VIN LOCATION
The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.
FUSE PANEL LOCATIONS
These vehicles are equipped with two fuse blocks. The Power Distribution Box is located in the engine compartment near the battery. The Interior Fuse Box is located on the instrument panel on the left hand side facing the driver side door.
Scheme 3
Scheme 4
Scheme 5
- 1 - 7.5 Amp - Power Mirror, Power Antenna
- 2 - 7.5 Amp - High-mount Stoplight
- 3 - 15 Amp - Parking Lamps
- 4 - 10 Amp - Left Headlamp
- 5 - 10 Amp - OBDII System
- 6 - 7.5 Amp - Air Bag System, Blower relay
- 7 - 7.5 Amp - Illuminated Switches
- 8 - 10 Amp - Right Headlamp, Fog Lamp System
- 9 - 10 Amp - Auto Lamps
- 10 - 7.5 Amp - Rear Blower, Speed Control, GEM System, Brake Interlock, Overhead Console
- 11 - 7.5 Amp - Warning Lights
- 12 - 10 Amp - Front/Rear Wash System
- 13 - 15 Amp - Brake On\Off Switch
- 14 - 10 Amp - ABS System
- 15 - 7.5 Amp - Air Bag System, Instrument Cluster
- 16 - 30 Amp - Front Wiper
- 17 - 15 Amp - Cigar Lighter
- 18 - 15 Amp - A/C System
- 19 - 25 Amp - Ignition Coil, PCM System
- 20 - 7.5 Amp - Radio, Power Antenna, GEM System, Anti-Theft, Cellular Phone
- 21 - 15 Amp - Hazard Lamps
- 22 - 10 Amp - Turn Signals
- 23 - 10 Amp - Rear Wiper System
- 24 - 10 Amp - Anti-Theft Relay
- 25 - 7.5 Amp - Instrument Cluster, GEM System
- 26 - 10 Amp - 4R70W Overdrive, DRL System, Back-up Lamps, 4-Wheel Drive, Rear Defroster
- 27 - 15 Amp - Under Hood Lamp, Map Lights, Glove Box Lamp, Dome Lamp, Visor Lamps, Accessory Relay, Dimmer Switch Illumination
- 28 - 7.5 Amp - GEM System
- 29 - 10 Amp - Audio System
- 30 - Not Used
- 31 - 7.5 Amp - Rear Blower System
- 32 - 7.5 Amp - Heated Rear Window
- 33 - 15 Amp - High Beam Lamps, DRL Module, Instrument Cluster
- 34 - 7.5 Amp - Lux. Audio System
- 35 - Not Used
- 36 - Not Used
