Information System and Entertainment System - Premium -- Explorer: Specifications Ford Explorer V

Entertainment Systems 2 illustrations

Torque Specifications

DescriptionPart NumberTorque
APIM screws0.6 Nm (5 lb-in)
AM/FM antenna with SDARS mounting bolt10 Nm (89 lb-in)
ACM screwsW7076282 Nm (18 lb-in)
Door speaker screwsW7053142 Nm (18 lb-in)
FCDIM screwsW7076282 Nm (18 lb-in)
FCIM screwsW7076282 Nm (18 lb-in)

Scheme 1

Scheme 1: Component Location
Scheme 1: Component Location
ItemDescriptionComments
1RH tweeter speaker
2RH front door speaker
3RH rear door speaker
4LH rear door speaker
5LH front door speaker
6LH tweeter speaker

Scheme 2

Scheme 2
Scheme 2
ItemDescriptionComments
1FCIM
2FCDIM
3ACM
4Antenna
5Antenna cable
6Audio input jack
7Antenna cable
