General Specifications
| Item | Specification |
|---|---|
| Pilot runout | 0.15 mm (0.0059 in) |
| Wheel bearing end play | 0 mm (0 in) |
| Wheel hub face runout | 0.254 mm (0.01 in) |
| Wheel hub flange bolt circle runout | 0.38 mm (0.015 in) |
| Wheel hub flange bolt runout | 0.38 mm (0.015 in) |
GENERAL SPECIFICATIONS
The driveline system consists of the following components
- Center support bearing
- Driveshaft assembly
- Front halfshafts
- Rear halfshafts
- ATC / rear axle
FWD vehicles, the transaxle transmits power from the engine to the halfshafts.
AWD vehicles, power is transmitted from the engine through the transaxle to the PTU. The PTU transfers engine power from the transaxle to the front halfshafts, and through the driveshafts to the ATC / rear axle and halfshafts. REFER to TRANSFER CASE - POWER TRANSFER UNIT (PTU) .
The engine angle is built into the engine mounts. If the engine angle is out of specification, the engine mounts must be inspected for damage.
Scheme 1
The VC label is located in the driver door jamb. The axle code is on the VC label.
The axle ratio is 2.93 and the ring gear has a diameter of 174 mm (6.8504 in).
The wheel speed sensor rings for FWD vehicles are located on the front halfshafts and are mounted to the rear inner spindles.
The wheel speed sensor rings are located on the front and rear halfshafts for AWD vehicles.
