Information System and Entertainment System - Premium Plus -- Explorer: Specifications Ford Explorer V

Entertainment Systems 2 illustrations

Torque Specifications

DescriptionPart NumberTorque
APIM screws0.6 Nm (5 lb-in)
AM/FM antenna with SDARS mounting bolt10 Nm (89 lb-in)
Audio amplifier bracket screwsW7056617 Nm (62 lb-in)
ACM screwsW7076282 Nm (18 lb-in)
Door speaker screwsW7053142 Nm (18 lb-in)
FCIM screwsW7076282 Nm (18 lb-in)
FDIM screwsW7076282 Nm (18 lb-in)

Scheme 29

Scheme 29: Component Location
Scheme 29: Component Location
ItemDescriptionComments
1RH tweeter speaker
2RF door speaker
3RH rear door speaker
4RH quarter trim panel speaker
5Audio amplifier
6LH quarter trim panel speaker
7LH rear door speaker
8LF door speaker
9LH tweeter speaker

Scheme 30

Scheme 30
Scheme 30
ItemDescriptionComments
1FCIM
2FDIM
3ACM
4USB cable
5Antenna
6Antenna cable
7GPSM
8Media hub
9Antenna cable
10APIM
