Parking Aid: Removal & Installation Ford Explorer IV

Collision/avoidance 4 illustrations ~306 words

REMOVAL AND INSTALLATION

  1. Disconnect the parking aid module bumper harness from the body harness.
  2. Remove the rear bumper cover. For additional information, refer to «BUMPERS»(ref-270925) .
  3. Remove the 4 insulator-to-bumper cover nuts and the insulator from the bumper cover.
  4. Disconnect the parking aid module bumper harness from the parking aid module.
  5. Remove the 2 parking aid module bracket bolts.
  6. Remove the parking module bracket assembly.
  7. Release the module tabs from the bracket and remove the module.
  8. To install, reverse the removal procedure.

Scheme 15

Scheme 15: Parking Aid Module - Mountaineer, Explorer Sport Trac
Scheme 15: Parking Aid Module - Mountaineer, Explorer Sport Trac
ItemPart NumberDescription
1W505413-S309Parking aid module bracket screw
2Parking aid module and parking aid speaker wiring harness connectors (part of 15K866)
315K866Parking aid module and bracket assembly
415A866Parking aid speaker
5Parking aid speaker push pins (2 required)

Scheme 16

Scheme 16
Scheme 16
ItemPart NumberDescription
1W702434-S439Parking aid module bracket screw
2Parking aid module and parking aid speaker wiring harness connectors (part of 13A409)
315K866Parking aid module and bracket assembly
415A866Parking aid speaker
  1. For Mountaineer, remove the RH quarter trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-270927) .
  2. For Explorer Sport Trac, remove the cab rear trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-270927) .
  3. For Mountaineer, if replacing the parking aid speaker only, proceed as follows: Disconnect the parking aid speaker electrical connector. Remove the parking aid speaker push pins. Remove the parking aid speaker.
  4. For Explorer Sport Trac, if replacing the parking aid speaker only, proceed as follows: Disconnect the parking aid speaker electrical connector. Disengage the parking aid speaker clips. Remove the parking aid speaker.
  5. For all vehicles, if replacing the parking aid module, proceed as follows: Disconnect the electrical connectors. Remove the parking aid module screw. Remove the parking aid module.
  6. To install, reverse the removal procedure.

Note. Mountaineer shown, Explorer Sport Trac similar.

Scheme 17

Scheme 17: Parking Aid Sensor - Mountaineer, Explorer Sport Trac
Scheme 17: Parking Aid Sensor - Mountaineer, Explorer Sport Trac
ItemPart NumberDescription
1Parking aid sensor electrical connectors (part of 15K868)
214489Parking aid sensors
  1. Remove the rear bumper cover. For additional information, refer to «BUMPERS»(ref-270925) .
  2. Disconnect the parking aid sensor(s) electrical connector(s).
  3. Press the retaining tabs and remove the parking aid sensor(s).
  4. To install, reverse the removal procedure.

Scheme 18

Scheme 18: Parking Aid Speaker - Explorer
Scheme 18: Parking Aid Speaker - Explorer
ItemPart NumberDescription
1Parking aid speaker bracket bolt
2Parking aid speaker and bracket assembly
3Parking aid speaker electrical connector
  1. Remove the LH C-pillar trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-270927) .
  2. Remove the bolt and the speaker and bracket assembly. Disconnect the electrical connector.
  3. To install, reverse the removal procedure.
