Power Window System: Other — Ford Explorer II (1994-2003)

Mechanical

Window alignment.
Window mounting (regulator and bracket).
Window frame interference.

Electrical

Blown fuse(s).
Damaged wiring harness.
Loose or corroded connections.
Damaged switches.
Damaged window motor.

POWER WINDOW MOTOR

Remove window motor from vehicle, see POWER WINDOW MOTOR R & I under REMOVAL & INSTALLATION. Using fused jumper wires, connect a fully charged battery to motor terminals. Observe motor. Motor should operate smoothly. Reverse leads. Motor should operate in reverse direction. Replace window motor if it does not operate as specified.

POWER WINDOW MASTER SWITCH

Remove master switch. See POWER WINDOW SWITCH under REMOVAL & INSTALLATION. Check for continuity between terminals as specified while operating switch. See appropriate MASTER SWITCH TESTING table. If continuity does not exist as specified, replace switch. (Scheme 6)or (Scheme 7).

Switch Position		Continuity Between Terminals No.
Neutral		1, 9 & 11; 2, 4 & 8; 2, 4 & 12; 5, 9 & 11; 6 & 7; 13 & 14
Left
Up		1, 9 & 11; 3 & 5
Down		5, 9 & 11; 1 & 3
Right
Up		2, 4 & 8; 10 & 12
Down		2, 4 & 12; 8 & 10

MASTER SWITCH TESTING

Switch Position		Continuity Between Terminals No.
Neutral		1 & 5; 12 & 14; 8, 9, 10, 11, 13, 15, 16, 17 & 18
Left Front
Up		8 & 19; 10 & 13
Down		10 & 19; 8 & 13
Right Front
Up		9 & 19; 11 & 13
Down		11 & 19; 9 & 13
Left Rear
Up		15 & 19; 13 & 17
Down		17 & 19; 13 & 15
Right Rear
Up		16 & 19; 13 & 18
Down		18 & 19; 13 & 16
Lockout Unlocked		19 & 20

MASTER SWITCH TESTING

Scheme 6

Scheme 7

POWER WINDOW SINGLE SWITCH

Remove suspect window switch. See POWER WINDOW SWITCH under REMOVAL & INSTALLATION. Check for continuity between terminals as specified while operating switch. See appropriate SWITCH TESTING table. If continuity does not exist as specified, replace switch. (Scheme 8)or (Scheme 9).

Switch Position	Continuity Between Terminals No.
Neutral	3 & 7; 1 & 2; 5 & 6
Up	2 & 4; 5 & 6
Down	4 & 5; 1 & 2

RIGHT FRONT & RIGHT REAR SWITCH TESTING

Switch Position	Continuity Between Terminals No.
Neutral	3 & 7; 1 & 5; 2 & 6
Up	4 & 5; 2 & 6
Down	2 & 4; 1 & 5

LEFT REAR PASSENGER SWITCH TESTING

Scheme 8

Scheme 9

ACCESSORY DELAY RELAY

Remove accessory delay relay from relay module located behind center of instrument panel. Check continuity using an ohmmeter. Continuity should exist between relay terminals No. 85 and 86, and also between terminal No. 30 and terminal 87A. (Scheme 10) Using fused jumper wires, connect battery terminals to relay terminals No. 85 and 86. Continuity should now exist between relay terminals No. 30 and 87. Replace relay if continuity is not as specified.

Scheme 10

Scheme 10: ACCESSORY DELAY RELAY

BATTERY SAVER & ONE-TOUCH DOWN RELAY

Remove battery saver relay or one-touch down relay from relay module located behind center of instrument panel. Check continuity using an ohmmeter. Continuity should exist between relay terminals No. 1 and 2, and also between terminals No. 3 and 4. (Scheme 11) Using fused jumper wires, connect battery terminals to relay terminals No. 1 and 2. Continuity should now exist between relay terminals No. 3 and 5. Replace relay if continuity is not as specified.

Scheme 11

Scheme 11: BATTERY SAVER & ONE-TOUCH DOWN RELAY

PRELIMINARY PROCEDURE

Verify customers complaint by operating power windows. Check window alignment, window mounting, window frame interference or damaged switches. Check for blown fuse(s), loose or corroded connectors, or damaged wiring harness. Repair or replace components as necessary.
If all components are okay, connect NGS tester to DLC located below instrument panel. Using NGS tester, perform DATA LINK DIAGNOSTIC TEST. If NGS tester displays CKT 914 or CKT 915=ALL MODULES NO RESP/NOT EQUIP, see MODULE COMMUNICATIONS NETWORK article to diagnosis network concern. If NGS tester displays NO RESP/NOT EQUIP for Generic Electronic Module (GEM), perform «TEST J: NO COMMUNICATION WITH GEM»(ref-29364-S10965897562001010800000) under SYSTEM TESTS.
If NGS tester displays SYSTEM PASSED, retrieve and record continuous DTCs. Erase continuous DTCs. Perform self-test diagnostics for GEM/CTM using NGS tester. If GEM/CTM DTCs are retrieved, see GENERIC ELECTRONIC MODULE/CENTRAL TIMER MODULE (GEM/CTM) DTC DEFINITIONS table to continue diagnosis. If no DTCs are retrieved, perform appropriate test under «SYSTEM TESTING»(ref-29364-S36994198232001010800000) .

DTC	Source Module	Description
B1302	GEM	(1) Accessory Delay Relay Coil Circuit Failure
B1304	GEM	(1) Accessory Delay Relay Coil Circuit Open Or Short To Battery
B1313	GEM/CTM	(1) Battery Saver Relay Coil Circuit Failure
B1315	GEM/CTM	(1) Battery Saver Relay Coil Circuit Short To Battery
B1317	GEM/CTM	(2) (3) Battery Voltage High
B1318	GEM/CTM	(2) (3) Battery Voltage Low
B1322	GEM/CTM	(3) (4) Left Front Door Ajar Circuit Short To Ground
B1323	GEM/CTM	(5) Door Ajar Light Circuit Failure
B1325	GEM/CTM	(5) Door Ajar Light Circuit Short To Battery
B1330	GEM/CTM	(3) (4) Right Front Door Ajar Circuit Short To Ground
B1334	GEM/CTM	(4) Deck Lid Ajar Rear Door Circuit Short To Ground
B1338	GEM/CTM	(4) Right Rear Door Open Warning Light Switch Circuit Short To Ground
B1340	GEM/CTM	(6) Chime Input Request Circuit Short To Ground
B1342	GEM/CTM	(7) GEM/CTM Is Defective
B1345	GEM	(8) Heated Backlite Input Circuit Short To Ground
B1347	GEM	(8) Heated Backlite Relay Circuit Failure
B1349	GEM	(8) Heated Backlite Relay Circuit Short To Battery
B1352	GEM/CTM	(3) (6) Ignition Key-In Circuit Failure
B1355	GEM/CTM	(9) Ignition Run Circuit Failure
B1359	GEM/CTM	(9) Ignition RUN/ACC Circuit Failure
B1371	GEM/CTM	(2) Illuminated Entry Relay Circuit Failure
B1373	GEM/CTM	(4) Interior Light Relay Coil Circuit Short To Battery
B1398	GEM	(10) Power Window One-Touch Window Relay Circuit Failure
B1400	GEM	(10) Power Window One-Touch Window Relay Coil Circuit Short To Battery
B1404	GEM	(10) Driver Door Power Window Down Circuit Open
B1405	GEM	(10) Driver Door Power Window Down Circuit Short To Battery
B1410	GEM	(3) (10) Driver Door Power Window Motor Circuit Failure
B1426	GEM/CTM	(5) Seat Belt Light Output Circuit Short To Battery
B1428	GEM/CTM	(5) Seat Belt Light Output Circuit Failure
B1431	GEM/CTM	(11) Wiper Brake/Run Relay Circuit Failure
B1432	GEM/CTM	(11) Wiper Brake/Run Relay Short To Battery
B1434	GEM/CTM	(11) Wiper Hi/Low Speed Relay Circuit Failure
B1436	GEM/CTM	(11) Wiper Hi/Low Speed Relay Circuit Short To Battery
B1438	GEM/CTM	(3) (11) Wiper Mode Select Switch Circuit Failure
B1441	GEM/CTM	(3) (11) Wiper Mode Select Switch Input Short To Ground
B1446	GEM/CTM	(3) (11) Wiper Park Sense Circuit Failure
B1450	GEM/CTM	(3) (11) Wiper/Wash Interval Delay Switch Input Circuit Failure
B1453	GEM/CTM	(3) (11) Wiper/Wash Interval Delay Switch Input Short To Ground
B1458	GEM/CTM	(11) Wiper/Washer Pump Motor Relay Circuit Failure
B1460	GEM/CTM	(11) Wiper/Washer Pump Motor Relay Coil Short To Battery
B1462	GEM/CTM	(3) (6) Seat Belt Switch Circuit Failure
B1466	GEM/CTM	(11) Wiper Hi/Low Speed Not Switching
B1467	GEM/CTM	(11) Wiper Motor Hi/Low Speed Circuit Short To Battery
B1473	GEM/CTM	(11) Wiper Motor Low Speed Circuit Failure
B1475	GEM/CTM	(10) Delayed Accessory Relay Contacts Short To Battery
B1476	GEM/CTM	(11) Wiper Motor High Speed Circuit Failure
B1483	GEM	(12) Brake Pedal Input Circuit Failure
B1485	GEM	(12) Brake Pedal Input Circuit Short To Battery
B1571	GEM/CTM	(4) Left Rear Door Ajar Circuit Failure
B1574	GEM/CTM	(4) Left Rear Door Ajar Circuit Short To Ground
B1577	GEM/CTM	GEM/CTM . (3) (6) Parking Light Input Circuit Short To Battery
B1610	GEM	(3) (4) Illuminated Entry Input Request Circuit Short To Ground
B1611	GEM	(11) Rear Wiper Mode Select Switch Circuit Failure
B1614	GEM	(11) Rear Wiper Mode Select Switch Circuit Short To Ground
B1814	GEM	(11) Rear Wiper Motor Down Relay Circuit Failure
B1816	GEM	(11) Rear Wiper Motor Down Relay Coil Circuit Short To Battery
B1818	GEM	(11) Rear Wiper Motor Up Relay Coil Circuit Failure
B1820	GEM	(11) Rear Wiper Motor Up Relay Circuit Short To Battery
B1833	GEM	(3) (13) Door Unlock Switch Circuit Short To Ground
B1834	GEM	(13) Door Unlock Disarm Output Circuit Failure
B1836	GEM	(13) Door Unlock Disarm Output Circuit Short To Battery
B1839	GEM	(11) Rear Wiper Motor Circuit Failure
B1840	GEM/CTM	(11) Front Wiper Power Circuit Failure
B1894	GEM	(11) Rear Wiper Motor Speed Sense Circuit Failure
B2105	GEM	(12) Throttle Position Input Signal Out Of Low Range
B2106	GEM	(12) Throttle Position Input Signal Out Of High Range
B2141	GEM/CTM	(14) NVM Configuration Failure
P0500	GEM	(12) Vehicle Speed Signal Circuit Failure
P1763	GEM	(6) Trans. Neutral In Tow Indicator Circuit Short To Battery
P1764	GEM	(6) Trans. Neutral In Tow Indicator Circuit Failure
P1804	GEM	(12) 4-Wheel Drive High Indicator Circuit Failure
P1806	GEM	(12) 4-Wheel Drive High Indicator Circuit Short To Battery
P1808	GEM	(12) 4-Wheel Drive Low Indicator Circuit Failure
P1810	GEM	(12) 4-Wheel Drive Low Indicator Circuit Short To Battery
P1812	GEM	(12) 4-Wheel Drive Mode Select Circuit Failure
P1815	GEM	(12) 4-Wheel Drive Mode Select Circuit Short To Ground
P1820	GEM	(12) Transfer Case Clockwise Shift Relay Coil Circuit Failure
P1822	GEM	(12) Transfer Case Clockwise Shift Relay Coil Short To Power
P1824	GEM	(12) 4-Wheel Drive Electric Clutch Relay Circuit Failure
P1826	GEM	(12) 4-Wheel Drive Low Clutch Relay Short To Battery
P1828	GEM	(12) Transfer Case Counterclockwise Shift Relay Circuit Failure
P1830	GEM	(12) Transfer Case Counterclockwise Shift Relay Coil Short To Battery
P1836	GEM	(12) Transfer Case Front Shaft Speed Sensor Circuit Failure
P1837	GEM	(12) Transfer Case Rear Shaft Speed Sensor Circuit Failure
P1838	GEM	(12) Transfer Case Shift Motor Circuit Failure
P1846	GEM	(12) Transfer Case Contact Plate "A" Circuit Failure
P1850	GEM	(12) Transfer Case Contact Plate "B" Circuit Failure
P1854	GEM	(12) Transfer Case Contact Plate "C" Circuit Failure
P1858	GEM	(12) Transfer Case Contact Plate "D" Circuit Failure
P1866	GEM	(12) Transfer Case System Concern
P1867	GEM	(12) Transfer Case Contact Plate General Circuit Failure
P1874	GEM	(12) Automatic Hall Effect Sensor Power Circuit Failure
P1875	GEM	(12) Automatic Hall Effect Sensor Power Circuit Short To Battery
P1891	GEM	(12) Transfer Case Contact Plate Ground Return Open Circuit
(1) Perform TEST A: ALL POWER WINDOWS ARE INOPERATIVE under SYSTEM TESTS. (2) See GENERATORS article in the STARTING & CHARGING SYSTEMS section for testing procedures. (3) This DTC may also be present from GEM/CTM wiggle test. (4) Test wiring for opens and/or shorts and repair as necessary. See appropriate wiring diagram in ILLUMINATION/INTERIOR LIGHTS article. (5) See INSTRUMENT PANELS article for testing procedures. (6) Test wiring for opens and/or shorts and repair as necessary. See appropriate wiring diagram in WARNING SYSTEMS article. (7) Clear DTCs. Retrieve DTCs. If DTC B1342 is retrieved, replace GEM/CTM and retest system operation. (8) See REAR WINDOW DEFOGGERS article for testing procedures. (9) See STEERING COLUMN SWITCHES article for testing procedures. (10) Perform appropriate test under SYSTEM TESTING . (11) See WIPER/WASHER SYSTEMS article for testing procedures. (12) See TRANSFER CASES article in the TRANSMISSIONS section for testing procedures. (13) See REMOTE KEYLESS ENTRY SYSTEMS article for testing procedures. (14) Vehicle speed calibration data is not programmed into GEM/CTM. Use NGS tester configuration card help screen to program tire size and axle ratio. Retest system operation. If DTC B2141 is still present, replace GEM/CTM and retest system operation.

(1)	Perform TEST A: ALL POWER WINDOWS ARE INOPERATIVE under SYSTEM TESTS.

(2)	See GENERATORS article in the STARTING & CHARGING SYSTEMS section for testing procedures.

(3)	This DTC may also be present from GEM/CTM wiggle test.

(4)	Test wiring for opens and/or shorts and repair as necessary. See appropriate wiring diagram in ILLUMINATION/INTERIOR LIGHTS article.

(5)	See INSTRUMENT PANELS article for testing procedures.

(6)	Test wiring for opens and/or shorts and repair as necessary. See appropriate wiring diagram in WARNING SYSTEMS article.

(7)	Clear DTCs. Retrieve DTCs. If DTC B1342 is retrieved, replace GEM/CTM and retest system operation.

(8)	See REAR WINDOW DEFOGGERS article for testing procedures.

(9)	See STEERING COLUMN SWITCHES article for testing procedures.

(10)	Perform appropriate test under SYSTEM TESTING .

(11)	See WIPER/WASHER SYSTEMS article for testing procedures.

(12)	See TRANSFER CASES article in the TRANSMISSIONS section for testing procedures.

(13)	See REMOTE KEYLESS ENTRY SYSTEMS article for testing procedures.

(14)	Vehicle speed calibration data is not programmed into GEM/CTM. Use NGS tester configuration card help screen to program tire size and axle ratio. Retest system operation. If DTC B2141 is still present, replace GEM/CTM and retest system operation.

GENERIC ELECTRONIC MODULE/CENTRAL TIMER MODULE (GEM/CTM) DTC DEFINITIONS

Check Accessory Delay Relay

Check accessory delay relay. See ACCESSORY DELAY RELAY under COMPONENT TESTS. If accessory delay relay is okay, repair Light Blue/Black wire and retest system operation. If accessory delay relay does not test as specified, replace accessory delay relay and retest system operation.
