Rear View Mirrors System Ford Explorer Sport Trac II

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

The main components of the exterior rear view mirrors are the following

1. Manually adjusted exterior mirror glass
2. Power adjusted exterior mirror glass (optional)
3. Exterior mirror glass adjustment motors (optional - power mirrors only)
4. Heated exterior mirror glass (optional)
5. Exterior mirror plastic housing

Power Exterior Rear View Mirrors - Power exterior rear view mirrors allow the driver or passenger mirror glass to be positioned electronically. The position of the power mirror glass is controlled by the exterior rear view mirror control switch, which is located on the LH front door trim panel. Adjusting the exterior rear view mirror control switch to the LH or RH position determines which power mirror glass will be controlled.

Heated Exterior Rear View Mirrors - The power exterior rear view mirrors are available with a heated mirror glass option, which heats the mirror glass to remove frost, snow, ice and condensation. The rear window defrost switch controls the operation of the heated exterior rear view mirrors. The heated exterior rear view mirrors only operate when the rear window defrost system is operating. The heated exterior rear view mirrors are heated for a period of 10 minutes when the rear window defrost switch is activated.

Interior Rear View Mirrors - The interior rear view mirrors can be equipped with the following

1. Interior rear view mirror
2. Interior auto-dimming rear view mirror (optional)
3. Microphone (optional)

For information on the nagivation system, refer to INFORMATION AND ENTERTAINMENT SYSTEMS article.

Interior Auto-Dimming Rear View Mirror - The interior auto-dimming rear view mirror automatically reduces the glare caused by headlamps reflecting in the interior rear view mirror. The interior auto-dimming rear view mirror adjusts the reflectance level of the interior rear view mirror glass to eliminate unwanted glare. The reflectance level of the mirror glass is variable and depends on the amount of rear glare in relation to ambient light conditions in front of the interior mirror. To provide increased visibility when backing up, the interior rear view mirror will automatically return to a high reflectance mode whenever the vehicle is in REVERSE.

Special Tools Illustration Tool Name Tool Number 73III Automotive Meter 105-R0057 or equivalent

Principles of Operation

The exterior mirror control switch is located on the LH door trim panel. Adjusting the exterior mirror control switch to the LH or RH position determines which exterior mirror glass will be controlled.

Heated Exterior Rear View Mirror

The rear window defrost switch controls the operation of the heated exterior rear view mirrors. The heated exterior rear view mirrors only operate when the rear window defrost system is operating. The heated exterior rear view mirror power is supplied by the rear defroster relay through smart junction box (SJB) fuse 13 (15A), which isolates the heated exterior mirrors from the rear window defroster system in the event of a concern.

Interior Auto-Dimming Rear View Mirror

The interior rear view mirror may be equipped with an auto-dimming feature. The interior auto-dimming rear view mirror automatically reduces the glare caused by headlamps reflecting in the interior rear view mirror. Power is supplied to the interior auto-dimming mirror when the ignition is in the RUN position or the accessory delay is active. The auto-dimming feature is disabled when the vehicle is in REVERSE.

The interior auto-dimming rear view mirror has 2 photoelectric sensors, a forward facing sensor and a rearward facing sensor, that detect forward and rearward light conditions. Based on these inputs, the automatic dimming feature adjusts the reflectance level of the interior rear view mirror glass to eliminate unwanted glare. The reflectance level of the mirror glass is variable and depends on the amount of rear glare in relation to ambient light conditions in front of the interior mirror.

When the forward sensor detects daytime conditions, the rearward sensor is inactive and the interior rear view mirror stays in a high reflectance mode. When the forward sensor detects nighttime conditions, the rearward sensor is active and detects glare from the headlights of vehicles approaching from the rear or other glare-producing light sources. To provide increased visibility when backing up, the interior rear view mirror will automatically return to a high reflectance mode whenever the vehicle is in REVERSE.

If the forward or rearward sensors are blocked, the interior auto-dimming rear view mirror might not work correctly.

Inspection and Verification

1. Verify the customer concern by operating the exterior/interior mirrors.
2. Visually inspect for the following obvious signs of mechanical and electrical damage. VISUAL INSPECTION CHART Mechanical Electrical Exterior mirror Exterior mirror control switch Interior rear view mirror Exterior mirror glass Smart junction box (SJB) fuse(s): 13 (15A) 18 (10A) Battery junction box (BJB) fuse 32 (5A) Exterior mirror control switch Exterior mirror motor Exterior mirror Heated exterior mirror glass Interior auto-dimming rear view mirror Loose or corroded connections Wiring harness
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the concern is not visually evident, verify the symptom and Go to «Symptom Chart - Rear View Mirrors»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) or Go to «Symptom Chart - Noise, Vibration and Harshness (NVH)»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) .

Symptom Chart - Rear View Mirrors

Symptom Chart - Rear View Mirrors

Symptom Chart - Noise, Vibration and Harshness (NVH)

Note. Noise, vibration and harshness (NVH) symptoms should be identified using the diagnostic tools that are available. For a list of these tools, an explanation of their uses and a glossary of common terms, refer to NOISE, VIBRATION AND HARSHNESS article. Since it is possible any one of multiple systems may be the cause of a symptom, it may be necessary to use a process of elimination type of diagnostic approach to pinpoint the responsible system. If this is not the causal system for the symptom, refer back to NOISE, VIBRATION AND HARSHNESS article for the next likely system and continue diagnosis.

Symptom Chart - Noise, Vibration and Harshness (NVH)

Pinpoint Test A: The Mirrors are Inoperative

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Mirrors for schematic and connector information.

Normal Operation

The exterior mirror control switch receives power through circuit SBB32 (VT/RD) and ground through circuit GD133 (BK). The exterior mirror control switch uses circuit CPM23 (GY) as the common circuit for both exterior mirror up/down and right/left movement.

This pinpoint test is intended to diagnose the following

1. Fuse
2. Wiring, terminals or connectors
3. Exterior mirror control switch

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

1. A1 CHECK CIRCUIT SBB32 (VT/RD) FOR AN OPEN Key in OFF position. Disconnect: Exterior Mirror Control Switch C527 Key in ON position. Measure the voltage between exterior mirror control switch C527-3, circuit SBB32 (VT/RD) harness side and ground. Is the voltage greater than 10 volts? YES : Go to A2 . NO : VERIFY that battery junction box (BJB) fuse 32 (5A) is OK. If OK, REPAIR the circuit. TEST the system for normal operation.
2. A2 CHECK CIRCUIT GD133 (BK) FOR AN OPEN Key in OFF position. Measure the resistance between exterior mirror control switch C527-1, circuit GD133 (BK) harness side and ground. Is the resistance less than 5 ohms? YES : Go to A3 . NO : REPAIR the circuit. TEST the system for normal operation.
3. A3 CHECK CIRCUIT CPM23 (GY) FOR A SHORT TO VOLTAGE Key in ON position. Measure the voltage between exterior mirror control switch C527-6, circuit CPM23 (GY) harness side and ground. Is voltage present? YES : REPAIR the circuit. TEST the system for normal operation. NO : Go to A4 .
4. A4 CHECK CIRCUIT CPM23 (GY) FOR A SHORT TO GROUND Key in OFF position. Measure the resistance between exterior mirror control switch C527-6, circuit CPM23 (GY) harness side and ground. Is the resistance greater than 10,000 ohms? YES : Go to A5 . NO : REPAIR the circuit. TEST the system for normal operation.
5. A5 CHECK CIRCUIT CPM23 (GY) FOR AN OPEN Disconnect: LH Exterior Mirror C520 Measure the resistance between exterior mirror control switch C527-6, circuit CPM23 (GY) harness side and LH exterior mirror C520-3, circuit CPM23 (GY) harness side. Is the resistance less than 5 ohms? YES : INSTALL a new exterior mirror control switch. REFER to «Exterior Mirror Control Switch»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) . TEST the system for normal operation. NO : REPAIR the circuit. TEST system for normal operation.

Pinpoint Test B: A Single Mirror is Inoperative

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Mirrors for schematic and connector information.

The exterior mirror control switch uses circuit CPM23 (GY) as the common circuit for both exterior mirror up/down and right/left movement.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Exterior mirror control switch
3. Exterior mirror motor
4. Exterior mirror

1. B1 CHECK THE LH EXTERIOR MIRROR Set the exterior mirror control switch to the LH mirror position. Use the exterior mirror control switch to operate the LH exterior mirror. Does the LH exterior mirror operate? YES : Go to B2 . NO : Go to B4 .
2. B2 CHECK THE EXTERIOR MIRROR CONTROL SWITCH Key in OFF position. Disconnect: Exterior Mirror Control Switch C527 Carry out the Exterior Mirror Control Switch Component Test. Refer to appropriate COMPONENT TESTING article. Did the exterior mirror control switch pass the component test? YES : Go to B3 . NO : INSTALL a new exterior mirror control switch. REFER to «Exterior Mirror Control Switch»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) . TEST the system for normal operation.
3. B3 CHECK CIRCUIT CPM23 (GY) FOR AN OPEN Disconnect: RH Exterior Mirror C601 Measure the resistance between exterior mirror control switch C527-6, circuit CPM23 (GY) harness side and RH exterior mirror C601-3, circuit CPM23 (GY) harness side. Is the resistance less than 5 ohms? YES : CHECK the RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.
4. B4 CHECK THE EXTERIOR MIRROR CONTROL SWITCH Key in OFF position. Disconnect: Exterior Mirror Control Switch C527 Carry out the Exterior Mirror Control Switch Component Test. Refer to appropriate COMPONENT TESTING article. Did the exterior mirror control switch pass the component test? YES : Go to B5 . NO : INSTALL a new exterior mirror control switch. REFER to «Exterior Mirror Control Switch»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) . TEST the system for normal operation.
5. B5 CHECK CIRCUIT CPM23 (GY) FOR AN OPEN Disconnect: LH Exterior Mirror C520 Measure the resistance between exterior mirror control switch C527-6, circuit CPM23 (GY) harness side and LH exterior mirror C520-3, circuit CPM23 (GY) harness side. Is the resistance less than 5 ohms? YES : CHECK the LH exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.

Pinpoint Test C: A Single Mirror Does Not Function With Switch Logic

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Mirrors for schematic and connector information.

The exterior mirror control switch controls the LH exterior mirror movement by switching voltage and ground to circuits CPM14 (GY/BN), CPM16 (BN/BU) and CPM23 (GY). The exterior mirror switch controls the RH exterior mirror movement by switching voltage and ground to circuits CPM18 (GN/BN), CPM19 (GY/OG) and CPM23 (GY).

Mirror Movement

1. When the LH/RH exterior mirror motor receives ground through circuit CPM16 (BN/BU)/CPM19 (GY/OG) and power through circuit CPM23 (GY), the LH/RH exterior mirror will operate left.
2. When the LH/RH exterior mirror motor receives power through circuit CPM16 (BN/BU)/CPM19 (GY/OG) and ground through circuit CPM23 (GY), the LH/RH exterior mirror will operate right.
3. When the LH/RH exterior mirror motor receives ground through circuit CPM14 (GY/BN)/CPM18 (GN/BN) and power through circuit CPM23 (GY), the LH/RH exterior mirror will operate downward.
4. When the LH/RH exterior mirror motor receives power through circuit CPM14 (GY/BN)/CPM18 (GN/BN) and ground through circuit CPM23 (GY), the LH/RH exterior mirror will operate upward.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Exterior mirror control switch
3. Exterior mirror motor
4. Exterior mirror

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. C1 CHECK THE EXTERIOR MIRROR CONTROL CIRCUITS FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: Exterior Mirror Control Switch C527 Key in ON position. Measure the voltage between ground and exterior mirror control switch: C527-2, circuit CPM18 (GN/BN) harness side. C527-5, circuit CPM14 (GY/BN) harness side. C527-6, circuit CPM23 (GY) harness side. C527-7, circuit CPM19 (GY/OG) harness side. C527-8, circuit CPM16 (BN/BU) harness side. Is voltage present? YES : REPAIR the circuit(s). TEST the system for normal operation. NO : Go to C2 .
2. C2 CHECK THE EXTERIOR MIRROR CONTROL CIRCUITS FOR A SHORT TO GROUND Key in OFF position. Disconnect: Exterior Mirror C520 (LH) or C601 (RH) Measure the resistance between ground and exterior mirror control switch: C527-2, circuit CPM18 (GN/BN) harness side. C527-5, circuit CPM14 (GY/BN) harness side. C527-6, circuit CPM23 (GY) harness side. C527-7, circuit CPM19 (GY/OG) harness side. C527-8, circuit CPM16 (BN/BU) harness side. Are the resistances greater than 10,000 ohms? YES : Go to C3 . NO : REPAIR the circuit(s). TEST the system for normal operation.
3. C3 CHECK THE EXTERIOR MIRROR CONTROL CIRCUITS FOR AN OPEN NOTE: LH mirror only. Measure the resistance between exterior mirror control switch: C527-5, circuit CPM14 (GY/BN) harness side and LH exterior mirror C520-1, circuit CPM14 (GY/BN) harness side. C527-6, circuit CPM23 (GY) harness side and LH exterior mirror C520-3, circuit CPM23 (GY) harness side. C527-8, circuit CPM16 (BN/BU) harness side and LH exterior mirror C520-7, circuit CPM16 (BN/BU) harness side. NOTE: RH mirror only. Measure the resistance between exterior mirror control switch: C527-2, circuit CPM18 (GN/BN) harness side and RH exterior mirror C601-1, circuit CPM18 (GN/BN) harness side. C527-6, circuit CPM23 (GY) harness side and RH exterior mirror C601-3, circuit CPM23 (GY) harness side. C527-7, circuit CPM19 (GY/OG) harness side and RH exterior mirror C601-7, circuit CPM19 (GY/OG) harness side. Are the resistances less than 5 ohms? YES : CHECK the LH or RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open or shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new LH or RH exterior mirror. REFER to «Exterior Mirror»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) . If the jumper harness is OK, INSTALL a new LH or RH exterior mirror motor. REFER to «Exterior Mirror Motor»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) . TEST the system for normal operation. NO : REPAIR the circuit(s). TEST the system for normal operation.

Pinpoint Test D: The Auto-Dimming Mirror Does Not Operate Correctly

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Mirrors for schematic and connector information.

The interior auto-dimming mirror can be equipped with or without a microphone. An interior auto-dimming mirror, equipped without microphone, receives power from circuit CBP18 (GY/OG) and ground from circuit GD133 (BK). An interior auto-dimming mirror, equipped with a microphone, receives power from circuit CBP05 (YE) and ground from circuit GD143 (BK/VT). Both interior auto-dimming mirrors will disable the auto-dimming feature when the selector lever is placed in REVERSE and voltage is sent to the interior auto-dimming mirror through circuit CBP15 (BN/BU). There are 2 photoelectric sensors: a forward facing sensor and a rearward facing sensor that detect forward and rearward light conditions. If the sensors are blocked, the interior auto-dimming feature might not work correctly. Always verify both sensors are not physically blocked before attempting to diagnose interior auto-dimming mirror concerns.

This pinpoint test is intended to diagnose the following

1. Fuse
2. Wiring, terminals or connectors
3. Interior auto-dimming mirror

Note. If the transmission range (TR) sensor is malfunctioning and the backup lamps are on all the time or do not turn on, the auto-dimming interior mirror will not darken or return to normal view.

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. D1 CHECK THE OPERATION OF THE BACKUP LAMPS Key in ON position. Move the selector lever through the entire range. Do the backup lamps illuminate only in REVERSE? YES : Go to D2 . NO : REFER to «EXTERIOR LIGHTING»(/ford/explorer-sport-trac/ii-2006-2010/remont/exterior-lights/#exterior-lighting-system) article to diagnose the backup lamps.
2. D2 VERIFY THE FORWARD AND REARWARD FACING SENSORS ARE NOT BLOCKED Visually verify the forward and rearward facing sensors are not blocked. Sources of blockage can include: stickers, window decals or tags. fold-down screens for TVs or DVD players. non-OEM window tinting. Were either of the sensors blocked? YES : If possible, REMOVE the blockage. TEST the system for normal operation. If it is not possible to remove the blockage, REVIEW the operation of the interior auto-dimming mirror with the customer. NO : Go to D3 .
3. D3 CHECK OPERATION OF THE INTERIOR AUTO-DIMMING MIRROR - DAYLIGHT CONDITIONS Key in ON position. Use a bright lamp to illuminate the forward facing sensor and the rearward facing sensor. The mirror should adjust to a high reflectance mode (mirror will be clear). Does the mirror adjust to the high reflectance (clear) mode? YES : Go to D4 NO : Go to D7 .
4. D4 CHECK OPERATION OF THE INTERIOR AUTO-DIMMING MIRROR - NIGHTTIME CONDITIONS WITHOUT GLARE Key in ON position. NOTE: Covering the sensor with a finger or hand is not adequate. Simulate nighttime conditions without glare: cover the forward sensor with black electrical tape or other dark material. cover the rearward facing sensor. The mirror should adjust to the high reflectance mode. Did the mirror adjust to the high reflectance (clear) mode? YES : Go to D5 . NO : Go to D7 .
5. D5 CHECK OPERATION OF THE INTERIOR AUTO-DIMMING MIRROR - NIGHTTIME CONDITIONS WITH GLARE Key in ON position. NOTE: Covering the sensor with a finger or hand is not adequate. Simulate nighttime conditions with glare: cover the forward sensor with black electrical tape or other dark material. illuminate the rearward facing sensor. The mirror should darken to a lower reflectance mode. Did the mirror darken to a lower reflectance (darker) mode? YES : Go to D6 . NO : Go to D7 .
6. D6 CHECK OPERATION OF THE INTERIOR AUTO-DIMMING MIRROR - NIGHTTIME CONDITIONS WITH THE VEHICLE IN REVERSE Key in ON position. NOTE: Covering the sensor with a finger or hand is not adequate. Simulate nighttime conditions with glare: cover the forward sensor with black electrical tape or other dark material. illuminate the rearward facing sensor. Select REVERSE. Did the mirror adjust to a high reflectance (clear) mode? YES : The system is operating normally at this time. REVIEW operation of the interior auto-dimming mirror feature with the customer. NO : Go to D7 .
7. D7 CHECK THE INTERIOR MIRROR FOR A MICROPHONE Check the interior mirror for a microphone. Is the interior mirror equipped with a microphone? YES : Go to D8 . NO : Go to D11 .
8. D8 CHECK CIRCUIT CBP05 (YE) FOR VOLTAGE Key in OFF position. Disconnect: Interior Auto-Dimming Mirror C9012 Key in ON position. Measure the voltage between interior auto-dimming mirror C9012-1, circuit CBP05 (YE) harness side and ground. Is the voltage greater than 10 volts? YES : Go to D9 . NO : VERIFY that smart junction box (SJB) fuse 5 (5A) is OK. If OK, REPAIR the circuit. TEST the system for normal operation.
9. D9 CHECK CIRCUIT GD143 (BK/VT) FOR AN OPEN Key in OFF position. Measure the resistance between interior auto-dimming mirror C9012-10, circuit GD143 (BK/VT) harness side and ground. Is the resistance less than 5 ohms? YES : Go to D10 . NO : REPAIR the circuit. TEST the system for normal operation.
10. D10 CHECK CIRCUIT CBP15 (BN/BU) FOR VOLTAGE Key in ON position. Select REVERSE. Measure the voltage between interior auto-dimming mirror C9012-3, circuit CBP15 (BN/BU) harness side and ground. Is the voltage greater than 10 volts? YES : INSTALL a new interior auto-dimming mirror. REFER to «Interior Rear View Mirror»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system__interior-rear-view-mirror) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.
11. D11 CHECK CIRCUIT CBP18 (GY/OG) FOR VOLTAGE Key in OFF position. Disconnect: Interior Auto-Dimming Mirror C911 Key in ON position. Measure the voltage between ground and interior auto-dimming mirror C911-1, circuit CBP18 (GY/OG) harness side. Is the voltage greater than 10 volts? YES : Go to D12 . NO : VERIFY SJB fuse 18 (10A) is OK. If OK, REPAIR the circuit. TEST the system for normal operation.
12. D12 CHECK CIRCUIT GD133 (BK) FOR AN OPEN Key in OFF position. Measure the resistance between interior auto-dimming mirror C911-2, circuit GD133 (BK) harness side and ground. Is the resistance less than 5 ohms? YES : Go to D13 . NO : REPAIR the circuit. TEST the system for normal operation.
13. D13 CHECK CIRCUIT CBP15 (BN/BU) FOR VOLTAGE Key in ON position. Select REVERSE. Measure the voltage between interior auto-dimming mirror C911-3, circuit CBP15 (BN/BU) harness side and ground. Is the voltage greater than 10 volts? YES : INSTALL a new interior auto-dimming mirror. REFER to «Interior Rear View Mirror»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system__interior-rear-view-mirror) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.

Pinpoint Test E: The Heated Exterior Mirror is Inoperative

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Power Mirrors for schematic and connector information.

When the rear window defrost is ON, power is supplied to the heated exterior mirrors from the rear defrost relay through circuit CBP13 (GY/BN). Ground is supplied to the LH exterior mirror through circuit GD133 (BK) and to the RH exterior mirror through circuit GD151 (BK/GN).

This pinpoint test is intended to diagnose the following

1. Fuse
2. Wiring, terminals or connectors
3. Exterior mirror glass
4. Exterior mirror

Scheme 19

Scheme 20

1. E1 CHECK THE REAR WINDOW DEFROST SWITCH OPERATION Key in ON position. With the engine running, depress the rear window defrost switch to the ON position. Place a hand on the rear window to verify that the rear window heats up. Does the heated rear window system operate? YES : Go to E2 . NO : REFER to «GLASS, FRAMES AND MECHANISMS»(/ford/explorer-sport-trac/ii-2006-2010/remont/heated-glassdefoggers/#windows-and-glass) article to diagnose the rear window defrost system.
2. E2 CHECK THE OPERATION OF THE LH EXTERIOR MIRROR With the rear window defrost switch in the ON position, place a hand on the LH exterior mirror to verify that the LH exterior mirror heats up. Does the LH exterior rear view mirror operate? YES : Go to E5 . NO : Go to E3 .
3. E3 CHECK CIRCUIT CBP13 (GY/BN) FOR VOLTAGE Key in OFF position. Disconnect: LH Exterior Mirror C520 Key in ON position. With the engine running, depress the rear window defrost switch to the ON position. Measure the voltage between LH exterior mirror C520-4, circuit CBP13 (GY/BN) harness side and ground. Is the voltage greater than 10 volts? YES : Go to E4 . NO : VERIFY that smart junction box (SJB) fuse 13 (15A) is OK. If OK, REPAIR the circuit. TEST the system for normal operation.
4. E4 CHECK CIRCUIT GD133 (BK) FOR AN OPEN Key in OFF position. Measure the resistance between LH exterior mirror C520-5, circuit GD133 (BK) harness side and ground. Is the resistance less than 5 ohms? YES : CHECK the LH exterior mirror jumper harness between the vehicle harness and the exterior mirror glass for open circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) . If the jumper harness is OK, INSTALL a new exterior mirror glass. REFER to «Exterior Mirror Glass»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.
5. E5 CHECK CIRCUIT CBP13 (GY/BN) FOR VOLTAGE Key in OFF position. Disconnect: RH Exterior Mirror C601 Key in ON position. With the engine running, depress the rear window defrost switch to the ON position. Measure the voltage between RH exterior mirror C601-4, circuit CBP13 (GY/BN) harness side and ground. Is the voltage greater than 10 volts? YES : Go to E6 . NO : REPAIR the circuit. TEST the system for normal operation.
6. E6 CHECK CIRCUIT GD151 (BK/GN) FOR AN OPEN Measure the resistance between RH exterior mirror C601-5, circuit GD151 (BK/GN) harness side and ground. Is the resistance less than 5 ohms? YES : CHECK the RH exterior mirror jumper harness between the vehicle harness and the exterior mirror glass for open circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) . If the jumper harness is OK, INSTALL a new exterior mirror glass. REFER to «Exterior Mirror Glass»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.

Exterior Mirror Damper Spring Alignment

Note. The LH exterior mirror glass has 2 exterior mirror damper springs. The RH exterior mirror glass has 1 exterior mirror damper spring.

Note. LH exterior mirror shown, RH exterior mirror similar.

1. Position the exterior mirror glass to the full outboard position, so that the exterior mirror damper springs and the exterior mirror damper spring tracks are visible. To help locate the exterior mirror damper springs, refer to «Exterior Mirrors - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system__exterior-mirrors-exploded-view) .
2. Inspect between the exterior mirror housing and the exterior mirror glass backing plate to see if an exterior mirror damper spring is out of the exterior mirror damper spring track. Refer to the following: Exterior mirror glass Exterior mirror damper spring Exterior mirror damper spring track
3. For an exterior mirror damper spring that is not in the exterior mirror damper spring track perform the following: Gently lift the exterior mirror glass outward until the bottom tip of the exterior mirror damper spring is above the exterior mirror damper spring track. If an exterior mirror damper spring or the exterior mirror glass is damaged, replace the exterior mirror glass. Refer to «Exterior Mirror Glass»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) . Position the exterior mirror damper spring into the exterior mirror damper spring track and release the exterior mirror glass.
4. For exterior mirror damper springs that are in the exterior mirror glass dampener spring tracks, remove the exterior mirror glass, «Exterior Mirror Glass»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) . Check for a mechanical binding condition or damaged exterior mirror parts. Install new exterior mirror parts as needed. Refer to «Exterior Mirrors - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system__exterior-mirrors-exploded-view) .
5. Operate the exterior mirror and check for correct operation.

Exterior Mirrors - Exploded View

Note. LH shown, RH similar.

Scheme 21

1. For additional information, refer to the procedures in this article.

REMOVAL AND INSTALLATION

Note. Do not remove the exterior mirror when repairing an individual part. Individual components can be installed without removing the exterior mirror.

1. Remove the front door trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/explorer-sport-trac/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
2. Remove the exterior mirror weather shield.
3. Disconnect the exterior mirror electrical connector.
4. Remove the 3 exterior mirror nuts. To install, tighten to 9 Nm (80 lb-in).
5. Remove the exterior mirror.
6. To install, reverse the removal procedure.

REMOVAL

Note. LH shown, RH similar.

1. Position the exterior mirror glass to the full inboard position and locate the notch at the bottom of the exterior mirror glass.
2. Release the exterior mirror glass. Insert a long flat-blade screwdriver into the notch. Gently turn the screwdriver until the 2 outboard glass backing plate hooks are released from the exterior mirror motor.
3. Remove the exterior mirror glass. Using your fingers, carefully release the 2 inboard glass backing plate hooks from the exterior mirror motor. If equipped, disconnect the electrical connectors from the exterior mirror glass.

INSTALLATION

1. Position the exterior mirror motor to the center position.
2. If equipped, connect the electrical connectors to the exterior mirror glass.
3. Position the exterior mirror glass onto the exterior mirror motor.
4. Place a hand against the back of the exterior mirror housing and a hand flat against the exterior mirror glass. Press the exterior mirror glass until it is fully seated.
5. Operate the exterior mirror and check for correct exterior mirror movement. If the exterior mirror glass movement is restricted, refer to «Exterior Mirror Damper Spring Alignment»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system__exterior-mirror-damper-spring-alignment) .

Note. RH shown, LH similar.

1. Remove the exterior mirror glass. For additional information, refer to «Exterior Mirror Glass»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) .
2. Remove the exterior mirror motor screws.
3. Disconnect the exterior mirror motor electrical connectors.
4. To install, reverse the removal procedure.

1. Remove the mirror glass. For additional information, refer to «Exterior Mirror Glass»(/ford/explorer-sport-trac/ii-2006-2010/remont/mirrors/#rear-view-mirrors-system) .
2. Release the 3 upper retaining tabs by carefully pressing down until the tab is free.
3. Release the lower inboard tag.
4. To install, reverse the removal procedure. Rotate the exterior mirror glass in all directions after installation to make sure all clips are completely attached.

Interior Rear View Mirror

Special Tools Illustration Tool Name Tool Number Mirror Remover 501-D118 Installer, Rear Mirror 501-025 (T94P-17700-AH)

Note. Auto-dimming mirror shown, base mirror similar.

Scheme 22

1. If equipped, remove the wire cover.
2. If equipped, remove the compass by pulling downward on the rearmost edge of the compass.
3. If equipped, disconnect the auto-dimming mirror electrical connector.
4. Insert the special tool between the mirror mount and windshield bracket from the bottom.
5. Release the mirror mount from the windshield bracket by pulling the tool away from the windshield.

1. Slide the mirror mount over the windshield bracket from the top and adjust the mirror to the up position.
2. Using the special tool, press the mirror assembly downward along the windshield until the mount is fully seated onto the windshield bracket.
3. If equipped, connect the auto-dimming mirror electrical connector.
4. If equipped, install the compass and wire cover.

Scheme 23

1. Remove the front door trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/explorer-sport-trac/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
2. Remove the exterior mirror control switch from the front door trim panel.
3. To install, reverse the removal procedure.
