GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Generator, 4.0L | |
| Rating | 70/121 amp (max) @ 1,800-6,000 generator rpm, approx. 500-2,000 engine rpm |
| Generator pulley ratio | 2.59:1 |
| Voltage regulator type | Electronic internal with generator |
| Generator, 4.6L | |
| Rating | 82/135 amp (max) @ 1,800-6,000 generator rpm, approx. 500-2,000 engine rpm |
| Generator pulley ratio - early build | 2.72:1 |
| Generator pulley ratio - late build | 2.52:1 |
| Voltage regulator type | Electronic internal with generator |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Generator B+ terminal nut | 8 |
| Generator bracket bolts (4.6L) | 10 |
| Generator bolts (4.0L) | 47 |
| Generator bolts (4.6L) | 25 |
| Generator pulley nut | 109 |
TORQUE SPECIFICATIONS
The generator is belt-driven by the engine accessory drive system. The generator has an internal voltage regulator that is not replaced separately. The generator and voltage regulator are repaired as an assembly.
Refer to CHARGING SYSTEM - GENERAL INFORMATION .
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | 6B209 | Front end accessory drive belt tensioner |
| 2 | 8620 | Front end accessory drive belt |
| 3 | W705790 - S901 | Generator B+ terminal nut |
| 4 | Generator B+ terminal (part of 14300) | |
| 5 | Generator electrical connectors (part of 14300) | |
| 6 | W500328 - S437 | Generator bolts (3 required) |
| 7 | 10300 | Generator |
| 8 | N807805 | Generator pulley nut |
| 9 | 10344 | Generator pulley |
