REMOVAL AND INSTALLATION
- Drain the engine cooling system. For additional information, refer to «Cooling System Draining, Filling and Bleeding»(ref-270902-S23782127182007110700000) .
- Release the clamp and disconnect the upper radiator hose from the thermostat housing cover.
- Remove the bolts and the thermostat housing cover. To install, tighten to 10 N.m (89 lb-in).
- Remove the thermostat.
- To install, reverse the removal procedure.
- Drain the engine cooling system. For additional information, refer to «Cooling System Draining, Filling and Bleeding»(ref-270902-S23782127182007110700000) .
- Disconnect the engine coolant temperature (ECT) sensor electrical connector.
- Release the clamp and disconnect the upper radiator hose.
- Release the clamp and disconnect the heater hose.
- Release the bypass hose clamp and position it down the hose.
- Remove the bolts and the thermostat housing. To install, tighten to 12 N.m (9 lb-ft).
- Inspect the thermostat housing O-ring seal. Install a new O-ring seal if necessary.
- To install, reverse the removal procedure.
Scheme 9
Scheme 9: REMOVAL AND INSTALLATION
| Item | Part Number | Description |
| 1 | 9D289 | Fuel vapor tube |
| 2 | 8260 | Upper radiator hose |
| 3 | W503279 | Thermostat housing bolt (2 required) |
| 4 | 8594 | Thermostat housing cover |
| 5 | N806807 | Thermostat O-ring seal |
| 6 | 8575 | Thermostat |
- Drain the cooling system. For additional information, refer to «Cooling System Draining, Filling and Bleeding»(ref-270902-S23782127182007110700000) .
- Remove the throttle body. For additional information, refer to «FUEL CHARGING AND CONTROLS - 4.6L (3V)»(ref-270905) .
- Disconnect the fuel vapor tube.
- Remove the bolts and position the thermostat housing cover aside.
- Remove the O-ring seal and the thermostat.
INSTALLATION
- Install the thermostat with the spring facing down.
- Install the O-ring seal.
- Position the thermostat housing cover and the bolts. Tighten to 10 Nm (89 lb-in).
- Connect the fuel vapor hose.
- Install the throttle body. For additional information, refer to «FUEL CHARGING AND CONTROLS - 4.6L (3V)»(ref-270905) .
- Fill and bleed the cooling system. For additional information, refer to «Cooling System Draining, Filling and Bleeding»(ref-270902-S23782127182007110700000) .
- Drain the engine cooling system. For additional information, refer to «Cooling System Draining, Filling and Bleeding»(ref-270902-S23782127182007110700000) .
- Remove the cooling fan. For additional information, refer to «Cooling Fan»(ref-270902-S21592733712007110700000) .
- Remove the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE»(ref-270912) .
- Remove the bolts and the coolant pump pulley. To install, tighten to 25 N.m (18 lb-ft).
- Release the clamp and disconnect the coolant pump bypass hose.
- Release the clamp and disconnect the heater hose.
- Release the clamp and disconnect the lower radiator hose.
- Remove the bolts, the coolant pump and the gasket. To install, tighten to 10 N.m (89 lb-in).
- Clean the mating surfaces with a plastic scraper and metal surface prep. Follow the directions on the packaging.
- To install, reverse the removal procedure. Install a new coolant pump gasket.
- Drain the cooling system. For additional information, refer to «Cooling System Draining, Filling and Bleeding»(ref-270902-S23782127182007110700000) .
- Remove the cooling fan. For additional information, refer to «Cooling Fan»(ref-270902-S21592733712007110700000) .
- Remove the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE»(ref-270912) .
- Remove the bolts and the coolant pump pulley. To install, tighten to 25 N.m (18 lb-ft).
- Remove the bolts and the coolant pump. To install, tighten to 25 N.m (18 lb-ft).
- Remove and discard the coolant pump O-ring.
- Clean the mating surfaces with a plastic scraper, if necessary, and metal surface prep. Follow the directions on the packaging.
- To install, reverse the removal procedure. Install a new coolant pump O-ring. Lubricate the O-ring with clean engine coolant.
Scheme 10
Scheme 10: Coolant Crossover Manifold Assembly
| Item | Part Number | Description |
| 1 | 14489 | Electrical connector (part of 12B637) |
| 2 | N807309 | Generator bracket bolts (2 required) |
| 3 | N804178 | Generator nuts (2 required) |
| 4 | 10300 | Generator |
Scheme 11
| Item | Part Number | Description |
| 5 | 8260 | Upper radiator hose |
| 6 | 18465 | Positive crankcase ventilation (PCV) heater hose |
| 7 | 18C266 | Heater hose |
| 8 | W710925 | Coolant crossover manifold assembly bolts (2 required) |
| 9 | 8C368 | Coolant crossover manifold assembly |
| 10 | 8C387 | RH coolant crossover manifold assembly gasket |
| 11 | 8C388 | LH coolant crossover manifold assembly gasket |
- Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-270948) .
- Drain the engine cooling system. For additional information, refer to «Cooling System Draining, Filling and Bleeding»(ref-270902-S23782127182007110700000) .
- Remove the intake manifold. For additional information, refer to «ENGINE - 4.6L (3V)»(ref-270890) .
- Rotate the accessory drive belt tensioner clockwise and detach the belt from the generator pulley.
- Disconnect the electrical connector.
- Loosen the generator nuts. To install, tighten to 25 Nm (18 lb-ft).
- Remove the generator bracket-to-coolant crossover bolts, and position the generator, bracket and wiring harness aside as an assembly. To install, tighten to 10 Nm (89 lb-in).
- Disconnect the PCV heater hose from the coolant crossover manifold assembly.
- Disconnect the heater hose from the coolant crossover manifold assembly.
- Disconnect the upper radiator hose from the coolant crossover manifold assembly.
- Remove the bolts, the coolant crossover manifold assembly and the gaskets. Discard the gaskets. To install, tighten to 10 Nm (89 lb-in).
- To install, reverse the removal procedure. Install new gaskets.
Scheme 12
Scheme 12: Radiator and Cooling Fan - Exploded View
| Item | Part Number | Description |
| 1 | N503924 | Power steering fluid reservoir bolt |
| 2 | 3R700 | Power steering fluid reservoir |
| 3 | 19972 | A/C tube - 4.6L (3V) |
| 4 | 19972 | A/C tube - 4.0L SOHC |
Scheme 13
| Item | Part Number | Description |
| 1 | 8260 | Upper radiator hose |
| 2 | 8286 | Lower radiator hose |
| 3 | 8W287 | Lower radiator hose retainer |
| 4 | 7J081 | Transmission fluid cooler tube latch assemblies (2 required) |
| 5 | 7H420 | Transmission-to-cooler tube |
| 6 | 7890 | Transmission fluid cooler hose |
Scheme 14
| Item | Part Number | Description |
| 1 | 14A624 | Fan clutch electrical connector |
| 2 | W500214 | Fan clutch wiring harness bracket bolt - 4.0L SOHC |
| 3 | W500214 | Fan clutch wiring harness bracket bolt - 4.6L (3V) |
| 4 | 14W163 | Fan clutch wiring harness retaining bracket - 4.6L (3V) only |
| 5 | 8A616 | Fan clutch |
| 6 | W709027 | Fan shroud bolts (4 required) |
| 7 | 8K618 | Upper fan shroud |
| 8 | 8K619 | Lower fan shroud |
| 9 | 7N291 | Transmission fluid cooler tube retainer |
Scheme 15
| Item | Part Number | Description |
| 1 | 19T558 | Radiator top seal |
| 2 | 19T557 | LH A/C condenser seal |
| 3 | 19T556 | RH A/C condenser seal |
| 4 | W711343 | Radiator support bracket-to-A/C condenser bolts |
| 5 | W707665 | Radiator support bracket-to-radiator support bolts (2 required) |
| 6 | W503932 | Radiator support bracket-to-radiator bolts (2 required) |
| 7 | 8B265 | RH radiator support bracket |
| 8 | 8B266 | LH radiator support bracket |
| 9 | 8005 | Radiator |
| 10 | 19710 | A/C condenser |
| 11 | W705589 | Push pin (4 required) |
| 12 | 8B384 | Radiator lower air deflector |
Scheme 16
| Item | Part Number | Description |
| 1 | W505425 | Fan-to-electronic fan clutch bolts (4 required) |
| 2 | 8600 | Fan |
| 3 | 8A616 | Electronic fan clutch |
| 4 | 8C290 | Electronic fan clutch wiring assembly |
- For additional information, refer to the appropriate procedures.
- With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-270881) .
- Drain the cooling system. For additional information, refer to «Cooling System Draining, Filling and Bleeding»(ref-270902-S23782127182007110700000) .
- Remove the air cleaner outlet pipe. For additional information, refer to «INTAKE AIR DISTRIBUTION AND FILTERING»(ref-270901) .
- Remove the coolant expansion tank. For additional information, refer to «Coolant Expansion Tank»(ref-270902-S33808349442007110700000) .
- Remove the bolt and position the power steering fluid reservoir aside. To install, tighten to 10 Nm (89 lb-in).
- Release the clamp and disconnect the upper radiator hose.
- Release the clamp and disconnect the lower radiator hose.
- Detach the lower radiator hose retainer from the lower fan shroud.
- Detach the transmission cooler hose retainer from the RH radiator support bracket.
- Remove the 4 lower radiator air deflector pushpins.
- Remove the latch assemblies from the transmission cooler tubes.
- Using the special tool, disconnect the transmission cooler tubes.
- Remove the upper fan shroud bolts, then unclip the upper fan shroud from the lower fan shroud and remove the upper fan shroud. To install, tighten to 7 Nm (62 lb-in).
- Disconnect the fan clutch electrical connector.
- Remove the fan clutch wiring harness bracket bolt. To install, tighten to 7 Nm (62 lb-in).
- Using the special tools, remove the cooling fan. To install, tighten to 55 Nm (41 lb-ft).
- Remove the bolts and the lower fan shroud.
- Detach the A/C tube from the retainer on the radiator support bracket.
- Remove the radiator support bracket-to-radiator support bracket bolts. To install, tighten to 15 Nm (11 lb-ft).
- Remove the radiator top seal.
- Deflect the A/C condenser seals and remove the A/C condenser-to-radiator support bracket bolts. Position the A/C condenser aside. To install, tighten to 12 Nm (9 lb-ft).
- Remove the radiator and the radiator support brackets as an assembly.
- Remove the bolts and separate the radiator support brackets and the radiator. To install, tighten to 12 Nm (9 lb-ft).
- To install, reverse the removal procedure.
Vehicle equipped with a 4.6L (3V)
- Remove the air cleaner outlet pipe. For additional information, refer to «INTAKE AIR DISTRIBUTION AND FILTERING»(ref-270901) .
- Remove the coolant expansion tank. For additional information, refer to «Coolant Expansion Tank»(ref-270902-S33808349442007110700000) .
- Remove the bolt and position the power steering fluid reservoir aside. To install, tighten to 10 Nm (89 lb-in).
- Remove the bolts, then unclip the upper fan shroud from the lower fan shroud and remove the upper fan shroud. To install, tighten to 7 Nm (62 lb-in).
- Disconnect the fan clutch electrical connector.
- Remove the fan clutch wiring harness bracket bolt. To install, tighten to 7 Nm (62 lb-in).
- Using the special tools, remove the cooling fan. To install, tighten to 55 Nm (41 lb-ft).
- Remove the bolts and separate the fan from the fan clutch. To install, tighten to 7 Nm (62 lb-in).
- If necessary, unclip and disconnect the fan clutch wiring harness.
- To install, reverse the removal procedure.
Vehicles equipped with a 4.6L (3V) engine
- Remove the air cleaner outlet pipe. For additional information, refer to «INTAKE AIR DISTRIBUTION AND FILTERING»(ref-270901) .
- Remove the coolant expansion tank. For additional information, refer to «Coolant Expansion Tank»(ref-270902-S33808349442007110700000) .
- Remove the bolt and position the power steering fluid reservoir aside. To install, tighten to 10 Nm (89 lb-in).
- Remove the bolts, then unclip the upper fan shroud from the lower fan shroud and remove the upper fan shroud. To install, tighten to 7 Nm (62 lb-in).
- Disconnect the fan clutch electrical connector.
- Remove the fan clutch wiring harness bracket bolt. To install, tighten to 7 Nm (62 lb-in).
- Using the special tools, remove the cooling fan. To install, tighten to 55 Nm (41 lb-ft).
- Remove the bolts and the lower fan shroud. To install, tighten to 7 Nm (62 lb-in).
- To install, reverse the removal procedure.
