID	0	1.03	1.02	1.0	RATIO
EQ_RAT21	PID	0	1.02	0.98	0.97	RATIO
ETC_TRIM	PID	0.05 (J)	0.24 (J)	0.24 (J)	0.24 (J)	DEG
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FLI	PID	40.7 (H)	56.42 (H)	54.81 (H)	51.34 (H)	%
GEAR	PID	1	1	5	6	GEAR
INJPWR_M	PID	12.31	13.94	13.94	13.99	VOLTS
LOAD	PID	51.3 (I)	16.97	27.92	32.57	%
MIL_DIS	PID	0	0	0	0	Miles
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	NO	YES	YES	YES/NO
NM	PID	0	0	0	0	COUNT
O2S11_IMPED	PID	4.95	1.01	1.03	0.99	VOLTS
O2S21_IMPED	PID	4.95	1.0	1.05	1.02	VOLTS
OSS	PID	0	0	1224	2163	RPM
OSS_SRC	PID	0	0	1220	2159	RPM
RPM	PID	0	616.5	1277	1605	RPM
STRT_RLY	PID	DISABLED	DISABLED	DISABLED	DISABLED	ENABLED/DISABLED
SYNC	PID	NO	YES	YES	YES	YES/NO
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
TFT	PID	85 (185)	49 (120.2)	74 (165.2)	76 (168.8)	DEG C (DEG F)
TFTV	PID	0.7	1.79	0.95	0.89	VOLTS
TORQUE	PID	155	6.67	36.07	108.2	Nm
TR	PID	PARK	PARK	OVERDRIVE	OVERDRIVE	POSITION
TR2	PID	OPEN	OPEN	CLOSED	CLOSED	OPEN/CLOSED
TSS/ISS	PID	0	585.3	1135	1614	RPM
TSS_SRC	PID	0	585.8	1136	1614	RPM
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 3.7L 4V MKS/MKT

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
EVMV	B50	0/OFF	778/VARYING	935/VARYING	648/ON	MA/ON/OFF- VARYING
FP	B62	OFF	ON	ON	ON	ON/OFF
HTR12	E1	OFF	ON	ON	ON	ON/OFF
HTRCM12	E1	613	652	652	652	MA
HTR22	E2	OFF	ON	ON	ON	ON/OFF
HTRCM22	E2	648	676	676	676	MA
VCTADV	E67	0	0.06	12.38	39	DEG
VCTADV2	E68	0	0.12	34.13	37.13	DEG
O2S11_HTR	E69	0	36.8	36.08	35.32	%
HTR11	E69	OFF	ON	ON	ON	ON/OFF
HTRCM11	E69	1.4	1.43	1.43	1.43	Amps
O2S21_HTR	E70	0	36.09	35.35	34.89	%
HTR21	E70	OFF	ON	ON	ON	ON/OFF
HTRCM21	E70	1.45	1.46	1.46	1.46	Amps
CAT_EVAL	PID	YES	NO	NO	YES	YES/NO
CLRDIST	PID	54.04	1.86	2.48	11.18	MILES
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPCV	PID	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FANDC	PID	7.99	10	7.99	7.99	%
FANVAR	PID	0	0	0	0	%
FTP_H20	PID	0.03	1.3	0	2.13	In-H 2 O
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
IGN_R/S	PID	ON	ON	ON	ON	ON/OFF
LONGFT1	PID	2.73 (I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	4.29 (I)	20 TO +20	20 TO +20	20 TO +20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
O2S_EVAL	PID	YES	NO	NO	YES	YES/NO
O2SHTR_EVAL	PID	YES	NO	NO	YES	YES/NO
RPMDSD	PID	800	608	608	608	RPM
SHRTFT1	PID	0 (I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	0 (I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	10	13.25	30	38.5	DEG
TRIP_CNT	PID	0	0	0	0	COUNT
VCTADVERR	PID	0	0.06	0.31	1.87	DEG
VCTADVERR2	PID	0	0.12	0	1.62	DEG
VCTDC	PID	0	0	47.32	48.56	%
VCTDC2	PID	0	0	47.93	49.45	%
VCTSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP

ACTUATORS/OUTPUTS - 3.7L 4V MKS/MKT

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B51/52/53	12	13-14	13-14	13-14	VOLTS
VREF	B64	5	5	5	5	VOLTS

OTHER - 3.7L 4V MKS/MKT

3.7L 4V Mustang

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
APP1	B28	0.76	0.76	3.86	3.66	VOLTS
APP2	B29	0.38	0.38	1.57	1.73	VOLTS
FPM	B32	58.72	58.72	59.41	58.72	%
MAF	B40	0.17	3.55	13.14	16.58	G/s
MAF_HZ	B40	725	1.90	3.20	3.52	KHz
IAT	B47	1.94/45 (113)	2.01/43 (109.4)	3.65/7 (44.6)	3.99/-4 (24.8)	VOLTS/DEG C (DEG F)
GENMON	B53	0	42.19	17.60	17.75	%
FTP	B65	2.62/0.61	2.43/0.61	2.62/0.61	2.32/0.61	VOLTS/PSI
FTP_H20	B65	0.172	1.173	1.552	0.205	In-H 2 O
O2S21_CUR	E10/E24	(I)	Switching	Switching	Switching	MA/uA
VCT_EXH_ACT2	E18	0	0.06	0	0.50	DEG
O2S11_CUR	E23/E27	(I)	Switching	Switching	Switching	MA/uA
CHT	E39	0.56/92 (197.6)	0.54/93 (199.4)	3.68/91 (195.8)	3.73/89 (192.2)	VOLTS/DEG C (DEG F)
VCT_EXH_ACT1	E52	0	0.06	0.25	0.12	DEG
VCT_INT_ACT1	E67	0	0.18	10.18	10.16	DEG
VCT_INT_ACT2	E68	0	0.37	10.00	9.68	DEG
TSS_SRC	T16	0	585.8	1136	1612	RPM
CPP/PNP	T27	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/DRIVE
O2S12	T29	(I)	(D)	(D)	(D)	VOLTS
O2S22	T49	(I)	(D)	(D)	(D)	VOLTS
APP	PID	0	0	7	14	%
B+	PID	12.5	13-14	13-14	13-14	VOLTS
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.3/156.2	PSI/Hz
BOO1	PID	OFF	OFF	OFF	OFF	ON/OFF
BOO2	PID	OFF	OFF	OFF	OFF	ON/OFF
DECHOKE	PID	YES	NO	NO	NO	YES/NO
EONV_RDY	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EQ_RAT11	PID	0	1.03	1.02	1.0	RATIO
EQ_RAT21	PID	0	1.02	0.98	0.97	RATIO
ETC_TRIM	PID	0.08 (J)	0.08 (J)	0.04 (J)	0.04 (J)	DEG
FLI	PID	40.7 (H)	56.42 (H)	54.81 (H)	51.34 (H)	%
GEAR	PID	1	1	5	6	GEAR
INJPWR_M	PID	12.31	13.94	13.94	13.99	VOLTS
LOAD	PID	0 (I)	16.97	27.92	32.57	%
MIL_DIS	PID	0	0	0	0	Miles
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	NO	YES	YES	YES/NO
NUM_MISFIRE	PID	0	0	0	0	COUNT
O2S11_IMPED	PID	4.95	0.09	0.09	0.09	VOLTS
O2S21_IMPED	PID	4.95	0.09	0.09	0.09	VOLTS
OSS_SRC	PID	0	0	1220	2159	RPM
RPM	PID	0	616.5	1277	1605	RPM
STRT_RLY	PID	DISABLED	DISABLED	DISABLED	DISABLED	ENABLED/DISABLED
SYNC	PID	NO	YES	YES	YES	YES/NO
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
TFT	PID	0.7/85 (185)	1.79/49 (120.2)	0.95/74 (165.2)	0.89/76 (168.8)	VOLTS/DEG C (DEG F)
TR	PID	PARK	PARK	OVERDRIVE	OVERDRIVE	POSITION
TSS_SRC	PID	0	585.8	1136	1614	RPM
VCT_EXH_DIF1	PID	0	0.43	0.56	0	DEG
VCT_EXH_DIF2	PID	0	0.25	0.18	0	DEG
VCT_INT_DIF1	PID	0	0.12	34.13	37.13	DEG
VCT_INT_DIF2	PID	0	0.12	34.13	37.13	DEG
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 3.7L 4V MUSTANG

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	OFF	ON	ON	ON	ON/OFF
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
EVAPCP	E32	0	46.21	80.92	99.99	%
HTR11	E69	OFF	ON	ON	ON	ON/OFF
O2S11_HTR	E69	26.66	36.8	36.08	35.32	%
HTR22	T22	OFF	ON	ON	ON	ON/OFF
HTRCM22	T22	0	812	773	729	MA/A
HTR12	T49	OFF	ON	ON	ON	ON/OFF
HTRCM12	T49	0	808	763	739	MA/A
O2S21_HTR	E70	26.66	36.09	35.35	34.89	%
HTR21	E70	OFF	ON	ON	ON	ON/OFF
CAT_EVAL	PID	YES	NO	NO	YES	YES/NO
CLRDIST	PID	54.04	1.86	2.48	11.18	MILES
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	2.73 (I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	4.29 (I)	20 TO +20	20 TO +20	20 TO +20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
O2S_EVAL	PID	YES	NO	NO	YES	YES/NO
O2SHTR_EVAL	PID	YES	NO	NO	YES	YES/NO
RPMDSD	PID	800	608	608	608	RPM
SHRTFT1	PID	0 (I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	0 (I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	10	13.25	30	38.5	DEG
VCT_EXT_DSD	PID	0	0.12	34.13	37.13	DEG
VCT_INTK_DSD	PID	0	0.12	34.13	37.13	DEG
VCTSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP

ACTUATORS/OUTPUTS - 3.7L 4V MUSTANG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52/E35	5	5	5	5	VOLTS
VPWR	B67/68	VBAT	VBAT	VBAT	VBAT	VOLTS

OTHER - 3.7L 4V MUSTANG

5.0L 4V Mustang

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
APP1	B28	4.08	4.08	3.7	3.41	VOLTS
APP2	B29	1.43	1.43	1.72	1.94	VOLTS
FPM	B32	0	0	0	0	%
ACP	B31	OPEN	OPEN	OPEN	OPEN	OPEN/CLOSED
MAF	B40	0	0.8	1.04	2.74	VOLTS
IAT	B47	2.28/37 (98.6)	2.9/24 (75.2)	3.74/4 (39.2)	3.86/0 (32)	VOLTS/DEG C (DEG F)
FTP	B65	2.61/0.61	2.53/0.61	2.59/0.6	1.5/0.6	VOLTS/PSI
FTP_H2O	B65	0.06	0.61	0.24	7.93	In-H 2 O
KNOCK_1	E7	0	69	175	265	N/A
MAF (M/T)	E25	0	1	1.5	1.3	VOLTS
O2S11_CUR	T4/T29	(I)	Switching	Switching	Switching	VOLTS/RICH-LEAN
O2S21	PID	(I)	Switching	Switching	Switching	VOLTS/RICH-LEAN
CHT	E30	3.59/93 (199.4)	3.57/94 (201.2)	0.73/82 (179.6)	3.56/94 (201.2)	VOLTS/DEG C (DEG F)
KNOCK_2	E45	0	81	106	297	N/A
TSS	T1	0	721	890	1674	RPM
OSS	T14	0	0	1385	2400	RPM
HTRCM11	T24	1.13	1.13	1.13	1.13	AMPS
HTRCM21	T35	1.14	1.14	1.14	1.14	AMPS
TR2 (A/T)	T17	CLOSED	CLOSED	OPEN	OPEN	OPEN/CLOSED
O2S12	T18	(I)	(D)	(D)	(D)	VOLTS
TFT	T20	0.88/77 (170.6)	0.88/77 (170.6)	1.0/74 (165.2)	0.87/78 (172.4)	VOLTS/DEG C (DEG F)
O2S22	T27	(I)	(D)	(D)	(D)	VOLTS
TCS	T33	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/NOT DEPRESSED
HTRCM12	T47	707	707	707	707	MA
HTRCM22	T49	703	703	703	703	MA
APP	PID	0	0	12.5	22.5	%
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.3/156.2	PSI/Hz
B+	PID	12.69	13-14.5	13-14.5	13-14.5	VOLTS
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_TRIM	PID	0.1 (J)	0.1 (J)	0.17 (J)	0.17 (J)	DEG
FLI	PID	0 (H)	64.28 (H)	69.33 (H)	69 (H)	%
GEAR (A/T)	PID	1	1	5	5	GEAR
LOAD	PID	48.93 (I)	15.19	17.79	52.08	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	YES	YES	YES	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	711	1299	1815	RPM
SYNC	PID	NO	YES	YES	YES	YES/NO
TR (A/T)	PID	P	P	OD	OD	POSITION
VCT_EXH_ACT1	E56	0	0	42.53	0	%
VCT_EXH_ACT2	E57	0	0	42.53	0	%
VCT_EXH_DIF1	PID	0	0	42.53	0	%
VCT_EXH_DIF2	PID	0	0	0	0	%
VCT_INT_ACT1	E56	0	0	42.53	0	%
VCT_INT_ACT2	E57	0	0	42.53	0	%
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 5.0L 4V MUSTANG

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	75/OFF	21.53/ON	24.31/ON	23.78/ON	%/ON/OFF
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
HFC	B18	OFF	ON (B)	OFF	OFF	ON/OFF
EVAPCP	E6	0/OFF	377/VARYING	0/VARYING	533/OFF	MA/OFF- VARYING
LFC	B34	OFF	ON (B)	OFF	OFF	ON/OFF
HTR11	T24	OFF	ON	ON	ON	ON/OFF
HTR21	T35	OFF	ON	ON	ON	ON/OFF
HTR12	T47	OFF	ON	ON	ON	ON/OFF
HTR22	T49	OFF	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	YES	NO	NO	YES/NO
EVAPSOAK	PID	NO	YES	YES	YES	YES/NO
EVAPSTA	PID	NOT RUNNING	6-MONITOR COMPLETE	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
LONGFT1	PID	0 (I)	2.34	20 TO +20	20 TO +20	%
LONGFT2	PID	0 (I)	20 TO +20	20 TO +20	20 TO +20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	0 (I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	0 (I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	10	19.75	34.25	36.75	DEG
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
VCT_EXH_DC1	PID	0	0	42.53	0	%
VCT_EXH_DC2	PID	0	0	42.53	0	%
VCT_INTK_DSD	PID	0	0	42.53	0	%

ACTUATORS/OUTPUTS - 5.0L 4V MUSTANG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52/E20/T31	5	5	5	5	VOLTS
VPWR	B67/68	VBAT	VBAT	VBAT	VBAT	VOLTS

OTHER - 5.0L 4V MUSTANG

5.4L 4V Mustang

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
APP1	B28	4.0	4.0	3.8	3.6	VOLTS
APP2	B29	1.43	1.43	1.57	1.66	VOLTS
MAF	B40	0.01	0.6	0.92	1.7	VOLTS
IAT	B47	1.45/55 (131)	2.28/37 (98.6)	3.29/16 (60.8)	3.39/13 (55.4)	VOLTS/DEG C (DEG F)
FTP	B65	2.63/0.61	2.61/0.61	2.33/0.61	2.33/0.61	VOLTS/PSI
FRP	E23	3.01/43.89	2.89/41.92	2.73/39.1	2.69/38.32	VOLTS/PSI
FRT	E26	1.36/60 (140)	1.49/56 (132.8)	2.1/42 (107.6)	1.93/46 (114.8)	VOLTS/DEG C (DEG F)
CHT	E30	3.27/103 (217.4)	3.35/101 (213.8)	3.49/97 (206.6)	3.41/99 (210.2)	VOLTS/DEG C (DEG F)
IAT2	E36	0.83/79 (174.2)	1.19/65 (149)	1.91/46 (114.8)	2.12/42 (107.6)	VOLTS/DEG C (DEG F)
O2S12	T18	(I)	(D)	(D)	(D)	VOLTS
CPP-BOT	T19	NO	NO	NO	NO	YES/NO
O2S22	T27	(I)	(D)	(D)	(D)	VOLTS
HTRCM21	T35	2.07	2.07	1.87	1.02	AMPS
OSS_SRC	T36	0	0	1290	2361	RPM
HTRCM12	T47	1.57 (AMPS)	1.57 (AMPS)	1.32 (AMPS)	648 (mA)	MA/AMPS
HTRCM22	T49	1.57 (AMPS)	1.57 (AMPS)	1.32 (AMPS)	664	MA/AMPS
APP	PID	0	0	6.5	10.5	%
BARO	PID	14.73/158.9	14.73/158.9	14.73/158.9	14.73/158.9	PSI/Hz
B+	PID	12.88	13-14.5	13-14.5	13-14.5	VOLTS
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_TRIM	PID	0 (J)	0.01 (J)	0.15 (J)	0.1 (J)	DEG
FLI	PID	0 (H)	75.7 (H)	72.45 (H)	70.33 (H)	%
LOAD	PID	73.37 (I)	16.22	34.92	41.87	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2S11	PID	(I)	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
O2S21	PID	(I)	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
RPM	PID	0	660-780	1200-1300	1450-1740	RPM
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 5.4L 4V MUSTANG

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
HFC	B18	OFF	ON (B)	OFF	OFF	ON/OFF
FP	B19	75/OFF	21.59/ON	21.26/ON	22.41/ON	%/ON/OFF
EVAPCV	B20	OFF	OFF	OFF	OFF	ON/OFF
FPM2	B25	99.71	99.71	103.4	99.71	%
FPM	B32	99.71	99.71	103.4	99.71	%
LFC	B34	OFF	ON (B)	OFF	OFF	ON/OFF
SPKDUR_5	E18	0	1.81	1.59	1.4	Ms
SPKDUR_4	E33	0	1.87	1.68	1.68	Ms
SPKDUR_3	E34	0	1.78	1.4	1.59	Ms
EVAPCP	E49	0/OFF	574/VARYING	633/VARYING	666/OFF	MA/OFF- VARYING
SPKDUR_7	E50	0	1.75	1.71	1.37	Ms
SPKDUR_2	E51	0	1.81	1.62	1.5	Ms
SPKDUR_8	E52	0	1.84	1.56	1.65	Ms
SPKDUR_6	E69	0	1.68	1.78	1.59	Ms
SPKDUR_1	E70	0	1.56	1.46	1.5	Ms
HTR11	T24	OFF	ON	ON	ON	ON/OFF
HTR21	T35	OFF	ON	ON	ON	ON/OFF
HTR12	T47	OFF	ON	ON	ON	ON/OFF
HTR22	T49	OFF	ON	ON	ON	ON/OFF
EGR_EVAL	PID	NO	NO	NO	NO	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	10	14.5	31.75	33.25	DEG

ACTUATORS/OUTPUTS - 5.4L 4V MUSTANG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52/E20/T31	5	5	5	5	VOLTS
VPWR	B67/68	VBAT	VBAT	VBAT	VBAT	VOLTS

OTHER - 5.4L 4V MUSTANG

2.0L 4V Edge

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FPM	B12	59.41	59.40	59.82	59.40	%
APP2	B26	0.40/7.84	0.40/7.84	0.59/11.76	0.53/10.58	VOLTS/%
AAT	B35	187.6 (69.8)	20.0 (68.0)	10.0 (50.0)	9.0 (48.2)	DEG C (DEG F)
AAT_V	B35	2.93	2.98	3.50	3.55	VOLTS
O2S12	B48	(I)	(D)	(D)	(D)	VOLTS
APP1	B52	0.79/15.68	0.79/15.68	1.19/23.92	1.34/26.66	VOLTS/%
TIP_PRS_BOOST	B74	99.40/14.42	99.40/14.42	102.93/14.93	104.86/15.21	KPa/PSI
FLP	E7	641.28/93.01	555.30/80.54	543.30/78.80	557.85/80.91	KPa/PSI
FLP_DSD	E7	545.85/79.17	551.85/80.04	578.81/83.95	581.84/84.39	KPa/PSI
FLP_V	E7	2.64	2.30	2.25	2.31	VOLTS
TIP_PRES_V	E8	1.60	1.60	1.66	1.68	VOLTS
FRP	E9	0.61/599.84/87.00	0.86/1739.54/252.3	1.23/3619.05/252.3	2.04/7697.99/1116.5	VOLTS/kPa/PSI
IAT	E10	2.48/21.9 (71.60)	2.54/21.0 (69.80)	2.97/12.0 (53.60)	3.08/10.0 (50.00)	VOLTS/DEG C (DEG F)
CAC_T	E11	26 (78.8)	24 (75.2)	16 (60.8)	13 (55.4)	DEG C (DEG F)
CAC_V	E11	2.90	2.96	3.32	3.46	VOLTS
ECT	E12	23 (73.4)	47 (116.6)	81 (177.8)	94 (201.2)	DEG C (DEG F)
CHT	E56	0/23 (73.4)	0/47 (116.6)	0/81 (177.8)	0/94 (201.2)	VOLTS/DEG C (DEG F)
FTP	E59	2.60/0.00/-0.00	1.86/-1.31/-0.19	2.54/-0.06/-0.01	2.16/-0.75/-0.11	VOLTS/kPa/PSI
VCT_INT_ACT1	E67	0.00	0.25	0.06	20.12	DEG
VCT_EXH_ACT1	E71	0.00	0.06	29.12	0.18	DEG
MAP	E83	1.60/98.93/14.35	0.65/37.99/5.51	0.76/45.98/6.67	1.12/69.98/10.15	VOLTS/kPa/PSI
O2S11_CUR	E89	(I)	Switching (C)	Switching (C)	Switching (C)	UA
APP	PID	0.00	0.00	12.50	16.50	%
APP_MAXDIFF	PID	0.00	0.00	0.06	0.00	DEG
B+	PID	VBAT	VBAT	VBAT	VBAT	VOLTS
BARO	PID	3.92/98.93/14.35/156.11/397.44	3.92/98.93/14.35/156.11/397.44	3.92/98.93/14.35/156.11/397.44	3.92/98.93/14.35/156.11/397.44	VOLTS/kPa/PSI/Hz/in-H 2 O
BOO1	PID	OFF	OFF	OFF	OFF	ON/OFF
BOO2	PID	OFF	OFF	OFF	OFF	ON/OFF
BRKOVR_ACTION	PID	9	9	9	9	NUMERIC VALUE
BRKOVRD_POSS	PID	64	64	65	65	NUMERIC VALUE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
DIST_BRKOVRD	PID	718.2 (446.27)	718.2 (446.27)	718.2 (446.27)	725.7 (450.93)	Km (Miles)
EQ_RAT11	PID	0	1.00	0.93	1.00	RATIO
ETC_TRIM	PID	0.52 (J)	0.54 (J)	0.54 (J)	0.53 (J)	DEG
FLI	PID	100.00 (H)	100.00 (H)	100.00 (H)	94.51 (H)	%
FRP_DSD	PID	369.90/53.65	1749.54/253.75	3669.04/532.15	7687.99/1115.05	KPa/PSI
LOAD	PID	0 (I)	29.80	24.70	48.23	%
MIL_DIS	PID	0	0	0	0	Miles
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	YES	YES	YES	YES/NO
O2S_EVAL	PID	YES	YES	YES	YES	YES/NO
O2S11_IMPED	PID	4.94	1.01	1.01	1.01	VOLTS
O2S11_READY	PID	NO	YES	YES	YES	YES/NO
O2SHTR_EVAL	PID	YES	YES	YES	YES	YES/NO
RPM	PID	0	855.75	1590.00	1537.25	RPM
SYNC	PID	NO	YES	YES	YES	YES/NO
TIP_PRS_DSD	PID	100.66/14.60	100.66/14.60	100.52/14.58	103.28/14.98	KPa/PSI
VCT_EXH_DIF1	PID	0.00	0.18	0.18	0.12	DEG
VCT_EXH_DSD	PID	0.00	0.00	20.18	0.50	DEG
VCT_INT_DIF1	PID	0.00	0.25	0.00	0.37	DEG
VCTSYS	PID	OPEN	CLOSED	CLOSED	CLOSED	OPEN/CLOSED LOOP
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 2.0L 4V EDGE

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
HTR12	B20	OFF	OFF	ON	ON	ON/OFF
HTRCM12	B20	0	0	0	0	A/mA
FP	B45	75.00	21.99	22.23	22.97	%
FTP_H2O	E59	0.137	5.378	0.368	3.274	In-H 2 O
HTR11	E72	OFF	ON	ON	ON	ON/OFF
O2S11_HTR	E72	24.70	37.25	33.33	30.19	%
EVAPCP	E91	0.00	27.28	0.00	90.99	%
EVAPCV	E91	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OF
TURBO_WGATE	E95	0.00	48.49	47.77	48.31	%
ETC [TAC_PCT]	PID	9.41	3.92	10.19	11.76	%
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
F_VCV	PID	0	7.95	6.69	10.90	%-VARYI
FAN_DSD	PID	7.99	7.99	7.99	7.99	%
FANDC	PID	7.84	7.84	7.84	7.84	%
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSE LOOP
GRILL_A_CMD	PID	0.00/CLOSED	31.76/VARYING	52.94/VARYING	61.56/VARYING	%/OPEN CLOSE
GRILL_A_INF	PID	0.00	31.37	50.19	56.47	%
GRILL_CMDCAL	PID	YES	NO	NO	NO	YES/NO
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
O2_DS_DISBL	PID	YES	NO	NO	NO	YES/NO
O2_DS1_ERR	PID	0	0.15	0.02	0.02	VOLTS
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/DISABLE
RO2FT1	PID	0	0.17	1.45	1.39	%
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	10.00	9.50	36.25	12.75	%
VCT_EXH_DC1	PID	0.00	0.00	39.53	0.00	%
VCT_INT_DC1	PID	0.00	0.00	0.00	39.08	%
VCT_INTK_DSD	PID	0	0	0	19.75	DEG
WGATE_PRES	PID	98.93/14.35	64.46/9.35	65.43/9.49	76.46/11.09	KPa/PSI
WGATE_V	PID	4.26	2.89	2.93	3.36	VOLTS
WGATE_VAC_DSD	PID	33.43/4.85	33.43/4.85	32.47/4.71	22.47/3.26	KPa/PSI
WGATE_VAC_INF	PID	0.00/0.00	34.47/5.00	32.95/4.78	22.47/3.26	KPa/PSI

ACTUATORS/OUTPUTS - 2.0L 4V EDGE

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B7/B31/E15/E18	5	5	5	5	VOLTS
VPWR	B5/B6	12.52	13-14	13-14	13-14	VOLTS

OTHER - 2.0L 4V EDGE

3.5L 4V Edge

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
APP1	B28	0.78/15.29	0.78/15.29	0.77/15.29	1.36/27.05	VOLTS/%
APP2	B29	0.37/7.45	0.37/7.45	0.37/7.45	0.68/7.45	VOLTS/%
FPM	B32	60.31	59.67	60.31	60.31	%
INJPWR_M	B33	11.91	14.06	14.18	14.20	VOLTS
MAF	B40	0	0.53	1.02	1.59	VOLTS
IAT	B47	1.71/50 (122)	2.19/40 (104)	3.77/8.8 (48)	3.84/6.6 (44)	VOLTS/DEG C (DEG F)
FTP	B65	2.63/0/0	2.47/-0.03/-206.84	2.24/-0.09/-620.53	2.57/-0.01/-68.95	VOLTS/PSI/Pa
O2S21_CUR	E10	(I)	Switching	Switching	Switching	MA/uA
VCT_EXH_ACT2	E18	0	0	0.68	46.93	DEG
O2S11_CUR	E27	(I)	Switching	Switching	Switching	MA/uA
O2S21	E28	(I)	Switching (C)	Switching (C)	Switching (C)	VOLTS
AAT	E29	4 (39.2)	4 (39.2)	5 (41)	6 (42.8)	DEG C (DEG F)
AAT_V	E29	2.10	2.56	3.63	3.63	VOLTS
CHT	E39	3.56/95 (203)	3.68/91 (195)	3.57/92 (197)	0.58/91 (195)	VOLTS/DEG C (DEG F)
VCT_EXH_ACT1	E52	0	0.12	0.06	46.93	DEG
VCT_INT_ACT1	E67	0	0.06	9.87	30.31	DEG
VCT_INT_ACT2	E68	0	0.06	9.93	30	DEG
O2S12	T29	(I)	(D)	(D)	(D)	VOLTS
B+	PID	12.5	13-14	13-14	13-14	VOLTS
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.3/156.2	PSI/Hz
FLI	PID	16.07 (H)	16.07 (H)	22.35 (H)	25.49 (H)	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2S11_IMPED	PID	5	0.09	0.09	0.09	VOLTS
O2S21_IMPED	PID	5	0.09	0.09	0.09	VOLTS
O2S11_TR	PID	116.6	116.6	123.7	123.7	Kohm
O2S21_TR	PID	116.7	116.7	123.9	123.9	Kohm
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 3.5L 4V EDGE

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	75/ON/OFF	38.26/ON	37.24/ON	37.17/ON	%/ON/OFF
EVAPCV	B20	0	0	0	0	%
EVAPCP	B32	0	19.57	22.66	20.42	%
FP	B62	8.3/75	3.6/27	3.6/27	3.8/29	VOLTS/%
VCT_EXH_DC2	E18	0	0	0	47.25	%
VCT_EXH_DC1	E52	0	0	0	48.23	%
VCT_INT_DC2	E67	0	0	45.62	45.14	%
VCT_INT_DC1	E68	0	0	47.51	45.92	%
HTR11	E69	ON	ON	ON	ON	ON/OFF
O2S11_HTR	E69	25.09	30.58	29.80	28.62	%
HTR21	E70	OFF	ON	ON	ON	ON/OFF
O2S21_HTR	E70	25.09	34.51	30.98	30.98	%
HTR22	T48	OFF	ON	ON	ON	ON/OFF
HTRCM22	T48	0	819	604	0	MA
HTR12	T49	OFF	ON	ON	ON	ON/OFF
HTRCM12	T49	0	777	569	0	MA
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAPSOAK	PID	NO	NO	YES	YES	YES/NO
EVAPSTA	PID	NOT RUNNING	6 MONITOR COMPT	6 MONITOR COMPT	6 MONITOR COMPT	STATUS
EVAP020C	PID	NO	NO	NO	NO	YES/NO
FANDC	PID	0	17.64	0	0	%
FAN_DSD	PID	0	18.02	0	0	%
FTP_H2O	PID	0.10	1.07	2.65	0.31	In-H 2 O
IACTRIM	PID	0	0	0	0	NUMERIC VALUE
LOAD	PID	0 (I)	32.94	43.13	59.60	%
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
MP_LRN	PID	YES	YES	YES	YES	YES/NO
O2_DS_DISBL	PID	YES	NO	NO	NO	YES/NO
O2_DS1_ERR	PID	0	0.12	0.19	0.02	VOLTS
O2_DS2_ERR	PID	0	0.19	0.10	0.11	VOLTS
O2SHTR_EVAL	PID	YES	NO	NO	NO	YES/NO
O2S_EVAL	PID	YES	NO	NO	NO	YES/NO
O2S11_READY	PID	NO	YES	YES	YES	YES/NO
O2S21_READY	PID	NO	YES	YES	YES	YES/NO
RPM	PID	0	613	1167	1603	RPM
R02FT1	PID	0	1	1.3	1.33	%
R02FT2	PID	0	0.98	1.85	1.47	%
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	10	16	26	45.75	DEG
SYNC	PID	NO	YES	YES	YES	YES/NO
VCT_EXH_DIF1	PID	0	0.12	0.06	1.31	DEG
VCT_EXH_DIF2	PID	0	0.25	1.62	1.06	DEG
VCT_INT_DIF1	PID	0	0.06	0.18	0.31	DEG
VCT_INT_DIF2	PID	0	0.06	0	0	DEG
VCTSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP

ACTUATORS/OUTPUTS - 3.5L 4V EDGE

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52/E35/T7	5	5	5	5	VOLTS
VPWR	B67/68	VBAT	VBAT	VBAT	VBAT	VOLTS

OTHER - 3.5L 4V EDGE

3.7L 4V Edge/MKX

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
APP1	B28	0.76	0.76	1.14	1.20	VOLTS
APP2	B29	0.38	0.38	0.58	0.61	VOLTS
FPM	B32	59.67	60.35	60.31	58.72	%
MAF	B40	0.02	3.42	12.32	30.64	G/s
MAF_HZ	B40	0	0.54	1.22	1.91	VOLTS
IAT	B47	1.70/51 (123.8)	2.81/28 (82.4)	3.36/17 (62.6)	3.35/17 (62.6)	VOLTS/DEG C (DEG F)
GENMON	B53	0	38.04	24.37	18.51	%
FTP	B65	2.64/0	2.49/-0.03	2.55/-0.01	2.17/-0.11	VOLTS/PSI
FTP_H20	B65	0.136	0.898	0.517	3.208	In-H 2 O
O2S21_CUR	E10/E24	(I)	Switching	Switching	Switching	MA/uA
VCT_EXH_ACT2	E18	0	0.06	20.06	50.68	DEG
O2S11_CUR	E23/E27	(I)	Switching	Switching	Switching	MA/uA
CHT	E39	0.56/93 (199.4)	0.60/90 (194)	0.62/89 (192.2)	0.62/89 (192.2)	VOLTS/DEG C (DEG F)
VCT_EXH_ACT1	E52	0	0.12	0.25	31.12	DEG
VCT_INT_ACT1	E67	0	0.06	9.81	9.43	DEG
VCT_INT_ACT2	E68	0	0.12	10.50	10.50	DEG
TSS_SRC	T16	0	582.25	1070.25	1474.50	RPM
O2S12	T29	(I)	(D)	(D)	(D)	VOLTS
O2S22	T49	(I)	(D)	(D)	(D)	VOLTS
APP	PID	0	0	12	14	%
B+	PID	12.5	13-14	13-14	13-14	VOLTS
BARO	PID	14.21/155.19	14.21/155.19	14.21/155.19	14.21/155.19	PSI/Hz
BOO1	PID	OFF	OFF	OFF	OFF	ON/OFF
BOO2	PID	OFF	OFF	OFF	OFF	ON/OFF
DECHOKE	PID	YES	NO	NO	NO	YES/NO
EONV_RDY	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EQ_RAT11	PID	0	1.006	0.995	1.024	RATIO
EQ_RAT21	PID	0	1.01	0.986	1.015	RATIO
ETC_TRIM	PID	0.03 (J)	0.06 (J)	0 (J)	0 (J)	DEG
FLI	PID	20.39 (H)	20 (H)	23.52 (H)	14.11 (H)	%
GEAR	PID	1	1	5	6	GEAR
INJPWR_M	PID	12.42	14.08	14.13	14.18	VOLTS
LOAD	PID	0 (I)	39.60	29.80	25.49	%
MIL_DIS	PID	0	0	0	0	Miles
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	NO	YES	YES	YES/NO
NUM_MISFIRE	PID	0	0	0	0	COUNT
O2S11_IMPED	PID	5.00	0.09	0.09	0.09	VOLTS
O2S21_IMPED	PID	5.00	0.09	0.09	0.09	VOLTS
OSS_SRC	PID	0	0	1072	2020	RPM
RPM	PID	0	590	1584	1499	RPM
STRT_RLY	PID	DISABLED	DISABLED	DISABLED	DISABLED	ENABLED/DISABLED
SYNC	PID	NO	YES	YES	YES	YES/NO
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
TFT	PID	0.69/86 (186.8)	0.64/89 (192.2)	0.72/85 (185)	0.67/88 (190.4)	VOLTS/DEG C (DEG F)
TR	PID	PARK	PARK	DRIVE/OVERDRIVE	DRIVE/OVERDRIVE	POSITION
TSS_SRC	PID	0	582.25	1070.25	1474.50	RPM
VCT_EXH_DIF1	PID	0	0	4.12	0.06	DEG
VCT_EXH_DIF2	PID	0	0.06	5.75	0.68	DEG
VCT_INT_DIF1	PID	0	0.12	0.43	0.93	DEG
VCT_INT_DIF2	PID	0	0	0.43	9.43	DEG
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 3.7L 4V EDGE/MKX

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	OFF	ON	ON	ON	ON/OFF
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
EVAPCP	E32	0	37.91	0	87.07	%
HTR11	E69	OFF	ON	ON	ON	ON/OFF
O2S11_HTR	E69	22.35	31.37	28.23	25.09	%
HTR22	T22	OFF	ON	ON	ON	ON/OFF
HTRCM22	T22	0	793	793	793	MA/A
HTR12	T49	OFF	ON	ON	ON	ON/OFF
HTRCM12	T49	0	838	838	838	MA/A
O2S21_HTR	E70	22.35	30.58	27.84	26.27	%
HTR21	E70	OFF	ON	ON	ON	ON/OFF
CAT_EVAL	PID	YES	NO	NO	YES	YES/NO
CLRDIST	PID	79.53	78.91	57.16	57.78	MILES
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	3.12 (I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	2.34 (I)	20 TO +20	20 TO +20	20 TO +20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
O2S_EVAL	PID	YES	NO	NO	YES	YES/NO
O2SHTR_EVAL	PID	YES	NO	NO	YES	YES/NO
RPMDSD	PID	600	600	600	600	RPM
SHRTFT1	PID	0 (I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	0 (I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	17.75	13.25	33.75	37.50	DEG
VCT_EXT_DSD	PID	0	0	27.56	49.56	DEG
VCT_INTK_DSD	PID	0	0	10.25	10.25	DEG
VCTSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP

ACTUATORS/OUTPUTS - 3.7L 4V EDGE/MKX

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52/E35	5	5	5	5	VOLTS
VPWR	B67/68	VBAT	VBAT	VBAT	VBAT	VOLTS

OTHER - 3.7L 4V EDGE/MKX

2.5L 4V Escape

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
GENMON	B14	0	41.38	21.07	17.68	%
APP1	B28	0.79	0.79	1.03	1.13	VOLTS
APP2	B29	0.38	0.38	0.58	0.62	VOLTS
ACP_PRESS	B31	1.56/66.26	1.52/63.94	1.23/45.82	1.13/39.44	VOLTS/PSI
MAF (A/T)	B40	0.01	0.53	1.17	1.91	VOLTS
MAF (M/T)	B40	0.01	0.41	0.73	1.97	VOLTS
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	1.4/58 (136.4)	1.54/55 (131)	2.71/30 (86)	2.75/29 (84.2)	VOLTS/DEG C (DEG F)
FTP	B65	2.6/0	2.56/0	2.61/0	2.61/0	VOLTS/PSI
FTP_H2O	B65	0.03	0.44	0.03	0.03	In-H 2 O
O2S11	E8	(I)	Switching (C)	Switching (C)	Switching (C)	VOLTS
CHT	E39	3.4/98.8 (210)	3.66/96.6 (206)	0.64/88 (190.4)	0.57/91 (195.8)	VOLTS/DEG C (DEG F)
MAP	E40	4/98.93/14.3/29.11	1.2/27.99/4.06/8.26	0.89/21.99/3.19/6.49	2.9/70.94/10.29/20.95	VOLTS/kPa/PSI/inHg
TSS_SRC (A/T)	T16	0	716.8	1265	1710	RPM
TFT (A/T)	T19	63 (145.4)	63 (145.4)	67 (152.6)	85 (185)	DEG C (DEG F)
TFTV (A/T)	T19	1.27	1.28	1.18	0.71	VOLTS
OSS_SRC (A/T)	T25	0	0	1248	2290	RPM
CPP_BOT (M/T)	T26	NO	NO	NO	NO	YES/NO
CPP_TOP (M/T)	T27	NO	NO	NO	NO	YES/NO
O2S12	T29	(I)	(D)	(D)	(D)	VOLTS
APP	PID	0	0	7	10.5	%
B+	PID	12.47	13-14	13-14	13-14	VOLTS
BARO	PID	14.35/156.1	14.35/156.1	14.35/156.1	14.21/155.2	PSI/Hz
ETC_TRIM	PID	0.15 (J)	0.06 (J)	0.05 (J)	0.02 (J)	DEG
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR (A/T)	PID	1	1	5	6	GEAR
HTRCM11	PID	0	0	1.5	1.5	Amps
HTRCM12	PID	0	0	630	630	MA
LOAD (A/T)	PID	0 (I)	20.78	30.98	54.51	%
LOAD (M/T)	PID	0 (I)	20	86.67	44.71	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
RPM	PID	0	649.5	1189	2171	RPM
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 2.5L 4V ESCAPE

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	75	40.04	40.09	40.29	%
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
EVAPCP	E32	0	24.71	21.96	0	%
HTR11	E69	OFF	ON	ON	ON	ON/OFF
HTR12	T49	OFF	ON	ON	ON	VOLTS/ON/OFF
CAT_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
HFC	PID	OFF	ON (B)	OFF	OFF	ON/OFF
LFC	PID	OFF	ON (B)	OFF	OFF	ON/OFF
LONGFT1	PID	20 TO +20	20 TO +20	20 TO +20	20 TO +20	%
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/DISABLED
RPMDSD	PID	650	650	650	650	RPM
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV (A/T)	PID	10	14-20	36-44	30-40	DEG
SPARKADV (M/T)	PID	10	14.25	45.25	53	DEG
STRT_RLY	PID	DISABLED	DISABLED	DISABLED	DISABLED	ENABLED/DISABLED
TCC (A/T)	PID	0	0	19.14	27.55	PSI
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
TQ_CNTRL	PID	NONE	NONE	NONE	NONE	_

ACTUATORS/OUTPUTS - 2.5L 4V ESCAPE

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B67/68	12.39	13-14	13-14	13-14	VOLTS

OTHER - 2.5L 4V ESCAPE

3.0L 4V Escape

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
GENMON	B14	0	44.58	31.54	31.28	%
APP1	B28	0.77	0.77	1.28	1.44	VOLTS
APP2	B29	0.37	0.37	0.65	0.72	VOLTS
ACP_PRESS	B31	1.3/54.37	1.3/50.17	1.3/51.04	1.3/49.59	VOLTS/PSI
MAF	B40	0	0.69	0.7-1.5	1.3-2	VOLTS
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	2.25/39 (102.2)	2.45/35 (95)	2.61/31.9 (89.6)	2.96/25 (77)	VOLTS/DEG C (DEG F)
FTP	B65	2.6/0	2.47/-0.03	2.6/0.01	2.6/0	VOLTS/PSI
O2S11	E8	(I)	Switching (C)	Switching (C)	Switching (C)	VOLTS
O2S21	E9	(I)	Switching (C)	Switching (C)	Switching (C)	VOLTS
MAP	E40	4/97.97/14.21/28.93	1.4/34.95/5.07/10.32	1.13/27.99/4.06/8.26	3.23/79.97/11.6/23.61	VOLTS/kPa/PSI/inHg
TSS_SRC	T16	0	625.8	1250	1684	RPM
TFT	T19	39 (102.2)	39 (102.2)	104.4-51.6 (220-125)	104.4-51.6 (220-125)	DEG C (DEG F)
OSS_SRC	T25	0	0	1277	2284	RPM
O2S12	T29	(I)	(D)	(D)	(D)	VOLTS
TR	T39	PARK	PARK	DRIVE/OVERDRIVE	DRIVE/OVERDRIVE	MODE
O2S22	T40	(I)	(D)	(D)	(D)	VOLTS
APP	PID	0	0	16	20.5	%
B+	PID	12.03	13-14	13-14	13-14	VOLTS
BARO	PID	14.21/155.2	14.21/155.2	14.21/155.2	14.35/156.1	PSI/Hz
CAT_EVAL	PID	NO	NO	NO	NO	YES/NO
ETC_TRIM	PID	0.22 (J)	0.21 (J)	0.33 (J)	0.28 (J)	DEG
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	5	6	GEAR
HTRCM11	PID	0	0	0	1.51	Amps
HTRCM12	PID	0	0	0	581	MA
HTRCM21	PID	0	0	0	1.52	Amps
HTRCM22	PID	0	0	0	591	MA
LOAD	PID	(I)	29.02	19-30	30-48	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
RPM	PID	0	689.5	1954	2294	RPM
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 3.0L 4V ESCAPE

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	75	40.04	40.09	40.29	%
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
EVAPCP	E32	0	56.08	20.39	0	%
HTR11	E69	OFF	ON	ON	OFF	ON/OFF
HTR21	E70	OFF	ON	ON	OFF	ON/OFF
HTR22	T48	OFF	ON	ON	ON	ON/OFF
HTR12	T49	OFF	ON	ON	ON	ON/OFF
CAT_EVAL	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FTP_H2O	PID	0.06	1.03	1.03	0.06	In-H 2 O
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
HFC	PID	OFF	ON (B)	OFF	OFF	ON/OFF
LFC	PID	OFF	ON (B)	OFF	OFF	ON/OFF
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/DISABLED
RPMDSD	PID	680	680	650	650	RPM
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	26.75	5-20	36-44	43.5	DEG
STRT_RLY	PID	DISABLED	DISABLED	DISABLED	DISABLED	ENABLED/DISABLED
TCC	PID	0	0	22.04	40.89	PSI
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
TQ_CNTRL	PID	NONE	NONE	NONE	NONE	_

ACTUATORS/OUTPUTS - 3.0L 4V ESCAPE

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B67/68	12.06	13-14	13-14	13-14	VOLTS

OTHER - 3.0L 4V ESCAPE

2.0L 4V Explorer

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FPM	B12	59.40	60.00	60.00	58.98	%
APP2	B26	0.39/7.84	0.39/7.84	0.48/9.41	0.39/7.84	VOLTS/%
AAT	B35	29 (84.2)	24 (75.2)	18 (64.4)	17 (62.6)	DEG C (DEG F)
AAT_V	B35	2.48	2.76	3.08	3.11	VOLTS
O2S12	B48	(I)	(D)	(D)	(D)	VOLTS
APP1	B52	0.77/15.29	0.77/15.29	0.94/18.82	0.77/15.29	VOLTS/%
TIP_PRS_BOOST	B74	99.42/14.42	99.4214.42	103.09/15.07	101.00/14.65	KPa/PSI
FLP	E7	718.77/104.25	622.80/90.33	570.81/82.79	566.33/82.14	KPa/PSI
FLP_DSD	E7	629.83/91.35	629.83/91.35	557.85/80.91	584.81/84.82	KPa/PSI
FLP_V	E7	2.95	2.57	2.36	2.34	VOLTS
TIP_PRES_V	E8	1.60	1.60	1.67	1.63	VOLTS
FRP	E9	0.96/2349.3/340.75	0.84/1689.5/245.05	1.08/3039.2/440.80	1.54/5498.5/797.50	VOLTS/kPa/PSI
IAT	E10	1.61/42 (107.6)	1.60/43 (109.4)	2.65/19 (66.2)	2.65/-40 (-40)	VOLTS/DEG C (DEG F)
IAT2	E10	1.61/-40 (-40)	1.60/-40 (-40)	2.65/19 (66.2)	2.65/-40 (-40)	VOLTS/DEG C (DEG F)
CAC_T	E11	42 (107.6)	38 (100.4)	22 (71.6)	21 (69.8)	DEG C (DEG F)
CAC_V	E11	2.17	2.34	3.07	3.10	VOLTS
ECT	E12	90 (194)	93 (199.4)	74 (165.2)	95 (203)	DEG C (DEG F)
CHT	E56	0/90 (194.0)	0/93 (199.4)	0/74 (165.2)	0/95 (203.0)	VOLTS/DEG C (DEG F)
FTP	E59	2.61/0.00/-0.00	2.13/-0.82/-0.12	1.62/-1.72/-0.25	1.96/-1.10/-0.16	VOLTS/kPa/PSI
VCT_INT_ACT1	E67	0.00	0.06	0.06	0.00	DEG
VCT_EXH_ACT1	E71	0.00	0.06	20.06	30.43	DEG
MAP	E83	1.60/98.93/14.35	0.68/39.98/5.80	0.56/28.95/4.20	1.20/69.98/10.15	VOLTS/kPa/PSI
O2S11_CUR	E89	(I)	Switching (C)	Switching (C)	Switching (C)	UA
APP	PID	0.0	0.0	11.5	0.0	%
APP_MAXDIFF	PID	0.00	0.00	0.06	0.00	DEG
B+	PID	VBAT	VBAT	VBAT	VBAT	VOLTS
BARO	PID	3.92/98.93/14.35/156.11/397.44	3.92/98.93/14.35/156.11/397.44	3.92/98.93/14.35/156.11/397.44	3.92/98.93/14.35/156.11/397.44	VOLTS/kPa/PSI/Hz/in-H 2 O
BOO1	PID	OFF	OFF	OFF	OFF	ON/OFF
BOO2	PID	OFF	OFF	OFF	OFF	ON/OFF
BRKOVR_ACTION	PID	0	0	0	0	NUMERIC VALUE
BRKOVRD_POSS	PID	27	27	27	27	NUMERIC VALUE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
DIST_BRKOVRD	PID	520.7 (323.6)	520.7 (323.6)	493.7 (306.83)	502.2 (312.11)	Km (Miles)
EQ_RAT11	PID	0	0.995	0.995	1.005	RATIO
ETC_TRIM	PID	0.08 (J)	0.08 (J)	0.31 (J)	0.27 (J)	DEG
FLI	PID	91.76 (H)	91.76 (H)	94.51 (H)	92.54 (H)	%
FRP_DSD	PID	369.9/53.65	1749.5/253.75	2929.2/424.85	5648.5/819.25	KPa/PSI
INJPWR_M	PID	0	0	0	0	VOLTS
LOAD	PID	0.00 (I)	32.54	16.86	52.54	%
MIL_DIS	PID	0	0	0	0	Miles
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	YES	YES	YES	YES/NO
O2S_EVAL	PID	YES	YES	YES	YES	YES/NO
O2S11_IMPED	PID	4.93	1.02	1.01	1.02	VOLTS
O2S11_READY	PID	NO	YES	YES	YES	YES/NO
O2SHTR_EVAL	PID	YES	YES	YES	YES	YES/NO
RPM	PID	0	780.75	1737.25	1447.25	RPM
SYNC	PID	NO	YES	YES	YES	YES/NO
TIP_PRS_DSD	PID	100.6/14.60	100.6/14.60	100.6/14.60	100.5/14.59	KPa/PSI
VCT_EXH_DIF1	PID	0.00	0.06	0.00	42.53	DEG
VCT_EXH_DSD	PID	0.00	0.00	20.00	29.06	DEG
VCT_INT_DIF1	PID	0.00	0.06	0.06	0.00	DEG
VCTSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 2.0L 4V EXPLORER

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
HTR12	B20	OFF	ON	ON	ON	ON/OFF
HTRCM12	B20	0	0	0	0	A/mA
FP	B45	75	25.28	23.37	24.49	%
FTP_H2O	E59	0.068	3.447	7.033	4.758	In-H 2 O
HTR11	E72	OFF	ON	ON	ON	ON/OFF
O2S11_HTR	E72	0.00	36.07	29.80	28.62	%
EVAPCP	E91	0.00	65.46	94.32	97.07	%
EVAPCV	E91	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
TURBO_WGATE	E95	0.00	47.91	46.49	45.21	%
ETC [TAC_PCT]	PID	9.41	1.96	5.09	5.49	%
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
F_VCV	PID	0.00	8.89	5.15	9.98	%-VARYING
FAN_DSD	PID	7.99	25.76	7.99	7.99	%
FANDC	PID	7.84	25.49	7.84	7.84	%
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
GRILL_A_CMD	PID	0/CLOSED	0/CLOSED	0/CLOSED	0/CLOSED	%/OPEN/CLOSED
GRILL_A_INF	PID	0	0	0	0	%
GRILL_CMDCAL	PID	NO	YES	YES	YES	YES/NO
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
O2_DS_DISBL	PID	YES	NO	NO	NO	YES/NO
O2_DS1_ERR	PID	0.00	0.12	0.04	0.02	VOLTS
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/DISABLED
RO2FT1	PID	0.00	0.12	1.40	1.31	%
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	10	10.75	36	29.50	%
VCT_EXH_DC1	PID	0.00	0.00	43.28	43.93	%
VCT_INT_DC1	PID	0	0	0	0	%
VCT_INTK_DSD	PID	0	0	0	0	DEG
WGATE_PRES	PID	98.9/14.35	64.4/9.35	65.9/9.57	54.4/7.90	KPa/PSI
WGATE_V	PID	4.26	2.88	2.95	2.53	VOLTS
WGATE_VAC_DSD	PID	33.4/4.85	33.4/4.85	32.4/4.71	41.9/6.09	KPa/PSI
WGATE_VAC_INF	PID	0.0/0.00	34.4/5.00	32.9/4.78	43.9/6.38	KPa/PSI

ACTUATORS/OUTPUTS - 2.0L 4V EXPLORER

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B7/B31/E15/E18	5	5	5	5	VOLTS
VPWR	B5/B6	12.52	13-14	13-14	13-14	VOLTS

OTHER - 2.0L 4V EXPLORER

3.5L 4V Explorer

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
APP1	B28	0.76/15.29	0.76/15.29	0.76/14.90	1.18/23.52	VOLTS/%
APP2	B29	0.37/7.45	0.37/7.45	0.59/11.76	0.49/9.80	VOLTS/%
ACP_PRESS	B31	118.32	209.67	95.70	133.98	PSI
FPM	B32	58.72	58.72	58.72	59.37	%
MAF	B40	0/0	0.73/5	1.38/22.14	1.67/127.47	VOLTS/g/s
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	1.16/66 (150.8)	1.82/48 (118.4)	2.36/37 (98.6)	2.41/37 (98.6)	VOLTS/DEG C (DEG F)
FTP	B65	2.62/0	2.21/-0.10	2.67/0.01	2.38/-0.06	VOLTS/PSI
FTP_H2O	B65	0	2.862	0.343	1.724	In-H 2 O
VCT_EXH_ACT2	E18	0	0.31	22	11.31	DEG
AAT	E29	25 (77)	25.6 (78)	29.1 (84.4)	33 (91.4)	DEG C (DEG F)
AAT_V	E29	1.35	2.64	2.53	2.30	VOLTS
CHT	E39	0.79/81.7 (179)	0.77/81 (177.8)	0.64/88 (190.4)	0.67/86 (186.8)	VOLTS/DEG C (DEG F)
KNOCK_1	E43	65535	214	284	419	N/A
VCT_EXH_ACT1	E52	0	0.18	51.06	21.93	DEG
KNOCK_2	E60	65535	188	205	270	N/A
VCT_INT_ACT1	E67	0	0	17.00	11.50	DEG
VCT_INT_ACT2	E68	0	0.43	18.56	11.12	DEG
O2S12	T29	(I)	(D)	(D)	(D)	VOLTS
O2S22	T40	(I)	(D)	(D)	(D)	VOLTS
APP	PID	0	0	0	13	%
BARO	PID	14.64/101/157.87	14.64/101/157.87	14.64/101/157.87	14.50/100/157.02	PSI/kPa/Hz
BRKOVR_ACTION	PID	2	2	2	2	NUMERIC VALUE
BRKOVRD_POSS	PID	131	131	132	132	NUMERIC VALUE
B+	PID	VBAT	VBAT	VBAT	VBAT	VOLTS
DECHOKE	PID	YES	NO	NO	NO	YES/NO
DIST_BRKOVRD	PID	812.97 (505.16)	812.97 (505.16)	812.97 (505.16)	813.97 (505.78)	Km (Miles)
EONV_RDY	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	5	6	GEAR
LOAD	PID	(I)	43.52	37.64	91.37	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	YES	YES	YES	YES/NO
OTS_STAT	PID	ENABLE	ENABLE	ENABLE	ENABLE	ENABLE/DISABLE
O2S11_CUR	PID	(I)	Switching	Switching	Switching	MA/uA
O2S11_IMPED	PID	5	0.09	0.09	0.09	VOLTS
O2S21_CUR	PID	(I)	Switching	Switching	Switching	MA/uA
O2S21_IMPED	PID	5	0.09	0.09	0.09	VOLTS
O2S11_READY	PID	NO	YES	YES	YES	YES/NO
O2S21_READY	PID	NO	YES	YES	YES	YES/NO
RPM	PID	0	601.50	1298.00	1569.50	RPM
SYNC	PID	NO	YES	YES	YES	YES/NO
VCT_EXH_DIF1	PID	0	0	1.81	2.31	DEG
VCT_EXH_DIF2	PID	0	0.31	3.00	1.93	DEG
VCT_EXH_DSD	PID	0	0	25.06	13.26	DEG
VCT_INT_DIF1	PID	0	0.06	0.50	0.87	DEG
VCT_INT_DIF2	PID	0	0.37	0.06	0.43	DEG
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 3.5L 4V EXPLORER

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
FP	B32	75/OFF	38.54/ON	37.40/ON	37.38/ON	%/ON/OFF
EVAPCP	E32	0	73.81	48.23	15.83	%
O2S11_HTR	E69	23.13	36.07	30.58	21.56	%
HTR11	E69	OFF	ON	ON	ON	ON/OFF
O2S21_HTR	E70	23.13	34.51	32.94	25.49	%
HTR21	E70	OFF	ON	ON	ON	ON/OFF
HTR22	T48	OFF	ON	ON	ON	ON/OFF
HTR12	T49	OFF	ON	ON	ON	ON/OFF
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
FANDC	PID	0	39.32	42.57	12.59	%
FAN_DSD	PID	0	39.32	42.35	12.54	%
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
O2SHTR_EVAL	PID	YES	YES	YES	YES	YES/NO
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/DISABLED
SHRTFT1	PID	0	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	0	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	10	11.75	31.50	16.25	DEG
VCT_EXH_DC1	PID	0	0	79.99	47.43	%
VCT_EXH_DC2	PID	0	0	51.58	44.93	DEG
VCT_INT_DC1	PID	0	0	37.12	41.55	DEG
VCT_INT_DC2	PID	0	0	43.43	44.88	%
VCT_INTK_DSD	PID	0	0	13.75	10.00	DEG

ACTUATORS/OUTPUTS - 3.5L 4V EXPLORER

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52	5	5	5	5	VOLTS
VPWR	B67/B68	VBAT	VBAT	VBAT	VBAT	VOLTS

OTHER - 3.5L 4V EXPLORER

3.5L 4V F-150

198-Pin PCM

Scheme 116

Scheme 116: 3.5L 4V F-150

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FPM	B27	60.39	60.39	59.40	59.40	%
CAC_T	B32	51 (123.8)	25 (77.0)	14 (57.2)	14 (57.2)	DEG C (DEG F)
CAC_V	B32	1.72	3.02	3.52	3.55	VOLTS
APP2	B54	0.40/7.84	0.40/7.84	0.56/10.98	0.58/11.37	VOLTS/%
APP1	B55	0.80/16.7	0.80/16.7	1.11/9.0	1.15/11.0	VOLTS/%
O2S12	B57	(I)	(D)	(D)	(D)	VOLTS
TIP_PRS_BOOST	B74	99.3/14.41	99.5/14.44	100.2/14.54	115.6/16.77	KPa/PSI
TIP_PRES_V	B74	1.56	1.56	1.56	1.79	VOLTS
IAT	B75	1.61/53 (127.4)	3.35/17 (62.6)	3.71/10 (51.8)	3.69/10 (51.8)	VOLTS/DEG C (DEG F)
VCT_EXH_ACT2	E17	0	0.06	46.00	42.06	DEG
VCT_INT_ACT1	E1	0	0.18	0.56	0.81	DEG
VCT_INT_ACT2	E18	0	0.12	0.25	0.31	DEG
VCT_EXH_ACT1	E29	0	0.06	48.25	41.93	DEG
CHT	E36	3.27/89 (192.2)	3.18/92 (197.6)	3.48/80 (176.0)	2.96/91 (195.8)	VOLTS/DEG C (DEG F)
O2S11_CUR	E62	(I)	Switching (C)	Switching (C)	Switching (C)	UA
FTP	E73	2.63/0	2.66/0	2.63/0	2.37/-0.06	VOLTS/PSI
APP	PID	0	0	4.5	13	%
B+	PID	VBAT	VBAT	VBAT	VBAT	VOLTS
BARO	PID	3.97	3.93	3.93	3.93	VOLTS
BOO1	PID	OFF	OFF	OFF	OFF	ON/OFF
BOO2	PID	OFF	OFF	OFF	OFF	ON/OFF
BRKOVRD_POSS	PID	45	45	45	45	NUMERIC VALUE
BRKOVR_ACTION	PID	0	0	0	0	NUMERIC VALUE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
DIST_BRKOVRD	PID	391.3 (243.16)	391.3 (243.16)	361.3 (224.53)	362.8 (225.46)	Km (Miles)
EQ_RAT11	PID	0	14.56	14.37	14.88	RATIO
EQ_RAT21	PID	0	14.83	14.84	14.61	RATIO
ETC_TRIM	PID	0.18 (J)	0.13 (J)	0.17 (J)	0.17 (J)	DEG
FLI	PID	93.72 (H)	93.72 (H)	92.54 (H)	93.72 (H)	%
INJPWR_M	PID	0	0	0	0	VOLTS
LOAD	PID	(I)	33.33	32.94	56.86	%
MIL_DIS	PID	0	0	0	0	Miles
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	YES	YES	YES	YES/NO
O2S11_IMPED	PID	4.93	1	1	1	VOLTS
O2S21_IMPED	PID	4.93	1	1	1	VOLTS
RPM	PID	0	653	1260	1357	RPM
STRT_RLY	PID	DISABLED	DISABLED	DISABLED	DISABLED	ENABLED/DISABLED
SYNC	PID	NO	YES	YES	YES	YES/NO
VCT_EXH_DIF1	PID	0	0.06	9.68	0.50	DEG
VCT_EXH_DIF2	PID	0	0.06	7.37	0.31	DEG
VCT_EXH_DSD	PID	0	0	38.56	42.43	DEG
VCT_INT_DIF1	PID	0	0.12	0.37	0.68	DEG
VCT_INT_DIF2	PID	0	0	0.25	0.37	DEG
TFT	PID	86 (186.8)	86 (186.8)	80 (176)	80 (176)	DEG C (DEG F)
TFTV	PID	0.71	0.69	0.80	0.79	VOLTS
TIP_PRS_DSD	PID	99.8/14.48	99.8/14.48	99.6/14.46	114.1/16.56	KPa/PSI
TR	PID	PARK	PARK	DRIVE	DRIVE	POSITION
TSS_SRC	PID	0	660.75	1146.50	1349.50	RPM
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 3.5L 4V F-150

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
HTR12	B1	OFF	ON	ON	ON	ON/OFF
HTRCM12	B1	0	609	854	854	A/mA
EVAPCP	B22	0	11.79	67.58	59.08	%
FP	B39	75	27.93	28.01	28.07	%
HTR22	B61	OFF	ON	ON	ON	ON/OFF
O2S11_HTR	E15	0	1.00	36.86	33.33	%
TURBO_WGATE	E16	0	0	0	6.75	%
CAT_EVAL	PID	YES	YES	NO	NO	YES/NO
CLRDIST	PID	19.88	19.88	1.24	2.48	MILES
EGR_EVAL	PID	YES	YES	NO	NO	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPCV	PID	OFF	OFF	OFF	OFF	%/ON/OFF
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FTP_H20	PID	0.103	0.275	0.103	1.689	In-H 2 O
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
F_VCV	PID	0	4.94	14.18	16.01	%-VARYING
HFC	PID	OFF	OFF	OFF	OFF	%
LFC	PID	OFF	OFF	OFF	OFF	%
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
O2S_EVAL	PID	YES	YES	YES	NO	YES/NO
O2SHTR_EVAL	PID	YES	YES	YES	NO	YES/NO
RPMDSD	PID	875	655	580	634	RPM
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	10.00	3.00	36.25	22.25	DEG
TURBO_BPASS	PID	OFF	OFF	OFF	OFF	ON/OFF
TURBO_BPASS_2	PID	OFF	OFF	OFF	OFF	ON/OFF
VCT_EXH_DC1	PID	0	0	29.80	43.79	%
VCT_EXH_DC2	PID	0	0	31.35	43.11	%
VCT_INT_DC1	PID	0	0	0.56	0.81	%
VCT_INT_DC2	PID	0	0	0.25	0.31	%
VCT_INTK_DSD	PID	0	0	0.25	0.31	DEG

ACTUATORS/OUTPUTS - 3.5L 4V F-150

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B101/B102/B103	VBAT	VBAT	VBAT	VBAT	VOLTS
VREF	B11/B52/E8	5	5	5	5	VOLTS

OTHER - 3.5L 4V F-150

3.7L 4V F-150

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
AAT	B17	39 (102.2)	28 (82.4)	24 (75.2)	25 (77.5)	DEG C (DEG F)
AAT_V	B17	1.97	2.57	1.65	1.52	VOLTS
APP1	B28	0.77/15.29	0.77/15.29	0.98/23.92	0.83/21.56	VOLTS/%
APP2	B29	0.38/7.45	0.38/7.45	0.61/12.15	0.55/10.98	VOLTS/%
ACP_PRESS	B31	141.23	111.65	155.15	138.91	PSI
FPM	B32	59.67	59.67	60.31	60.31	%
MAF	B40	0.07	3.33	15.89	27.53	VOLTS
MAF_HZ	B40	711	1.73	3.30	4.11	KHz
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	1.59/53 (127.4)	2.52/34 (93.2)	2.90/26 (78.8)	2.91/26 (78.8)	VOLTS/DEG C (DEG F)
FTP	B65	2.63	2.50	2.41	2.44	VOLTS
FTP_H2O	B65	0.68	0.86	1.44	1.24	In-H 2 O
VCT_EXH_ACT2	E18	0	0.31	0.43	27	DEG
CHT	E39	3.48/98 (208.4)	3.51/97 (206.6)	0.65/87 (188.6)	0.65/85 (185)	VOLTS/DEG C (DEG F)
KNOCK_1	E43	208	222	179	283	N/A
VCT_EXH_ACT1	E52	0	0.06	0.31	31.06	DEG
KNOCK_2	E60	224	211	279	293	N/A
VCT_INT_ACT1	E67	0	0.18	10.25	9.75	DEG
VCT_INT_ACT2	E68	0	0.25	10.43	9.62	DEG
O2S12	T29	(I)	(D)	(D)	(D)	VOLTS
O2S22	T40	(I)	(D)	(D)	(D)	VOLTS
APP	PID	0	0	7	2.5	%
BARO	PID	14.5/401.46	14.5/401.46	13.19/365.33	13.19/365.33	PSI/in-H 2 O
BRKOVRD_POSS	PID	2	2	2	2	NUMERIC VALUE
BRKOVR_ACTION	PID	0	0	0	0	NUMERIC VALUE
B+	PID	VBAT	VBAT	VBAT	VBAT	VOLTS
DECHOKE	PID	YES	NO	NO	NO	YES/NO
DIST_BRKOVRD	PID	30.97 (19.25)	30.97 (19.25)	0.49 (0.31)	0.99 (0.62)	Km (Miles)
EONV_RDY	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	5	6	GEAR
LOAD	PID	(I)	31.37	38.82	48.62	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	YES	YES	YES	YES/NO
OTS_STAT	PID	ENABLE	ENABLE	ENABLE	ENABLE	ENABLE/DISABLE
O2S11_CUR	PID	(I)	Switching	Switching	Switching	MA/uA
O2S11_IMPED	PID	5	0.09	0.09	0.09	VOLTS
O2S21_CUR	PID	(I)	Switching	Switching	Switching	MA/uA
O2S21_IMPED	PID	5	0.09	0.09	0.09	VOLTS
O2S11_READY	PID	NO	YES	YES	YES	YES/NO
O2S21_READY	PID	NO	YES	YES	YES	YES/NO
RPM	PID	0	649.75	1095	1603.25	RPM
SYNC	PID	NO	YES	YES	YES	YES/NO
VCT_EXH_DIF1	PID	0	0.12	1.31	0.50	DEG
VCT_EXH_DIF2	PID	0	0.18	1.75	0.81	DEG
VCT_EXH_DSD	PID	0	0	48.81	49.62	DEG
VCT_INT_DIF1	PID	0	0.18	0	0.62	DEG
VCT_INT_DIF2	PID	0	0.25	0.06	0.56	DEG
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 3.7L 4V F-150

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
FP	B32	75/OFF	31.27/ON	31.01/ON	31.51/ON	%/ON/OFF
EVAPCP	E32	0	35.35	43.33	14.7	%
O2S11_HTR	E69	21.56	35.29	35.68	30.98	%
HTR11	E69	OFF	ON	ON	ON	ON/OFF
O2S21_HTR	E70	21.56	34.51	32.15	28.23	%
HTR21	E70	OFF	ON	ON	ON	ON/OFF
HTR22	T48	OFF	ON	ON	ON	ON/OFF
HTR12	T49	OFF	ON	ON	ON	ON/OFF
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
HFC	PID	OFF	ON (B)	OFF	OFF	ON/OFF
LFC	PID	OFF	ON (B)	OFF	OFF	ON/OFF
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/DISABLED
SHRTFT1	PID	0	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	0	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	17.75	9	10	26.75	DEG
VCT_EXH_DC1	PID	0	0	0	51.22	%
VCT_EXH_DC2	PID	0	0	37.45	49.57	%
VCT_INT_DC1	PID	0	0	44.42	45.31	%
VCT_INT_DC2	PID	0	0	43.94	44.08	%
VCT_INTK_DSD	PID	0	0	10.31	10.25	DEG

ACTUATORS/OUTPUTS - 3.7L 4V F-150

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52	5	5	5	5	VOLTS
VPWR	B67/B68	VBAT	VBAT	VBAT	VBAT	VOLTS

OTHER - 3.7L 4V F-150

5.0L 4V F-150

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
AAT_V	B17	1.82	2.49	2.59	2.57	VOLTS
APP1	B28	0.79/15.68	0.80/15.68	0.96/19.21	1.11/21.96	VOLTS/%
APP2	B29	0.40/7.84	0.41/7.84	0.42/8.23	0.55/10.98	VOLTS/%
ACP_PRESS	B31	143.84	256.07	104.11	104.11	PSI
FPM	B32	59.71	59.71	60.31	59.67	%
MAF	B40	0	5.18	21.86	14.54	G/s
MAF_HZ	B40	0.70	2.11	3.70	3.22	KHz
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	1.39/58 (136.4)	2.19/40 (104)	2.76/28 (82.4)	2.78/28 (82.4)	VOLTS/DEG C (DEG F)
FTP	B65	2.63/0	2.53/-0.02	2.56/0.01	2.28/-0.08	VOLTS/PSI
FTP_H2O	B65	0	0.655	0.413	2.415	In-H 2 O
VCT_INT_ACT1	E2	0	0.18	0.31	0.43	DEG
KNOCK_1	E7	0	160	262	220	N/A
VCT_INT_ACT2	E16	0	0.12	0.18	0.12	DEG
CHT	E30	3.37/101 (213.8)	3.27/104 (219.2)	3.27/104 (219.2)	3.22/106 (222.8)	VOLTS/DEG C (DEG F)
KNOCK_2	E45	0	130	242	237	N/A
VCT_EXH_ACT1	E56	0	0.06	0.06	33.25	DEG
VCT_EXH_ACT2	E57	0	0.18	0.18	33.25	DEG
O2S12	T18	(I)	(D)	(D)	(D)	VOLTS
O2S22	T27	(I)	(D)	(D)	(D)	VOLTS
APP	PID	0	0	5	10	%
BARO	PID	14.35/156.11/397.44	14.35/156.11/397.44	14.50/157.02/401.46	14.35/156.11/397.44	PSI/Hz/in-H 2 O
BRKOVRD_POSS	PID	88	88	83	84	NUMERIC VALUE
BRKOVR_ACTION	PID	1	1	0	0	NUMERIC VALUE
B+	PID	VBAT	VBAT	VBAT	VBAT	VOLTS
DECHOKE	PID	YES	NO	NO	NO	YES/NO
DIST_BRKOVRD	PID	32.97 (20.49)	32.97 (20.49)	1594 (990.99)	1598 (993.47)	Km (Miles)
EONV_RDY	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
ETC_TRIM	PID	0.12 (J)	0.13 (J)	0.15 (J)	0.16 (J)	DEG
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	5	6	GEAR
LOAD	PID	(I)	25.88	85.49	39.21	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	YES	YES	YES	YES/NO
OTS_STAT	PID	ENABLE	ENABLE	ENABLE	ENABLE	ENABLE/DISABLE
O2S11_CUR	PID	(I)	Switching	Switching	Switching	MA/uA
O2S11_IMPED	PID	4.99	0.97	0.97	0.97	VOLTS
O2S21_CUR	PID	(I)	Switching	Switching	Switching	MA/uA
O2S21_IMPED	PID	4.97	0.98	0.98	0.97	VOLTS
O2S11_READY	PID	NO	YES	YES	YES	YES/NO
O2S21_READY	PID	NO	YES	YES	YES	YES/NO
RPM	PID	0	599.50	1759.75	1428.75	RPM
SYNC	PID	NO	YES	YES	YES	YES/NO
VCT_EXH_DIF1	PID	0	0	4	3.87	DEG
VCT_EXH_DIF2	PID	0	0	4	1.43	DEG
VCT_EXH_DSD	PID	0	0	13.81	22.12	DEG
VCT_INT_DIF1	PID	0	0.12	0	0	DEG
VCT_INT_DIF2	PID	0	0.06	0	0	DEG
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 5.0L 4V F-150

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
FP	B32	75/OFF	38.54/ON	37.40/ON	37.38/ON	%/ON/OFF
EVAPCP	E49	0	28.00	75.89	53.64	%
HTR11	T24	OFF	ON	ON	ON	ON/OFF
O2S11_HTR	T24	23.13	45.88	43.13	31.37	%
HTR21	T35	OFF	ON	ON	ON	ON/OFF
O2S21_HTR	T35	23.13	44.70	36.47	35.29	%
HTR12	T47	OFF	ON	ON	ON	ON/OFF
HTR22	T49	OFF	ON	ON	ON	ON/OFF
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
HFC	PID	OFF	ON (B)	OFF	OFF	ON/OFF
LFC	PID	OFF	ON (B)	OFF	OFF	ON/OFF
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
O2SHTR_EVAL	PID	YES	YES	YES	YES	YES/NO
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/DISABLED
SHRTFT1	PID	0	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	0	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	25	16.25	44.25	34.50	DEG
VCT_EXH_DC1	PID	0	0	55.46	50.80	%
VCT_EXH_DC2	PID	0	0	55.04	51.69	DEG
VCT_INT_DC1	PID	0	0	0	0	DEG
VCT_INT_DC2	PID	0	0	0	0	%
VCT_INTK_DSD	PID	0	0	0	0	DEG

ACTUATORS/OUTPUTS - 5.0L 4V F-150

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52	5	5	5	5	VOLTS
VPWR	B67/B68	VBAT	VBAT	VBAT	VBAT	VOLTS

OTHER - 5.0L 4V F-150

6.2L 4V F-150

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
APP1	B28	0.78/15.29	0.77/15.29	1.04/20.78	1.05/20.78	VOLTS/%
APP2	B29	0.38/7.45	0.39/7.45	0.40/7.84	0.57/11.37	VOLTS/%
ACP_PRESS	B31	163.27	182.99	192.27	178.93	PSI
FPM	B32	59.61	59.71	60.41	59.71	%
MAF	B40	0.23	7.00	10.32	37.52	G/s
MAF_HZ	B40	0.71	2.41	2.81	4.69	KHz
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	1.18/65 (149)	1.76/49 (120.2)	2.63/32 (89.6)	2.64/31 (87.8)	VOLTS/DEG C (DEG F)
FTP	B65	2.62/0	2.14/-0.12	2.52/-0.02	1.66/-0.24	VOLTS/PSI
FTP_H2O	B65	0.035	3.413	0.724	6.759	In-H 2 O
KNOCK_1	E7	0	591	1188	1198	N/A
CHT	E30	3.54/96 (204.8)	3.51/96 (204.8)	3.50/97 (206.6)	3.45/98 (208.4)	VOLTS/DEG C (DEG F)
KNOCK_2	E45	0	616	968	875	N/A
O2S12	T18	(I)	(D)	(D)	(D)	VOLTS
O2S22	T27	(I)	(D)	(D)	(D)	VOLTS
APP	PID	0	0	8	8.5	%
BARO	PID	13.92/153.36/385.40	13.92/153.36/385.40	13.77/152.45/381.39	14.06/154.28/389.41	PSI/Hz/in-H 2 O
BRKOVRD_POSS	PID	45	45	45	45	NUMERIC VALUE
BRKOVR_ACTION	PID	0	0	0	0	NUMERIC VALUE
B+	PID	VBAT	VBAT	VBAT	VBAT	VOLTS
DECHOKE	PID	YES	NO	NO	NO	YES/NO
DIST_BRKOVRD	PID	541.76 (336.64)	541.76 (336.64)	504.78 (313.66)	506.78 (314.90)	Km (Miles)
EONV_RDY	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
ETC_TRIM	PID	0.17 (J)	0.24 (J)	0.30 (J)	0.30 (J)	DEG
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	4	5	GEAR
LOAD	PID	(I)	29.41	72.54	85.09	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	YES	YES	YES	YES/NO
OTS_STAT	PID	ENABLE	ENABLE	ENABLE	ENABLE	ENABLE/DISABLE
O2S11_CUR	PID	(I)	Switching	Switching	Switching	MA/uA
O2S11_IMPED	PID	4.99	0.97	0.97	0.98	VOLTS
O2S21_CUR	PID	(I)	Switching	Switching	Switching	MA/uA
O2S21_IMPED	PID	4.97	0.98	0.98	0.97	VOLTS
O2S11_READY	PID	NO	YES	YES	YES	YES/NO
O2S21_READY	PID	NO	YES	YES	YES	YES/NO
PSP	PID	OFF	OFF	OFF	OFF	ON/OFF
RPM	PID	0	605.75	1406.50	1454.75	RPM
SYNC	PID	NO	YES	YES	YES	YES/NO
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 6.2L 4V F-150

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
EVAPCV	B20	0/OFF	0/OFF	0/OFF	100/OFF	%/ON/OFF
VCTDC	E2	0	0	0	0	%
VCTDC2	E16	0	0	0	0	%
FP	B32	75/OFF	83.52/ON	34.58/ON	34.48/ON	%/ON/OFF
EVAPCP	E49	0	24.33	4.10	6.42	%
HTR11	T24	OFF	ON	ON	ON	ON/OFF
O2S11_HTR	T24	21.17	37.25	32.94	29.80	%
HTR12	T47	OFF	ON	ON	ON	ON/OFF
O2S21_HTR	T47	21.17	39.21	32.54	29.80	%
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
O2SHTR_EVAL	PID	NO	NO	NO	NO	YES/NO
O2S_EVAL	PID	YES	YES	NO	NO	YES/NO
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/DISABLED
SHRTFT1	PID	0	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	0	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	35.25	10.50	44.25	38.25	DEG
VCTADV	PID	0	0.12	0.18	0.12	DEG
VCTADV2	PID	0	0.12	0.12	0.18	DEG
VCTADVERR	PID	0	0.12	0.18	0.12	DEG
VCTADVERR2	PID	0	0.12	0.06	0.12	DEG
VCT_DSD	PID	0	0	0.06	0	DEG

ACTUATORS/OUTPUTS - 6.2L 4V F-150

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52	5	5	5	5	VOLTS
VPWR	B67/B68	VBAT	VBAT	VBAT	VBAT	VOLTS

OTHER - 6.2L 4V F-150

4.6L 2V E-Series

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
GENMON	B14	0	30.45	21.87	19.53	%
APP1	B28	0.79	0.79	1.44	1.89	VOLTS
APP2	B29	0.39	0.39	0.72	0.94	VOLTS
FPM	B32	60.3	60.33	60.24	59.66	%
MAF	B40	0.01	0.61	1.7	2.42	VOLTS
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	2.55/33 (91.4)	3.28/19 (66.2)	4.22/-3 (26.6)	4.26/-4 (24.8)	VOLTS/DEG C (DEG F)
FTP	B65	2.62/0	2.62/0	1.66/-0.24	2.62/0	VOLTS/PSI
CHT	E15	0.65/87 (188.6)	0.78/81 (177.8)	0.64/88 (190.4)	0.69/85 (185)	VOLTS/DEG C (DEG F)
MAP	E40	4.3/100.93/14.64/29.8	1.2/31.99/4.64/9.44	2.7/64.94/9.42/19.17	3.39/78.94/11.45/23.31	VOLTS/kPa/PSI/inHg
KNOCK_1	E46	259	260	953	867	N/A
DPFEGR	E48	0.25-1.3	0.25-1.3	0.25-4.65	0.25-4.65	VOLTS
HTRCM11	E69	0	1.8	1.71	1.74	AMPS
OSS_SRC	T2	0	0	1415	2623	RPM
O2S12	T16	(I)	(D)	(D)	(D)	VOLTS
HTRCM12	T18	0 (A)	1.15 (A)	979 (mA)	983 (mA)	MA/A
TFT	T19	40 (104)	41 (105.8)	38 (100.4)	44 (111.2)	DEG C (DEG F)
TFTV	T19	2.22	2.19	2.32	2.03	VOLTS
O2S22	T20	(I)	(D)	(D)	(D)	VOLTS
TR	T26	PARK	PARK	OVERDRIVE	OVERDRIVE	MODE
TR2	T27	CLOSED	CLOSED	OPEN	OPEN	OPEN/CLOSED
TSS_SRC	T37	0	604.5	595.8	1813	RPM
APP	PID	0	0	20.5	34.5	%
BARO	PID	14.36/156.6	14.36/156.6	14.36/156.6	14.36/156.6	PSI/Hz
B+	PID	12.9	13-14	13-14	13-14	VOLTS
DECHOKE	PID	NO	NO	NO	NO	YES/NO
ETC_TRIM	PID	0.12 (J)	0.12 (J)	0.04 (J)	0.13 (J)	DEG
FLI	PID	9.8 (H)	10.2(H)	7.84 (H)	10.98 (H)	%
GEAR	PID	1	1	4	4	GEAR
LOAD	PID	0 (I)	20.78	20	79.61	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2S11_CUR	PID	(I)	Switching	Switching	Switching	MA/uA
O2S11_IMPED	PID	4.96	1	0.95	0.93	VOLTS
O2S21_CUR	PID	(I)	Switching	Switching	Switching	MA/uA
O2S21_IMPED	PID	4.96	1.02	1.02	0.94	VOLTS
RPM	PID	0	626	937	1771	RPM
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 4.6L 2V E-SERIES

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
PCVHC	E6	0	0	100	100	%
EGRPCT	E21	0	0	36.86	66.67	%
HTR11	E69	OFF	ON	ON	ON	ON/OFF
HTR12	T18	OFF	ON	ON	ON	ON/OFF
TCC	T22	0	0	0	100	%
EGR_EVAL	PID	YES	YES	NO	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	NO	NO	YES	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
OTS_STAT	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/DISABLED
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/DISABLED
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	7.25	12.75	34.25	29.75	DEG

ACTUATORS/OUTPUTS - 4.6L 2V E-SERIES

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52/E63/T10	5	5	5	5	VOLTS
VPWR	B30/B67/B68	12.44	13-14	13-14	13-14	VOLTS

OTHER - 4.6L 2V E-SERIES

5.4L 2V E-Series

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PTO (5R110W)	B3	OFF	OFF	OFF	OFF	ON/OFF
PTOLOAD	B6	NO	NO	NO	NO	YES/NO
PTOIR_V (5R110W)	B8	0	0	0	0	VOLTS
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
GENMON	B14	0	52.95	30.3	33.43	%
APP1	B28	0.78	0.78	1.33	1.62	VOLTS
APP2	B29	0.39	0.39	0.67	0.81	VOLTS
FPM	B32	59.7	60.3	60.33	59.66	%
MAF	B40	0	0.71	1.49	1.58	VOLTS
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	1.9/46 (114.8)	2.51/34 (93.2)	3.91/5 (41)	4/2 (35.6)	VOLTS/DEG C (DEG F)
FTP	B65	2.6/0	2.6/0	2.1/-0.13	1.95/-0.17	VOLTS/PSI
FTP_H2O	B65	0.06	0.75	0.03	0.13	In-H 2 O
CHT	E15	0.61/88.8 (192)	0.67/88 (190.4)	0.91/75 (167)	0.65/87 (188.6)	VOLTS/DEG C (DEG F)
KNOCK 1	E46	41	41	61	91	N/A
HTRCM11	E69	0	1.7	1.7	1.7	AMPS
OSS_SRC	T2	0	0	1298	2359	RPM
O2S12	T16	(I)	(D)	(D)	(D)	VOLTS
HTRCM12	T18	0	1.26	1.33	1.33	AMPS
O2S22	T20	(I)	(D)	(D)	(D)	VOLTS
APP	PID	0	0	17	26	%
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.21/155.2	PSI/Hz
B+	PID	12.52	13-14	13-14	13-14	VOLTS
DECHOKE	PID	NO	NO	NO	NO	YES/NO
ETC_TRIM	PID	0.33 (J)	0.35 (J)	0.3 (J)	0.3 (J)	DEG
FLI	PID	9.41 (H)	9.41 (H)	6.27 (H)	6.66 (H)	%
GEAR (4R75E)	PID	1	1	4	4	GEAR
GEAR (5R110W)	PID	1	1	5	6	GEAR
LOAD	PID	0 (I)	24.71	34.9	52.16	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2S11_CUR	PID	(I)	Switching	Switching	Switching	MA/uA
O2S11_IMPED	PID	4.96	1.02	1.07	1.03	VOLTS
O2S21_CUR	PID	(I)	Switching	Switching	Switching	MA/uA
O2S21_IMPED	PID	4.97	1.02	0.97	0.99	VOLTS
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/DISABLED
RPM	PID	0	720	1100	1600	RPM
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 5.4L 2V E-SERIES

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PTOIL	B11	OFF	OFF	OFF	OFF	ON/OFF
FP	B19	75/OFF	20/ON	20/ON	23/ON	%/ON/OFF
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
EVAPCP	E31	0	39.61	0	0	%
HTR11	E69	OFF	ON	ON	ON	ON/OFF
HTR12	T18	OFF	ON	ON	ON	ON/OFF
TCC (4R75E)	T22	0/OFF	0/OFF	0/OFF	39.29/ENGAGED	%/OFF- ENGAGED
HTR22	T48	ON	ON	ON	ON	ON/OFF
TSPC (5R110W)	T50	VBAT	VBAT	VBAT	VBAT	VOLTS
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/DISABLED
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	27.5	11	22.75	8.75	DEG

ACTUATORS/OUTPUTS - 5.4L 2V E-SERIES

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B30/B67/B68	12-13	13-14	13-14	13-14	VOLTS
VREF	B52/E63/T10	5	5	5	5	VOLTS

OTHER - 5.4L 2V E-SERIES

Scheme 117

Scheme 117: 6.8L 2V E-Series

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0	1.77/0	1.6/0	2.18/-0.11	VOLTS/PSI
FTP_H2O	B3	0	6	7.2	3.1	In-H 2 O
APP1	B5	4.09	4.09	4.07	3.83	VOLTS
PTOIR_V	B7	0	0	0	0	VOLTS
BOO1	B8	OFF	ON (E)	OFF	OFF	ON/OFF
PTOLOAD	B9	NO	NO	NO	NO	YES/NO
APP2	B17	1.44	1.44	1.46	1.64	VOLTS
PTO	B26	OFF	OFF	OFF	OFF	ON/OFF
APP3	B28	0.9	0.9	0.91	1.2	VOLTS
GENMON	E6	0	39.43	22.27	19.13	%
IAT	E22	2.2/40 (104)	2.62/31.6 (89)	3.16/21 (69.8)	3.12/22 (71.6)	VOLTS/DEG C (DEG F)
MAF	E25	0	0.75	1.56	1.8	VOLTS
O2S11	E28	(I)	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
O2S21	E29	(I)	Switching (C)	Switching (C)	Switching (C)	VOLTS/RICH-LEAN
CHT	E41	0.7/86 (186.8)	0.7/84 (183.2)	0.7/89 (192.2)	0.68/86 (186.8)	VOLTS/DEG C (DEG F)
BOO2	E65	OFF	ON (E)	OFF	OFF	ON/OFF
HTRCM11	E69	0	0	0	479	MA
OSS_SRC	T3	0	0	1317	2261	RPM
TSS_SRC	T15	0	588.5	824	1618	RPM
O2S12	T24	(I)	(D)	(D)	(D)	VOLTS
O2S22	T25	(I)	(D)	(D)	(D)	VOLTS
TFT	T29	40.5 (105)	38.8 (102)	61.6 (143)	73.8 (165)	DEG C (DEG F)
TFT_V	T29	2.2	2.27	1.32	0.97	VOLTS
HTRCM12	T47	0	0	0	916	MA
ACC_CMD	PID	OFF	ON (A)	OFF	OFF	ON/OFF
APP	PID	0	0	0.5	12.5	%
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.3/156.2	PSI/Hz
B+	PID	12.54	13-14	13-14	13-14	VOLTS
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_TRIM	PID	0.03 (J)	0.04 (J)	0.03 (J)	0.07 (J)	DEG
GEAR	PID	1	1	6	6	GEAR
LOAD	PID	0 (I)	26	44	51	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	670	1290	1659	RPM
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 6.8L 2V E-SERIES

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
EVAPCV	B13	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
PTOIL	B42	OFF	OFF	OFF	OFF	ON/OFF
TCIL	B43	OFF	OFF	OFF	OFF	ON/OFF
EVAPCP	E1	0	93.73	97.26	0	%
PCVHC	E2	0	0	0	0	%
HTR11	E69	OFF	ON	ON	ON	ON/OFF
HTR12	T47	OFF	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	NO	YES	YES	YES	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	10	13.5	33.5	26-34	DEG

ACTUATORS/OUTPUTS - 6.8L 2V E-SERIES

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	12-13	13-14	13-14	13-14	VOLTS
VREF	E57/T40	5	5	5	5	VOLTS

OTHER - 6.8L 2V E-SERIES

5.4L 3V Expedition/Navigator

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
GENMON	B14	0	42.75	23.8	19.71	%
APP1	B28	0.8	0.8	1.28	1.63	VOLTS
APP2	B29	0.41	0.41	0.64	0.82	VOLTS
ACP_PRESS	B31	1.54/73.51	1.5/70.76	1.47/69.16	1.33/62.06	VOLTS/PSI
FPM	B32	40.34	40.3	40.3	39.66	%
MAF	B40	0	0.77	1.03	1.75	VOLTS
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	2.12/42 (107.6)	2.62/32 (89.6)	3.01/24 (75.2)	3.07/23 (73.4)	VOLTS/DEG C (DEG F)
FTP	B65	2.6/0	2.6/0	1.78/-0.21	2.3/-0.08	VOLTS/PSI
FTP_H2O	B65	2.6/0	2.6/0	1.78/-0.21	2.3/-0.08	In-H 2 O
KNOCK_2	E6	240	267	206	351	N/A
KNOCK_1	E7	181	184	193	261	N/A
CHT	E30	3.6/93.8 (201)	3.5/95.5 (204)	3.37/97.7 (208)	3.5/93.8 (201)	VOLTS/DEG C (DEG F)
O2S12	T18	(I)	(D)	(D)	(D)	VOLTS
HTRCM11	T24	0	0	1.68	1.68	Amps
O2S22	T27	(I)	(D)	(D)	(D)	VOLTS
HTRCM12	T47	0	0	909	909	MA
APP	PID	0	0	14.5	26	%
B+	PID	12.65	13-14	13-14	13-14	VOLTS
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.3/156.2	PSI/Hz
DECHOKE	PID	NO	NO	NO	NO	YES/NO
ETC_TRIM	PID	0 (J)	0 (J)	0 (J)	0 (J)	DEG
FLI	PID	91.77 (H)	92.16 (H)	91.37 (H)	87.45 (H)	%
GEAR	PID	1	1	5	6	GEAR
LOAD	PID	0 (I)	22.35	41.96	60.39	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2S11_CUR	PID	(I)	Switching	Switching	Switching	MA/uA
O2S11_IMPED	PID	4.97	1.01	1.05	0.96	VOLTS
O2S21_CUR	PID	(I)	Switching	Switching	Switching	MA/uA
O2S21_IMPED	PID	4.97	1.03	0.82	1.02	VOLTS
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/DISABLED
RPM	PID	0	695	1087	1497	RPM
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 5.4L 3V EXPEDITION/NAVIGATOR

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	75/OFF	29.4/ON	28.5/ON	28.96/ON	%/ON/OFF
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
VCTDC	E2	0	0	42.26	42.56	%
VCTDC2	E16	0	0	43.77	41.35	%
EVAPCP	E49	0	32.16	0	98.82	%
HTR11	T24	OFF	ON	ON	ON	ON/OFF
HTR12	T47	OFF	ON	ON	ON	ON/OFF
CHT_F	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	NO	NO	YES	YES	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
OTS_STAT	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/SABLED
PCVHC	PID	0	0	0	0	%
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	29.5	11.25	45.25	46.75	DEG
VCTADV	PID	0	0.31	45	20.5	DEG
VCTADV2	PID	0	0.3	45.5	20.13	DEG
VCTADVERR	PID	0	0.5	0.62	0.25	DEG
VCTADVERR2	PID	0	0.62	0.31	0.62	DEG
VCT_DSD	PID	0	0	50.56	40.38	DEG

ACTUATORS/OUTPUTS - 5.4L 3V EXPEDITION/NAVIGATOR

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52	5	5	5	5	VOLTS
VPWR	B67/B68	12.77	13-14	13-14	13-14	VOLTS

OTHER - 5.4L 3V EXPEDITION/NAVIGATOR

6.2L 2V F-Series Super Duty

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FANSS	B3	6375	575	775	950	RPM
SMC_MON	B7	OFF	OFF	OFF	OFF	ON/OFF
PTOIR_V	B8	0	0	0	0	VOLTS
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
PTO	B22	OFF	OFF	OFF	OFF	ON/OFF
APP1	B28	0.84	0.82	1.45	1.36	VOLTS
APP2	B29	0.42	0.41	0.73	0.69	VOLTS
ACP_PRESS	B31	80	83	80	81	PSI
ACP_V	B31	0.8	0.86	107	1.06	VOLTS
FPM	B32	61.32	61.32	60.35	60.31	%
MAF	B40	0.29	5.23	14.28	32.09	G/s
BOO2	B46	OFF	OFF	OFF	OFF	ON/OFF
IAT	B47	1.96/43.8 (111)	2.11/40.5 (105)	2.65/28.8 (84)	3.38/13.8 (57)	VOLTS/DEG C (DEG F)
B+	B62	12.4	13-14	13-14	13-14	VOLTS
FTP	B65	2.6/0.61	2.6/0.61	2.3/0.61	1.45/0.61	VOLTS/PSI
FTP_H2O	B65	0.06	0.03	2.17	8.34	In-H 2 O
KNOCK_1	E7	0	689	749	946	N/A
CHT	E30	0.56/92 (197.6)	0.55/93 (199.4)	3.51/95.5 (204)	3.4/98.8 (210)	VOLTS/DEG C (DEG F)
KNOCK_2	E45	0	528	670	834	N/A
TSS_SRC	T1	0	619	1127	1472	RPM
O2S11_CUR	T4/T29	(I)	Switching	Switching	Switching	MA/uA
OSS_SRC	T14	0	0	1185	2042	RPM
O2S12	T18	(I)	(D)	(D)	(D)	VOLTS
CPP/PNP (M/T)	T19	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/DRIVE
TFT	T20	65.5 (150)	70 (158)	87.7 (190)	88.8 (192)	DEG C (DEG F)
TFTV	T20	1.17	1.05	0.66	0.64	VOLTS
HTRCM11	T24	0	1.66	1.66	1.49	AMPS
O2S22	T27	(I)	(D)	(D)	(D)	VOLTS
O2S21_CUR	T28/T39	(I)	Switching	Switching	Switching	MA/uA
HTRCM21	T35	0	1.09	1.66	1.5	AMPS
HTRCM12	T47	0 (AMP)	1.09 (AMP)	1.09 (AMP)	895 (mA)	MA/AMP
APP	PID	0	0	7	16.5	%
APP_MODE	PID	NO PEDAL	NO PEDAL	PART PEDAL	PART PEDAL	NO PEDAL/PART PEDAL
BARO	PID	14.79/159.3	14.79/159.3	14.73/158.9	14.86/159.7	PSI/Hz
CAT_EVAL	PID	YES	YES	YES	YES	YES/NO
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EONV_RDY	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
ETC_TRIM	PID	0.51 (J)	0.51 (J)	0.51 (J)	0.51 (J)	DEG
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
FLI	PID	89 (H)	88 (H)	85 (H)	95 (H)	%
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
GEAR	PID	1	1	5	6	GEAR
GLOAD	PID	0	21	51	87	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	NO	NO	NO	NO	YES/NO
O2S_EVAL	PID	OFF	NO	YES	YES	YES/NO
PTOLOAD	PID	OFF	OFF	OFF	OFF	OFF/ON
RPM	PID	0	598	1047	1493	RPM
VCTADVERR	PID	0	0.62	1	1.37	DEG
VCTADVERR2	PID	0	0.18	1	1.12	DEG
VCTSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/CLOSED LOOP
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 6.2L 2V F-SERIES SUPER DUTY

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PTOIL	B11	OFF	OFF	OFF	OFF	ON/OFF
FP	B19	75/OFF	35/ON	34.5/ON	34.6/ON	%/ON/OFF
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON/OFF
VCTDC	E2	0	0	39	44.46	VOLTS
VCTDC2	E16	0	0	45.92	43.12	VOLTS
EVAPCP	E49	0	24.16	98.53	98.19	%
O2S11_HTR	T24	0	41	39	37	%
TCIL	T33	OFF	OFF	OFF	OFF	ON/OFF
O2S21_HTR	T35	0	41	39	35	%
HTR11	T24	OFF	ON	ON	ON	ON/OFF
HTR12	T47	OFF	ON	ON	ON	ON/OFF
O2SHTR_EVAL	PID	NO	NO	YES	YES	YES/NO
RPMDSD	PID	602	600	525	565	RPM
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	10	15.75	40	38	DEG
TCC	PID	0	134.0	388.0	KPa
VCTADV	PID	0	0.62	52.06	50.25	DEG
VCTADV2	PID	0	0.18	52.06	49.88	DEG

ACTUATORS/OUTPUTS - 6.2L 2V F-SERIES SUPER DUTY

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52/E20/T31	5	5	5	5	VOLTS
VPWR	B67/68	VBAT	VBAT	VBAT	VBAT	VOLTS

OTHER - 6.2L 2V F-SERIES SUPER DUTY

6.8L 3V F-Series Super Duty

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PTOLOAD	B6	OFF	OFF	OFF	OFF	ON/OFF
PTOIR_V	B8	0.02	0.02	0.02	0	VOLTS
BOO1	B13	OFF	OFF	OFF	OFF	ON/OFF
PTO	B22	OFF	OFF	OFF	OFF	ON/OFF
APP1	B28	0.74	0.74	1.25	1.36	VOLTS
APP2	B29	0.36	0.37	0.63	0.68	VOLTS
FPM	B32	60.25	60.35	60.25	60.31	%
MAF	B40	0/697	8/2.52	30/4.27	58/5.46	G/s / Hz
BOO2	B46	OFF	OFF	OFF	OFF	ON/OFF
IAT	B47	2.9/22.7 (73)	3.3/15 (59)	3.7/7.2 (45)	3.7/6.1 (43)	VOLTS/DEG C (DEG F)
B+	B62	12.4	13-14	13-14	13-14	VOLTS
FTP	B65	2.6/0	2.6/0	2.3/-0.07	2.1/-0.11	VOLTS/PSI
KNOCK_1	E7	0	0	301	525	N/A
CHT	E30	0.61/89 (192.2)	0.6/90 (194)	3.58/94 (201.2)	3.56/96 (204.8)	VOLTS/DEG C (DEG F)
KNOCK_2	E45	0	0	289	448	N/A
TSS_SRC	T1	0	782	860	1623	RPM
O2S11_CUR	T4/T29	(I)	Switching	Switching	Switching	MA/uA
TFT	T20	1.6/55.5 (132)	1.5/57.7 (136)	1.1/68.8 (156)	1.1/68.8 (156)	VOLTS/DEG C (DEG F)
O2S21_CUR	T28/T39	(I)	Switching	Switching	Switching	MA/uA
O2S12	T30	(I)	(D)	(D)	(D)	VOLTS
TCS_STATE	T33	OFF	OFF	OFF	OFF	ON/OFF
APP	PID	0	0	15.5	26.5	%
BARO	PID	14.3/156.2	14.3/156.2	14.05/154.7	14.3/156.2	PSI/Hz
ETC_TRIM	PID	0.39(J)	0.43(J)	0.36(J)	0.36(J)	DEG
GEAR	PID	1	1	6	6	GEAR
LOAD	PID	0 (I)	20	41	56	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
RPM	PID	0	654	1127	1618	RPM
VSS	PID	0	0	48 km/h (30 MPH)	89 km/h (55 MPH)	Km/h / MPH

SENSORS/INPUTS - 6.8L 3V F-SERIES SUPER DUTY

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PTOIL	B11	OFF	OFF	OFF	OFF	ON/OFF
FP	B19	75	31	31	31	%
EVAPCV	B20	0	0	0	0	%
TCIL	B33	OFF	OFF	OFF	OFF	ON/OFF
CDD (CYL 10)	E1	VBAT	VBAT	VBAT	VBAT	VOLTS
IMTV	E14	0	0	0	0	%
CDJ (CYL 9)	E17	VBAT	VBAT	VBAT	VBAT	VOLTS
CDG (CYL 3)	E18	VBAT	VBAT	VBAT	VBAT	VOLTS
CDH (CYL 8)	E33	VBAT	VBAT	VBAT	VBAT	VOLTS
CDB (CYL 6)	E34	VBAT	VBAT	VBAT	VBAT	VOLTS
EVAPCP	E49	0	0	0	99.9	%
CDC (CYL 5)	E50	VBAT	VBAT	VBAT	VBAT	VOLTS
CDE (CYL 2)	E51	VBAT	VBAT	VBAT	VBAT	VOLTS
CDI (CYL 4)	E52	VBAT	VBAT	VBAT	VBAT	VOLTS
CDF (CYL 7)	E69	VBAT	VBAT	VBAT	VBAT	VOLTS
CDA (CYL 1)	E70	VBAT	VBAT	VBAT	VBAT	VOLTS
O2S11_HTR	T24	22	36	30	21	%
O2S21_HTR	T35	22	36	29	21	%
LONGFT1	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
LONGFT2	PID	(I)	20 TO +20	20 TO +20	20 TO +20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SHRTFT2	PID	(I)	10 TO +10	10 TO +10	10 TO +10	%
SPARKADV	PID	13.50	12.25	27.75	32	DEG

ACTUATORS/OUTPUTS - 6.8L 3V F-SERIES SUPER DUTY

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52/E20 T31	5	5	5	5	VOLTS
VPWR	B67/B68	VBAT	VBAT	VBAT	VBAT	VOLTS

OTHER - 6.8L 3V F-SERIES SUPER DUTY

Engine Controls - Reference Values (Except Diesel & Hybrid) (Section 6): Other Ford Explorer V
