Torque Specifications
| Description | Part Number | Torque |
|---|
| Auxiliary climate control housing bolt | W710330 | 9 Nm (80 lb-in) |
| Auxiliary climate control housing floorpan bracket nuts | N800889 | 9 Nm (80 lb-in) |
| Auxiliary evaporator outlet and inlet line fitting nuts (front and rear) | W520413 | Intaractive 15 Nm (133 lb-in) |
| Auxiliary line bracket bolts | W505427 | 5 Nm (44 lb-in) |
| Auxiliary line bracket nuts | W707137 | 5 Nm (44 lb-in) |
| TXV bolt | | 8 Nm (71 lb-in) |
| Auxiliary TXV fitting nut | W520413 | 8 Nm (71 lb-in) |
| Fuel tank strap bolt | N811781 | 35 Nm (26 lb-ft) |
Scheme 1
Scheme 1: Component Location
| Item | Description |
|---|
| 1 | Auxiliary blower motor |
| 2 | Auxiliary blower motor speed control |
| 3 | Auxiliary temperature blend door actuator |
| 4 | Auxiliary mode door actuator |
Scheme 2
| Item | Description |
|---|
| 1 | Auxiliary evaporator outlet and inlet jumper lines |
| 2 | Auxiliary TXV |
| 3 | Auxiliary evaporator core |
| 4 | Auxiliary heater core |
