Engine Cooling System: Maintenance Ford Explorer IV

Cooling System (Mechanical) 1 illustration ~320 words

Cooling System Draining, Filling and Bleeding

Special Tools Illustration Tool Name Tool Number RADKITPLUS 078-00497

Scheme 17

Scheme 17: Cooling System Draining, Filling and Bleeding
Scheme 17: Cooling System Draining, Filling and Bleeding
ItemSpecification
Motorcraft Premium Gold Engine Coolant with Bittering Agent (US only) VC-7-B (US); CVC-7-A (Canada); or equivalent (yellow color)WSS-M97B51-A1

Material

Draining

WARNINGTo avoid personal injury, do not unscrew the radiator cap while the engine is operating or hot. The cooling system is under pressure; steam and hot liquid can come out forcefully when the cap is loosened slightly. Failure to follow these instructions may result in personal injury.
CAUTIONThe coolant must be recovered in a suitable, clean container for reuse. If the coolant is contaminated, it must be recycled or disposed of correctly.
CAUTIONAll vehicles are filled with Motorcraft Premium Gold Engine Coolant. Always fill the cooling system with the same type coolant that is present in the system. Do not mix coolant types.

Note. The addition of Cooling System Stop Leak Pellets darkens Motorcraft Premium Gold Engine Coolant from yellow to golden tan.

Note. Less than 80 percent of the coolant capacity can be recovered with the engine in the vehicle. Dirty, rusty or contaminated coolant requires replacement.

  1. Make sure the engine is cool.
  2. Wrap a thick cloth around the radiator cap. Slowly turn the cap counterclockwise (left) until the pressure begins to release.
  3. Step back while the pressure releases.
  4. When you are sure all the pressure has been released, use the cloth to turn and remove the cap.
  5. Place a suitable container below the radiator draincock. Drain the coolant. Tighten the radiator draincock when finished.

Cooling System Flushing

ItemSpecification
Premium Cooling System Flush VC-1ESR-M14P7-A

Material

All vehicles

  1. Drain the cooling system. For additional information, refer to «Cooling System Draining, Filling and Bleeding»(ref-270902-S23782127182007110700000) .
  2. Remove the bolts, thermostat housing cover and thermostat. Install the thermostat housing cover and bolts without the thermostat. Tighten to 10 Nm (89 lb-in).
  3. Remove the throttle body (TB). For additional information, refer to «FUEL CHARGING AND CONTROLS - 4.6L (3V)»(ref-270905) .
  4. Disconnect the fuel vapor hose.
  5. Remove the bolts, thermostat housing cover and thermostat. Install the thermostat housing cover, the O-ring seal and the bolts without the thermostat. Tighten to 10 Nm (89 lb-in).
  6. Using a suitable cooling system flushing tool, flush the engine and radiator. Use cooling system flush.
  7. Install the thermostat, O-ring seal, thermostat housing cover and bolts. Tighten to 10 Nm (89 lb-in).
  8. Install the thermostat, O-ring seal, thermostat housing cover and bolts. Tighten to 10 Nm (89 lb-in).
  9. Connect the fuel vapor hose.
  10. Install the TB. For additional information, refer to «FUEL CHARGING AND CONTROLS - 4.6L (3V)»(ref-270905) .
  11. Fill and bleed the cooling system. For additional information, refer to «Cooling System Draining, Filling and Bleeding»(ref-270902-S23782127182007110700000) .
